Object Oriented Systems

1
Object Oriented Systems

• Lecture 4

2
Todays Lecture

• This lecture we will briefly but suspiciously
  depart from pointers to consider
• 1. Single Dimensional Arrays
• 2. Multi Dimensional Arrays
• 3. Arrays as Parameters
• 3. C-Style Strings
• 4. The Null Terminator
• 5. String Manipulation
• 6. C String Object

3
Arrays Quick Refresher

• An array is a collection of variables of the same
  type.
• These are collected together under a common name.
• In C all arrays consist of contiguous memory
  locations.
• The lowest address in this spread of memory will
  be the first element in the array.
• The highest address will be the last element.

4
Single-Dimension Arrays

• The general form for declaring an array is
• type var_namesize
• For example to declare an array of 100 doubles
• double hipHip100
• An element is accessed by indexing the array
  name, as follows
• hipHip3 47.23

5
Counting from zero

• Like Java, in C all arrays begin at 0.
• hipHip0 (first element)
• Hence if we declared an array such as.
• char p10
• Then this would declare an array that has 10
  elements, p0 through to p9.
• As a programmer youve gotta to learn to count
  from 0..

6
Arrays are pretty flexible

• Bracket notation can be used to initialise the
  contents of an array
• int array4 8, 67, 4, 7
• We can do simple arithmetic to generate subscript
  values, e.g.
• c arrayj
• arrayj2 4
•  The exception to this is when an array is first
  created, the size of the array must be an
  integer, or a constant variable, e.g.
• int array6
•   double arrayj

7
Differences with Java

• So far this looks very similar to Java. It is.
• The most significant different lies in error
  checking.
• C has no bounds checking on arrays. You can
  overwrite either end of the area and actually
  write over some other variables data.
• It is the programmers job to try and make sure
  this doesnt happen (unless you want it to of
  course)

8
Example

• For example take the following code fragment
• int count10
• int i
• for (i0 ilt100 i) counti i

In Java this code will cause an error when you
try to compile it, because the for loop will
cause the array count to overrun. In C, even
though it is incorrect, it will compile.
9
The Story in Memory

• So what is actually going on when you set up an
  array?
• memory
• Each element is held in the next location along
  in memory
• Essentially what the PC is doing is looking at
  the FIRST address (which is pointed to by the
  variable p) and then just counts along.

10
Two-Dimensional Arrays

• A two dimensional array is essentially an array
  of one dimensional arrays. In general
• type var_namesize1size2
• For example to declare an array of integers, of
  size 10,20
• int bigGeek1020
• Elements are accessed in a very similar way to
  one dimensional arrays
• bigGeek211 7

11
Example Noughts and Crosses

• We can also use brackets notation to set up
  two-dimensional arrays. For example
• char board33
• X,,O ,
• X,X, ,
• X,O,O
• This 3x3 array of characters, has a total of 9
  elements, ranging from board00 to
  board22.

12
Example Graphically

• This board of elements can be represented
  graphically as

SIZE 2
0
1
2
0
SIZE 1
1
2
13
Example In Memory

• But this is just a graphical representation. In
  memory the elements are all housed in addresses
  adjacent to each other
• The variable board still points to the address of
  the first element.

14
2. Multi-Dimensional Arrays

• But the excitement doesnt end there. No Sireee.
• C can handle arrays of almost any dimension.
• The limit of dimensions that you can have, if
  there is a limit, will be determined by the
  specific compiler you are using.
• For Example it would be quite reasonable to see
  an array such as
• int multi643578

15
A small shortcut

• If you know exactly how many elements your array
  will have , and if you fill the array when you
  declare it, you can even leave out the array size
  when you declare the array.
• For example if you want a 5 element array you
  could use the following
• int myArray -200, -100, 0, 100, 200

16
3. Arrays as Parameters

• Passing arrays is an exception to the normal
  send-by-value parameter passing.
• There are several ways of passing arrays to
  functions but in each case we only pass the
  arrays address. This is very similar what we
  just considered when we were passing variables by
  reference.
• Because of this we are not sending a copy - any
  changes in the function will affect our original
  array!

17
methods for passing Arrays

• void foo1 (int x10) //sized array
• void foo2 (int x) //unsized array
• void foo3 (int x) //pointer

Here we take in an address and use x to remember
it as an array with 10 elements
but the length of the array doesnt matter as
far as C is concerned
another method we will consider later
18
Passing Multidimensional Arrays

• Finally, be careful when sending
  multi-dimensional arrays to functions

void mal (int x45) int
main() int hipHip333 mal(hipHip)

For a multi-dimension array we must declare all
but the first of the dimensions
19
4. Strings in C/C

• Odd as it might seem, there is no in built data
  type in C for a string variable.life is hard
  in C
• Instead strings in C programs are represented
  by arrays of the char data type.
• For example you could assign a string to a char
  array as follows
• char text Goodbye Cruel World
• This is essentially the same as
• char text G, o, o, d, b, y, e.
  . .

20
Null Terminated Strings

• The terminating null is a special character that
  is represent by \0, which equates to numerical 0
  (not character 0).
• The example from the last slide actually
  allocates 20 bytes of storage in memory and
  stores the string in that location.
• However this is despite the fact that Goodbye
  Cruel World only has 19 characters in it.
• The reason that 20 bytes are allocated is that at
  the end of the string is a terminating null and
  C accounts for the \0 when allocating storage.

21
THE POWER OF THE \0!

• Null terminated strings at first seem a lot of
  hassle if you are used to Java strings.
• When the program encounters a terminating null in
  the character array, it interprets the location
  as the end of the string.
• To see how this is done, have a look at the
  following code

22
NULLTEST.CPP

• int main()
• char str I love coding.
• cout ltlt str ltlt endl
• str10 \0
• cout ltlt str ltlt endl
• OUTPUT I love coding.
• I love cod

23
What is actually happening

• So what is happening here? The second time the
  string is sent to the screen only part of the
  original is displayed.
• This is because as far as the computer is
  concerned the string ends at character 10 in the
  array.
• The rest of the characters are still in storage,
  but wont be displayed because we have hit the
  terminating null.
• before
• after

24
null characters

• We could have simply assigned a zero in place of
  \0 in the code listing a few slieds back.
• Either is acceptable because a numerical 0 and
  the char data type version, /0, are equivalent.
• For example the following two lines of code are
  equivalent
• str7 /0 str7 0

25
This all seems like hard work

• The String operations we are discussing in this
  lecture are how strings are handled in C.
• Most C compilers provide a class that
  simplifies the difficulties inherent in the C way
  of handling strings
• STL - basic_string (string/wstring)
• C builder - AnsiString
• Visual C - Cstring
• Nonetheless, you do need to know about
  null-terminated strings.

26
String Manipulation Functions

• Also, as with Java, the operator in C will
  not compare the contents of strings, only the
  values of the pointers to the two strings.
• However there is still a lot of support for null
  terminated strings. The standard C library has
  several functions for string manipulation that
  will all work in your C programs.
• To use these functions we need to include them.
  Just like the stdio.h library, here we need to
  use
• include ltcstdlibgt

27
Concatenation

• strcat this function concatenates the first
  string with a copy of the second string. The null
  terminator originally ending the first string is
  overwritten, and a new null terminator added to
  the end.
• ...
• char str30 Tim Brailsford
• strcat(str, is very tall)
• ...
• Tim Brailsford is very tall

28
Copying

• strcpy this function is used to copy one string
  to another. The source string can be a variable
  or a literal. Take the following code as an
  example
• char buff30
• strcpy(buff, This is a test)
• char buff2 A second string
• strcpy(buff, buff2)

29
Careful with strcpy!

• Accidentally overwriting the end of a character
  array is even easier to than with the numeric
  arrays discussed earlier.
• For instance, imagine youve done the following
• char buff10 A String
• // later
• strcpy(buff, This is a test.) //oops!
• Here we set up an array to hold 10 characters and
  initially assigned a string requiring 9 bytes.
• Later on, possibly forgetting how large the array
  was, we copied a string to buff that requires 16
  bytes, overwriting the by 6 bytes.
• 6 bytes of memory somewhere was just erased by
  this mistake.

30
Length

• strlen simply returns the length of a string,
  in essence it just moves along the string
  character by character until it finds the null
  terminator, and then returns the count.
• ...
• char str40 Steve Benfords Millions
• int length strlen(str)
• ...

24
31
String Manipulation Functions

• The most common ones are
• strcat(s1,s2) Concatenates a string onto the end
  of s1
• strcmp(s1,s2) Compares two strings for equality
• strcpy(s1,s2) Copies s2 into s1
• strstr(s1,ch) Returns a pointer to the first
  occurrence of ch
• strlen(s1) Returns the length of s1
• strupr(s1) Converts s1 to uppercase
• strlwr(s1) Converts s1 to uppercase
• sprintf() Builds a string based on the parameters

32
The String Object

• Up to now weve been doing it the hard way.
• We know C does not have built in support for
  strings.
• However standard C can handle strings in 2 ways
• The first weve looked at in detail Null
  Terminated Strings (often called C-Strings) which
  are complicated but good for the soul.
• But the STL also provides us with a string class
  too.

33
The String Classes
This is a more generalised template class from
which string is derived.
basic_string
string
wstring
This is the primary class utilised. It supports
8-bit char strings.
similar class but wstring supports wide-character
strings.
34
Are these Classes Necessary?

• Weve all become masters of the null-terminated
  string! Why do we need a string class?
• The reason is to do with what weve considered in
  the last few lectures overloading.
• The basic operators such as ,,- and so on
  cannot be overloaded to be able to handle
  null-terminated strings. For example, consider
  the following code
• char str150, str250, str350
• str1 Gordon //cant do str2 the
  Gopher //cant do
• str1 str1 str2 //error

35
Part of the STL

• The STL (standard template library) has
  containers, algorithms and iterators.
• the String class is a container. To include the
  string classes just include the ltstringgt library
  at the top of your code.
• 3 constructors
• string()
• string(const char str)
• string(const string str)

Note that the string class is all in lowercase
Takes in a null-terminated string
Takes in another string object as a parameter
all lowercase
36
Now we can use

• Assignment
• Concatenation
• Concatenation Assignment
• Equality
• ! Inequality
• lt Less than
• lt Less than or equal
• gt Greater than
• gt Greater than or equal
• Subscripting
• ltlt Output
• gtgt Input

Now we dont need functions such as strcpy() and
strcat()
Just overloading the operators so they can be
used as indexing.
37
Scooby-Doo Example
3 Different ways of setting up an object of the
string class

• string str1 Shaggy
• string str2(Doo)
• string str3(str2)
• str2 Scooby str3
• str3 Scrappy str3
• cout ltlt str1 ltlt says... it wasnt me
• if (str3ltstr2) cout ltlt str3 ltlt comes before ltlt
  str2
• else cout ltlt str2 ltlt comes before ltlt
  str3
• cout ltlt Type in your name
• cin gtgt str1
• cout ltlt str1 ltlt would have got away with it
• ltlt if it wasnt for you pesky kids

concatenation
comparison
inputting
38
How long is a string?

• The most important point of this however is that
  at no point do you define how long your string
  will be.
• string objects automatically size and re-size
  themselves.
• Hence it is not possible to overrun the end of as
  string like you can with null terminated strings.
• The most commonly used function is the .size()
  method
• for (i0 iltstr.size() i)
• cout ltlt stri
• cout ltlt endl

39
Substrings

• Another capability provided by the class string
  is substr, which returns the substring of a
  string.
• The substring is specified as a starting position
  and a length as arguments to substr.
• string date March 7, 1994 string year
  date.substr(9, 4)
• cout ltlt Year is ltlt Year ltlt endl
• If you go over the strings limits these values
  are just set to the max possible.

40
Inserting

• Of course we would use to concatenate a string.
• However this is just a specific use of the more
  general append method
• string insert(position, str, start, num)
• The start and num parameters indicate what parts
  of str should be taken, to insert at place
  position in the string.
• string str1(Scooby DOO)
• string str2(Scrappy)
• str2.insert(2, str1, 7, 3)
• cout ltlt str2

OUTPUT ScDOOrappy
41
Replacing Erasing

• The replace method is identical to insert except
  it overwrites the characters that were already
  there.
• string str1(Scooby DOO)
• string str2(Scrappy)
• str2.insert(2, str1, 7, 3)
• cout ltlt str2
• Erase() is the method you would use to remove
  characters from your string.

OUTPUT ScDOOpy
42
Searching

• The string class also provides the ability to
  find a substring within a string the find()
  method.
• Find accepts two arguments - the search string
  and the starting position for the search
• string scooby Wilmas lost her
  glassesagain
• int i scooby.find(her, 0)
• cout ltlt i is ltlt i ltlt endl
• The member function returns an integer of the
  position of the first match. rfind() does the
  same job but works backwards.

start point
43
Getting at the C-String

• string objects can be incredibly useful - but
  what if youre a purist and want a
  null-terminated string. (E.g. when opening a
  file).
• Its easy to do. Just use.
• const char c_str() const
• This returns a point to the null terminated
  character array within the string object. Take
  care with it because it can easily change
• Eg fstream fin( fileName.c_str() )

44
And now, the end is nearrr

• Make sure youve run through the first Pointer
  Exercises. This is still basic C.
• Lunch Time. Go go go.
