Static EXtended Checking for Cyclone

1
Static EXtended CheckingforCyclone

• Greg Morrisett

2
The Legacy of C

• 1988 Buffer overrun exploited by Morris Worm.
• . . .
• 1999 Buffer overruns in Active-X.
• 2001 Buffer overruns in WU-FTP.
• 2002 Buffer overruns in Windows RPC.
• 2003 Buffer overruns in MS SQL server.
• 2004 Buffer overruns in RealPlayer.
• 2005 Buffer overrun in LSASS.
• 2006 Buffer overruns in ATI Nvidia drivers.
• 2007 Buffer overrun in Vista ANI code.

3
Not the Only Problem...

• C suffers from many problems...
• Must bypass the type system to do simple things
  (e.g., allocate and initialize an object).
• Libraries put the onus on the users (e.g., check
  return codes).
• Not enough info at runtime for needed
  checks.(e.g., printf is passed arguments of the
  right type).
• Programmer controlled memory management (leads
  to data corruption, leaks).
• ifdef-testing-hell

4
Why not throw out the C code?

• Alas, theres a lot of it.
• Vista gt 50 million lines of code
• Suns Java runtime gt 700 thousand lines
• Java is only portable thanks to ifdef
• Besides, C occupies a useful space
• Its ported to every architecture in the world.
• It gives programmers control over data structure
  layout, memory management, instructions, etc.
• Useful for devices, kernels, runtimes, etc.
• It makes costs manifest.
• Crucial for embedded or real-time systems.

5
Cyclone

• A type-safe dialect of C.
• Goals
• well-typed program won't crash
• in particular, rule out buffer overruns the
  like
• looks behaves like C
• familiar syntax and semantics
• retain control over boxing, allocation,
  bit-twiddling, and to some degree, memory
  management.
• some useful additions polymorphism, subtyping,
  tagged unions, pattern matching, exceptions, etc.
• plays nicely with C

6
Cyclone Users

• In-kernel Network Monitoring Penn
• MediaNet Maryland Cornell
• Open Kernel Environment Leiden
• RBClick Router Utah
• xTCP Utah Washington
• GeekOS Maryland
• Protocol Parsing ATT
• Minix modules Netherlands
• Ported to a variety of platforms
• Nintendo DS!
• Cyclone compiler, tools, libraries
• Over 100 KLOC
• Plus many sample apps, benchmarks, etc.
• Good to eat your own dog food

7
Lots of other tools for C

• e.g., SPLint, Jeckyll, Metal, Deputy, Prefast,
  ...
• But Ccured Cyclone focus on soundness.
• Ccured Scheme
• no annotation by programmer
• insert meta-data tests
• use global optimizer to eliminate overheads
• Cyclone Modula
• programmer must annotate types
• no run-time type tests
• local analysis only

8
Cyclone/GCC vs. Java/GCC
9

• Macro-benchmarks
• Ported a variety of security-critical apps
• little overhead (e.g., 2 for the Boa
  Webserver.)
• lots of bugs found

10
AES C version

• int cipherUpdateRounds(cipherInstance cipher,
  keyInstance key, BYTE input,
• int inputLen, BYTE
  outBuffer, int rounds)
• int j, t
• word8 block4MAXBC
• if (cipher NULL key NULL
  cipher-gtblockLen ! key-gtblockLen)
• return BAD_CIPHER_STATE
• for (j 0 j lt cipher-gtblockLen/32 j)
• for(t 0 t lt 4 t) blocktj
  input4jt 0xFF
• switch (key-gtdirection)
• case DIR_ENCRYPT rijndaelEncryptRound(block,
  key-gtkeyLen, cipher-gtblockLen,
  key-gtkeySched, rounds)
• break
• case DIR_DECRYPT rijndaelDecryptRound(block,
  key-gtkeyLen, cipher-gtblockLen,
  key-gtkeySched, rounds)
• break
• default return BAD_KEY_DIR
• for (j 0 j lt cipher-gtblockLen/32 j)
• for(t 0 t lt 4 t) outBuffer4jt
  (BYTE) blocktj

11
AES Cyclone version

• int cipherUpdateRounds(cipherInstance cipher,
  keyInstance key, BYTE ?input,
• int inputLen, BYTE
  ?outBuffer, int rounds)
• int j, t
• word8 block4MAXBC
• if (cipher NULL key NULL
  cipher-gtblockLen ! key-gtblockLen)
• return BAD_CIPHER_STATE
• for (j 0 j lt cipher-gtblockLen/32 j)
• for(t 0 t lt 4 t) blocktj
  input4jt 0xFF
• switch (key-gtdirection)
• case DIR_ENCRYPT rijndaelEncryptRound(block,
  key-gtkeyLen, cipher-gtblockLen,
  key-gtkeySched, rounds)
• break
• case DIR_DECRYPT rijndaelDecryptRound(block,
  key-gtkeyLen, cipher-gtblockLen,
  key-gtkeySched, rounds)
• break
• default return BAD_KEY_DIR
• for (j 0 j lt cipher-gtblockLen/32 j)
• for(t 0 t lt 4 t) outBuffer4jt
  (BYTE) blocktj

12
Refined pointer qualifiers

• Fat pointers arbitrary arithmetic but the
  representation is different (3 words)
• char ? a "fat" pointer to a sequence of
  characters.
• numelts(s) returns number of elements in
  sequence s (0 when s
  NULL)
• Thin pointers same representation as C, but
  restrictions on pointer arithmetic.
• char NULL or a pointer to at least one
  character.
• char _at_ a pointer to at least one character.
• char _at_numelts42 pointer to a sequence of 42
  characters.

13
Fat pointers

• To support dynamic checks, we must insert extra
  information (e.g., bounds for an array)
• Similar to Ccureds representation.

14
Can we eliminate fat pointers?

• Fat pointers are convenient, but
• expensive
• break compatibility
• give us failure points

15
Aha!

• int f(int n, int A)_at_requires(n
  numelts(A))_at_ensures(0 lt result lt n)
• Hoare-Style Specifications.
• Say, like ESC/Java, Spec, or SPLint.

16
Static EXtended Checking

• Add support for specifications to types
• _at_requires, _at_ensures, _at_throws
• quantifier-free 1st-order, multi-sorted logic
• Calculate verification conditions (VCs)
• For each possible failure point,
• compute a predicate of the form A ? C
• where A describes the state of the machine
• and C is a condition ensuring the failure cannot
  occur (e.g., index in bounds)
• Throw at VCs at a prover
• if prover can show VC is true, can omit check

17
Example strcpy

• strcpy(char ?d, char ?s)
• while (s ! 0)
• d s
• s
• d
• d 0

Run-time checks are inserted to ensure that s
and d are not NULL and in bounds. 6 words
passed in instead of 2.
18
Better

• strcpy(char ?d, char ?s)
• unsigned i, n numelts(s)
• assert(n lt numelts(d))
• for (i0 i lt n si ! 0 i)
• di si
• di 0

This assert is dynamic. But its presenceis
enough to eliminate the checks.
19
Even Better

• strncpy(char d, char s, uint n)
• _at_assert(n lt numelts(d) n lt
  numelts(s))
• unsigned i
• for (i0 i lt n si ! 0 i)
• di si
• di 0

No fat pointers or dynamic checks. But caller
must check the pre-condition.
20
Ensures Throws Specs

• val_t lookup(key_t x)
• _at_ensures(result ! NULL x ! NULL)
• _at_throws(x NULL exn NullExn
• x ! NULL exn LookupFail)
• void insert(key_t k, val_t v)
• _at_requires(k!NULL v!NULL)
• _at_throws(false)

21
How Effective?

• For the 165 files (78 Kloc) that make up the
  standard libraries and compiler
• CLibs stdio, string,
• CycLib list, array, splay, dict, set, bignum,
• Compiler lex, parse, typing, analyze, xlate to
  C,
• with almost no specifications, eliminated 96 of
  the (static) checks
• null 33,121 out of 34,437 (96)
• bounds 13,402 out of 14,022 (95)
• 225s for bootstrap compared to 221s with all
  checks turned off (2 slower) on this laptop.
• Optimization standpoint seems pretty good.

22
Not all Rosy

• Don't do as well at array-intensive code.
• For instance, on the AES reference
• 75 of the checks (377 out of 504)
• 2 slower than all checks turned off.
• 24 slower than original C code.(still passing
  around fat pointers)
• The primary culprits
• loop invariants are too weak.
• lack of context (i.e., pre/post-conditions).
• prover only understands limited constraints.

23
Challenges

• Assumed I could use off-the-shelf technology.
• But ran into a few problems
• scalable VC generation
• textbooks dont tell you this stuff!
• usable theorem provers
• (not the real focus.)
• some foundational issues
• semantic model, soundness
• see ICFP06 and ESOP07 papers on Hoare
  Type-Theory.

24
Verification-Condition Generation

• We started with textbook strongest
  post-conditions
• SPx e A Aa/x ? xea /x (a fresh)
• SPS1S2 A SPS2 (SPS1 A)
• SPif (e) S1 else S2 A
• SPS1(A ? e?0) ? SPS2(A ? e0)

25
1st Problem with Textbook SP

• SPx e A Aa/x ? xea/x
• What if e has effects?
• In particular, what if e is itself an assignment?
• Solution use a monadic interpretation
• SP Exp ? Assn ? Term ? Assn
• Terms are pure (i.e., logic).

26
For Example

• SPx A (x, A)
• SPe1 e2 A let (t1,A1) SPe1 A
• (t2,A2) SPe2 A1
• in (t1 t2, A2)
• SPx e A let (t,A1) SPe A
• in (ta/x, A1a/x ? x ta/x)

27
One Issue

• Of course, this over sequentializes the code.
• C has very liberal order of evaluation rules
  which are hopelessly unusable for any sound
  analysis.
• So our back-end forces the evaluation to be
  left-to-right to match our analysis.

28
Next Problem Diamonds

• SPif (e1) S11 else S12
• if (e2) S21 else S22
• ...
• if (en) Sn1 else Sn2A
• Textbook approach explodes paths into a tree.
• SPif (e) S1 else S2 A
• SPS1(A ? e?0) ? SPS2(A ? e0)
• This simply doesn't scale.
• e.g., one procedure had assn with 1.5B nodes.
• WP has same problem. (see Flanagan Leino)

29
Solution

• Factor out a local environment A xe1 ?
  ye2 ? ? Bwhere neither B nor ei contains
  program variables (i.e., x,y,)
• Only the environment needs to change on update
  SPx 3 xe1 ? ye2 ? ? B
  x3 ? ye2 ? ? B
• So most of the assertion (B) remains unchanged
  and can be shared.

30
Diamond Problem Revisited

• SPif (e) S1 else S2 xe1 ? ye2 ? ? B
• (SPS1 xe1 ? ye2 ? ?B?e?0) ?
• (SPS2 xe1 ? ye2 ? ?B?e0)
• (xt1 ?yt2? ? B1) ?
• (xu1?yu2 ? ? B2)
• xax ? yay ? ?
• ((ax t1 ? ay t2 ? ? B1) ?
• (ax u1 ? ay u2? ? B2))

31
How does the environment help?
SPif (a) x3 else x y if (b) x5 else
skip xe1 ? ye2 ? B
?
xv ? ye2
?
?
?
b0 ? vt
b?0 ? v5
?
?
?
a?0 ? t3
B
a0 ? te2
32
Tah-Dah!

• I've rediscovered SSA.
• monadic translation sequentializes and names
  intermediate results.
• only need to add fresh variables when two paths
  compute different values for a variable.
• so the added equations for conditionals
  correspond to ?-nodes.
• Like SSA, worst-case O(n2) but in practice O(n).
• Best part all of the VCs for a given procedure
  share the same assertion DAG.

33
Scaling
34
Space Scaling
35
So far so good

• Of course, I've glossed over the hard bits
• memory
• loops
• procedures
• Let's talk about memory first

36
What about Memory?

• As in ESC, use a functional array
• t upd(tm,ta,tv) sel(tm,ta)
• with McCarthy axioms
• sel(upd(m,a,e),a) e
• (a1 ltgt a2) ? sel(upd(m,a1,e),a2) sel(m,a2)
• upd(upd(m,a,e1),a,e2) upd(m,a,e2)
• Then reading writing treated as access to a
  distinguished mem variable
• SPp e A Aa/mem ? memupd(a?p,e)

37
Widening

• Given A?B, calculate some C such that A ? C and
  B ? C and C lt A, B.
• Then we can compute a fixed-point for loop
  invariants iteratively
• start with pre-condition P
• process loop-test body to get P'
• see if P' ? P. If so, we're done.
• if not, widen P?P' and iterate.
• (glossing over variable scope issues.)

38
Our Widening

• Conceptually, to widen A?B
• Calculate the DNF
• really only traverse assertion DAG by memoizing
• Factor out syntactically common primitive
  relations
• In practice, we do a bit of closure first.
• e.g., normalize terms relations.
• e.g., xe expands to x ? e ? x ? e.
• Captures any primitive relation that was found on
  every path.

39
Back to Loops

• The invariants we generate aren't great.
• worst case is that we get "true"
• we do catch loop-invariant variables.
• if x starts off at i, is incremented and is
  guarded by x lt e lt MAXINT then we can get x gt
  i.
• But
• covers simple for-loops well
• it's fast only a couple of iterations
• user can override with explicit invariant

40
Procedures

• Originally, intra-procedural only
• Programmers could specify pre/post-conditions.
• Recently, extended to inter-procedural
• Calculate SP's and propagate to callers.
• If too large, we widen it.
• Go back and strengthen pre-condition of
  (non-escaping) callee's by taking "disjunction"
  of all call sites' assertions.

41
Proving

• Original plan was to use off-the-shelf
  technology.
• eg., Simplify, SAT solvers, etc.
• But ran into problems
• Simplify unsound treatment of ints
• SAT too slow (esp. with 64-bits)

42
Proving done in two stages

• First stage
• Given a VC A ? C
• Widen A to a set of primitive relns.
• Calculate DNF for C and check that each
  disjunct is a subset of A.
• (C is quite small so no blowup here.)
• This catches a lot
• all but about 2 of the checks we eliminate!
• void f(int _at_x) x
• if (x ! NULL) x
• for (i0 i lt numelts(A) i)Ai

43
2nd Stage

• Given A ? C, try to show A ? ?C inconsistent.
• Conceptually
• explore DNF tree (i.e., program paths)
• the real exponential blow up is here.
• so we have a programmer-controlled throttle on
  the number of paths we'll explore (default 33).
• accumulate a set of primitive facts.
• at leaves, run difference constraint algorithm
• Convert facts to constraints of form (x - y) lt
  c.
• Calculate shortest paths, look for negative
  cycles.

44
Summary of SEXC-Cyclone

• Simple assertions aimed at type errors.
• Started with strongest post-conditions.
• Effects Rewrote as monadic translation.
• Diamond Factored variables into an environment
  to preserve sharing (SSA).
• Memory use functional arrays
• Loops Simple but effective widening for
  calculating invariants.
• Extended to inter-procedural summaries.
• Simple, but fast custom prover.
• From 75-95 of checks eliminated.

45
Currently

• Memory
• The functional array encoding of memory doesn't
  work well -- should incorporate alias analysis.
• e.g., cant accomodate malloc/free
• doesnt yield modular specs (need modifies)
• Can we adapt separation logic? Will it actually
  help?
• Whats the full type theory look like?
• Work with A. Nanevski L. Birkedal a start.

46
False Positives

• We still have 2,000 checks left.
• I suspect that most are not needed.
• How to draw the eye to the ones that are?
• strengthen pre-conditions artificially(e.g.,
  assume no aliasing, overflow, etc.)
• if we still can't prove the check, then it should
  be moved up to a "higher-rank" warning.

47
Lots of Borrowed Ideas

• ESC M3 Java
• Touchstone, Special-J, Ccured
• SPLint (LCLint)

48
More info...

• http//cyclone.thelanguage.org
• Acks
• Yanling Wang (Cornell)
• Aleks Nanevski (MSR)
• Mike Hicks, Nikhil Swamy (Maryland)
• Trevor Jim (ATT)
• Dan Grossman (Washington)
