RONDO: A Programming Platform for Generic Model Management

1
RONDO A Programming Platform for Generic
Model Management

• Sergey Melnik University of Leipzig,
  Germany
• Erhard Rahm University of Leipzig,
  Germany
• Philip A. Bernstein Microsoft Research,
  Redmond, WA

Presented by Ali Riza KONAN Aycan YALÇIN
2
Outline

• Introduction
• Generic Model Management
• Motivating Scenario
• Conceptual Structures
• Operators
• Implementation
• Prototype
• Related Works
• Conclusion

3

• Introduction

4
IntroductionProblems

• Amount of programming for development of metadata
  intensive applications
• Lack of common programming platform
• Lack of great infrastructures
• - Storing metadata in files, not in DBs
• - Tool specific infrastructure

5
IntroductionGoals

• Reduce the amount of programming
• Generalize the transformation operations
• e.g. Relational DB ? XML Schema
• Handling metadata management in a generic
  fashion
• Simplifying the development of applications

6
IntroductionProposal

• Defining and developing a set of
• algebraic operators to manipulate
• metadata in large chunks

7

• Generic Model Management

8
Generic Model Management Properties

• Not limited to a specific language or application
  domain
• Using high-level algebraic operators to
  manipulate models and mappings
• such as match, merge, compose
• Applying operators to models and mappings as a
  whole

9

• Motivating Scenario

10
Motivating Scenario
To solve such tasks at a high level of
abstraction using a concise generic script
11
Motivating Scenario (contd)

• Steps of change propagation
• Detect the changes introduced in s2
• Remove d1 images of the deleted elements in s1
• Merge XML schema counterparts of added and
  renamed columns in s1 into d1 to obtain d2
• During these steps intevention of a human
  engineer may be required.

12
Motivating Scenario (contd)

• It is assumed that a translation tool is
  available as an operator (SQL2XSD) which takes as
  input a relational schema and produces as output
  an XML schema and a mapping between the original
  and converted schema elements.
• In this scenario c is obtined by using this
  tool
• ltc,s2_cgt SQL2XSD(s2)

13
Motivating Scenario (contd)
Rectangles ? Schemas Arcs ? Mapping between
schemas
14
Motivating Scenario (contd)

• NOTICE
• The above script is not limited to propagating
  changes from relational schemas to XML schemas.
• Reverse propagation is also possible.

15

• Conceptual Structures

16
Conceptual Structures

• Models
• Morphisms
• Selectors

17
Conceptual Structures Models

• Model as DAG
• (Directed Acyclic Graph)
• The nodes ? model elements (relations and attr.
  in relational schemas, type definitions in XML
  schemas, clauses of SQL st.)
• Each element is uniquely identified by an object
  identifier(OID)
• lts, p, ogt ? s source node, p edge label, o
  target node
• In the graph, the ovals denote OIDs (Object
  Identifier), rectangles denote literals.
• Used in the prototype to visualize models

18
Conceptual Structures Models (contd)

• Model as Relation
• M(S OID, P OID, OOID U Literal, N Integer)
• Here, N is optional attribute used for ordering
  and S,P,O form a unique key.
• Used for internal computations
• SQL query for node ordering
• SELECT M.O FROM M WHERE M.Ssrc node
  ANDM.Pedge label ORDER BY M.N.
• In the example, M.Sa1 M.Pcolumn.

19
Conceptual Structures Morphisms

• A binary relation over two (possibly overlapping)
  sets of OIDs, i.e., a set of pairs ltl, rgt drawn
  from OIDOID

• No semantics about the transformation of
  instances
• e.g. No SQL WHERE-clause
• Additional properties may be added to ltl,rgt pairs
• e.g Similarity value between nodes

20
Conceptual Structures Morphisms (contd)

• Advantages
• can represent a mapping between different kinds
  of models (Relational ? XML)
• can always be inverted and composed (SQL view
  cannot)
• implemented and manipulated easily

21
Conceptual Structures Selectors

• a set of node identifiers from a model
• can be viewed as a relation with a single
  attribute, S(VOID), where V is a unique key.

22

• Operators

23
Operators

• Primitive Operators
• Derived Operators
• Complex Operators

24
Operators Primitive Operators
m model s selector map morphism
25
Operators Primitive Operators (Contd)

• Other Primitive Operators
• Set Operators
• Union ()
• Difference (-)
• Intersection (?)
• All Operator (All(m)) Returns a selector that
  contains those nodes of
• m that
  denote the model elemets of the models
•
  meta-model
• Copy Operator(Copy(m,s)) Creates a copy of a
  model in which
•
  selected node IDs are replaced by new,
•
  uniquely created IDs

26
Operators Derived Operators

• Functional combinations of other operators
• Range(map)
• return Domain(Invert(map))
• RestrictRange(map, selector)
• return Invert(RestrictDomain(Invert(map),
  selector))
• Traverse(selector, map)
• return Range(RestrictDomain(map, selector))
• Restrict(map, m1, m2)
• return RestrictRange(
• RestrictDomain(map, All(m1)),
  All(m2))

27
Operators Complex Operators

• Extract Delete
• Match
• Merge

28
Operators Complex Op.s (Extract Delete)

• ltm,m_mgt Extract(m,s)
• (m well-formed model, sselector)
• m satisfies folowing properties
• 1. contains all selected nodes
• 2. well-formed
• 3. m equally or less expressive than m
• 4. minimal model that satisfies 1-3

29
OperatorsComplex Op.s(Extract Delete contd)

• Algorithm
• 1. Create a closure of m (?m)
• 2. Assign s s (s is temporal)
• 3. For each x in s, extend s to satisfy
  condition 2 and 3
• 4. Apply 3 until a fixpoint is reached
• 5. t Subgraph(m, s)
• 6. Obtain a cover of t (?t)
• 7. Return Copy(t, All(t))
• Deleting is an extraction of the unselected
  portion,
• operator Delete(m, s)
• return Extract(m, All(m)-s)

30
Operators Complex Op.s (Match)

• ltm1_m2gt Match(m1,m2)
• Uncovers how to models correspond to each other
• Takes 2 graphs as input
• Requires info that is not presented in the
  schemas
• ? Cannot be fully automated

31
Operators Complex Op.s (Merge)

• ltm, m1_m, m2_mgt Merge(m1,m2,map)
• Used to combine two models into one
• Input models m1 and m2 are well-formed
• Should produce a well-formed model m

32
Operators Complex Op.s (Merge contd)

• m satisfies
• . At least as expressive as each of the
  input models
• . Minimal
• map(morphism) describes elments of m1 and
• m2 that are
  equivalent or should be
• merged into a
  single element in m
• mi_m counterparts of the elements of mi in the

• merged model m

33

• Implementation

34
Implementation

• Extract Delete
• Match
• Merge

35
ImplementationExtract Delete

• Primary key constraints PID DID
• Referential constraint PRODUCTS.PID
  O_DETAILS.PID
• Constraints c1,c2,c3

36
Implementation Match

• Implemented by using SF(Similarity Flooding)
  algorithm(a graph matching algorithm)
• The attribute Sim is added to morphism as 3rd
  attribute to hold similarity value of each pair
  of nodes
• operator Match(m1, m2, seed)
• multimap SFJoin(m1, m2, seed)
• multimap Restrict(multimap, m1, m2)
• map FilterBest(multimap)
• return ltmap, multimapgt
• Seed is obtained by NGramMatch algorithm which
  computes similarities of literals in m1 and m2

37
Implementation Match (contd)

• SF Algorithm
• Inputs Two graphs(m1, m2), seed
• seed (a weighted binary relation) a set of
  initial similarity values between the nodes of
  the graph.
• ltl,rgt?a pair of seed
• Each ltl,rgt carries a sim value between 0 and 1
• Output A weighted binary relation
• Propagates the initial similarity of nodes to the
  surrounding nodes (using the instution that
  neighbors of similar nodes are similar)

38
Implementation Merge

• To implement Merge operator, an algorithm called
  GraphMerge is developped
• The algorithm consists of three conceptual steps
• Node renaming nodes at the blunt ends are
  renamed
• to their
  targets at sharp ends
• Graph union a set union of two sets of
  edges
• Conflict resolution for not well-formed models
• (costliest step since
  requires
• human
  feedback)

39
Implementation Merge (contd)
40
Implementation Merge (contd)
Morphism map (x,y, ),(x1,y2, ),(x1,y2,
) Target element is kept and source element is
discarded. e.g. x will be kept and y will be
discarded
Implementation Merge (contd)
41
Implementation Merge (contd)

• In the merged graph, node z1 which represents
  CUST attribute has now bocome an attribute of two
  different relations. To solve this kind of
  conflicets a heuristic is developed
• Track the origin of each edge in the merged graph
• Assign a tag to each edge
• Source node of a map -
• A target node of map
• None of two o
• e.g. ltx,z1gt obtained by renaming from ltx,x2gt is
  tagged with -
• since x target node and x2 source node
• Eliminate the edge(s) which causes conflict by
  considering the priority

42
Implementation Merge (contd)
43
Implementation Merge (contd)
Merge Algorithm
G Merged model s
All source nodes of map m1_G
Morphism between m1 and G m2_G
Morphism between m2 and G m
Copy of G
44

• Prototype

45
Prototype
46
Prototype

• Interpreter
• central component
• executes scripts
• can be run from command line
• or invoked by external app.s tools
• orchestrates the data flow

47
Prototype

• Operators
• a native implementation
• e.g. ReadSQLDDL, WriteSQLDDL
• ReadDb, WriteDb
• all primitive operators
• GUI operators like EditMap,
  EditSelector
• operators SFJoin and GraphMerge
• schema translation conversion
  operators
• scripts
• e.g. alias ReadSQLDDL ltJava class namegt
• Range, Match, Merge

48
Prototype (contd)

• NOTICE
• The specification of the commonly used native
  or derived operators can be grouped in a single
  script and utilized in other scripts using
  include statements

49
Prototype (contd)

• Facilities of the interpreter
• debugging
• e.g. examine the execution traces
• flexible handling of input and output
• e.g. operators having more than one parameter
• as output

50
Prototype (contd)

• Currently supported features are
• SQL DDL
• XML Schema
• RDF Schema
• SQL views
• UML

51
Prototype (contd)

• To introduce a new modelling language
• Step 1 Provide import/export operators
• Step 2 Implement callbacks for operators
• All, Extract and GraphMerge

52
Prototype (contd)
Code Breakdown (LOC)
53

• Related Work

54
Related Work

• In previous work, schemas were represented as
  graphs having is-a, has-a, functional dependency
  relationships.
• In this approach, the graphs are syntactic
  structures. Morphisms are used as schema
  correspondences. Selectors have been first
  introduced.

55
Related Work (contd)

• One of the surprises of the present work is how
  much leverage one can get out of simple
  morphisms.
• For minimizing the amount of manual
  post-processing in schema matching, the
  structural matcher is used instead of machine
  learning.
• Each converter is implemented as a custom,
  non-generic operator.

56
Related Work (contd)

• The operators presented are mostly syntactic,
  just like the conceptual structures, and are
  expressed as graph transformations.

57

• Conclusions

58
Conclusions

• The main conclusions are the following
• One can solve practical problems using the model
  management operators
• The solutions require a relatively small amount
  of code
• One can get very far using a relatively weak
  representation for models and mappings

59

• THANKS FOR YOUR VALUABLE TIME
