Tracing Routes

1
Tracing Routes

• TSM 352
• System Security

2
Introduction to Trace Route

• Traceroute is the generic name of a program that
  shows you the route over the network between two
  systems, listing all the intermediate routers a
  connection must pass through to get to its
  destination.
• Can help you determine why your connections to a
  given server might be poor, and can often help
  you figure out where exactly the problem is.
• Shows you how systems are connected to each
  other, letting you see how your gateway connects
  to the Internet as well as how the target system
  is connected.

3
Traceroute Utilities

• Typically a command-line-invoked program, but is
  often provided with a GUI front-end and is always
  one of the tools in a network probing tool
  box.
• On a Unix system (including Mac OS X) traceroute
  is run from the command line
• traceroute

• In a Microsoft system, the command has a slightly
  different spelling, due to the 8-character
  limitations of earlier operating systems
• C tracert
• There are also a number of visual routing
  programs available. These provide geographical
  information as a supplement to the IP/Domain name
  information provided by the typical traceroute
  program.

4
Sample Traceroute

• root_at_Inside1 hunt-1.5 traceroute
  216.239.51.101
• traceroute to 216.239.51.101 (216.239.51.101), 30
  hops max, 38 byte packets
• 1 192.168.1.254 (192.168.1.254) 1.175 ms
  1.087 ms 1.068 ms
• 2 216.249.153.254 (216.249.153.254) 3.052 ms
  2.111 ms 2.049 ms
• 3 192.168.169.254 (192.168.169.254) 2.528 ms
  2.278 ms 2.273 ms
• 4 192.168.70.254 (192.168.70.254) 3.630 ms
  3.249 ms 3.095 ms
• 5 216.249.175.253 (216.249.175.253) 4.780 ms
  4.059 ms 4.075 ms
• 6 10.0.1.125 (10.0.1.125) 13.872 ms 13.653 ms
  12.055 ms
• 7 lou-belknap-1-0-0-1-a.kec.net
  (199.120.154.161) 13.497 ms 12.713 ms 14.064
  ms
• 8 sl-gw31-chi-1-1.sprintlink.net (160.81.92.13)
  25.693 ms 26.044 ms 27.206 ms
• 9 sl-bb21-chi-4-0.sprintlink.net
  (144.232.26.29) 244.835 ms 91.989 ms 28.618 ms
• 10 p4-0.sprint.chcgil06.us.bb.verio.net
  (144.232.19.234) 25.931 ms 25.924 ms 25.773 ms
• 11 p16-3-0-0.r02.chcgil01.us.bb.verio.net
  (129.250.5.115) 27.203 ms 26.883 ms 25.841 ms
• 12 p16-5-0-0.r01.chcgil01.us.bb.verio.net
  (129.250.2.220) 28.527 ms 26.427 ms 26.869 ms
• 13 p16-1-0-1.r20.asbnva01.us.bb.verio.net
  (129.250.5.103) 54.239 ms 52.364 ms 52.459 ms
• 14 p16-7-0-0.r02.asbnva01.us.bb.verio.net
  (129.250.2.83) 52.859 ms 51.897 ms 51.353 ms
• 15 ge-1-1.a00.asbnva01.us.ra.verio.net
  (129.250.26.97) 52.701 ms 55.343 ms 52.642 ms
• 16 ge-3-2.a00.asbnva01.us.ce.verio.net
  (168.143.105.58) 52.092 ms 52.513 ms 52.877 ms
• 17 216.239.48.77 (216.239.48.77) 51.610 ms
  52.824 ms 52.076 ms

5
Reading the Output

• Line number the TTL value
• rDNS or machine that responds If it fails, the
  IP address is used. (this may be left out with
  the -n option).
• IP address that responds
• RTTs Three round trip times in milliseconds -
  how long it took a packet to get from me to that
  system and back again, called the latency between
  the two systems.

6
Partial Timeouts

• A timeout is indicated with an asterisk ()
• Sometimes, a line in the output may have one or
  two of the times missing, with an asterisk where
  it should be. For example, you might get a line
  like this
• sl-bb21-chi-4-0.sprintlink.net (144.232.26.29)
  244.835 ms
• In this case, the machine is up and responding,
  but for whatever reason it did not respond to the
  second and third packets. This is quite common.
  Responses like this are most often computers,
  rather than dedicated routers. For example,
  systems running Solaris routinely show an
  asterisk instead of the second RTT.
• It's important to remember that timeouts are not
  necessarily an indication of packet loss. This is
  a common misconception, but since there are only
  three probes, dropping one response is no big
  deal.

7
Full Timeouts

• 18 216.239.47.113 (216.239.47.113) 51.621 ms
  52.797 ms 52.635 ms
• 19 216.239.47.102 (216.239.47.102) 53.621 ms
  52.013 ms 52.143 ms
• etc.
• If your trace ends in all timeouts, this means
  that the target system could not be reached.
• The packets could not make it there and back
• May not be reaching the target
• May be reaching, but not returning
• May be an intentional block due to a firewall or
  other security measures, and the block may affect
  traceroute but not actual server connections.

8
Error Indicators

• A trace can end with one of several error
  indications indicating why the trace cannot
  proceed. In this Linux example, the router is
  indicating that it has no route to the target
  host
• 4 rbrt3.exit109.com (208.225.64.50) 35.931 ms
  !H 39.970 ms !H
• The !H is a host unreachable error message (it
  indicates that an ICMP error message was
  received). The trace will stop at this point.
  Possible ICMP error messages of this nature
  include
• !H Host unreachable. The router has no route to
  the target system.
• !N Network unreachable.
• !P Protocol unreachable.
• !S Source route failed. You tried to use source
  routing, but the router is configured to block
  source-routed packets.
• !F Fragmentation needed. This indicates that the
  router is misconfigured.
• !X Communication administratively prohibited.
  The network administrator has blocked traceroute
  at this router.

9
TTL Warnings

• Sometimes, with some versions of traceroute, you
  will see TTL warnings after the times
• 6 qwest-nyc-oc12.above.net (208.185.156.26)
  90.0 ms (ttl251!) 90.0 ms (ttl251!) 90.0 ms
  (ttl251!)
• This merely indicates that the TTL (time-to-live)
  value on the reply packet was different from what
  was expected.
• This probably means that your route is
  asymmetric. This is not shown by all versions of
  traceroute, and can be safely ignored.

10
Windows Output

• C\tracert www.google.com
• Tracing route to www.google.com 216.239.51.101
• over a maximum of 30 hops
• 1
• 2
• 3
• 4
• 5 10 ms 10 ms 10 ms 10.0.1.125
• 6 10 ms 10 ms 10 ms
  lou-belknap-1-0-0-1-a.kec.net 199.120.154.161
• 7 20 ms 20 ms 30 ms
  sl-gw31-chi-1-1.sprintlink.net 160.81.92.13
• 8 20 ms 30 ms 20 ms
  sl-bb21-chi-4-0.sprintlink.net 144.232.26.29
• 9 20 ms 30 ms 20 ms
  p4-0.sprint.chcgil06.us.bb.verio.net
  144.232.19.234
• 10 20 ms 30 ms 20 ms
  p16-3-0-0.r02.chcgil01.us.bb.verio.net
  129.250.5.115
• 11 30 ms 30 ms 40 ms
  p16-5-0-0.r01.chcgil01.us.bb.verio.net
  129.250.2.220
• 12 50 ms 50 ms 50 ms
  p16-1-0-1.r20.asbnva01.us.bb.verio.net
  129.250.5.103
• 13 50 ms 50 ms 61 ms
  p16-7-0-0.r02.asbnva01.us.bb.verio.net
  129.250.2.83
• 14 50 ms 50 ms 50 ms
  ge-1-1.a00.asbnva01.us.ra.verio.net
  129.250.26.97
• 15 50 ms 50 ms 50 ms
  ge-3-2.a00.asbnva01.us.ce.verio.net
  168.143.105.58
• 16 50 ms 50 ms 50 ms 216.239.48.77

11
Windows Output

• Different order of output fields
• RTTs first
• rDNS
• IP
• Notice that this trace was completed, unlike the
  Linux traceroute above that never did complete.
  This is due to the basic differences of how the
  Linux and Microsoft trace programs work. If one
  fails, it is probably a good idea to try the
  other.
• The Windows version does not show ICMP error
  messages in the manner described above. Errors
  are shown as (possibly ambiguous or confusing)
  text. For example, a host unreachable error
  will be shown as Destination net unreachable on
  Windows.

12
The Reverse Route

• Any connection over the Internet actually depends
  on two routes the route from your system to the
  server, and the route from that server back to
  your system. These routes may be (and often are)
  completely different (asymmetric).
• Only the router interfaces on your side report
  back to your traceroute
• Unfortunately, there are no easy ways to check
  the reverse route unless you have access to the
  machine at the other end.
• It is often helpful to try the trace from a
  variety of network connections, if available.
• Many systems have a web page where you can run a
  traceroute from their system back to yours. In
  combination with your trace to their system, this
  can give you the other half of the picture.
• For a list of web sites that allow a variety of
  tracing facilities from their site (to yours or
  other sites) see www.traceroute.org.
• .

13
Reverse Route Example

• The following is an example of one such site. In
  the next two traces, I run a trace to University
  of Maryland site, and then a reverse from that
  site back to my machine

14
Two Directions
205.168 - 205.171 Sprint, out of Denver,
CO 144.232 Sprint, out of Reston, VA
sl-bb23-rly-15-3.sprintlink.net (144.232.20.45)
Elkridge Maryland chi Chicago ewr Newark,
NJ dca Washington DC sl-st21-ash-6-0.sprintlin
k.net (144.232.19.17 Ashburn, VA
15
Visual Route Site

• http//visualroute.visualware.com/
• a web site that allows you to trace from Dulles,
  Washington DC to any place. It is an example of
  the visualroute program which is shareware
  and expires after 15 days, or costs 49
• http//www.jefferypsanders.com/traceit.html
• a site where you can download a program that will
  let you build your own database. Freeware.

16
Analyzing Timeouts

• Trace ends in Timeouts
• There could be a problem.
• A system is blocking traceroute attempts,
• The next step is to figure out where the problem
  is.
• The problem is no necessarily with the last hop
  from which a reply was received
• The source of the problem is either
• The connection between that system and the next
  system on the route
• The next system itself
• You may just have to wait for the problem to be
  fixed, especially if the problem system is not at
  your ISP and thus you aren't a paying customer of
  that network.
• The problem could lie somewhere on the return
  route between the system giving the timeouts and
  your own system, and that problem may not be
  reflected in the previous parts of the trace
  because the route may be entirely different.

17
Example Timeout Problem

• 16 c1-pos5-3.snjsca1.home.net (24.7.66.77)
  136.612 ms 129.795 ms 129.133 ms
• 17 bb1-pos6-0-0.rdc1.sfba.home.net (24.7.72.18)
  130.473 ms 137.609 ms 134.162 ms
• The last reachable system on the route is at hop
  17.
• The problem may be with the system at hop 18
• The network connection between hops 17 and 18.
• The return route.
• The only way to tell is to see the reverse trace.
  A reverse trace from hop 17 would be useful here
  as well, to verify that the routes are indeed
  different.
• It may be difficult or impossible to obtain
  traceroutes from those systems, because the
  network administrator at home.net would have to
  run them for you, and is probably too busy to
  worry about such a request.
• In this case, you can try running traces to the
  target system from various other places. In the
  above example, if you knew what router was
  normally at hop 18 (from seeing it in previous
  traces), you could try a trace to that router
  from another site.

18
Long Routes

• traceroute to 24.48.145.237 (24.48.145.237), 30
  hops max, 40 byte packets
• 1 main2-249-97.iad.above.net (209.249.97.3)
  1.143 ms 0.559 ms 0.382 ms
• 2 core1-main2-oc3-1.iad.above.net
  (209.249.0.25) 0.574 ms 0.886 ms 0.429 ms
• 3 sjc-iad-oc12-1.sjc.above.net (207.126.96.121)
  82.134 ms 82.537 ms 82.158 ms
• 4 sl-gw8-sj-0-1.sprintlink.net
  (144.232.192.129) 82.523 ms 82.383 ms 82.949
  ms
• 5 sl-bb12-sj-6-0.sprintlink.net (144.232.3.109)
  82.348 ms 82.762 ms 83.029 ms
• 6 sl-bb10-sj-8-0.sprintlink.net (144.232.3.85)
  83.346 ms 83.012 ms 83.006 ms
• 7 sl-bb10-rly-6-0.sprintlink.net (144.232.9.13)
  136.004 ms 135.804 ms 136.274 ms
• 8 sl-bb6-dc-0-0-0.sprintlink.net
  (144.232.7.170) 137.625 ms 137.204 ms 136.794
  ms
• 9 gip-dc-2-fddi1-0.gip.net (204.59.144.194)
  137.344 ms 138.156 ms 139.390 ms
• 10 gip-arch-1-atm2-0-0-132-atm.gip.net
  (204.59.5.25) 311.850 ms 325.246 ms 285.607 ms
• 11 gip-telehouse-1-atm0-0-0-333-atm.gip.net
  (204.59.5.14) 281.472 ms 291.957 ms 314.661 ms
• 12 gip-linx-fddi0.gip.net (204.59.2.198)
  277.425 ms 297.364 ms 248.030 ms
• 13 linx-gw1.UK.EU.net (195.66.224.90) 291.800
  ms 213.447 ms 221.377 ms
• 14 Nyk-nr01.NY.US.EU.net (134.222.228.158)
  266.863 ms 301.220 ms 320.008 ms
• 15 nyc-core-02.inet.qwest.net (205.171.17.9)
  206.191 ms 233.207 ms
• 16 nyc-core-03.inet.qwest.net (205.171.17.85)
  235.085 ms 270.805 ms 252.668 ms
• 17 nyc-core-01.inet.qwest.net (205.171.17.82)
  281.931 ms 277.519 ms 278.152 ms
• 18 wdc-core-02.inet.qwest.net (205.171.5.235)
  265.548 ms 233.789 ms 219.698 ms

19
High Latency

• As the latency of a connection increases
• Interactive response suffers
• Download speed can also suffer (remember TCP
  windowing
• Inherent Connection-type Latency
• Typical Modem latency 120-130ms.
• ISDN line 40-45ms.
• If you use a connection of this type, you won't
  see any better than these numbers.
• If you see a large jump in latency from one hop
  to the next, that could indicate a problem.
• It could be a saturated (overused) network link
• A slow network link
• An overloaded router
• A problem anywhere on the return route from the
  high-latency hop as well.
• A long hop, such as a cross-country link or one
  that crosses an ocean
• You can use ping to get a better idea of the
  latency as well as the packet loss to a given
  site or router
• Traceroute only does three probes per router (by
  default), which isn't a very good sample on its
  own.

20
Long Route Example

• C\tracert core1.London1.Level3.net
• Tracing route to core1.London1.Level3.net
  212.113.2.65
• over a maximum of 30 hops
• 1 10 ms
• 2
• 3
• 4
• 5 10 ms 10 ms 10 ms 10.0.1.125
• 6 10 ms 10 ms 20 ms
  lou-belknap-1-0-0-1-a.kec.net 199.120.154.161
• 7 20 ms 30 ms 20 ms
  sl-gw31-chi-1-1.sprintlink.net 160.81.92.13
• 8 20 ms 20 ms 30 ms
  sl-bb23-chi-4-0.sprintlink.net 144.232.10.49
• 9 20 ms 20 ms 20 ms
  sl-bb22-chi-13-0.sprintlink.net 144.232.26.49
• 10 20 ms 30 ms 20 ms 144.232.8.186
• 11 20 ms 30 ms 20 ms
  so-4-0-0.mp2.chicago1.level3.net 209.247.10.169
• 12 50 ms 60 ms 60 ms
  unknown.level3.net 64.159.0.238
• 13 121 ms 120 ms 120 ms
  so-2-0-0.mp2.london1.level3.net 212.187.128.154
• 14 120 ms 120 ms 120 ms
  loopback0.core1.london1.level3.net 212.113.2.65
• Trace complete.
• Note the jump in delay time in line 13 for the
  transatlantic hop.

21
Trace to China

• C\tracert www.linkwan.com
• Tracing route to www.linkwan.com 202.96.137.89
• over a maximum of 30 hops
• 10 70 ms 60 ms 60 ms
  sl-bb20-sea-8-2.sprintlink.net 144.232.18.49
• 11 60 ms 60 ms 70 ms
  sl-bb21-tac-10-0.sprintlink.net 144.232.18.86
• 12 180 ms 190 ms 190 ms
  sl-bb20-tok-15-3.sprintlink.net 144.232.19.242
• 13 180 ms 190 ms 190 ms
  sl-bb21-tok-15-0.sprintlink.net 203.222.36.34
• 14 240 ms 241 ms 240 ms
  sl-bb20-hk-14-2.sprintlink.net 203.222.33.6
• 15 230 ms 240 ms 241 ms 203.222.38.54
• 16 431 ms 440 ms 441 ms
  sla-cnatel-1-0.sprintlink.net 203.222.39.38
• 17 481 ms 451 ms 491 ms 202.97.33.153
• 18 1282 ms 1292 ms 1292 ms
  pos9-0-r1-c-gz-b.gd.cn.net 61.140.0.2
• 19 441 ms 440 ms 431 ms
  pos1-0-r1-c-sz-c.gd.cn.net 202.105.1.246
• 20 430 ms 451 ms 431 ms 61.140.1.18
• 21 410 ms 431 ms 431 ms 61.144.236.34

22
Tracing Private IP Ranges

• Private addresses should never be visible over
  the Internet. But, sometimes you will see them in
  traceroute output. If they appear within your
  local network, this is okay private addresses
  inside your own network can be visible to you.
  If, however, they appear within someone else's
  network, this can be problematic
• 10 ebay-2-gw.customer.ALTER.NET (157.130.197.90)
  114.204 ms 123.232 ms 120.957 ms
• 11 10.1.2.5 (10.1.2.5) 110.693 ms 114.475 ms
  107.747 ms
• 12
• 13
• The private address 10.1.2.5 within another
  network should not be visible to us. In this
  case, though, it is the last visible address
  before the trace ends in timeouts.
• Visibility of private IP addresses doesn't
  necessarily mean that the route does not work. It
  is often simply the way the administrators of the
  target network have set up their system. In fact,
  the output above, despite the private IP address
  and the timeouts, shows a route that works
  perfectly well for web access.
• However, a route which includes private addresses
  is difficult to troubleshoot. You can't ping the
  private routers to see if there is any packet
  loss. You can't trace directly to them from other
  sites. And in general, they show a certain level
  of cluelessness in how the network is set up

23
Route Looping

• 14 hou-core-03.inet.qwest.net (205.171.5.146)
  165.484 ms 164.335 ms 175.928 ms
• 15 hou-core-02.inet.qwest.net (205.171.23.5)
  162.291 ms 172.713 ms 171.532 ms
• 16 kcm-core-01.inet.qwest.net (205.171.5.201)
  212.967 ms 193.454 ms 199.457 ms
• 17 dal-core-01.inet.qwest.net (205.171.5.203)
  206.296 ms 212.383 ms 189.592 ms
• 18 kcm-core-01.inet.qwest.net (205.171.5.201)
  210.201 ms 225.674 ms 208.124 ms
• 19 dal-core-01.inet.qwest.net (205.171.5.203)
  189.089 ms 201.505 ms 201.659 ms
• 20 kcm-core-01.inet.qwest.net (205.171.5.201)
  334.19 ms 320.39 ms 245.182 ms
• dal-core-01.inet.qwest.net (205.171.5.203)
  218.519 ms 210.519 ms 246.635 ms
• We have learned about routing loops they are
  the result of incomplete routing tables and
  packets that try to come through before complete
  convergence has occurred.

24
Odd Traceroute Results

• 11 USW-phx-gw.customer.ALTER.NET (137.39.162.10)
  142.840 ms 151.245 ms 129.564 ms
• 12 206.80.192.221 (206.80.192.221) 127.569 ms
  vdsla121.phnx.uswest.net (216.161.182.121)
  185.214 ms
• 13 vdsla121.phnx.uswest.net (216.161.182.121)
  442.912 ms 205.956 ms 221.537 ms
• 14 vdsla121.phnx.uswest.net (216.161.182.121)
  164.728 ms 186.997 ms 190.414 ms
• vdsla121.phnx.uswest.net (216.161.182.121)
  306.964 ms 189.152 ms 221.288 ms
• Hop 12 Responses from two different machines.
• Hops 13, 14, and 15 are all showing the same
  address! Since the response times are actually
  different, though, we can guess that they are, in
  reality, different systems. The trace ends
  normally at hop 15.
• So what the heck is going on here? US West says
  this is a security measure, to hide the details
  of their internal network. The last few hops all
  return the address of the end-user's ADSL line,
  rather than their actual address. I'm not
  entirely sure what kind of security this is
  meant to provide.
• Obviously, this makes any kind of troubleshooting
  of this connection next to impossible. If you
  encounter problems in this situation, the best
  you can do is contact the network provider and
  let them deal with it.

25
How the Trace Program Works

• Send consecute IP packets with incrementing
  time-to-live (TTL) values
• Each time a packet passes through a router, its
  TTL value is decremented by one when it reaches
  zero, the packet is dropped, and an ICMP
  Time-To-Live Exceeded error message is returned
  to the sender.
• Eventually either the final destination is
  reached, or the maximum value (default is 30) is
  reached and the traceroute ends.
• At the final destination, a different error is
  returned. Most traceroute programs work by
  sending UDP datagrams to some random
  high-numbered port where nothing is likely to be
  listening. When that final system is reached,
  since nothing is answering on that port, an ICMP
  Port Unreachable error message is returned, and
  we are finished.
• The Windows version of traceroute uses ICMP Echo
  Request packets (ping packets) rather than UDP
  datagrams.
• A few versions of traceroute, such as the one on
  Solaris, allow you to choose either method
  (high-port UDP or ICMP echo requests).

26
Source Routing

• Normally IP routing is dynamic with each router
  making a decision about which next-hop router to
  send the datagram to. Applications have no
  control of this, and are normally not concerned
  with it. It takes tools such as Traceroute to
  figure out what the route really is.
• The idea behind source routing is that the sender
  specifies the route. Two forms are provided
• Strict source routing. The sender specifies the
  exact path that the IP datagram must follow. If a
  router encounters a next hop in the source route
  that isn't on a directly connected network, an
  ICMP "source route failed" error is returned.
• Loose source routing. The sender specifies a list
  of IP address that the datagram must traverse,
  but the datagram can also pass through other
  routers between any two addresses in the list.
• Traceroute provides a way to look at source
  routing, as we can specify an option allowing us
  to force a source route, and see what happens.
• The source route options are actually called
  "source and record route" (LSRR and SSRR, for
  loose and strict) since the list of IP addresses
  is updated as the datagram passes along the path.

27
How Source Routing Works

• 1. The sending host takes the source route list
  from the application, removes the first entry (it
  becomes the destination address of the packet),
  moves all the remaining entries left by one
  entry, and places the original destination
  address as the final entry in the list. The
  pointer is set to 1.
• 2. Each router that handles the packet checks
  whether it is the destination address of the
  packet. If not, the packet is forwarded as
  normal. In other words, this particular router
  is not one of the ones in the loose source list
  of IPs.
• 3. If the router is the destination, and the
  pointer is not yet greater than the length, then
• 4. The next address in the list now becomes the
  destination address,
• 5. The IP address corresponding to the outgoing
  interface replaces the source address just used,
  and
• 6. The pointer is incremented by 1.

28
Source Routing Operation
29
Loose-Source Routing Example

• First look at a regular trace between two lab
  machines
• root_at_Outside root traceroute 216.249.144.202
• traceroute to 216.249.144.202 (216.249.144.202),
  30 hops max, 50 byte packets
• 1 216.249.144.205 (216.249.144.205) 2.616 ms
  2.058 ms 2.178 ms
• 2 216.249.144.202 (216.249.144.202) 5.908 ms
  !S 3.743 ms !S 3.684 ms !S
• Now, lets force it to pass through the .210
  machine
• root_at_Outside root traceroute -g
  216.249.144.202 216.249.144.210
• traceroute to 216.249.144.210 (216.249.144.210),
  30 hops max, 50 byte packets
• 1 216.249.144.210 (216.249.144.210) 1.256 ms
  1.191 ms 1.177 ms
• 2 216.249.144.205 (216.249.144.205) 2.616 ms
  2.058 ms 2.178 mx
• 3 216.249.144.202 (216.249.144.202) 5.908 ms
  !S 3.743 ms !S 3.684 ms !S

30
Source Routing in Real Life

• This is most likely what you will see these days
• root_at_Outside root traceroute -g 216.239.33.100
  216.249.144.230 -n
• traceroute to 216.249.144.230 (216.249.144.230),
  30 hops max, 46 byte packets
• 1 216.249.144.230 1.264 ms 1.207 ms 1.195 ms
• 2 216.249.153.254 2.597 ms !S 1.818 ms !S
  1.804 ms !S
• In this example I tried to specify a loose source
  route and trace to www.google.com. You will
  notice the !S on the first router leaving the
  labs network it is configured like most
  routers these days to not permit source routing
  of any kind. The specified intermediate router
  has already been tagged (the .230 machine), but
  that doesnt matter to the .254 router. It is set
  up to disallow any source routing, so it will not
  forward any packets that have the IP option of
  source routing enabled.

31
Our Tracing Lab

• Compare Windows vs Linux traceroute utilities.
• How NATing effects tracing
• Look at how a firewall might effect tracing
  both inbound and outbound
• Take a look at source routing
• Learn a few tracing tricks

32
Research/Presentation Opportunity

• Talk about the visual trace programs. What do
  they offer? What are their differences? How are
  they able to provide the geographical
  information?
• How are IPs related to geography? What changes
  in this topic (if any) will be implemented with
  the adoption of the IPv6 standards?
