Title: Multimedia Databases

1
Multimedia Databases

Eran Stiller Omer Gertel

2
In this presentation

Introduction
What is a Multimedia Database
Why do we need it
Modeling Multimedia Databases
Design Methodology
Modeling the WWW as a Multimedia Database
WebSQL
Using the Multimedia Design Methodology
Graphical extension to SQL SQLD

3
What is a Multimedia Database

Multimedia Data-types
Movies Pictures Sound Clips Documents etc
Advanced Querying Possibilities

4
Why Do We Need It

Tremendous Amounts of
Digitized Multimedia Content
Video servers Ifilms IMDB AllMusic etc
Querying for Digitized Information
A Picture is Worth a Thousand Words

5
The Leading Concept

Extracting Information from Multimedia Objects
On the Fly
Creating a Design Methodology
Simple Intuitive Upward Compatible
Unbound by Data-type Application Usage

6
Modeling Multimedia Databases

Using Object Relational Data Models
Data Description Language

7
Data Description Language

Example
Movie Database
MOVIE(Title Year Director Length)
What About the Movie
Add It to the Database
Create Additional Functions

8
Data Description Language

First Approach
Complex Type
Create Type Movie_t(
Title varchar(20)
Year int
Director varchar(20)
Length int
MV blob)
Create Table Movie of type Movie_t

9
Data Description Language

Second Approach
Extended Type
Create Table Movies(
Title varchar(20)
Year int
Director varchar(20)
Length int
MV movie_blob)

10
Data Description Language

Concerns
Distinguishing the Digitized Information
Conclusion
Naming Convention
The Core Special Attribute

11
Data Description Language

Example Continued
A New Relation
MOVIE(Title Year Director Length Core)
What About Querying
Show the opening sequence of all movies directed
by Spielberg in 1993.

12
Data Description Language

SQL-like Language
Select Movie.opening_seq
From Movie
Where Year1993 AND DirectorSpielberg

13
Data Description Language

SQL Solution
Declare External opening_seq(movie_blob)
Returns movie_blob
Language C
Smart Interpreter

14
A Design Methodology

Core-ER Diagram
Core-ORDB schema

15
Core-ER Diagram

Entities
Abstract Entities
Core Entities

16
Core-ER Diagram

Attributes
Conventional Attributes
Unconventional Attributes

17
Core-ER Diagram

Methods
Core as Input
Entity as Input

18
Core-ER Diagram

Keys and Relationships
Exactly as in ER Diagrams

19
Core-ER Diagram

Example

20
CER to Core-ORDB Schema

We Need Rules For
Abstract Entities
Core Entities
Methods
Relationships
Embedded ER Diagram
Keys
Core Can Be a Key
Example

Employee(SSN name picture position salary
Dept)

EMail(EMailID From To Date Date R Size
RespTo Core)

Declare External Keyword(Email string) Returns
BOOLEAN

Has(SSN EMailID)

Note Core Can Be A Key!

26
A Design Methodology

Conclusion
Full Upward Compatibility
An Easy to Use Solution

27
Modeling the WWW

WebSQL
Using the Multimedia Design Methodology

28
WebSQL

SQL-Like Language
Minimal Relational Approach
Queries Based Both On The Content And On The
Hypertext Structure Of The Web

29
WebSQL

Content Based Queries
Document(url title text type length
lastModify)

30
WebSQL

Example
Find All HTML Documents About Hypertext
Select D.url D.title D.length D.lastModify
From Document D such that D mentions
Hypertext
Where D.type text/html

31
WebSQL

Hypertext Structure Based Queries
Document(url title text type length
lastModify)
Anchor(base href label)

32
WebSQL

Example
Find All Links to Applet from Documents About
Java
Select Y.label Y.href
From Document X such that X mentions Java
Anchor Y such that base X
Where Y.label contains Applet

33
WebSQL

Hypertext Link Classification
Interior ()
Local ()
Global ()
Empty Path ()
Path Regular Expressions
Alternation ( )
Repetition ( )
Concatenation ( . )

34
WebSQL

Example
Select D.url D.title
From Document D such that
http//www.cs.huji.ac.il . D
Where D.title contains database

35
WebSQL

Example
Select X.url X.title Y.url Y.title
From
Document X such that X mentions Computer
Science
Document Y such that X . Y

36
Modeling the WWW

WebSQL
Already Implemented in Java
Specific Solution
Refers Only To Documents
Using the Multimedia Design Methodology

37
Multimedia Databases

Well Be Back Right After The Break

38
Modeling the WWW

WebSQL
Already Implemented in Java
Specific Solution
Refers Only To Documents
Using the Multimedia Design Methodology

39
Multimedia Design Methodology

Entities
HTMLdoc(h_url title type length lastModify
core)
Links(l_url label)
Include(h_url l_url)

40
Multimedia Design Methodology

Methods
Contains(HTMLdoc.title string)
Reach_by(HTMLdoc.url url_to by_n l_type)
Mentions(HTMLdoc string)
Linktype(HTMLdoc url)

41
Multimedia Design Methodology

Example
Find All HTML Documents About Hypertext
Select HTMLdoc.h_url
From HTMLdoc
Where Contains(HTMLdoc.title Hypertext)

42
Multimedia Design Methodology

Example
Find All Links to Applet from Documents About
Java
Select Links.l_url
From HTMLdoc Links Include
Where mentions(HTMLdoc java) AND
HTMLdoc.h_url Include.h_url AND
Links.l_url Include.l_url AND
substring(applet Links.label)

43
Multimedia Design Methodology

Example
Select Links.l_url
From HTMLdoc Links Include
Where substring(database HTMLdoc.title) AND
HTMLdoc.h_url Include.h_url AND
Links.l_url Include.l_url AND
reach_by(http//www.cs.huji.ac.il
Links.l_url 2 local)
Hint Weve seen it before

44
Multimedia Design Methodology

Example
Select HTMLdoc.h_url Links.l_url
From HTMLdoc Links
Where mentions(HTMLdoc Computer Science) AND
reach_by(HTMLdoc.h_url Links.l_url 2 local)

45
Multimedia Design Methodology

Simplified Model But
Complicated Real World
Taking Another Step

46
Multimedia Design Methodology

Entities
HTMLdoc(h_url title type length
lastModify core)
WebObject(w_url label objectType
interactive core)
Properties(position size props)
Include(h_url w_url position size props)

47
Multimedia Design Methodology

Methods
Contains(HTMLdoc.title string)
Reach_by(HTMLdoc.url url_to by_n l_type)
Mentions(HTMLdoc string)
Linktype(HTMLdoc url)
And Additional Methods
DisplayDoc(HTMLdoc)
DisplayObj(WebObject Properties.position
Properties.size Properties.props)

48
Multimedia Design Methodology

Example
List All Documents That Have a Video-Clip Or a
Picture Labeled Sharon
Select HTMLdoc.h_url
From HTMLdoc WebObject Include
Where HTMLdoc.h_url Include.h_url AND
WebObject.w_url Include.w_url AND
(WebObject.objectType Image OR
WebObject.objectType Video) AND
WebObject.label Sharon

49
Multimedia Design Methodology

Still Not Complicated Enough
The Last Step

50
Modeling the WWW

WebSQL
Already Implemented in Java
Specific Solution
Refers Only To Documents
Using the Multimedia Design Methodology
General Methodology Used
Doesnt Require a Special Web SQL-Like Language
Easily Expandable

51
SQLD

Graphical Extension to SQL
Answering a Multimedia Database Query
Easier than Creating Specific Display Solutions
Display Specifications Are Included in the Query

52
SQLD

Video Store Database
Movie(available title director producer
date classification rating core poster)
Movie_Actors(title name role)
Actors(name age biography picture)

53
SQLD

List All Actors in Gone With the Wind with
Their Pictures and Biographies
Select MA.name A.biography A.picture
From Movie_Actors MA Actors A
Where MA.title Gone With the Wind AND
A.name MA.name
Display Panel main Panel info On main(east)
With MA.name As list On main(west)
A.picture As image On info(north)
A.biography As text On info(south)

54
(No Transcript)
55
SQLD

Display All Action Movies and Their Posters
Allowing to Play the movie If Desired
Select title poster core
From Movie
Where classification Action
Display Panel main Panel b On main(east)
With poster As image On main(west)
title As list On b(north)
Play As button On b(south)
Trigger mpegplay( core )

56
(No Transcript)
57
SQLD

Campus Map Database
Campus(campus_areaarea_map)
Building(building_name building_picture
campus_area coordinates)
Floor(building_name floor floor_map)
Room(building_name floor room_name
description homepage info coordinates)

58
SQLD

Show a Map of Main Campus With a List of the
Buildings in it
Select C.area_map B.building_name
From Campus C Building B
Where C.campus_area Main Campus
Display Panel main
With B.building_name As list On main(east)
C.area_map As image On main(west)

59
(No Transcript)
60
SQLD

Show a Map of Main Campus With a List of the
Buildings in it
Select C.area_map B.building_name
B.coordinates
From Campus C Building B
Where C.campus_area Main Campus
Display Panel main
With B.building_name As list On main(east)
C.area_map As image On main(west)
All B.coordinates As polygon On
main(west)

61
(No Transcript)
62
SQLD

Show a Map of Main Campus With a List of the
Buildings in it
Select C.area_map B.building_name
From Campus C Building B
Where C.campus_area Main Campus
Display Panel main
With B.building_name As list On main(east)
Trigger building_maps( building_name
)
C.area_map As image On main(west)

63
SQLD

Where building_maps(input) is
Select B.building_name B.building_picture
F.floor
From Building B Floor F
Where B.building_name input AND
F.building_name B.building_name
Display Panel main Panel b On main(south)
With building_picture As image On main(north)
building_name As title On main(north)
All floor As button On b(east)
Trigger floor_buildings( building_name
floor )
Select Floor To Visit On b(west)

64
(No Transcript)
65
SQLD

And floor_buildings(input1 input2) is
Select F.floor_map R.floor R.room_name
R.info R.homepage R.coordinates
From Floor F Room R
Where F.building_name input1 AND
F.floor input2 AND
R.floor F.floor

66
SQLD

And floor_buildings(input1 input2) is
Display Panel main
Panel b On main(west)
Panel c On main(east)
With floor_map As image On c(north)
All coordinates As poly On c(north)
room_name As list On b(north)
info As text On b(center)
All Distinct floor As button On c(south)
Trigger floor_buildings(buildin
g_namefloor)
homepage As button On b(south)

67
(No Transcript)
68
SQLD

SQL-Like Queries
Application-Like Display Controller
Makes Most of Both Worlds
Simple to Use
User Friendly Output

69
Conclusion

Multimedia Content Becomes More and More Popular
Correct Generic Models Bring Easy to Use Results
Clean Simple Solutions Come From Extending the
Existing Format

70
References

Chitta Baral Graciela Gonzalez and Tran Son
Conceptual Modeling and Quering in Multi-media
Databases Department of CS UTEP
Alberto O. Mendelzon George A. Mihaila and Tova
Milo Quering the World Wide Web University of
Toronto and Tel-Aviv University 1996
Chitta Baral Graciela Gonzalez and Tran Son A
Multimedia Display Extension to SQL Language
Design and Architecture Department of CS UTEP
1997
Chitta Baral Graciela Gonzalez and Tran Son
Issues in Querying Multimedia Databases
Department of CS UTEP
Isabel F. Cruz Michael Averbuch Wendy T. Lucas
Mellisa Radzyminski Kirby Zhang Delaunay a
Database Visualization System Database
Visualization Reaserch Group Tufts University
