Title: VMware Virtualization of Oracle and Java


1
VMware Virtualization of Oracle and Java
  • Scott B. Drummonds
  • Tim Harris

2
Agenda
  • VMware Virtualization Overview
  • Architecture, performance, and overheads
  • Best Practices
  • Oracle, Java
  • Performance Data
  • Scaling, large memory pages, AMD RVI
  • Conclusions

3
VMware Virtualization of Oracle and Java
4
VMware Infrastructure 3 Architecture
5
VMware ESX Virtualization Architecture
Guest
Guest
File System
TCP/IP
CPU resource is controlled by The scheduler, and
virtualized by the monitor Memory is allocated
by the VMkernel, and virtualized by the
monitor Network and I/O devices are emulated
and proxies though native device drivers
Monitor
Monitor
VMkernel
Virtual NIC
Virtual SCSI
Memory Allocator
Scheduler
Virtual Switch
File System
NIC Drivers
I/O Drivers
Physical Hardware
6
Speeding Up Virtualization
Where are the various virtualization performance
hits?
7
Multi-Mode Monitors
Guest
Guest
Guest
There are different types of monitors for
different workloads and CPU types VMware ESX
provides a dynamic framework to allow the best
monitor for the workload
Binary Translation
Para- Virtualization
Hardware Assist
VMkernel
Virtual NIC
Virtual SCSI
Memory Allocator
Scheduler
Virtual Switch
File System
NIC Drivers
I/O Drivers
Physical Hardware
8
MMU Virtualization without hardware support
  • Guest maintains sets of page tables
  • In native execution, they would have been used
    for address translation
  • Virtual Machine Monitor (VMM) maintains a set of
    shadow page tables
  • There is one shadow page table for each guest
    page table
  • VMM sets CR3 to point to shadow page tables
  • Translation happens using shadow page tables
  • Guest page tables contain VPN-PPN translations,
    while shadows contain VPN-MPN translations

CR3
Guest page tables
VPN-PPN translations
Shadow page tables
VPN-MPN translations
9
Rapid Virtualization Indexing
VPN - PPN mapping
  • RVI provides mechanism to avoid shadow page
    tables
  • Provides a second layer of page tables
  • Contain physical to machine address translations
  • Hypervisor maintains them
  • So, with RVI
  • Guest page tables contain virtual to physical
    translation
  • Second level tables contain physical to machine
    translation
  • Using two tables, hardware converts virtual
    address to machine address

guest CR3
guest page tables
nested CR3
hypervisor page tables
PPN - MPN mapping
10
What is Page Sharing?
VM 1
VM 2
VM 3
  • Content-based
  • Hint (hash of page content) generated for 4K
    pages
  • Hint is used for a match
  • If matched, perform bit by bit comparison
  • COW (Copy-on-Write)
  • Shared pages are marked read-only
  • Write to the page breaks sharing

Hypervisor
VM 1
VM 2
VM 3
Hypervisor
11
ESX Server Memory Ballooning
Borrow Pages
VM with VMware Tools Installed
  • Guest OS has better information than VMkernel
  • Which pages are stale
  • Which pages are unused
  • Guest Driver installed with VMware Tools
  • Artificially induces memory pressure
  • VMkernel decides how much memory to reclaim, but
    guest OS gets to choose particular pages

May page content out to virtual disk
Expand
VM with VMware Tools Installed
Lend Pages
May bring contentfrom virtual disk
Shrink
12
Oracle Databases on VI3
13
Oracle Database Characteristics
  • What its not
  • Its not a Huge I/O consumer
  • Most common Oracle databases have modest I/O
    profiles
  • It does not have a small memory footprint
  • Large-ish memory footprint and modest I/O most
    common
  • Tuning a DB for virtualization is not unique
    rocket science
  • Many standard tuning activities benefit
    virtualized DBs substantially

14
Capacity Planner Data for Oracle Databases
  • Out of 13K Physical Oracle DBs considered
  • 65 of systems on 2 core systems, averaging 5
    CPU utilization
  • Roughly 4 of systems fully consume more than 2
    cores
  • Most consume between 2 and 4G of RAM
  • Static RAM consumption points to fixed SGA with
    fixed of PGAs

15
Oracle DB Workload Characteristics
  • Memory
  • Large In-Memory Footprint (SGA)
  • Ensure good cache hit ratio
  • Target 98 or higher
  • Small number of processes to protect against TLB
    misses
  • I/O
  • Lower than generally assume (50 IOP per second
    average)
  • Depends on quality of SQL execution plans
  • Overall Privileged Instructions
  • I/O, Context Switch (TLB misses)

16
Making your DB Ready to Virtualize
  • Well Tuned DB for Physical is Good for Virtual
  • Poor Execution Plans even worse in Virtual
  • Cause poor cache re-use
  • Cause additional I/O and hence CPU Overhead
  • Cause additional impact on storage
  • Minimize Full Table Scans
  • Up to date statistics for CBO
  • Small number of DB file scattered read events
  • Tune SQL with high number of physical reads per
    execute

17
Virtualization Overhead for Oracle DBs
  • Well Tuned DB
  • Typically 10 to 20 additional CPU required over
    physical
  • Poorly Tuned DB
  • Maybe 20 to 30 or even more
  • Depends on SQL execution plans
  • User Impact of Additional CPU Requirements
  • Allocate additional CPU per VM to cover overhead
  • Results in minimal impact to user response time
  • If VM CPU pegged then expect substantial impact
    on user

18
Oracle Physical to Virtual Conversion Process
  • All but the Hungriest DBs will fit on a VM
  • Use smallest VM that will suffice
  • Ie. 1 vCPU VM more efficient than 2 vCPU if it
    fits
  • Current limit of 4 vCPU per VM
  • Will not exist for long
  • Limits virtualization of DBs that consume more
    than 3 physical cores
  • Appears to be a small number of all DBs
  • Less than 5 in our surveys

19
General Best Practices for Virtualizing DBs
  • Characterize DBs into three rough groups
  • Green DBs typically 70
  • Ideal candidate for virtualization
  • Well tuned and modest CPU consumption
  • Yellow DBs typically 25
  • Likely candidate for virtualization
  • May need some SQL tuning and monitoring to
    understand CPU and I/O requirements
  • Red DBs typically 5
  • Unlikely candidates until larger VMs available
  • Consumes 4 or more physical cores
  • Not a lot of SQL tuning to be done

20
OLTP vs DSS Oracle Workloads and Virtualization
  • OLTP Workloads
  • Assume frequent small queries
  • Should hit efficient index almost all the time
  • Basic Diagnostics with AWR report
  • Need small physical reads per exec, no full table
    scans
  • DSS Workloads
  • Should hit summary tables vs base tables as much
    as possible
  • Use materialized views to roll up as batch jobs
    at night
  • Daytime load should be index look ups
  • May summarize delta from summary in real time
    when necessary

21
Direct I/O
  • Guest-OS Level Option for Bypassing the guest
    cache
  • Uncached access avoids multiple copies of data in
    memory
  • Avoid read/modify/write module file system block
    size
  • Bypasses many file-system level locks
  • Enabling Direct I/O on Linux

vi init.ora filesystemio_optionssetall Check
iostat 3 (Check for I/O size matching the DB
block size)
22
Asynchronous I/O
  • An API for single-threaded process to launch
    multiple outstanding I/Os
  • Multi-threaded programs could just just multiple
    threads
  • Oracle databases uses this extensively
  • See aio_read(), aio_write() etc...
  • Enabling AIO on Linux

rpm -Uvh aio.rpm vi init.ora filesystemio_opti
onssetall Check ps aef grep dbwr
strace p io_submit() for io_submit in syscall trace
23
Use Large Pages
  • Guest-OS Level Option to use Large MMU Pages
  • Maps the large SGA region with fewer TLB entries
  • Reduces MMU overheads
  • Enabling Large Pages on Linux

vi /etc/sysctl.conf (add the following
lines) vm/nr_hugepages2048 vm/hugetlb_shm_group
55 cat /proc/vminfo grep Huge HugePages_Total
1024 HugePages_Free 940 Hugepagesize
2048 kB
24
Linux Versions
  • Some older Linux versions have a 1Khz timer to
    optimize desktop-style applications
  • There is no reason to use such a high timer rate
    on server-class applications
  • The timer rate on 4vcpu Linux guests is over
    70,000 per second!
  • Use RHEL5.1
  • Install 2.6.18-53.1.4 kernel or later
  • Put divider10 on the end of the kernel line in
    grub.conf and reboot.
  • All the RHEL clones (CentOS, Oracle EL, etc.)
    work the same way.

25
Page Sharing and Large Memory Pages
  • Large Pages In Oracle
  • Can increase efficiency of memory management
  • Large Pages are Not Shared
  • Expect less reduction in memory consumption with
    large pages
  • Hardware Assisted Memory Management
  • Benefits from use of Large Pages
  • No other hypervisor uses large pages today
  • Expect AMD RVI and Intel EPT to work well with
    VMware Infrastructure
  • And likely not with hypervisors that dont
    support large pages

26
Page Sharing With Oracle DBs
  • Page Sharing in Vmware Infrastructure
  • Reduce memory consumption by sharing common pages
  • Common pages include
  • OS related pages
  • Executable related pages
  • Ie. Oracle executables for each VM running Oracle
  • Serves to allow larger SGA with overall memory
    consumption reduction

27
Oracle Performance Study SwingBench
  • TPC-like Transaction Processing Benchmark
  • Order-entry benchmark order product processing
  • Java client generator with Oracle back-end

28
SwingBench Configuration
  • Database
  • of Users 5,011,872
  • of Products 5,011,872
  • Db size 5.11GB
  • Test
  • Test duration 10 mins
  • of Users per run 30
  • Think time 0
  • New customer - 11
  • Browse products - 28
  • Order products - 28
  • Process orders - 5
  • Browse orders - 28
  • Oracle 11g (11.1.0)
  • RHEL4 x86_64
  • SGA 3GB
  • PGA 1GB
  • RHEL5 U1
  • 64 bit
  • 2.6.18-53.1.13.el5
  • Dell PowerEdge 2950
  • Mem 8GB
  • Two dual core) Intel(R) Xeon(R) CPU 5160 _at_
    3.00GHz processor 4GB cache
  • Storage CX 3-40 (30 disks)
  • ESX version 3.5 build 60217
  • Number of VMs 1
  • vCPU 4
  • Mem 6GB
  • vDisk 16GB
  • vNIC 1

29
Measuring the Performance of DB Virtualization
30
SwingBench Oracle Single DB Scaling
Oracle 10GR2 Swingbench Throughput (txns/sec)
Number of virtual CPUs in Database/Guest
31
Study The Oracle DVD-Store Benchmark
  • Simulate a large multi-tier application with
    Oracle as the back-end database
  • Simulates DVD store transactions
  • Java client tier
  • Oracle Database

Sun 16-core x4600 M2 VMware ESX 3.5 Oracle 10G
R2 RHEL4, Update 4, 64-bit
EMC CLARiiON CX-340 30 x 15k Spindles
32
Many Large Databases Scaling Out
  • What happens when we consolidate more than one
    large database per host?
  • Increase number of large databases and measure
    performance
  • Key criteria Throughput and Response Time
  • Scale DVD-Store Benchmark
  • From 1 to 7 Databases, each with their own VM
  • From 2 to 16 Physical CPU cores
  • From 32 to 256 GB of RAM

33
Large Database Consolidation Study
34
Oracle Performance (Response time)
35
Java on VI3
36
Java Workload Characteristics
  • CPU
  • Intensive threads not processes
  • Memory
  • Heavy
  • Network
  • Tends to be light
  • Storage
  • Tends to be light

37
Page Sharing Java
  • Common pages to OS
  • Common pages to JVM
  • Common application pagesonly where apps are
    identical?
  • Garbage collection
  • Fewer zero pages
  • Tends to fill up assigned memory
  • Configurable through JVM?

38
Page Sharing and Large Memory Pages
  • Beware of the combination of large pages and
    memory over-commitment
  • large pages are not shared
  • when sharing is needed, large pages are backed by
    normal pages (4K)
  • This is a repeat of earlier slide in Oracle
    sectionreconcile for final

39
VM Memory Over-commitment with Java
  • JVM is a VM within the OS
  • If balloon driver takes memory from JVM, access
    to JVM heap will force guest swapping
  • this is particularly bad with JVM heap access
    which tends to be randomno locality

40
Balloon and Swap Interaction
  • oom_killer

41
Java Config
  • Multiple JVMs known to outperform single large
    JVM
  • Requires app with a scale-out model
  • Scaling out VMs a better idea
  • DRS

42
Java Tuning
  • Understand
  • Objects created and put in Eden
  • After certain life, pushed to long-lived area
  • GC sweeps Eden aggressively and less so with
    long-lived area
  • So
  • Eden sizing impacts memory access
  • GC thread count increases raise memory access
    profile and virtual overhead
  • This is another reason for using our model of
    multiple VMs each with their own JVM

43
JRockit
  • BEA
  • OS-less
  • Optimal out-of-box

44
Common App Tuning
  • Linux kernel 2.6.22.16 (check)
  • RHEL
  • SUSE 250 Hz
  • Others

45
Performance Data
46
Java Scalability
  • Will Java scale to 16 cores?
  • If no, show graph.

47
SwingBench Oracle Single DB Scaling
Oracle 10GR2 Swingbench Throughput (txns/sec)
Number of virtual CPUs in Database/Guest
48
Large Database Consolidation Study
Scaling to 16 Cores, 256GB RAM!
49
Oracle Performance (Response time)
50
Storage Protocols Sequential Read Throughput
51
Storage Protocols Sequential Write Throughput
52
VMFS Performance VMFS versus RDM
Write a Comment
User Comments (0)
About PowerShow.com
