Liferay, Jira & Crowd Integration

1
Liferay, Jira Crowd Integration
Prepared By Attune Infocom Pvt
Ltd www.attuneinfocom.in contact_at_attuneinfocom.in
2
Liferay Installation
2

• Installation requirement for liferay 1GB RAM
• Download liferay distribution with various
  application server for now we will use liferay
  tomcat6
• Intsall java jdk and environment variable
  JAVA_HOME set to OS
• You can Download the desired bundle from
  http//www.liferay.com/web/guest/downloads/portal
  and unzip to particular folder
• Run Liferay by double-click on the startup.bat.
  Open a browser and go to http//localhost8080
• Liferay have sample data with it (7cogs) to demo
  application to remove this, delete seven-cog
  folder from liferay-dir/tomcat/web-apps/ in
  liferay-dir/data/ also delete hsql database
  folder
• Re-start your application using startup.bat
• Liferay can be configured to use many different
  databases. i.e. we will change the default
  database (Hypersonic) of the Liferay-Tomcat
  bundle to point to a MySQL database

3
Liferay Installation
3

• We are now using Liferay v5.2 unifies the
  configuration of the database in a single file
  for all application servers. As most other
  configuration options you can set this up in the
  portal - ext.properties file as follows (example
  for MySQL)
• jdbc.default.driverClassNamecom.mysql.jdbc.Driver
  jdbc.default.urljdbcmysql//localhost/lportal?u
  seUnicodetruecharacterEncodingUTF-8useFastDate
  Parsingfalse
• jdbc.default.username
• jdbc.default.password
• If you dont have existing portal-ext.pro file
  than manually create it and save it to -
  liferay-home\tomcat\webapps\ROOT\WEB-INF\class
  es
• Now you have to make sure that you have already
  created database like this - create database
  lportal character set utf8
• If you want configure extra setting than read
  full administration pdf from liferay.com and
  install appropriate libraries

4
Jira Installation
4

• Pre-requisite for Jira Installation
• Browsers if you have disabled Javascript in
  your browser or are using a script blocker like
  NoScript, you will need to enable Javascript for
  JIRA to get the full experience JIRA has to
  offer.
• Java - JIRA requires a Java Developers Kit
  (JDK) to be installed on the server and set java
  home variable JAVA_HOME
• Application Server tomcat 5 or 6 or any
  other server

5
Jira installation
5

• Jira available in two distributions
  standalone and ear/war
• We will install in war distribution and uses
  tomcat version 6
• First you download your application
  distribution from
  http//www.atlassian.com/software/jira/JIRADownloa
  dCenter.jspa and unzip JIRA, Ensure that you
  download the WAR/EAR version, not the Standalone
  version that is recommended on the Downloads page.

6
Jira Configuration for war distribution
6

• JIRA needs to be told what type of database
  you'll be using. The database is specified in
• JIRA_INSTALL/edit-webapp/WEB-INF/classes/entityen
  gine.xml
• Locate the ltdatasourcegt tag near the bottom, and
  change the field-type-name attribute value. See
  the relevantsetup guide for your database to find
  out what value should be used for
  field-type-name
• Also in entityengine.xml , ensure the
  lttransaction-factorygt...lt/transaction-factorygt
  tag contains

7
Jira Configuration for war distribution
7

• Specify the location of your JIRA Home
  Directory
• (note that you need to do this before you
  build JIRA)
• Edit the jira-application.properties file
• (see the JIRA Installation Directory page to
  find where this file is located), add a
  'jira.home' property and set it to your desired
  location for JIRA home directory. Please use
  forward-slashes ("/")
• Tomcat does not come with some libraries
  required to run JIRA. To fix this, download
  jira-jars-tomcat6.zip (1.5Mb), and copy the
  contained jars to Tomcat's lib/ directory.
• To prevent exceptions related to logging, please
  ensure that commons-logging-1.0.4.jar and
  log4j-1.2.15.jar are present in Tomcat's /lib/
  directory. Also ensure that these files are not
  present in Tomcat's webapps/jira/WEB-INF/lib
  directory.
• Additionally, if you are running Sun's
  distribution of Tomcat, download tomcat-dbcp.jar
  and copy it to the tomcat6/lib directory.

8
Jira Configuration for war distribution
8

• A JIRA 'context' now needs to be set up in
  Tomcat. To do this
• Make a Catalina/localhost/ directory in Tomcat's
  conf/ directory.
• Copy dist-tomcat/tomcat-6/jira.xml from the built
  JIRA distribution to your Tomcat's
  conf/Catalina/localhost/ directory.
• Customise the copied jira.xml as follows

9
Jira Integration with crowd
9

• Prerequisites
• To install crowd Refer to the Crowd
  installation guide for instructions. We will
  refer to the Crowd root folder as CROWD.
• To install JIRA (version 3.7.4 or later). Refer
  JIRA installation guide We will refer to the JIRA
  root folder as JIRA.
• Purposes of this document is, we will assume
  that you have used the 'Standalone' (i.e. the
  easier and recommended) installation method of
  JIRA. If you need to install JIRA as an EAR/WAR,
  simply explode the EAR/WAR and make the necessary
  changes as described below, then repackage the
  EAR/WAR.
• Run the JIRA Setup Wizard, as described in the
  JIRA documentation During this setup process, you
  will define the JIRA administrator's username and
  password. It is easier to do this before you
  integrate JIRA with Crowd.
• After setting up JIRA, shut down JIRA before you
  begin the integration process described below.

10
Jira Integration with crowd
10

• The JIRA application will need to locate users
  from a directory configured in Crowd. You will
  need to set up a directory in Crowd for JIRA.
  This directory may be any Crowd-configured
  directory, such as an LDAP directory hooked up to
  Crowd or a Crowd internal directory.
• JIRA also requires particular groups to exist
  in the directory in order to authenticate users.
  You need to ensure that these three groups exist
  in the JIRA Directory in Crowd
• jira-users
• jira-developers
• jira-administrators
• You also need to ensure that the JIRA
  Directory in Crowd contains at least one user who
  is a member of all three groups.
• Log in to the Crowd Administration Console and
  navigate to Applications gt Add Application.
• Complete the 'Add Application' wizard for the
  JIRA application. See the instructions. The Name
  and Password values you specify in the 'Add
  Application' wizard must match the application.
  name and application.password that you will set
  in the JIRA/atlassian-jira/WEB-INF/classes/crowd.p
  roperties file.

11
Jira Integration with crowd
11

• Once Crowd is aware of the JIRA application,
  Crowd needs to know which users can authenticate
  (log in) to JIRA via Crowd. As part of the 'Add
  Application' wizard, you will set up your
  directories and group authorizations for the
  application.

12
Jira Integration with crowd
12

• If you are using the Crowd WAR distribution,
  then you will need to get the CROWD client
  libraries from the standalone distribution,
  available on our download site.
• Copy the Crowd client libraries and configuration
  files to JIRA
• Copy From Copy To
• CROWD/client/crowd-integration-client-X.X.X.jar
  JIRA/atlassian-jira/WEB-INF/lib
  CROWD/client/conf/crowd.properties
  JIRA/atlassian-jira/WEB-INF/classes
• If you are using JIRA 3.11 or earlier, you
  will need to remove the seraph-0.7.12.jar file
  from JIRA's WEB-INF/lib/ directory and replace it
  with the following filehttp//repository.atlassi
  an.com/maven2/com/atlassian/seraph/atlassian-serap
  h/0.10/atlassian-seraph-0.10.jar
• If you are using JIRA 3.12.2 or earlier, you
  will need to update JIRA's xfire libraries
  Remove the xfire-all-1.2.1.jar file from JIRA's
  WEB-INF/lib/ directory. Copy the following two
  files from Crowd's client/lib/ directory to
  JIRA's WEB-INF/lib/ directory
• xfire-aegis-1.2.6.jar
• xfire-core-1.2.6.jar

13
Jira Integration with crowd
13

• Replace JIRA's cache configuration file Copy
  From CROWD/client/conf/crowd-ehcache.xml Replace
  File JIRA/atlassian-jira/WEB-INF/classes/crowd-eh
  cache.xml
• Edit JIRA/atlassian-jira/WEB-INF/classes/crowd.
  properties. Change the following properties
• application.name jira The application name
  must match the name that you specified when you
  defined the application in Crowd (see Step 1
  above).
• application.password -- The password must match
  the one that you specified when you defined the
  application in Crowd (see Step 1 above).
• crowd.server.url -- http//localhost8095/crowd/s
  ervices/ If your Crowd server's port is
  configured differently from the default (i.e.
  8095), set it accordingly.
• session.validationinterval -- Set to 0, if you
  want authentication checks to occur on each
  request. Otherwise set to the number of minutes
  between request to validate if the user is logged
  in or out of the Crowd SSO server. Setting this
  value to 1 or higher will increase the
  performance of Crowd's integration.

14
Jira Integration with crowd - Authenticator
14

• Edit the JIRA config file JIRA/atlassian-jira/W
  EB-INF/classes/osuser.xml. Comment out any
  existing authentication providers and
  uncomment/insert the Crowd providers

15
Jira Integration with crowd - Authenticator
15

• View JIRA/atlassian-jira/WEB-INF/classes/proper
  tyset.xml. If there is no entry for the
  CrowdPropertySet, add the following ltpropertysetgt
  item at the end of the file as the last
  ltpropertysetgt item
• ltpropertyset name"crowd" lass"com.atlassian.crow
  d.integration.osuser.CrowdPropertySet"/gt
• At this stage, JIRA is set up for centralised
  authentication. If you wish, you can now enable
  single sign-on (SSO) to JIRA.
• Skip this step if you are using the JIRA NTLM
  plugin to enable SSO. Instead, follow the
  instructions on configuring JIRA for NTLM SSO.
  Edit JIRA/atlassian-jira/WEB-INF/classes/seraph-c
  onfig.xml. Change the authenticator node to read
  ltauthenticator class"com.atlassian.crowd.integrat
  ion.seraph.JIRAAuthenticator"/gt
• JIRA's authentication and access request calls
  will now be performed using Seraph. Now when
  authentication or access request calls are
  performed versus the OS User framework, the JIRA
  stack will call the Crowd providers and property
  set implementations.

16
Crowd Installation
16

• Download Crowd. Please check your unzip
  program before extracting the downloaded archive
  see the note on the Crowd installation front
  page
• Unzip the download archive into a directory of
  your choice. Note Do not specify directory names
  that contain spaces. We'll refer to this
  installation directory as CROWD_INSTALL.
• Specify your Crowd Home directory by editing
  the configuration file at
  CROWD_INSTALL\crowd-webapp\WEB-INF\classes\crowd
  -init.properties.
• The Crowd Home directory is where Crowd will
  store its configuration information. If you are
  using the embedded HSQL database, supplied for
  evaluation purposes, Crowd will also store its
  database in this directory. To specify the
  directory
• Open the crowd-init.properties file.
• Choose the appropriate line in the file,
  depending upon your operating
• Remove the at the beginning of the line.
• Enter name of the directory you want Crowd to use
  as its Home directory.
• On Windows 1.crowd.homec/data/crowd-home

17
Crowd Installation
17

• Run the start-up script, found in your
  CROWD_INSTALL directory
• start_crowd.bat for Windows.
• start_crowd.sh for Mac and Unix-based systems.
• Point a web browser at http//localhost8095/crowd
  where you will see the Crowd Setup Wizard.
  Follow the instructions in the Wizard. You can
  also read more information about the Setup
  Wizard.
• Go to the following URL in your web browser
  http//localhost8095/crowd or http//localhost80
  95/crowd/console.
• If there are no errors, you should see the
  'License' screen described below.
• If there is an error in your configuration, you
  will see the 'Crowd Checklist' screen. Read more
  about troubleshooting your installation.

18
Crowd Installation
18

• Licensing
• Installation Type

19
Crowd Installation
19

• JDBC Connection

20
Crowd Installation
20

• Mail Server
• Notification Email Address The email address
  which will receive notifications about server
  events.
• From Email Address Crowd will add this email
  address as the 'sender' on the emails generated
  by Crowd and sent to users.
• Subject Prefix The prefix which will appear
  at the start of the email subject, for all emails
  generated by Crowd. This can be useful for email
  client programs that offer filtering rules.
• Mail Server Type Select the 'SMTP Server'
  radio button.
• SMTP Host The hostname of the SMTP mail
  server, e.g. 'localhost' or 'smtp.acme.com'.
• SMTP Port The port on which the SMTP mail
  server listens. The default is '25'.
• Username The username that your Crowd server
  will use when it logs in to your mail server.
• Password The password that your Crowd server
  will use when it logs in to your mail server.

21
Crowd Installation
21

• Administrator Setting

22
Thank you!
22
Contact Us For more information Attune
Infocom Pvt Ltd www.attuneinfocom.com contact_at_at
tuneinfocom.com Phone [phone] Cell
91-9737339652
