Cube 5 and Beyond

1
Cube 5 and Beyond
2
New Features in Cube 5
3
Major New Features of Cube Base
New Features in Cube 5

• Cube GIS Window
• Direct sharing of data between ESRI products and
  Cube
• Work environment is similar to ArcGIS
• Integrated ESRI spatial functions within the
  model work stream
• Full support of ESRI-supported data formats
  including Microsoft Virtual Earth
• On-the-fly projection
• Dynamic intersection displays
• Wizard for adding user programs
• Multiple model applier types

4
Cube GIS
New Features in Cube 5

• New map production tools
• Can support all native formats supported by ESRI
• Includes New Feature Explorer
• Imports / exports to and from GDB and Citilabs
  legacy formats
• Can incorporate Python scripts within model flow
• Data may also be stored in Citilabs legacy
  formats

5
Cube GIS
New Features in Cube 5

• Based on ArcObjects from ArcGIS Engine
• Provides enhanced GIS capabilities to Cube users
  at no additional cost
• Can take advantage of ArcGIS license and
  extensions already on your computer
• Stores data in geodatabase format
• 5.0- Personal geodatabase (MDB)
• 5.1- Enterprise geodatabase (SQL, Oracle )
• Provides geo-processing functions based on ESRI
  Technology

6
Cube GIS WindowNew Map Production Tools
New Features in Cube 5
Ink Pen Drawing Tools
Layout Navigation Tools
Layout Menu
New Data Frame Button
Focus Data Frame Control
7
Cube GIS Window High-Quality Mapping Using ESRI
MXD Files
Demonstration of Cube 5

• Map View
• Typical Working Environment
• Layout View
• Working Print Preview
• MXD Support
• Cube Creates
• Cube Writes
• Cube Reads

8
New Geodatabase Manager
Demonstration of Cube 5

• Provides Database Management Tools
• Creates Cube Geodatabase
• Provides Import/Export Capabilities
• Provides Scenario Management
• Allows Updates/Changes to Projections
• Provides Property Information about Cube Networks
• Allows Transit Networks to Sync with Other
  Infrastructure Networks
• Provides Database Compaction Tool

9
Cube GIS WindowHigh-quality Mapping Using ESRI
MXD Files
Demonstration of Cube 5
10
Cube GIS WindowNode/Point Chart Graphics
Demonstration of Cube 5
11
Cube GIS WindowHCM Level-of-Service Mapping
Demonstration of Cube 5
12
Cube GIS WindowFull ESRI Symbology Library
Demonstration of Cube 5
13
Cube GIS WindowDynamic Bandwidth, Colors..
Demonstration of Cube 5
Display keyed network attributes using
bandwidth and color
14
Cube GIS WindowDynamic Intersection Displays
Demonstration of Cube 5

• Display
• Queue
• Capacity
• Delay
• Volume by time period

15
New in Cube Base e-mail Model Status
Demonstration of Cube 5

• When running from Voyager, ask for an email to be
  sent when model run is completed along with
• status of the run
• any user-defined outputs
• Can also send a text message to phone in a
  similar fashion

16
New in Cube Base External Program Wizard
Demonstration of Cube 5

• Enables users to more easily add external
  programs to the Cube Base program menu
• Works with All Types of Programs

17
New in Cube Base Multiple Model Appliers
Demonstration of Cube 5

• Built to Work with Multi-User Web-based
  Environments
• Allows to set available keys (parameters, file
  options, etc) for several model user types along
  with separate passwords

18
Cube Land
Key technologies in the Labs

• Innovation in land use pricingvia
  auction/bidding theory
• Econometric-based model
• Integrates Cube Voyagers transport accessibility
  measures and ESRIs spatial mapping/analysis
  capabilities
• Works directly with zone-based land use
  information
• Forecasts land rent/prices to better evaluate
  development pressures

19
Major New Features of Cube Voyager
New Features of Cube Voyager

• Cube Voyager
• Geodatabase Read/Write
• PT select link
• PT mustusemode and bestpathonly for FTA New
  Starts Analysis
• Two extensions
• Cube Avenue extension to Cube Voyager providing
  mesoscopic dynamic traffic assignment
• Cube Cluster extension to Cube Base bringing
  distributed processing to Cube

20
PT User Benefits Analysis Features
New Features of Cube Voyager

• BESTPATHONLY
• Selects only path with least cost from enumerated
  routes
• Can be any mode
• MUSTUSEMODE
• Selects mode combinations from enumerated routes
• Can use a single mode, group of single modes or
  mode combination to evaluate
• Alternative methods available for headway
  calculation
• New controls for route enumeration and evaluation
  processes

21
Extension to Cube Voyager -- Cube Avenue
New Features of Cube Voyager

• Mesoscopic assignment (dynamic traffic
  assignment)
• representing vehicles as discrete packets or
  individual vehicles
• assigning a specific time of departure
• routing the vehicles along multiple paths in
  response to dynamic traffic conditions
• representing queues and bottlenecks including
  blocking back
• providing the ability to represent intersection
  geometrics and traffic control systems in detail.
• Region-wide, corridor-level
• Evacuation modeling, greater analysis of
  geometrics, traffic control and ITS strategies

22
Extension for Cube Voyager -- Cube Cluster
New Features of Cube Voyager

• Brings very large time reductions in model runs
• Provides 2 types of savings
• Multi take a three time period run and run the
  mode choice models on three PCs simultaneously
• Intra run one mode choice model over multiple
  PCs.
• Time savings can be substantial
• Take a 10 hour run model and put across 10 pcs.
  Reduced to 1 hour and 10 minutes
• Architecture 1 desktop license plus multiple,
  low cost node licenses

23
New Extension for Cube Voyager Cube Cluster
New Features of Cube Voyager
24
Key Technologies in the Labs
25
New traffic assignment methods

• Most packages use link-based Frank-Wolf
• requires less memory and relatively easy to
  implement
• but may experience low convergence speed at the
  vicinity of the equilibrium solution.
• New methods
• Conjugate and Bi-Conjugate Frank Wolf
  Path-based
• more complex and need much more memory
• but converges faster to higher accuracy levels.
• Gradient Projection Algorithm
• Origin Based should be more accurate
• Higher speeds than path based methods.
• Limitation of not being able to efficiently
  handle networks with turn penalties/prohibitions.
• .

26
New traffic assignment methods
27
New traffic assignment methods

• We are actively working with our customers,
  David Boyce, and other researchers to explore and
  test the OBA, Algorithm B, and TAPAS
  methodologies.
• Stochastic Methods although a popular
  alternative methodology in uncongested networks
  for customers using TRIPS and Tranplan, a new
  stochastic methodology is being built for Voyager
  5.1.
• Route Choice As an advance from the basic
  stochastic methods, we are building discrete
  route choice algorithms giving users the freedom
  of using any variables in their custom utility
  functions.

28
Key technologies in the Labs
29
Mint web-based modeling
30
Demonstration of Sugar Network Editor and Mint
