Executive Summary 95 and98 Bond Construction Program

1
Next Generation Middle School Prototype Hardy
Oak Site Electric Easement Alignment 2003 Bond
Program
Garrett J. Sullivan, Executive DirectorConstructi
on Management Engineering Department
July 11, 2005
2
Hardy Oak MS Electric Utility Easement

• Six Options for the Hardy Oak MS Electric Utility
  Service Easement have been formulated for
  consideration after meeting with both HOAs.
• Option 1 No Change to Current Electric Utility
  Service Plan
• Cost 0.00
• Option 2 Relocate Utility Poles (12 ft) Along
  Remington Heights
• Cost 12,000
• Option 3 Provide Underground Service Along
  Remington Heights
• Cost 40,975
• Option 4 Provide Overhead Service from Mesa
  Vista (South)
• Cost 25,500
• Option 5 Provide Overhead Service from Mesa
  Vista (North)
• Cost 17,500
• Option 6 Provide Underground Service from Mesa
  Vista
• Cost 35,955

3
General Notes

• Note 1 Two of Six Utility Poles currently set
  along Remington Heights/NEISD
  Boundary are Temporary Only
• Note 2 One Utility Pole will be required along
  Mesa Vista however, per
  discussion with CPS, Pole 50-B (45 ft high)
  can be replaced with a 50 ft pole with
  no additional utility poles added
  along Mesa Vista/NEISD Utility Easement
• Note 3 Current construction contract includes
  150 ft of underground electric
  utility service it can realigned in any
  direction from transformer
• Note 4 Underground trenching costs estimated at
  61.50 / linear foot
• Note 5 Clearing, Tree Trimming and removal
  costs are construction estimates
  CPS will direct final clearing based on
  alignment selected
• Note 6 NEISD will grant CPS Easement based on
  Option Selected

4
CPS Note on All 3 PlatsMesa Vista / Remington
Heights / NEISD

• The City of San Antonio as part of its electric
  and gas system (City
• Public Service Board) is hereby dedicated the
  easements and
• rights-of-way for electric and gas distribution
  and service facilities
• in the area designated on this plat as "Electric
  Easement," "Gas
• Easement," "Anchor Easement," "Service Easement,"
  "Overhang Easement,"
• "Utility Easement," and "Transformer Easement,"
  for the purpose of
• installing, constructing, reconstructing,
  maintaining, removing,
• inspecting, patrolling and ERECTING POLES,
  hanging or burying wires,
• cables, conduits, pipelines or transformers, each
  with its necessary
• appurtenances together with the right of ingress
  and egress over
• grantor's adjacent land, the right to relocate
  said facilities within
• said easement and right-of-way areas, and the
  right to remove from said
• lands all trees or parts thereof, or other
  obstructions which endanger
• or may interfere with the efficiency of said
  lines or appurtenances
• thereto. It is agreed and understood that no
  buildings, concrete slabs,
• or walls will be placed within said easement
  area.

5
Hardy Oak MS Electric Easement Alignment
Remington Heights Subdivision
Mesa Vista Subdivision
6
Hardy Oak MS Electric Easement Alignment
Current Conditions
Remington Heights Subdivision
Mesa Vista Subdivision
7
(No Transcript)
8
Hardy Oak MS Electric Easement AlignmentNo
Change to Current Electric Utility Service Plan
OPTION 1
Cost 0.00
9
Hardy Oak MS Electric Easement
AlignmentRelocate Utility Poles (12 ft) Along
Remington Heights
OPTION 2
Cost 12,000
10
Hardy Oak MS Electric Easement
AlignmentProvide Underground Service Along
Remington Heights
OPTION 3
Cost 40,975
11
Hardy Oak MS Electric Easement
AlignmentProvide Overhead Service from Mesa
Vista (South)
Possible CPS Tree Clearing ( 13 ft Wide) Along
NEISD Electric Easement
OPTION 4
Cost 25,500
Mandatory CPS Tree Clearing ( 13 ft Wide) Along
NEISD Electric Easement
12
Hardy Oak MS Electric Easement
AlignmentProvide Overhead Service from Mesa
Vista (North)
Possible CPS Tree Clearing ( 13 ft Wide) Along
NEISD Electric Easement
OPTION 5
Cost 17,500
Mandatory CPS Tree Clearing ( 13 ft Wide) Along
NEISD Electric Easement
13
Hardy Oak MS Electric Easement
AlignmentProvide Underground Service from Mesa
Vista
Possible CPS Tree Clearing ( 13 ft Wide) Along
NEISD Electric Easement
OPTION 6
Cost 35,955
Mandatory CPS Tree Clearing ( 13 ft Wide) Along
NEISD Electric Easement
14
Summary Presentation Hardy Oak Middle School
Electric Utility Easement
Questions?
15
Hardy Oak MS Electric Easement
AlignmentRelocate Utility Poles (12 ft) Along
Remington Heights
OPTION 2A
Cost 16,000
