SIMPLE NETWORK MANAGEMENT PROTOCOL (SNMP)

1
SIMPLE NETWORK MANAGEMENT PROTOCOL(SNMP)

• VIJAY CHAND UYYURU
•
  VENKAT KANCHERLA
•
  PRATEEK ARORA

2
What is network management?

• Network management includes deployment,
  integration, and coordination of the hardware,
  software, and human elements
• to monitor, test, poll, configure, analyze, and
  control the network and element resources to meet
  the real-time , operational performance, and
  quality of service requirements at a reasonable
  cost.

3
Five areas of network management

• Performance management to quantify, measure,
  report, analyze and control the performance of
  network components.
• Fault management to log, detect, and respond to
  fault conditions in the network.
• Configuration management allows a network
  manager to track which devices are on the managed
  network and the hardware and software
  configurations of these devices.
• Accounting management allows the network
  manager to specify, log, and control user and
  devices access to network resources.
• Security management to control access to
  network resources according to some well defined
  policy.

4
Protocols for Network management

• CMISE/CMIP (the Common Management Information
  Services Element/Common Management Information
  Protocol )
• SNMP (Simple Network Management Protocol)
• Disadvantages of CMIP over SNMP
• the CMIP protocol takes more system resources
  than SNMP by a factor of ten
• CMIP is large and complete management system that
  only the best equipped networks can afford to run
  it.
• advantage of SNMP over CMIP is that its design is
  simple
• Disadvantages of SNMP
• Because it is so simple, the information it deals
  with is neither detailed, nor well organized
  enough to deal with the growing networks
  (corrected in later versions).

5
Evolution of SNMP

• In early days of the ARPANET, they used ping to
  detect the problem.
• When ARPANET turned into WWW, better tools to
  network management are needed.
• SNMP provided a systematic way of monitoring and
  managing a computer network.
• Three versions in SNMP
• SNMPv1 The initial implementation of
  the SNMP protocol, which is described in RFC 1098
  and RFC 1157
• SNMPv2 An improved version of SNMPv1
  that includes additional protocol operations for
  the SNMPv2 Structure of Management Information
  (SMI) (RFC 1441-1452)
• SNMPv3 SNMPv3 has yet to be
  standardized

6
What is SNMP?

• The Simple Network Management Protocol (SNMP) is
  an application-layer protocol that facilitates
  the exchange of management information between a
  network management system (NMS), agents, and
  managed devices. SNMP uses the Transmission
  Control Protocol/Internet Protocol (TCP/IP)
  protocol suite.
• SNMP is a part of Internet network Architecture
• SNMP enables network administrators to manage
  network performance, find and solve network
  problems, and plan for network growth.

7
Purpose of SNMP

• Although the original purpose of SNMP was to let
  network administrators remotely manage an
  Internet system, the design of SNMP lets network
  administrators manage applications as well as
  systems.
• Lets you manage and monitor all network
  components from one console

8
Network management architecture
9
Components of a managed network

• Managed nodes
• Agent
• Management stations
• Management Information Base (MIB)
• A management protocol

10
Management stations

• General-purpose computers running special
  software
• The management station contain one or more
  processes that communicate with agents over the
  network, issuing commands and getting responses
• An NMS (network management station) executes
  applications that monitor and control managed
  devices.
• It controls the collection, processing, analysis,
  and display of network management information
• NMSs provide the bulk of the processing and
  memory resources required for network management.

11
Managed device

• A managed device is a network node that contains
  an SNMP agent and that resides on a managed
  network
• Managed devices collect and store management
  information and make this information available
  to NMSs using SNMP
• A managed device might be a host, router, bridge,
  hub, printer, or modem.

12
Agent

• a network-management software module that resides
  in a managed device that communicates with
  management stations.
• An agent has local knowledge of management
  information and translates that information into
  a form compatible with SNMP.

13
SNMP Management information base

• Each device maintains one or more variables that
  describes its state. These variables are called
  objects.
• The collection of all objects in a network is
  given in a datastructure called MIB (management
  information base)
• MIBs are accessed using a network-management
  protocol such as SNMP and identified by object
  identifiers.
• The MIB hierarchy can be depicted as a tree with
  a nameless root, the levels of which are assigned
  by different organizations.
• When an SNMP manger requests information from an
  SNMP agent, the SNMP agent retrieves the current
  value of the requested information from the
  Management Information Base (MIB).

14
Network management protocol

• The protocol runs between the managing entity and
  managed device.
• Allows managing entity to query the status of
  managed device
• Agents use it to inform the managing entity of
  exceptional events.
• Data are sent using the ASN.1(abstract syntax
  notation one) transfer syntax.
• The structure of management information, SMI, is
  the language used to define the management
  information residing in a managed-network entity.
  SMI is used to ensure that the syntax and
  semantics of the network management data are well
  defined.

15
Windows Server 2003 SNMP Components at Each
TCP/IP Layer
16
Windows Server 2003 SNMP Components
Component Name Associated Programs Component Type Description
Microsoft SNMP Service Snmp.exe Agent Receives SNMP requests and delivers them to the appropriate SNMP subagent DLL for processing. The service is also responsible for intercepting events (traps) from the SNMP subagents and forwarding trap messages to the appropriate management systems.
SNMP Subagents Inetmib1.dll, Hostmib.dll, Lmmib2.dll, and others Agent Provides a set of entry points. When an SNMP request is received, the SNMP service delivers it to the appropriate subagent by calling one of these entry points. After the subagent processes the message, it passes the information back to the SNMP service, which then forwards the message to the SNMP manager.
SNMP Utility API Snmpapi.dll Both Agent and Manager Provides utilities that the SNMP service uses for memory management operations, address-decoding routines, object identifier handling routines, and so forth. Provides a set of routines that SNMP subagents use to handle and order SNMP objects. Although use of the Snmpapi.dll is not required, the framework defined by this tool greatly facilitates the development of new SNMP subagents.
SNMP Trap Service Snmptrap.exe Manager Uses the WinSNMP API to forward a trap message sent by an SNMP agent to the appropriate SNMP manager application

17
Windows Server 2003 SNMP Components
Component Name Associated Programs Component Type Description
WinSNMP API -and- Management API Wsnmp32.dll -and- Mgmtapi.dll Manager Helps develop SNMP management software applications The WinSNMP API provides a set of functions for encoding, decoding, sending, and receiving SNMP messages .The Management API is a simple API that resides on top of the WinSNMP and SNMP Utility APIs. It provides a limited set of functions that you can use to develop basic SNMP management applications quickly.
SNMP Manager Application Snmputil.exe Manager Provides a basic command-line utility with which to retrieve information from any SNMP agent in your network. This example of a management application was developed using the Management API.
18
SNMP Protocol Basics

• SNMP does not manage the network by itself but
  instead provides a tool for the manager to manage
  the corresponding devices.
• The preferred transport protocol for carrying
  SNMP messages is UDP and the preferred port
  number for the SNMP is port 161. Port 162 is used
  for trap messages.

19
SNMP Management Systems and Agents

• SNMP manager An SNMP manager, also known as an
  SNMP management system or a management console,
  is any computer that sends queries for IP-related
  information to a managed computer, known as an
  SNMP agent.
• SNMP agent An SNMP agent is any computer or
  other network device that monitors and responds
  to queries from SNMP manager.
• The SNMP manager displays the information it
  receives.
• The SNMP agent does not display the information
  that it sends to an SNMP manager.

20
SNMP Community

• To enable SNMP communications between an SNMP
  manager and SNMP agents, we configure the SNMP
  manager and the SNMP agents that it manages as
  members of an SNMP community. The community name
  functions like a password to authenticate
  communications between the SNMP manager and
  agent.
• The SNMP community is an SNMP-defined group.

21
SNMP Community

• A community name acts as a password that is
  shared, typically by multiple SNMP agents and one
  or more SNMP managers. We configure the SNMP
  manager and the computers or devices that it
  manages as members of a single SNMP community.
• An SNMP agent only accepts requests from SNMP
  managers that are on the agents list of
  acceptable community names.

22
Understanding the Management Information Base
(MIB)

• When an SNMP manager requests information from an
  SNMP agent, the SNMP agent retrieves the current
  value of the requested information from the
  Management Information Base (MIB).
• The MIB defines the managed objects that an SNMP
  manager monitors on an SNMP agent.
• Each system in a network maintains a MIB that
  reflects the status of the managed resources on
  that system, such as the version of the software,
  amount of free hard drive space etc.

23
Manager Requesting number of Sessions from an
SNMP Agent
24
Manager Requesting number of Sessions from an
SNMP Agent

1. The SNMP manager, Host A, forms an SNMP message
   that contains an information request(Get) for the
   number of active sessions, the name of the
   community to which the SNMP manager belongs, and
   the destination of the message the IP address
   of the SNMP agent, Host B.
2. The SNMP manager sends the information request to
   Host B by using the SNMP service libraries.

25
Manager Requesting number of Sessions from an
SNMP Agent

1. When Host B receives the message, it verifies
   that the community name contained in the packet
   is on its list of acceptable community names,
   evaluates the request against the agents list of
   access permissions for that community, and
   verifies the source IP address. If the
   information is incorrect then the agent sends a
   trap message authentication failure to the
   specified trap destination, Host C.
2. The master agent component of the SNMP agent
   calls the appropriate extension agent to retrieve
   the requested session information from the MIB.

26
Manager Requesting number of Sessions from an
SNMP Agent

1. Using the session information that it retrieved
   from the extension agent, the SNMP service forms
   a return SNMP message that contains the number of
   active sessions and the destination the IP
   address of the SNMP manager, Host A.
2. Host B sends the response to Host A.

27
Information Types

• An SNMP manager can request the following types
  of information from the SNMP agents that it
  monitors
• Network protocol identification and statistics.
• Dynamic identification of devices attached to the
  network.
• Hardware and software configuration data.
• Device error and event messages.
• Program and application usage statistics.

28
SNMP Messages

• SNMP sends operation requests and responses as
  SNMP messages. An SNMP message consists of an
  SNMP protocol data unit (PDU) plus additional
  message header elements defined by the relevant
  RFC.
• An SNMP agent sends information in two
  situations
• When it responds to a request from an SNMP
  manager and
• When a trap event occurs.

29
SNMP Message Types

• Get Accesses and retrieves the current value of
  one or more MIB objects on an SNMP agent.
• GetResponse Replies to a Get, GetNext, or Set
  operation.
• GetNext Obtains the information from selected
  columns from one or more rows of a table.
• GetBulk Accesses multiple values at one time
  without using GetNext message.
• Set Changes the current value of an MIB object.
• Trap Notifies the SNMP manager when an
  unexpected event occurs locally on the managed
  host.
• All the above messages except Trap and
  GetResponse are from Manager to Host.

30
SNMP Message Types
31
Message Sent Between an SNMP Manager and its
Managed Devices
32
SNMP Basic Message Format
33
SNMP Message Header

• SNMPv2 message headers contain two fields
  Version Number and Community Name. The following
  descriptions summarize these fields
• Version numberSpecifies the version
  of SNMP that is being used.
• Community nameDefines an access
  environment for a group of NMSs. NMSs within the
  community are said to exist within the same
  administrative domain. Community names serve as a
  weak form of authentication because devices that
  do not know the proper community name are
  precluded from SNMP operations.

34
PDU Formats

• Get, GetNext, Response, Set, and Trap PDUs
  Contain the Same Fields.

35
SNMP Protocol Data Unit (PDU)

• The following descriptions summarize the fields
  illustrated in Figure
• PDU typeIdentifies the type of PDU transmitted
  (Get, GetNext, Inform, Response, Set, or Trap).
• Request IDAssociates SNMP requests with
  responses.

36
SNMP Protocol Data Unit (PDU)

• Error statusIndicates one of a number of errors
  and error types. Only the response operation sets
  this field. Other operations set this field to
  zero.
• Error indexAssociates an error with a particular
  object instance. Only the response operation sets
  this field. Other operations set this field to
  zero.
• Variable bindingsServes as the data field of the
  SNMPv2 PDU. Each variable binding associates a
  particular object instance with its current value
  (with the exception of Get and GetNext requests,
  for which the value is ignored).

37
SNMP Applications

• Command generator The command generator
  generates the GetRequest, GetNextRequest,
  GetBulkRequest, and SetRequest PDUs and handles
  the received responses to these PDUs.
• The command responder executes in an agent and
  receives, processes, and replies to received
  GetRequest, GetNextRequest, GetBulkRequest, and
  SetRequest PDUs.

38
SNMP Applications

• Notification originator The notification
  originator application in an agent generates Trap
  PDUs these PDUs are eventually received and
  processed in a notification receiver application
  at a managing entity.
• Proxy forwarder The proxy forwarder application
  forwards request, notification, and response PDUs.

39
SNMP Vulnerability and Security
40
WHAT ARE THE THREATS?

• Modification of Information
• The modification threat is the danger that some
  unauthorized entity may alter in-transit SNMP
  messages generated on behalf of an authorized
  principal in such a way as to effect unauthorized
  management operations, including falsifying the
  value of an object.

41
WHAT ARE THE THREATS? (contd.)

• Masquerade
• The masquerade threat is the danger that
  management operations not authorized for some
  user may be attempted by assuming the identity of
  another user that has the appropriate
  authorizations.

42
WHAT ARE THE THREATS? (contd.)

• Disclosure
• The disclosure threat is the danger of
  eavesdropping on the exchanges between managed
  agents and a management station. Protecting
  against this threat may be required as a matter
  of local policy.

43
WHAT ARE THE THREATS? (contd.)

• Message Stream Modification
• The SNMP protocol is typically based upon a
  connection-less transport service which may
  operate over any sub-network service. The
  re-ordering, delay or replay of messages can and
  does occur through the natural operation of many
  such sub-network services.
• The message stream modification threat is the
  danger that messages may altered, in order to
  effect unauthorized management operations.

44
WHAT IS NOT A THREAT?

• Denial of Service
• The current SNMP security model does not attempt
  to address the broad range of attacks by which
  service on behalf of authorized users is denied.
• Indeed, such denial-of-service attacks are in
  many cases in distinguishable from the type of
  network failures with which any viable network
  management protocol must cope up with.

45
WHAT IS NOT A THREAT? (contd.)

• Traffic Analysis
• The current SNMP security model does not attempt
  to address traffic analysis attacks. Indeed, many
  traffic patterns are predictable devices may be
  managed on a regular basis by a relatively small
  number of management applications and therefore
  there is no significant advantage afforded by
  protecting against traffic analysis.

46
GOALS AND CONSTRAINTS

• Based on the foregoing account of threats in the
  SNMP network management environment, the goals of
  a SNMP security model are as follows
• Provide for verification that each received SNMP
  message has not been modified during its
  transmission through the network.
• Provide for verification of the identity of the
  user on whose behalf a received SNMP message
  claims to have been generated.

47
GOALS AND CONSTRAINTS (contd.)

• Provide for detection of received SNMP messages,
  which request or contain management information,
  whose time of generation was not recent.
• Provide, when necessary, that the contents of
  each received SNMP message are protected from
  disclosure.

48
SECURITY SERVICES

• Data Integrity is provision of the property that
  data or data sequences has not been altered or
  destroyed in an unauthorized manner.
• Data Origin Authentication is the provision of
  the property that the claimed identity of the
  user on whose behalf received data was originated
  is corroborated.

49
SECURITY SERVICES (contd.)

• Data Confidentiality is the provision of the
  property that information is not made available
  or disclosed to unauthorized individuals,
  entities, entities, or processes.
• Message timeliness and limited replay protection
  is the provision of the property that a message
  whose generation time is outside of a specified
  time window is not accepted.

50
VULNERABILITY

• Following are some of the SNMP vulnerabilities
  with reference to CERT database.
• Vulnerability Note VU4923 The Microsoft SNMP
  agent, prior to Windows NT 4.0 Service Pack 4.0,
  will leak memory. An intruder can craft a
  malicious SNMP packet and consume memory on a
  victim host. Solution is to upgrade to Windows NT
  service pack 4 or later.
• Vulnerability Note VU173910 A vulnerability
  exists in multiple Symantec security appliances
  that could allow a remote attacker to modify the
  configuration of the device using SNMP. Solution
  according to the Symantec Advisory is to update
  the firmware from Symantec enterprise website.

51
VULNERABILITY (contd.)

• Vulnerability Note VU835846 Ethereal contains a
  vulnerability in the way it processes that fails
  to properly handle malformed SNMP packets.
  Solution is to either upgrade to version 0.10.5
  or later, or to disable SNMP protocol dissector.
• Vulnerability Note VU329230 A vulnerability
  exists in multiple Symantec security appliances
  that could allow a remote attacker to bypass the
  firewall using a source port of 53/udp. Solution
  according to the Symantec Advisory, is to upgrade
  the product specific firmware and hot fixes are
  available via the Symantec Enterprise Support
  site.

52
Review questions

1. What are the five areas of network management and
   explain them?
2. What is the purpose of SNMP?
3. What are the components in network management
   architecture and define them?
4. What are the types of messages between SNMP
   manager and agent?
