Earth System Modelling the NDG

• Bryan Lawrence
• (Kerstin Kleese, Roy Lowry, Kevin ONeill, Andrew
  Woolf others)
• NCAS/British Atmospheric Data Centre
• Rutherford Appleton Laboratory, CCLRC

2
NDG Partners

• As funded a partnership between
• British Atmospheric Data Centre (BADC, PI Bryan
  Lawrence)
• British Oceanographic Data Centre (BODC, Co-I
  Roy Lowry)
• CLRC E-science Centre (Co-I Kerstin Kleese)
• PCMDI at LNL in the US (Dean Williams, Bob Drach,
  Mike Fiorino)
• Project has caught the imagination, extra funding
  now supports
• A number of groups at the NERC Centre for Ecology
  and Hydrology
• (CEH Ecology DataGrid)
• NERC Earth Observation Data Centre Plymouth
  Marine Lab Remote Sensing
• Not directly funded major collaborators will
  include
• ClimatePrediction.net, GODIVA (NERC e-science
  projects)
• NCAS/CGAM The Centre for Global Atmospheric
  Modelling at the University of Reading (via Lois
  Stenman-Clark and Katherine Bouton)
• Project will support HIGEM

3
Outline

• Motivation
• The NDG Goals
• NDG Metadata
• Networks
• Summary

4
British Atmospheric Data Centre
The Role Key words Curation and Facilitation!
5
Easily catalogued, but successful preservation?
Phaistos Disk, 1700BC
One could argue that the writers of these
documents did a brilliant job of preserving the
bits-and-bytes of their time And yes theyve
both been translated many times, its a shame
the meanings are different
6
NERC Metadata Gateway - SST

• No clean handover from discovery to browse and
  use!
• Geospatial coordinates forgotten. Time reference
  forgotten. Need to get entire field(s), and find
  correct time!
• And if I want to compare data from different
  locations?
• - multiple logins
• - multiple formats
• - discovery?

7
How good is our metadata?

• A priori would any user know to look in the
  COAPEC data set?
• Earth system-science means we have to remove
  these boundaries!
• detailed file level metadata isnt visible, and
  so data mining applications impossible.

NB Dynamic catalogues!
8
Finding Data
The Goal Very simple interface, hide the complex
software!
9
A newer dataset
The extreme relevance of this example from Amazon
was pointed out by Jon Callahan (LAS project,
PMEL)!
10
PCMDI Best practice!
Final references are papers!
Is the information coupled to the datasets? What
if I take a dataset home, and another, and
another and then forget which is which?
(if you know where to look)
Can I ask the question what datasets used the
Semtner sea ice parameterisation?
11
Huge variety of Data Sets
12
Different types of data returned Wallingford
Supporting very diverse user community NetCDF is
not enough
13
Modelling advances Baseline Numbers

• T42 CCSM (current, 280km)
• 7.5GB/yr, 100 years -gt .75TB
• T85 CCSM (140km)
• 29GB/yr, 100 years -gt 2.9TB
• T170 CCSM (70km)
• 110GB/yr, 100 years -gt 11TB

14
Capacity-related Improvements
Increased turnaround, model development, ensemble
of runs Increase by a factor of 10, linear
data

• Current T42 CCSM
• 7.5GB/yr, 100 years -gt .75TB 10 7.5TB

15
Capability-related Improvements
Spatial Resolution T42 -gt T85 -gt T170 Increase
by factor of 10-20, linear data Temporal
Resolution Study diurnal cycle, 3 hour
data Increase by factor of 4, linear data
CCM3 at T170 (70km)
16
Capability-related Improvements
Quality Improved boundary layer, clouds,
convection, ocean physics, land model, river
runoff, sea ice Increase by another factor of
2-3, data flat Scope Atmospheric chemistry
(sulfates, ozone), biogeochemistry (carbon
cycle, ecosystem dynamics), middle Atmosphere
Model Increase by another factor of 10, linear
data
17
Model Improvement Wishlist
Grand Total Increase compute by a Factor
O(1000-10000)
18
Climate in 20010 A graphic Illustration
Figures from Gary Strand, NCAR, ESG website
19
Summary thus far

• Contentions
• The average atmospheric scientific project
  involves about 1/3 of the time data handling!
  (Getting, reformatting etc).
• The problem for earth system model projects is
  about to get worse for everyone, from the
  initiator, to the archiver, to the analyst, to
  the contributor, to the improver.
• (Remember the documentation problem is growing
  exponentially too new sub-components etc)

20
The NERC DataGrid
21
(No Transcript)
22
The Data Use Chain
23
Requirements Information (1)
Scientist are are real people too Jon Callahan
(from the LAS project at PMEL)

• Amazon Discovery gives good examples
• Browse
• Similar datasets
• Details
• Content examples

• Our domain Issues
• require
• Dealing with Volume
• Formats
• Providing Tools

Learn from the library and book handling
community!
All require documentation (aka metadata) We
need to improve our information handling
24
NDG Metadata Taxonomy
25
What is metadata?
The answer depends on who you are!
26
NDG A and B metadata in practice

• Clear separation of function between use and
  discovery.
• Standards Compliant
• Avoid tie-in to details of particular fields or
  data formats or even components
• Metadata model (B)
• Intermediate schema, supports multiple
  discovery formats
• NDG Data Model (A).
• provides an abstract semantic model for the
  structure of data within NDG,
• enables the specification of concrete instances
  for use by NDG Data Services

27
(B) Metadata Model

28
(B) Metadata Model an NDG Intermediate Schema,
Conceptual Overview
29
NDG Discovery Service Element
Traditional and Grid Service (GT3) Interfaces
30
NDG Semantic Data Model (A)
31
NDG Prototype
Layout not important (yet!) Its whats under the
hood that counts ( the data is NOT in NetCDF.
The original data is available the search
covered data that could have been harvested
the architecture works!)
32
NDG Metadata Status

• We have built a SIMPLE prototype based primarily
  on our data model and used our structures to
  find, locate, reformat and deliver data typical
  of BODC and BADC observational data. (This is a
  first)
• We are about to re-engineer.
• Key issues to address will be
• Vocabularies, and
• Ontologies
• Developing a Model Attribute Language (with CGAM,
  PRISM, PCMDI and others).
• Populating our metadata a boring and laborious
  job!

33
Metadata Origins
Consider a hierarchy of data users beginning with
an individual scientist,
who may herself be part of a research group,

itself part of a community
sharing resources, lying in the wider internet
To be well integrated the metadata should have a
role at each level!
(The data portal client and server interface may
be different at each level).
At each level extra metadata will be required,
probably produced by dedicated staff at the
research group, or data centre.
34
Requirements (2)

• We need to think about our networks and our tools
  for moving and keeping track of data!
• We cant rely on the leave it at the
  supercomputer site
• How do we do joint analysis?
• How do we process the data at all?
• Malcolm Atkinson quoting Jim Gray pointed out
  that it takes
• o(minute) to grep or ftp a GB
• o(2 days) to grep or ftp a TB
• o(3 years) to grep or ftp a PB
• Requires
• sophisticated fire and forget file transfer
  (that has to out perform sneaker net).
• Disk and compute resources for processing.

35
SuperJanet4

• We need to address
• local firewall issues (not just at the Met
  Office)
• spur bandwidths. The limits are not in the
  backbones!

• 2 Mbit/s link
• 80 minutes to transfer 500 MB cf 40 minutes with
  GridFTP, or less than 1 minute between DL and RAL
  (1 Gbit/s)

36
ESG1 Results (Supercomputing, 2001)
Dallas to Chicago
Allcock et al. 2001
37
Starting with the LAS
Deployment for UK users within a few weeks
(constraint is primarily access control)
38
LAS Simple Box fill Output
Work for us to do Labelling is inadequate as yet
..
39
Cache management in LAS/CDAT
Cache also checks if enough room, deletes oldest
files if necessary and checks against disk space
limit.
40
Summary

• Earth System Modelling extends the data handling
  challenge.
• We need better information management
• We need better tools for moving things around
• We need better tools for using remote data
• and we need data manipulation hardware!
• The NDG is attempting (with help) to address
• Information management
• Data movement
• Tools to manipulate large volumes of data.
