Sparse Normalized Local Alignment Nadav Efraty Gad M' Landau

1
Sparse Normalized Local AlignmentNadav
EfratyGad M. Landau
2
Goal

• To find the substrings, X and Y, whose
  normalized alignment value
• LCS(X,Y)/(XY)
• is the highest,
• Or higher than a predefined similarity level.

3

• Introduction
• The O(rLloglogn) normalized local LCS algorithm
• The O(rMloglogn) normalized local LCS algorithm
• Conclusions and open problems

4
Introduction
5
Background - Global similarity

• LCS-.
• computing a dynamic programming
• table of size (n1)x(m1)
• T(i,0)T(0,j)0
• for all i,j (1 i m 1 j n)
• if XjYi then T(i,j)T(i-1,j-1)1,
• else, T(i,j)maxT(i-1,j) , T(i,j-1)

6
Background - Global similarity
The naive LCS algorithm
XjYi T(i,j)T(i-1,j-1)1
Xj?Yi T(i,j)maxT(i,j-1),T(i-1,j)
7
Background - Global similarity
The typical staircase shape of the layers in the
matrix
8
Background - Global similarity

• Edit distance measures the minimal number of
  operations that are required to transform one
  string into another one.
• operations
• substitution
• Deletion
• insertion.

9
Background - Local similarity

• The Smith Waterman algorithm (1981)
• T(i,0)T(0,j)0 ,
• for all i,j (1 i m 1 j n)
• T(i,j)maxT(i-1,j-1) S(Yi,Xj) , T(i-1,j) D(Yi)
  , T(i,j-1) I(Xj) , 0

10
Background - Local similarity
The weaknesses of the Smith Waterman algorithm

• Mosaic effect - Lack of ability to discard poorly
  conserved intermediate segments.

• Shadow effect Short, but more biologically
  important alignments may not be detected because
  they are overlapped by longer (and less
  important) alignments.

• The sparsity of the essential data is not
  exploited.

11

• The solution Normalization
• The statistical significance of the local
• alignment depends on both its score and
• length. Instead of searching for an alignment
• that maximizes the score S(X,Y), search for
• the alignment that maximizes
• S(X,Y)/(XY).

12

• Arslan, Egecioglu, Pevzner (2001) uses a
  mathematical technique that allows convergence to
  the optimal alignment value through iterations of
  the Smith Waterman algorithm.
• SCORE(X,Y)/(XYL), where L is a
  constant that controls the amount of
  normalization.
• O(n2logn).

13
Our approach

• The degree of similarity is defined as
  LCS(X,Y)/(XY).
• M - a minimal length constraint.
• Similarity level.

14
The O(rLloglogn) normalized local LCS algorithm
15
Definitions

• A chain is a sequence of matches that is strictly
  increasing in both components.

• The length of a chain from match (i,j) to match
  (i,j) is i-ij-j, that is, the length of the
  substrings which create the chain.

• A k-chain(i,j) is the shortest chain of k
  matches starting from (i,j).

• The normalized value of k-chain(i,j) is k
  divided by its length.

16
The algorithm

• For each match (a,b), construct k-chain(a,b) for
  1kL (LLCS(X,Y)).
• Examine all the k-chains with kM, starting from
  each match, and report either
• The k-chains with the highest normalized value.
• k-chains whose normalized value exceed a
  predefined threshold.

17

• Problem k-chain(a,b) is not the prefix of
• (k1)-chain(a,b).

18
Solution (k1)-chain(a,b) (a,b)
is concatenated to a k-chain(i,j) below and to
the right of (a,b).
19
Question How can we find the proper match
(i,j) which is the head of the k-chain that
should be concatenated to (a,b) in order to
construct (k1)-chain(a,b) .
20

• Definitions
• Range- The range of a match (i,j) is
  (0i-1,0j-1).
• Mutual range- An area of the table which is
  overlapped by at least two ranges of distinct
  matches.
• Owner- (i,j) is the owner of the range where
  k-chain(i,j) is the suffix of (k1)-chain(a,b)
  for any match (a,b) in the range.
• L separated lists of ranges and their owners are
  maintained by the algorithm.

21

• If (a,b) is in the range of a single match
  (i,j) (it is not in a mutual range),
  k-chain(i,j) would be the suffix of
  (k1)-chain(a,b).
• If (x,y) is in the mutual range of two matches,
  how can we determined which of them should be
  concatenated to (a,b)?
• Lemma A mutual range of two matches is owned
  completely by one of them.

22

• Lemma A mutual range of two matches, p ((i,j))
  and q ((i,j)), is owned completely by one of
  them.
• Proof There are two distinct cases
• Case 1 ii and jj

X
0
J
n
J
0
Y
i
(i,j)
(i,j)
i
(i,j)
(i,j)
m
23
Case 2 ilti and jgtj The mutual range of p and
q is (0...i-1,0...j'-1). Entry (i-1,j'-1) is
the mutual point (MP) of p and q. p will be the
owner of the mutual range if Lp(j-j')
Lq(i'-i)
24
The algorithm

• Preprocessing.
• Process the matches row by row, from bottom up.
  For the matches of row i
• Stage 1 Construct k-chains 1kL for all the
  matches in the row i, using the L lists of ranges
  and owners.
• Stage 2 Update the lists of ranges and owners
  with the matches of row i and their k-chains.
• Examine the k-chains of all matches and report
  the ones with the highest normalized value.

25
Stage 2

• Let LROk be the list of ranges and owners that
  are the heads of k-chains.
• Insert each match (i,j) of row i which is the
  head of a k-chain to LROk.
• If there is already another match with column
  coordinate j, extract it from LROk.

Row 0
Row 0
Row i
Row i1
26
Stage 2 cont

• While for (i',j'), which is the left neighbor of
  (i,j) in LROk
• (length of k-chain(i,j)i'-i) (length of
  k-chain(i,j)j-j'),
• (i',j') should be extracted from LROk.

Row 0
Row i
27
Stage 1

• Constructing (k1)-chain(i,j) concatenating
  (i,j) to the match in LROk which is the owner of
  the range of (i,j).
• Record the value of (k1)-chain(i,j) with the
  match (i,j).

Row 0
Row i
28
Reporting the best alignments

• The best alignment is either the alignment with
  the highest normalized value or the alignments
  whose similarity exceed a predefined value.
• Check all the k-chains, kM, starting from each
  match and report the best alignments.

29
Complexity analysis

• Preprocessing- O(nlogSY)
• Stage 1-
• For each of the r matches we construct at most L
  k-chains.
• Using a Johnson Tree stage 1 is computed in
  O(rLloglogn) time.
• Stage 2- Each of the r matches is inserted and
  extracted at most once to each of the LROks.
  Total, O(rLloglogn) time.

30
Complexity analysis

• Reporting the best alignments is done in O(rL)
  time.
• Total time complexity of this algorithm is
  O(nlogSY rLloglogn).
• Space complexity is O(rLnL).

31
The O(rMloglogn) normalized local LCS algorithm
32
The O(rMloglogn) normalized local LCS algorithm

• Reoprts
• The normalized alignment value of the best
• possible local alignment. (value and
• substrings).

33
Computing the highest normalized value

• Definition A sub-chain of a k-Chain is a path
  that contains a
• sequence of x k consecutive matches of the
  k-Chain.
• Claim When a k-chain is split into a number of
  non
• overlapping consecutive sub-chains, the
  normalized value of
• a k-chain is smaller or equal than that of its
  best sub-chain.
• Result The normalized value of any k-chain (kM)
  is smaller or
• equal than the value of its best sub-chain with M
  to 2M-1
• matches.

34
Computing the highest normalized value

• A sub-chains of less than M matches may not be
  reported.
• Sub-chains of 2M matches or more, can be split
  into shorter sub-chains of M to 2M-1 matches.
• Is it sufficient to construct all the sub-chains
  of exactly M matches?

• No - Sub-chains of M1 to 2M-1 matches can not be
  split to sub-chains of M matches.

35
Computing the highest normalized value

• The algorithm For each match construct all the
  k-chains, for k2M-1.
• The algorithm constructs all these chains, that
  are, in fact, the sub-chains of all the longer
  k-chains.
• A longer chain can not be better than its best
  sub-chain.

• This algorithm is able to report the highest
  normalized value of a sub-chain (of at least M
  matches) which is equal to the highest normalized
  value of a chain of at least M matches.

36
Constructing the longest optimal alignment
Definition A perfect alignment is an alignment
of two identical strings. Its normalized value is
½ Unless the optimal alignment is perfect, the
longest optimal alignment has no more than 2M-1
matches.
37

• Constructing the longest optimal alignment

Assume there is a chain with more than
2M-1matches whose normalized value is the
optimal, denoted by LB.

• LB may be split to a number of sub-chains of M
  matches, followed by a single sub-chain of
  between M and 2M-1 matches.

• The normalized value of each such sub-chain must
  be equal to that of LB, otherwise, LB is not
  optimal.

• Each such sub-chain must start and end at a
  match, otherwise, the normalized value of the
  chain comprised of the same matches will be
  higher than that of LB.

38
Constructing the longest optimal alignment

• Note that if we concatenate two optimal
  sub-chains where the head of the second is next
  to the tail of the first the concatenated chain
  is optimal.

10/30
10/30
20/60

• when the head of the second is not next to the
  tail of the first, the concatenated chain is not
  optimal.

10/30
10/30
0/2
20/62

• The tails and heads of the sub-chains from which
  LB is comprised must be next to each other.

39
Constructing the longest optimal alignment

• If the tails and heads of the optimal sub-chains
  from which LB is comprised are next to each other
  then their concatenation (i.e. LB) is optimal.
  Lets examine the first two sub-chains

M/L
2M/2L
M/L

• But, what happens if we examine the following
  sub-chain

M/L
M/L

• Its number of matches is M1 and its length is
  L2.
• Since M/Llt½, (M1)/(L2)gtM/L. Thus, we found a
  chain of M1 matches whose normalized value is
  higher than that of LB, in contradiction to the
  optimality of LB.

40
Closing remarks
41
The advantages of the new algorithm

• The first algorithm to combine the normalized
  local and the sparse.
• Ideal for textual local comparison (where the
  sparsity is typically dramatic) as well as for
  screening bio sequences.
• As a normalized alignment algorithm, it does not
  suffer form the weaknesses from which non
  normalized algorithms suffer.
• A straight forward approach to the minimal
  constraint which is easy to control and
  understand, and in the same time, does not
  require reformulation of the original problem.
• the minimal constraint is problem related rather
  than input related.

42
The end
