Environmental Degradation Energy Utilization

1
Environmental DegradationEnergy Utilization

• Klaus S. Lackner
• Columbia University
• New York NY
• September 2003

2
Energy Sources

• Biomass Firewood
• Draft animals
• Wind/water mills
• Solar heat and photovoltaic
• Fossil carbon coal oil gas tar shale
• Nuclear Energy
• Fusion

3
Energy Uses

• Heat
• cooking metallurgy chemical products
  fertilizers to plastics
• Mechanical energy
• Transportation manufacturing agriculture
• Cooling
• Desalination
• Cleanup

4
Total Energy
Fossil Energy
Non Fossil Energy
5
Energy consumption and wealth
10 billion people trying to consume energy as US
citizens do today would raise world energy demand
10 fold
6
Pollution Issues
7
Pollution Issues II
8
Fossil Energy Is Vital to the World Economy
9
Fossil Carbon Accumulates in the Air CO2 increase
in the atmosphere accounts for 58 of all fossil
CO2 emissions
Changes in the industrial age are large on a
geological scale
Anthropogenic increase of carbon dioxide is well
documented for this century.
10
50000 Gt
Oil Gas Tars Shales
Carbon Sources and Sinks

Coal
Methane Hydrates
21st Centurys Emissions
Scales of Potential Carbon Sinks
Soil Detritus
Ocean
Atmo-sphere
Plants
pH 2000
1800
constant
39000 Gt
Carbon Resources
11
50 increase in biomass
180ppm increase in the air
30 of the Ocean acidified
30 increase in Soil Carbon
12
10 - 30 TeraWatt
2050
of Carbon Neutral
Primary Energy
13
Net Zero Carbon Economy
CO2 extraction from air
CO2 from concentrated sources
Electricity Hydrogen
Biological Chemical
Permanent safe disposal
Underground Chemical Storage
14
Hydrogen economy cannot run on electricity

• There are no hydrogen wells

Tar coal shale and biomass could support a
hydrogen economy. Wind photovoltaics and nuclear
energy cannot.
15
Energy States of Carbon
The ground state of carbon is a mineral carbonate
Carbon
400 kJ/mole
Carbon Dioxide
60...180 kJ/mole
Carbonate
16
Net Carbonation Reaction for Serpentine
Mg3Si2O5(OH)4 3CO2(g) 3MgCO3 2SiO2 2H2O(l)
heat/mol CO2 -63.6 kJ
Accelerated from 100000 years to 30 minutes
17
Magnesium resources that far exceed world fossil
fuel supplies
18
Rockville Quarry
19
Mineral Disposal of CO2
1 GW Electricity
Coal Strip Mine
Zero Emission Coal Power Plant 70 Efficiency
Coal
CO2
4.3 kt/day
Mineral Carbonation Plant
Earth Moving 40 kt/day
11 ktons/day
28 kt/day 36 MgO
Heat
Open Pit Serpentine Mine
Sand Magnesite
1.4 kt/day Fe 0.2 kt/day Ni Cr Mn
35 kt/day
Mining crushing grinding 7/t CO2
Processing 10/t CO2 No credit for byproducts
20

CO2 N2 H2O SOx NOx and other
Pollutants

Zero Emission Principle
Air
Need better sources of oxygen
Power Plant
Carbon
Solid/Liquid Waste
21
ADVANCED ZERO EMISSION PLANT CONCEPTS
22
How much wind (6m/sec)
Wind area that carries 10 kW
0.2 m 2 for CO2
80 m 2 for Wind Energy
Wind area that carries 22 tons of CO2 per year
23
Air
CO2
Volumes are drawn to scale
24
Extraction from Air Power Equivalent from
gasoline v 6 m/s 60000 W/m2
Areas are drawn to scale
25
60m by 50m 3kg of CO2 per second 90000 tons per
year 4000 people or 15000 cars Would feed EOR
for 800 barrels a day. 250000 units for
worldwide CO2 emissions
26
(No Transcript)
27
(No Transcript)
28
Materially Closed Energy Cycles
O2
O2
Energy Source
Energy Consumer
H2O
H2O
29
Ca(OH)2 as an absorbent
Flux D/L D 1.3910-5m2/s diffusion
coefficient L is boundary thickness is density
of CO2
Ca(OH)2 solution
CaCO3 precipitate
CO2 mass transfer is limited by diffusion in air
boundary layer
30
Public Institutions and Government
guidance
Carbon Board
certification
Permits Credits
Certified Carbon Accounting
certificates
31
Sustainable Development

• 1 2 billion without any electricity

32
The Fossil Carbon Pie
600 Gt C
Soon
Past
Distant Future
33
The Fossil Carbon Pie
Past
Soon
5000 Gt C
Distant Future
With Carbon Sequestration
