John Nousek Penn State University

1

John Nousek (Penn State University) Neil Gehrels
(Goddard Space Flight Center)
International Workshop on Astronomical X-ray
Optics - Prague, Czech Rep. 6-9 Dec. 2009
2
Swift launch 20 Nov 2004 !!
3
5th Anniversary of Swift Conference

• Celebration of Swift held at Penn State, 18-20
  Nov. 2009
• Attracted more than 150 participants 1/3 Penn
  State, 1/3 US 1/3 from ten other countries
• Discussed impact of Swift on areas of
  astrophysics, and planned for future developments
  and science direction of the Swift Observatory

4
Swift GRB Science

• Swift has redefined the field of GRB science.
• ??? GRB backgroud
• ??? Swift comparisons
• Duration
• Host galaxies
• Distance distributions
• Energetics
• Beaming

ARAA Annual Reviews 2009 Gehrels, Ramirez-Ruiz
and Fox
5
GRB Properties
Two types Short GRBs (t lt 2s) Long GRBs (t
gt 2s) Redshift range 0.2 - 2 SGRBs
0.009 - 8.2 LGRBs Energy release in ?-rays
1049-1050 ergs SGRBs 1050-1051 ergs
LGRBs Jet opening angle 15 deg SGRBs 5
deg LGRBs Both types have delayed extended
high-E emission
ARAA article
GRB 990123 HST image
Fruchter et al.
6
GRB Spectra
prompt
afterglow with synchrotron fit
GRB 051111
Butler et al. 2006
7
VELA GRB discovery 1973
Compton / BATSE isotropy inhomogeneity 2
duration classes 1991
Compton / EGRET GeV extended emission 1994
8
BeppoSAX afterglow distance 1997
Fireball Model 1997
HETE-II GRB030329 / SN2003dh XRFs 2003
9
Swift Mission
3 instruments, each with - lightcurves
- images - spectra Rapid slewing
spacecraft Rapid telemetry to ground
UVOT Position - lt 1 arcsec
XRT Position - 5 arcsec
BAT Position - 2 arcmin
.
Tlt10 sec
Tlt90 sec
Tlt2 min
10
475 GRB as of 1 Nov 2009 85 with X-ray
detections 60 with optical detection 155 with
redshift (41 prior to Swift) 46 short GRBs
localized (0 prior to Swift)
Swift Statistics
11
XRT lightcurve
Swift GRB Data
GRB 091029
BAT lightcurve
UVOT image
12
XRT lightcurve
Swift GRB Data
GRB 091029
flare
BAT lightcurve
steep-flat-medium shape
UVOT image
13
ShortvsLong

Kouveliotou et al. 2003
14
GRB Spectroscopy
GRB 080607
Prochaska et al. 2008
Savaglio 2006
15
Blast from the past! GRB 090423

z 8.29 look back time 13.0 billion
light years
Lyman break redshifted from UV to IR
GROND Greiner et al
McMahon Tanvir
Tanvir et al. 2009 Salvaterra et al. 2009
16
Evolution of Swift Operations GRBs More!

• Original prime mission 2004-2006 Swift the GRB
  Explorer
• Up to Nov. 2004 Pre-launch
• Swift primarily a GRB detection and afterglow
  followup mission
• Ground-breaking operations design allows
  immediate response to GRBs
• Automated follow-up allows introduction of new
  GRB without new schedule
• Targets of Opportunity limited to new non-Swift
  GRBs or rare events
• Expected schedule re-plans only once / month ToO
  once / week
• Planning using TAKO software / five times a week
• Prime mission 2005-2006
• Execution closely follows plans, except
• XRT TEC power supply fails, forcing operations to
  passively maintain XRT below -50 C
• Automated target process is great success
  allowing highly flexible and rapid ToO response

17
Swift Operations Currently

• 1st mission extension 2006-2008 High-z GRBs
  and the GI Program
• Swift reduces time on late afterglow followup and
  increases effort on finding high redshift GRBs
• Swift introduces GI targets, followed by pressure
  for increased ToO and monitoring campaigns
• TAKO planning software modified to incorporate
  XRT temperature control other ancillary software
  improves ACS reliability
• Improved ToO automation allows multiple ToOs in
  short period without new schedule (including
  nights and week-ends)

• Targets of Opportunity and Monitoring Campaigns
  occur every day
• Typical load of 4-12 ToO or Monitoring
  observations every day

18
Supernova Studies with Swift

• XRT and UVOT observations of SNe
• 66 observed to date of all types (26 Ia, 18 Ibc,
  22 II)
• UV, optical X-ray densely-sampled light curves
• Largest sample of SN light curves in the UV
• Unique UV characterizations of SN Ia's (incl UV
  spectra)

SN 2006bp (Type IIP)
Supernova Lightcurves
Immler et al. 2007 Brown et al. 2008
19
X-Ray SN Studies
- XRT observations probe SNe
environments mass-loss rates - Signature of
SN shock traveling through dense shell -
Shells are outer H/He-rich layers from
Luminous Blue Variable phase
SN 2006bp
Immler et al.
20
SN 2008D Shock Breakout
SN 2007uy
- XRT monitoring of NGC 2770 (27 Mpc)
revealed extremely luminous X-ray outburst - EX
2x1046 ergs - No BAT, no radio late gtgt
probably no jets - UVOT detection of SN rising
90 min later - SN Ib/c - Shock breakout. May
occur for all SN
9 Jan 2008
Soderberg et al. 2008
21
Nova Studies with Swift
Thermonuclear detonation of accumulated accretion
on white dwarf

• - 25 novae observed
• - Rise and fall of few keV emission from
• shocked ejecta
• - Super-Soft emission in some from
• WD surface (kTBB 30 eV)
• - Extensive observations of RS Oph 2006
• (400 ksec) revealed unexpected
• luminous SSS state and 35 sec QPO
• - Earth mass ejected at 4000 km/s into wind of
  companion Red Giant

1.6 kpc
RS Oph
22
Swift Trigger on Large Stellar Flare

• BAT triggered on a stellar flare from nearby (d5
  pc) EV Lac (dM3e, Prot 4 days)
• XRT spectra show Fe K 6.4 keV emission first for
  an active dMe star
• UVOT enhancement large but unknown instrument
  safed at gt200,000 counts/s
• Brightest stellar flare observed
• Erad 1038 erg
• EV Lac is young magnetically active isolated
  star.
• Previous super-flare was from binary RS CVn
  system, II Peg

Osten et al 2007, 2008
23
BAT Sky Monitoring
SWIFT J1816.7-1613
4U 0115634
Newly discovered source (Atel 1456)
Known pulsar in outburst (Atel 1426)
536 sources monitored 65 detectable on a
daily basis 60 with gt 30 mcrab outbursts 15
mCrab sensitivity in 1 day
Krimm et al
http//swift.gsfc.nasa.gov/docs/swift/results/tran
sients/
24
TOOs for Transients GRBs
- Swift can perform rapid X-ray and optical
observations of transients - TOO rapidly
uploaded as RA DEC. Response time is lt1 hour
to 1 day - Web page for TOO requests
http//www.swift.psu.edu/too.html - Duty
scientists always on call for urgent TOOs - New
"command from home" mode for after-hour TOOs -
Expert international teams provide rapid
advice GRB follow-up (48 members)
Supernova (22 members) CVs novae (24
members) Hard X-ray survey (18 members)
AGN (4 members) GeV and TeV ?-rays (4
members) - Daily planning telecon to decide
schedules
25
Swift Operations Ahead

• 2nd mission extension 2009-2011 Swift the ToO
  Observatory
• Swift executes 70-75 separate pointings per day
• Each pointing is planned, although significant
  labor by human science planner to have each
  pointing a different target
• Under an initiative approved by 2008 Senior
  Review, MOC has conducted an Automation
  Initiative to streamline science planning
• Elements include
• Target management database MySQL database to
  automatically ingest target information from ToO
  requests, target lists from GI approved proposals
  and GRB information from GCN circulars
• More highly automated TAKO software will allow
  higher automation to XRT temperature control and
  ACS slew behavior
• Goal is to allow faster, easier science planning,
  with capability to increase GI monitoring
  campaigns and rapid ToO response to large numbers
  of targets

26
Conclusions

• Swift has delivered a remarkably successful
  science mission to date, powered by an innovative
  operations concept that has continued to evolve
  as driven by scientific interest
• The latest changes will enable an even more
  responsive observatory, giving more GI monitoring
  and ToO responsiveness
• For Senior Review 2010, How do you suggest ways
  to use Swift, and how is that important for
  astrophysics?

27
Cosmic Timeline Early Universe Probes
z0
z12
z5
28
Hint That These Probes Work
z6.29
z6.28
GRB 050904
SDSS Quasar
29
We Need Higher Redshift Observations

• Swift SDSS only probed the very near edge of
  reionization
• We need a statistically significant sample that
  probes well into the epoch of reionization
• We need to find 30-50 GRBs from 5ltzlt12
• 10x what Swift found (5ltzlt7)
• We need to find 200-400 quasars from 6ltzlt10
• 10x all zgt6 quasars found (6ltzlt6.5)

z12
z5
30
Current Capabilities Needs

• Current capabilities from Swift SDSS needed to
  observe high redshift objects are
• Rapid localization and observations of GRBs
• Rapid notifications to enable observations by
  other facilities
• A very large field of view for finding GRBs
  quasars
• BREADTH versus Depth for rare objects (Critical)
• To probe high redshift objects we need
• Greater sensitivity to high redshift bursts
• Redshifted gamma-ray photons into the X-ray
• Prompt, uniform follow-up of afterglows in the IR
  (Critical)
• Rapid redshift determination (in minutes)
• Observations above the atmosphere are essential
  to eliminate terrestrial lines that confuse
  surveys

31
The Solution JANUS
1960
1980
2000
1960
1970
2020
1980
1990
2000
2010
BCD
DEF
GHI
ABC
JKL RST VWX XYZ
TUV
Testing
Increasing Capabilities
Support
Space Network
X-Ray Flash Monitor (XRFM) Detects localizes
high-z GRBs 1-20 keV, 4 sr field-of-view
Near-IR Telescope (NIRT) High-z GRB quasar
spectroscopy 0.7-1.7 µm, 1? pos, redshifts, 0.36
degree2 field-of-view,
Spacecraft Rapid communication w/ ground, rapid
slewing (50/100 sec), stable platform
32
JANUS Mission Concept Sky Survey Mode
400 quasars
20,000 square degree Survey
33
JANUS Mission Concept GRB Mode
50 GRBs
34
JANUS Objectives

• Determine star formation history
• by using 50 GRBs
• Explore the coevolution of galaxies black holes

• by using 400 quasars
• Determine if dominant source of reionization
