The Future of Voice and Data Mobility

1
The Future of Voice and Data Mobility
Lee BlackEmerging TechnologiesLee.Black_at_Motorola
.com
2
Voice and Data Mobility
Clients
WirelessNetworks
Common IP Core
IP-Enabled Applications Voice Video Data
Private 2-way Wi-Fi Wi-Max Mesh Cellular
Seamless Mobility A consistent user experience,
anywhere, anytime
3
End-to-end solutions
Capture Information in real time, at the point of
business activity
Mobile Office
Radios
Mobile Computing
Data Capture
Rugged PCs
Move Information instantaneously to and from the
point of greatest impact
Canopy
MESH
Wi-Fi
IP Backhaul
RFID
Manage The seamless flow of information with
exceptional efficiency and security
Motorola Services
MSP
4
Handheld Mobile Computing Products
Industrial MC
Application Specific
Enterprise MC
Premium
MC75 802.11HSDPA EVDO-A GPS Camera
MC70 802.11EGPRS EVDO GPS
MC9090 I-Safe//RFiD
MC909x 802.11 / EDGE / iDEN
Mid Market
MC3000TR Gun 802.11
MC3000TR 802.11 WM6.1
MC55 802.11 EGPRS GPS
VC6096 In-Vehicle Computer
VC5000 Forklift Computer
Value
MC35 802.11 EDGE
WT4000 Wearable
CA50
5

• MC75 Overview

6
Imagine
MC75
7
MC75 Premium Mobile Computer

• Package
• Standard 1.5x battery
• Sealed IP54
• Rugged 5 feet to Concrete at room temperature
• Data Capture
• 2M Pixel Auto Focus Digital Camera with Flash on
  select skus
• Laser scanner or 2D barcode Imager
• Integrated Sirf III GPS, A-GPS capable via SUPL
  industry standard
• 3.5 High Resolution VGA Display
• Numeric or Qwerty/Azerty/Qwertz keypads
• Processing
• CPU Bulverde 624 MHz
• Memory 128MB Ram, 256 MB Flash
• Symbol APIs, Symbol SMDK
• Windows Mobile 6.0 Phone Edition
• Connections
• WWAN 3G GSM HSDPA or CDMA EVDO Rev A
• WLAN - a/b/g on select skus Cisco CCX compatible.
• PAN Bluetooth V. 2.0

8
MC75 Features
Large speaker, mic, high quality receiver and
transducer
1D scanner or 2D Imager
Flash light for camera
Housing for stylus
2.0 Mega Pixel Auto-focus Camera
Spring loaded stylus to protect screen from wear
Hand strap for comfortable handhold
Approx. 425g (with 1.5X battery)
Lithium-Ion 3600 mAh or 4800 mAh Smart Battery
9
Applications Are The Key
10
Electronic Citations

• Increase officer safety
• Improve accuracy and reduce errors
• Tickets issued in a 2-3 minutes
• Automatically uploaded to the courts, reduce
  contested tickets

11
Mobile Identification

• Rugged biometric fingerprint reader
• Remotely check local and remote crime database
• ID anyone who cannot produce a license
• Works with multiple backend AFIS modules

12
Mobile CAD/RMS

• Provide CAD/RMS access to anyone without a laptop
  computer. Foot patrol, equestrian, bicycles,
  segway, etc
• Leverage real-time network coverage for remote
  NCIC or other criminal database checks

13
Mobile Video

• Visual Verification
• Increased Situational Awareness
• Increased Preparedness
• Enhanced Safety

14
Asset Management

• Computers/electronics
• 2-way radios
• Medical supplies
• Cargo containers
• Court documents
• Food products (safety)
• People
• Airline bags
• Police/Fire evidence

15
Evacuation Management
16
First Responder Accountability
17
Building Code Enforcement
Scoring and Pass/Fail
Rules and Fire Codes
August 3, 2009
18
Product or Incident Inspection Trailer
Inspection FEMA/Katrina
Image Markup
19
Partner Strategy
ISVs
Alliances
Distributors
Business Partners
20
Motorola Market Leadership
21
Public Safety Warranty

• Covers our entire Mobile Computing family of
  products
• Service provides
• 1 or 3-day in depot turn-around-time
• Telephone access to technical team for issue
  diagnosis and problem resolution
• Normal wear and tear as well as accidental
  damage abuse to displays, keypads, plastics,
  etc
• Benefits
• No surprise repair expenses
• Reduced need to carry expensive spare pool
• 2 5 years of protection at a one-time cost
• Includes Comprehensive - no charge
• Image, Battery mtc Express Ship options
• Lower TCO

22
Summary
Motorola delivers a unique combination of
best-in-class network infrastructure, devices,
services and public safety application to ensure
a reliable and cost effective solution to all of
your voice and data needs
True Voice and Data Mobility
Wireless Network
Public Safety Apps
Rugged Devices



Reliable, Secure voice and data devices
Hardened 4G wireless networks
Software for Public Safety
23
Thank You
Questions?
