Title: Lecture 16: RISC Architecture, Pipeline Hazards


1
Lecture 16RISC Architecture, Pipeline Hazards
  • Soon Tee Teoh
  • CS 147

2
Computer Architecture Notes
  • Stored-program computer
  • In contrast to fixed-program computer,
    stored-program computer can load and run
    different programs easily without any re-design
  • von Neumann architecture
  • Single storage structure to hold both program and
    data
  • Whats Moores Law?
  • Attributed to Gordon Moore, co-founder of Intel
  • The number of transistors on an integrated
    circuit doubles every 18 months (although Gordon
    Moore himself didnt say 18 months)
  • Implication Assume that Moores law will be
    fulfilled, therefore if I am a chip manufacturer,
    I better perform up to Moores law, otherwise Id
    probably lose to my competitors.
  • Another implication If I am a software
    developer, I can design my software assuming that
    computers in the future will be faster

3
RISC or CISC
  • 2 different types of ISA, different philosophy,
    trade-offs
  • RISC (Reduced Instruction Set Computers)
  • CISC (Complex Instruction Set Computers)
  • RISC
  • Memory accesses restricted to load/store, data
    manipulation are register-to-register
  • Limited number of addressing modes
  • All instructions same length
  • Instructions are elementary
  • CISC
  • Memory access directly available to most
    instructions
  • Many different addressing modes
  • Instructions of varying lengths
  • Some instructions simple, some complex
  • Many ISAs are between RISC and CISC

4
Reduced Instruction Set Computer
  • RISC has elementary, fixed-length instructions,
    and few addressing modes.
  • We use an example RISC architecture.
  • This RISC architecture uses load-store memory
    access that is, operations are not performed
    directly on memory rather, they are performed
    only on registers
  • 32 registers We need many registers to reduce
    load/store memory access to temporarily save
    operands.
  • The entire instruction set is given in Table
    12-1, page 540
  • 32-bit instructions. 7-bit opcode field, 5-bit
    register field, 15-bit immediate field
  • 2 formats (1) 3-registers, (2) 2-registers
    immediate

7 bits 5 bits 5 bits
5 bits 10 bits
3 registers Opcode
DR SA SB
7 bits 5 bits 5 bits
15 bits
2 registers immediate Opcode
DR SA Immediate
5
Addressing Modes
  • This RISC uses 4 addressing modes
  • Register ADD DR SA SB
  • Action RDR RSA RSB
  • Register indirect LD DR SA
  • Action RDR MRSA
  • Immediate ADI DR SA IM
  • Action RDR RSA se IM
  • Relative BZ DR SA IM
  • Action if RSA 0, then PC PC 1 se IM

6
Jump and Link
  • The Jump and Link (JML) instruction allows the
    programmer to implement procedures
  • Instruction format JML DR SA IM
  • Action PC PC 1 se IM, RDR PC 1
  • JML sets PC to a new value, the address of the
    callee procedure, and also stores the return
    address in a register.
  • When the callee procedure returns, use the Jump
    Register (JMR) instruction
  • Instruction format JMR DR SA
  • Action PC RSA
  • When the callee returns, use the JMR instruction
    with the register that stored the return address
    of the caller.
  • For nested procedure calls, need to use software
    stack.

7
BrA The branch address RAA The jump address Z
If zero (from Function Unit) BS, PS Flags for
branch/jump instructions
BS1 BS0 . (BS1 (PS Z))
MUX C 0 1 3 2
BrA RAA
EX IR DOF EX
PC
Address
From Figure 11-8, page 558, except we ignore the
SLT instruction
Instruction Memory
1
Instruction
PC-1
IR
Constant Unit
SH
Register File
AA
BA
Instruction Decoder
CS
PC-1
MA MB AA BA CS
1 0 MUX A
1 0 MUX B
MA
MB
MA Select PC or Register A for functional
unit MB Select Constant or Register B AA, BA
Select which registers to read CS Sign extend or
zero fill the constant
PC-2
Address
RAA
Data Memory
BS PS MW FS SH
A B Function Unit F
Data out
SH FS
Data in
Adder
SH Shift amount for barrel shifter FS Which
function MW Memory write enable RW Write to
register file DA Select which register to
write MD Memory of function unit
Data Memory
Z
Address
BrA
MW
0 1 MUX D
RW DA
MD
Register File
RW DA MD
8
Pipeline Hazards
  • A pipeline hazard prevents the next instruction
    in the instruction stream from being executing
    during its designated clock cycle.
  • Two kinds
  • Data hazard
  • Control hazard

9
Data Hazard
Example MOVA R1, R5 ADD R2, R1, R6
1 2 3 4
5
MOVA R1, R5 IF DOF
EX WB ADD R2, R1, R6
IF DOF EX WB
At cycle 3, the ADD instruction needs to read the
value of R1, but R1 is only available in cycle
4. (Assume that registers are written in the
first half of the clock cycle and read in the
second half of the clock cycle.) We have a data
hazard!
10
How to Deal with Data Hazard
  • 3 options
  • Compiler detects data hazard and inserts NOP
    (no-op, or non-operation, an instruction that
    does nothing)
  • Hardware detects data hazard and delays execution
    of instruction
  • Hardware implements data forwarding to eliminate
    data hazard

11
Hardware Detect Data Hazard
  • Once hazard is detected, hardware inserts NOPs
    automatically. This is illustrated with bubbles
    in the pipeline picture.

MOVA R1, R5 ADD R2, R1, R6
1 2 3 4
5
MOVA R1, R5 IF DOF
EX WB ADD R2, R1, R6
IF DOF ADD R2, R1,
R6 IF
DOF EX WB
Disabled instruction repeated next cycle
Hazard detected
NOPs inserted to disable pipeline
12
How to Detect Data Hazard
Data hazard detected
DHS HA HB HA MADOF . (DAEX AADOF) .
RWEX HB MBDOF . (DAEX BADOF) . RWEX
Instruction in DOF stage takes operand from
register
Instruction in EX stage writes to register
Destination register in EX stage is equal to read
register in DOF stage
13
BS1 BS0 . (BS1 (PS Z))
MUX C 0 1 3 2
Detecting data hazard, from Figure 11-12, page 566
BrA RAA
EX IR DOF EX
PC
Address
Instruction Memory
1
Instruction
PC-1
IR
Constant Unit
SH
Register File
AA
BA
Instruction Decoder
CS
PC-1
MA MB AA BA CS
1 0 MUX A
1 0 MUX B
MA
MB
PC-2
Address
RAA
Data Memory
A B Function Unit F
SH FS

Data out
Data in
HA
Adder
Data Memory
Z
Address
BrA

DHS
MW
HB
0 1 MUX D
RW DA
Circuitry for DHS
MD
Register File
RW DA MD
14
Data hazard stall, from Figure 11-12, page
566 Set RW, MW to 0 in the DOF stage to prevent
write. Set BS to 0 in the DOF stage to prevent
branch. Set DA to 0 in the DOF stage to prevent
infinite stall. Disable all the PC registers.
BS1 BS0 . (BS1 (PS Z))
MUX C 0 1 3 2
BrA RAA
EX IR DOF EX
PC
Address
Instruction Memory
1
Instruction
PC-1
IR
Constant Unit
SH
Register File
AA
BA
Instruction Decoder
CS
PC-1
MA MB AA BA CS
1 0 MUX A
1 0 MUX B
MA
MB
Set RW, DA, BS and MW to 0
PC-2
Address
RAA
Data Memory
BS
A B Function Unit F
SH FS

Data out
Data in
HA
Adder
Data Memory
Z
DHS
Address
BrA

DHS
MW
HB
0 1 MUX D
RW DA
Circuitry for DHS
MD
Register File
RW DA MD
15
BS1 BS0 . (BS1 (PS Z))
MUX C 0 1 3 2
Data forwarding, from Figure 11-13, page
568, except SLT instruction not implemented Data
already available in EX stage, simply load
directly into DOF stage
BrA RAA
EX IR DOF EX
PC
Address
Instruction Memory
1
Instruction
PC-1
IR
Constant Unit
SH
Register File
AA
BA
Instruction Decoder
PC-1
CS
MA MB AA BA CS
2 1 0 MUX A
2 1 0 MUX B
HA
HB
MA
MB
PC-2
Address
RAA
Data Memory
A B Function Unit F
SH FS

Data out
Data in
Adder
HA
Data Memory
Z
Address
MD
BrA

MUX D
MW
HB
MD
0 1 MUX D
RW DA
MD
Register File
RW DA MD
16
Control Hazard
  • Without any intervention, instructions
    immediately following branch instructions will be
    executed regardless of whether branch is taken.
    This causes error.

Example 1 BZ R1, 18 2 MOV R2, R3 3 MOV
R1, R2
Suppose that R1 contains 0, then PC set to 20
1 2 3 4
5 6
BZ R1 18 IF
DOF EX WB MOV R2 R3
IF DOF
EX WB MOV R1 R2
IF
DOF EX WB
But these 2 instructions have already been loaded
17
How to Deal with Control Hazard
  • Insert 2 NOPs after a branch instruction
  • A smart compiler can rearrange code to try to
    move 2 instructions into the positions after the
    branch that should be executed anyway. Usually,
    these 2 instructions are originally just before
    the branch instruction. If no such instructions
    can be found, then the compiler just has to use
    NOPs.
