Optimal k-mer superstrings for protein
identification and DNA assay design.

• Nathan Edwards
• Center for Bioinformatics and Computational
  Biology
• University of Maryland, College Park

2
k-mer (Sub-)Problems

• Enumerate
• For all (distinct) k-mers, do
• Existence
• ...with respect to exact ( inexact) count x
• Uniqueness
• ...with respect to exact inexact match
• Near-neighbors
• ...with respect to inexact match
• Representation
• Represent (distinct) k-mers for other tools
• Fast annotation of k-mer counts on original
  sequences

3
Applications of k-mer sets

• Peptide Identification
• Represent all amino-acid 30-mers
• ...that occur at least twice in human dbEST
• PCR Primer Design
• Test DNA 20-mer primers for uniqueness
• What does it mean to be unique?
• DNA sequencing error / repeat detection
• Eliminate mers that are too rare or too frequent
• Pathogen signatures
• Near-neighbors imply potential false-positives

4
k-mer Superstring Problem

• Given
• A set of sequences S S1, ..., Sn
• Sequence database
• Word size k
• Find
• A new set of sequences T T1, ..., Tm
• Such that
• Total length of T is minimized, and
• T is complete and correct w.r.t. k-mers of S

5
k-mer Superstring Problem

• Completeness
• All of the k-mers of S are represented
• Correctness
• No additional k-mers are present
• Minimize the total representation length
• Correlates with running time

6
Shortest (common) superstring problem

• General strings (arbitrary length)
• Single output string
• Completeness for input sequences only
• Classical NP-hard problem
• Garey and Johnson
• Approximate within 2.5OPT
• Max-SNP hard
• One of the first algorithmic approaches to genome
  assembly

7
de Bruijn Sequences

• de Bruijn sequences represent all words of length
  k from some alphabet A.
• A 0,1, k 3 s 0001110100
• A 0,1, k 4 s 0000111101011001000

8
de Bruijn Graph A 0,1, k 4
1
1
0
1
0
1
1
0
1
0
1
0
1
0
0
0
9
de Bruijn Sequences Graphs

• de Bruijn graphs (k,A)
• Edges represent length k words from A
• Each node has
• in degree A
• out degree A
• Eulerian tour constructs de Bruijn sequence.

10
Sequencing-by-Hybridization-graph
ACDEFGI, ACDEFACG, DEFGEFGI
11
Compressed SBH-graph
ACDEFGI, ACDEFACG, DEFGEFGI
12
Sequence Databases CSBH-graphs

• Original sequences correspond to paths

ACDEFGI, ACDEFACG, DEFGEFGI
13
C3 Enumeration

• Complete
• All k-mers are present
• Correct
• No other k-mers are present
• Compact
• No k-mer is present more than once

14
Correct, Complete, Compact (C3) Enumeration

• Set of paths that use each edge exactly once

ACDEFGEFGI, DEFACG
15
Correct, Complete (C2) Enumeration

• Set of paths that use each edge at least once

ACDEFGEFGI, DEFACG
16
Patching the CSBH-graph

• Use artificial edges to fix unbalanced nodes

17
Patching the CSBH-graph

• Use matching-style formulations to choose
  artificial edges
• Optimal C2/C3 enumeration in polynomial time.
• Chinese Postman Problem
• Edmonds and Johnson, 73
• l-tuple DNA sequencing
• Pevzner, 89
• Shortest (Common) Superstring
• MAX-SNP-hard, 2.5 approx algorithm

18
Related work

• Chinese Postman Problem
• Undirected graph, weighted edges
• Shortest path that uses all the edges
• Solvable in polynomial time
• Construct minimum weighted matching between nodes
  of odd-degree
• Add matching to graph and find Eulerian path
• Minimize weight of extra edges used

19
C2 Enumeration

• Chinese postman problem, except
• Directed graph
• Add edges from nodes with surplus in-degree to
  nodes with surplus out-degree
• Fixed cost teleportation option
• Can always start a new sequence
• Find optimal set of additional edges
• Transportation problem / min cost flow instance

20
C3 Enumeration
in-out
in-out
Cost k
21
Reusing Edges

• ACDEHAC, ACDFHAC, ACDGHACD

22
Reusing Edges

• C3 ACDEHACDFHAC, ACDGHACD

23
Reusing Edges

• C2 ACDEHACDFHACDGHAC

24
C2 Enumeration
in-out
in-out
4
10
Shortcut paths
7
25
C3 Enumeration
in-out
in-out
Cost 0
Cost 0
Cost k
26
Sample Preparation for Peptide Identification
27
Single Stage MS
MS
m/z
28
Tandem Mass Spectrometry(MS/MS)
m/z
Precursor selection
m/z
29
Tandem Mass Spectrometry(MS/MS)
Precursor selection collision induced
dissociation (CID)
m/z
MS/MS
m/z
30
Peptide Identification

• For each (likely) peptide sequence
• 1. Compute fragment masses
• 2. Compare with spectrum
• 3. Retain those that match well
• Peptide sequences from protein sequence databases
• Swiss-Prot, IPI, NCBIs nr, ...
• Automated, high-throughput peptide identification
  in complex mixtures

31
Novel Splice Isoform

• Human Jurkat leukemia cell-line
• Lipid-raft extraction protocol, targeting T cells
• von Haller, et al. MCP 2003.
• LIME1 gene
• LCK interacting transmembrane adaptor 1
• LCK gene
• Leukocyte-specific protein tyrosine kinase
• Proto-oncogene
• Chromosomal aberration involving LCK in
  leukemias.
• Multiple significant peptide identifications

32
Novel Splice Isoform
33
Novel Splice Isoform
34
Novel Mutation

• HUPO Plasma Proteome Project
• Pooled samples from 10 male 10 female healthy
  Chinese subjects
• Plasma/EDTA sample protocol
• Li, et al. Proteomics 2005. (Lab 29)
• TTR gene
• Transthyretin (pre-albumin)
• Defects in TTR are a cause of amyloidosis.
• Familial amyloidotic polyneuropathy
• late-onset, dominant inheritance

35
Novel Mutation
Ala2?Pro associated with familial amyloid
polyneuropathy
36
Novel Mutation
37
Compressed EST Peptide Sequence Database

• For all ESTs mapped to a UniGene gene
• Six-frame translation
• Eliminate ORFs lt 30 amino-acids
• Eliminate amino-acid 30-mers observed once
• Compress to C2 FASTA database
• Complete, Correct for amino-acid 30-mers
• Inclusive gene-centric peptide sequence database
• Size lt 3 of naïve enumeration, 20774 FASTA
  entries
• Running time 1 of naïve enumeration search
• E-values 2 of naïve enumeration search results

38
Compressed EST Peptide Sequence Database

• For all ESTs mapped to a UniGene gene
• Six-frame translation
• Eliminate ORFs lt 30 amino-acids
• Eliminate amino-acid 30-mers observed once
• Compress to C2 FASTA database
• Complete, Correct for amino-acid 30-mers
• Gene-centric peptide sequence database
• Size lt 3 of naïve enumeration, 20774 FASTA
  entries
• Running time 1 of naïve enumeration search
• E-values 2 of naïve enumeration search results

39
Sequence Databases CSBH-graphs

• All k-mers represented by an edge have the same
  count

1
2
2
1
2
40
CSBH-graph subgraphs

• Quickly determine those that occur twice

2
2
1
2
41
k-mer (Sub-)Problems

• Enumerate
• For all (distinct) k-mers, do
• Existence
• ...with exact ( inexact) count x
• Uniqueness
• ...exact inexact match
• Near-neighbors
• ...inexact match
• Representation
• Represent (distinct) k-mers for other tools
• Fast annotation of k-mer counts on original
  sequences

42
Large scale instances!

• CSBH-graph instances
• Partition set of all k-mers, determine
  non-trivial nodes
• Days on condor grid (250 CPUs) to construct
• 100,000,000 nodes and edges (sparse dense)
• Min-cost flow instances
• 500,000 nodes and edges
• Algorithms must be linear in problem size
• Out-of-core Eulerian path algorithm?
• Currently testing out-of-core connected-components


43
Grid computing

• Heterogeneous machines
• Varying disk/memory/MHz/cores capabilities
• Centralized scheduler
• Jobs started asynchronously
• Other jobs may preempt current job
• Input files may need to be staged
• 250 simultaneous requests for a 3Gb file?
• How to guarantee integrity of input files?
• Problem decomposition may be non-trivial
• Jobs sizes need to fit the least capable machine
• Sometimes need to game the scheduler
• Need to ensure the integrity of job output

44
Uniqueness Oracles

• Oracle for uniqueness of 20-mers in the Human
  genome (size 3Gb)
• Count occurrences in the genome 0,1,2
• Construct 20-mer superstring for 20-mers with
  count 1
• Construct 20-mer superstring for 20-mers with
  count gt 1
• Easy(-ish) for exact sequence match O(n)
• Fast automata, hash tables, suffix trees.

45
Polymerase Chain Reaction
46
Polymerase Chain Reaction
47
Inexact sequence match

• Inexact sequence matching O(nmk)
• Errors/Mismatches (k) 1,2,3
• distinct 20-mers (m) O(n)
• Achieve expected linear time using a hybrid
  approach (blastn)
• Exact search for short chunks of primers
• Expensive alignment only where chunks match
• Large chunks ) Fast, but miss occurrences
• Small chunks ) Slow, find all matches

48
Inexact sequence match

• Baeza-Yates Perleberg
• Correct and O(n) for small k
• At least 1 chunk is observed with no error.
• Small k ? Large chunks ? Fast and correct
• Form of locality sensitive hashing

g
? ?
q
49
Locality Sensitive Hashing

• For each primer
• store a (set of) hash(es) in hash-table
• At each position in the genome
• look-up a (set of) hash(es) in hash-table
• if any hash is found, do more expensive check
• Need to weigh
• sensitivity (false negatives) vs
• specificity (false positives)
• Our application requires speed and no false
  negatives!

50
Random Projection

• Choose T templates of l random care positions

g
q
51
Random Projection

• Choose T templates of l random care positions

g
t1
t1 0 1 1 0 1 0 1 0 0 0 1 0 1 0 1 0
0
52
Random Projection

• Choose T templates of l random positions

g
t1
t2
t1 0 1 1 0 1 0 1 0 0 0 1 0 1 0 1 0
0 t2 1 0 1 0 0 1 0 1 0 0 0 0 0 1 0
0 1
53
Random Projection

• Choose T templates of l random positions

g
t1
t2
t1 0 1 1 0 1 0 1 0 0 0 1 0 1 0 1 0
0 t2 1 0 1 0 0 1 0 1 0 0 0 0 0 1 0
0 1
54
Random Projection

• Choose T templates of l random positions

g
t1
t2
t1 0 1 1 0 1 0 1 0 0 0 1 0 1 0 1 0
0 t2 1 0 1 0 0 1 0 1 0 0 0 0 0 1 0
0 1
55
Gapped seed-set design problem

• Given
• mer-size m ( 20 )
• errors k ( 1,2,3)
• cares l ( 10,12,14 )
• Find the smallest set of templates with no false
  negatives.
• Minimize running time.

56
Gapped seed set design formulation (for k 2)

• Cover the edges of Km with copies of Km-l
• How many triangles to cover K6?(m 6, k 2, l
  3)
• Some instances of (m,2,m-3) cover each edge
  exactly once
• Steiner triple systems

57
How many triangles cover K6?

• 15 edges total
• Is 5 triangles possible?

58
How many triangles cover K6?

• 15 edges total
• Is 5 triangles possible? NO!

59
How many triangles cover K6?

• 15 edges total
• Is 5 triangles possible? NO!
• Each node requires 3 triangles
• Triangles must account for at least 18 edges

60
How many triangles cover K6?

• 15 edges total
• Is 5 triangles possible? NO!
• Each node requires 3 triangles
• Triangles must account for at least 18 edges

61
Gapped seed set design formulation 2

• Set cover instance
• Ground set all possible placements of the k
  errors (alignments)
• Covering sets all possible placements of the l
  care positions
• For (m20,k2,l10),
• 190 elements, 184,756 sets!
• Greedy approximation algorithm works

62
Gapped seed set design formulation 3
Templates
Positions (m)
Remove any kposition nodes, at least 1
templatemust have degree l.
l
63
Gapped seed set design formulation 3

• Polynomial size in terms of number of templates
• Select T in advance and test whether sufficient.
• Greedily add 1,2,3,... templates.
• Apply iteratively to achieve feasible solution

64
Solution for (20,2,10)

• .................... Positions
• t1
• t2
• t3
• t4
• t5
• t6

• Need gt 4 templates, 6 is optimal

65
Remember the application!

• We are checking some templates twice!
• We compute hash(es) at each position in the
  genome
• Any template that is a shift of another will be
  computed at some nearby genomic position!

66
Solution for (20,2,10)

• .................... Positions
• t1
• t2
• t3
• t4
• t5
• t6

• Need at most 3 templates...can we do better?

67
Solution for (20,2,10) w/ shift

• .................... Positions
• t1
• t2

• Optimal is 2 templates...

68
Gapped seed set designSolution strategies

• Randomized algorithms
• Greedy algorithm
• Directly to set cover instance
• Indirectly to bipartite instance
• Integer programming
• On set cover and bipartite instances
• Solution of greedy algorithm subproblem
• ...in parallel, using COIN-OR SYMPHONY
• Branch-and-bound enumeration
• Solution of greedy algorithm subproblem
• ...in parallel, using COIN-OR ALPS library

69
What about edit-distance?

• Formulations can be generalized
• Similar solution strategies can be applied
• (All) symmetry lost!
• This may actually be helpful
• Much harder to solve
• Is greedy still good?
• Solutions typically require more templates

70
Uniqueness Oracles

• Integrated with CSBH-graph construction algorithm
• Ensure edge-count property is preserved
• Sequence database of unique / non-unique 20-mers
  for small genomes
• D. melanogaster, up to edit-distance 2
• Currently working to scale to human...

71
Other Projects / Interests

• HMMs for Peptide Spectrum Matching
• with UMd, CS
• Rapid Microorganism Identification Database
• www.RMIDb.org
• Pathogen detection using Spectral Matching
• with USDA

• Locality sensitive hashing
• spectra, peptide sequence
• Statistical techniques
• statistical significance
• importance sampling
• CSBH-graph applications
• genome assembly
• Grid computing
• Web-applications
• Relational databases

72
Future Research Directions

• Extend k-mer superstring algorithms
• Range of word sizes, variable length words
• Other sequence properties (Tryptic peptides, Tm)
• Identification of protein isoforms
• Optimize proteomics workflow for isoform
  detection
• Identify splice variants in cancer cell-lines
  (MCF-7) and clinical brain tumor samples
• Aggressive peptide sequence enumeration
• dbPep for genomic annotation
• Open, flexible informatics infrastructure for
  peptide identification

73
Future Research Directions

• Proteomics for Microorganism Identification
• Specificity of tandem mass spectra
• Revamp RMIDb prototype
• Incorporate spectral matching
• Primer design
• Uniqueness oracle for inexact match in human
• Integration with Primer3
• Tiling, multiplexing, pooling, tag arrays

74
Acknowledgements

• Chau-Wen Tseng, Xue Wu
• UMCP Computer Science
• Catherine Fenselau, Steve Swatkoski
• UMCP Biochemistry
• Calibrant Biosystems
• PeptideAtlas, HUPO PPP, X!Tandem
• Funding National Cancer Institute
