Title: Dependence of MultiTransonic Accretion on Black Hole Spin


1
Dependence of Multi-Transonic Accretion on Black
Hole Spin
  • Paramita Barai
  • Graduate Student, Physics Astronomy
  • Georgia State University
  • Atlanta, GA, USA
  • 06/29/2005

2
Contents
  • Introduction Motivation
  • What are we doing?
  • Our system formulations
  • Results
  • Conclusions

3
Introduction
  • Mach number
  • Accretion flow
  • Subsonic M lt 1
  • Supersonic M gt 1
  • Transonic crosses M 1
  • Transition
  • Smooth -- Sonic point
  • Discontinuous -- Shock
  • Multi-transonic flow ? 3 sonic points

4
Motivation
  • BH inner boundary condition Supersonic flow at
    Event Horizon (EH)
  • Far away from EH subsonic
  • Hence BH accretion is essentially transonic
  • Except cases where already supersonic initially
  • Multi-transonic flow ? Shock Formation
  • Transonic Flow is relevant in various
    astrophysical situations
  • Black Hole (BH) or Neutron Star (NS) accretion
  • Collapse / Explosion of stars
  • Solar / Stellar winds
  • Formation of protostars galaxies
  • Interaction of supersonic galactic (or
    extragalactic) jets with ambient medium

5
Draw fig in board
  • BH spin angular momentum of accreting matter
    directions
  • Show prograde retrograde accretion flow
    explicitly (or, co counter rotating BH)

6
Highlights
  • Study variation of dynamic and thermodynamic
    properties of accretion flow very close to event
    horizon their dependence on spin of BH
  • Found Higher shock formation possibility in
    retrograde accretion flow (i.e. BH spin is
    opposite to rotation of accreting matter) as
    compared to prograde flow

7
  • What do we do?
  • Formulate solve conservation equations
    governing general relativistic, multi-transonic,
    advective accretion flow in Kerr metric
  • Calculate flow behavior very close (? 0.01 rg) to
    event horizon as function of a
  • Can be done at any length scale
  • Notations
  • Gravitational Radius
  • Black Hole Spin / Kerr Parameter a

8
Describing Our System
  • No self-gravity, no magnetic field
  • Units G c MBH 1
  • Boyer-Lindquist coordinates ( )
  • Observer frame corotating with accreting fluid
  • ? Specific angular momentum of flow -- aligned
    with a
  • Stationary axisymmetric flow
  • Euler Continuity eqns
  • Polytropic equation of state
  • K specific entropy density
  • ? adiabatic index, n polytropic index

9
Our System
  • Specific proper flow enthalpy, h
  • Polytropic sound speed, as
  • Frame dragging neglected
  • Weak viscosity limit
  • Very large radial velocity close to BH ?
    Timescale (viscous gtgt infall)
  • Effect of Viscosity ? ? ? ? Flow behavior as
    function of ? provides information on viscous
    transonic flow

10
Metric Others
  • Kerr metric in equatorial plane of BH (Novikov
    Thorne 1973)
  • Angular velocity, ?
  • Normalization
  • 4th Component of velocity

11
Accretion Disk
  • Vertically integrated model (Matsumoto et al.
    1984)
  • Flow in hydrostatic equilibrium in transverse
    direction
  • Equations of motion apply to equatorial plane of
    BH
  • Thermodynamic quantities vertically averaged over
    disk height
  • Calculate quantities on equatorial plane
  • 1-dimensional quantities, vertically averaged
  • Disk height, H(r) from Abramowicz et al. 1997

12
Conserved Quantities
  • Specific energy (including rest mass)
  • Mass accretion rate
  • Entropy accretion rate

13
Quantities at Sonic Point
  • Radial fluid velocity
  • Sound speed
  • Quadratic eqn for (du/dr)c

14
Sonic Point Quantities
15
(No Transcript)
16
Results
  • For some P4 -- get 3 sonic points on solving
    eqn
  • rout gt rmid gt rin
  • rout, rin X-type sonic points
  • rmid O-type sonic pt (unphysical no steady
    transonic soln passes thru it)
  • Multitransonic Accretion ?(rin) gt ?(rout)
  • Multitransonic Wind ?(rin) lt ?(rout)
  • General astrophysical accretion ? Flow thru rout
  • Flow thru rin possible only in case of a shock
  • If supersonic flow thru rout is perturbed to
    produce entropy ?(rin) ?(rout), it joins
    subsonic flow thru rin forming a standing shock
  • Shock details from GR Rankine-Hugoniot conditions

17
(No Transcript)
18
E-? Multi-Transonic Space For Different ?
19
(No Transcript)
20
Variation of E-? Multi-Transonic Space for Change
in Kerr Parameter, a
21
(No Transcript)
22
Angular Momentum
  • We found
  • At higher values of angular momentum
    multi-transonicity is more common for retrograde
    flow
  • Weakly rotating flows, found in several physical
    situations
  • Detached binary systems fed by accretion from OB
    stellar winds
  • Semidetached low-mass non-magnetic binaries
  • Supermassive BHs fed by accretion from slowly
    rotating central stellar clusters
  • Turbulence in standard Keplerian accretion disk

23
Important Conclusion Differentiating Accretion
Properties of Co Counter Rotation of Central
Black Hole
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
Differentiating Pro Retro-Grade Flows
  • Prograde Accretion Flow
  • Multi-transonic regions at lower value of ?
  • Retrograde Accretion Flow
  • Multi-transonicity much more common
  • Covers higher value of angular momentum (?)

28
Terminal Behavior of Accretion Variables
  • Terminal value of accretion variable, A
  • A? A (at r? re ?)
  • Integrate flow from rc down to r? ? get A?
  • Studied variation of A? with a ? BH spin
    dependence of accretion variables very close to
    event horizon
  • Can be done for any r? ? dependence of flow
    behavior on BH spin at any radial distance from
    singularity

29
(No Transcript)
30
(No Transcript)
31
Discussion Summary
  • Study dependence of multi-transonic accretion
    properties on BH spin at any radial distance /
    accretion length scale
  • Very close to event horizon
  • Possible shock location
  • Found non-trivial difference in the accretion
    behavior for co counter rotating BH
  • Prograde flow (co-rotating BH) low ?
  • Retrograde flow (counter-rotating BH) high ?
    greater shock formation possibility

32
Astrophysical Implications
  • Preliminary step towards understanding how BH
    spin affects astrophysical accretion and related
    phenomenon
  • Shock waves in BH accretion disks must form
    through multi-transonic flows
  • Study of the post shock flow helpful in
    explaining
  • Spectral properties of BH candidates
  • Cosmic (galactic extragalactic) jets powered by
    accretion (formation dynamics)
  • Origin of Quasi Periodic Oscillations in galactic
    sources

33
Thank You All
34
Observational Consequences
  • Debate Determining BH spin from observations
  • Most popular approach study of skew shaped
    fluorescent iron lines
  • Our approach presents the potential to deal with
    this problem
  • We predict behavior of flow properties
  • For hot, low-? prograde accretion flow high-?
    retrograde flow

35
