Recent Methods and Problems in Authentication Protocol Analysis

1
Recent Methods and Problems inAuthentication
Protocol Analysis

• Jonathan Millen
• SRI International
• Menlo Park, CA, USA
• millen_at_csl.sri.com
• WADIS '03
• December 6, 2003

2
Outline

• Background
• What is cryptographic protocol analysis
• Why is it a hard problem
• Overview of analysis approaches
• Recent Work
• Strand spaces
• Digression - group management protocol analysis
• The constraint solver
• Continuing research problems

3
Resources

• CAPSL Web Site
• www.csl.sri.com/users/millen/capsl
• Bibliography
• capsl/protsec.bib (references like AB99)
• Clark-Jacob Library
• www.cs.york.ac.uk/security/Publications.html
• capsl/library.html
• SPORE Library (Comon)
• www.lsv.ens-cachan.fr/spore
• Constraint solver tutorial and Prolog code
• capsl/constraints.html
• Ryan-Schneider text, Crypto. Protocol Analysis
  CSP

4
Cryptosystems

• Cryptosystem algorithm for encrypting plaintext
  into ciphertext, and decrypting, using keys.
• Cryptographic protocol exchange of messages for
  distributing keys or applying a cryptosystem to
  data.
• Symmetric-key cryptosystem the same key is used
  for encrypting and decrypting.
• Examples DES, IDEA, Skipjack, Blowfish, RC4, AES
  (Rijndael)
• Public-key cryptosystem different keys are used
  for encrypting and decrypting. The encryption
  key may be made public.
• Examples RSA, El Gamal, Elliptic curve
• Diffie-Hellman (key agreement)

5
Cryptographic Protocols

• For key distribution provide two parties with
  keys suitable for private or authenticated
  communication
• For authentication to provide one party with
  assurance that a message was sent by another
  party in the same session.
• For other purposes fair exchange, auctions,
  voting,
• Examples
• SSL - in browsers (now TLS)
• Kerberos - remote unitary login
• EKE, SRP - password based
• Cybercash - electronic commerce
• IKE, ISAKMP, JFK by IETF
• New ones are continually proposed

6
The Security ThreatActive Attacker

• Attacker can
• -intercept all messages
• -modify addresses and data
• Attacker cannot
• -encrypt or decrypt without the key

7
Protocol Vulnerabilities - Ground Rules

• "Attacker" synonyms
• intruder, spy, saboteur, penetrator, enemy,
  adversary
• Attacker can intercept any message
• Ability to read, record, misdeliver any message
• Method sniffers, and intrusions in firewalls or
  routers
• Attacker can introduce new messages
• Construct messages using primitive operations
• Falsify (unencrypted) source, destination
  addresses
• Strong encryption assumption an attacker cannot
  decrypt any message without the key.
• Attacker is a legitimate network user with a
  name, key, etc.
• Other users follow the protocol
• This is often called the Dolev-Yao model DY83

8
Example - Needham-Schroeder

• The Needham-Schroeder symmetric-key protocol
  NS78
• A ? S A, B, Na
• S ? A Na, B, Kc, Kc, AK(B) K(A)
• A ? B Kc, AK(B)
• B ? A NbKc
• A ? B Nb-1Kc
• A, B are principals S is a trusted key server
• K(A) is a secret key shared by A and S
• X, YK means X concatenated with Y, encrypted
  with K
• Na, Nb are nonces fresh (not used before)
• Kc is a fresh connection key
• Denning-Sacco replay attack in 1981 DS81

9
Denning-Sacco Attack

• Assume that the attacker has recorded a previous
  session, and compromised the connection key Kc
  used in that session.
• first part
  omitted
• A ? B Kc, AK(B) attacker replay of old
  message
• B ? A NbKc
• A ? B Nb-1Kc forged by attacker
• B now believes he shares a fresh secret key Kc
  with A.
• Denning-Sacco moral use a timestamp (calendar
  clock value) to detect replay of old messages.
• Better use of nonces could also work

10
Folklore - Attack Terms

• Replay record and later re-introduce a message
  or part
• Masquerading pretending to be another party
• Forge source address
• Man-in-the-middle pass messages through to
  another session A ? X ? B
• Oracle take advantage of normal protocol
  responses as encryption and decryption services
• Type confusion substitution of a different type
  of message field (e.g., key vs. nonce)
• Parallel attack takes advantage of two or more
  concurrent protocol runs of the same role,
  different sessions

11
Design Principles

• Abadi-Needham prudent engineering practice
  paraphrased
• See AN94 also Anderson and Needham AN95
• 1. Every message should say what it means.
• 2. The conditions for a message to be acted on
  should be clearly set out.
• 3. Mention the principals name explicitly in the
  message if it is essential to the meaning.
• 4. Be clear as to why encryption is being done.
• 5. Dont assume a principal knows the content of
  encrypted material that is signed by that
  principal.
• 6. Be clear on what properties you are assuming
  about nonces.
• 7. Predictable quantities used for
  challenge-response should be protected from
  replay.

12
More Design Principles

• 8. Timestamps must take into account local clock
  variation and clock maintenance mechanisms.
• 9. A key may have been used recently, yet be old.
• 10. If an encoding is used to present the meaning
  of a message, then it should be possible to tell
  which encoding is being used.
• 11. The protocol designer should know which trust
  relations his protocol depends on.
• Good advice, but
• Are you sure when you have followed all of them?
• Is the protocol guaranteed to be secure then?
• Is it optimal and/or minimal?

13
Formal Methods
Crypto Protocol Analysis
Formal Models
Computational Models
Dolev-Yao (ideal encryption)
Probabilistic poly-time Random oracle (bit
leakage)
Belief Logics
Model Checking
Inductive Proofs
State space exploration Specialized
or general-purpose tools
By hand or using verification tools
BAN logic GNY, SvO, ... Authentication, Nonrepudi
ation
14
Why Protocol Analysis is Hard
15
Protocol Analysis is Undecidable

• Several proofs
• First undecidability proof by Even Goldreich,
  EG83
• Simpler use of Post Correspondence problem by
  Heintze Tygar, HT96
• Undecidability comes from unboundedness in the
  model
• Number of protocol instances (runs, sessions) is
  unbounded
• Messages from attacker are unbounded in
  structural depth
• Number of possible values for some data fields is
  infinite

16
BAN Logic

• Papers
• Burrows, Abadi, Needham, A logic of
  authentication, ACM Trans. Computer Systems
  8(1), 1990 (also DEC SRC Research Rpt 39)
• Subsequent extensions, e.g., GNY logic
• Gong, Needham, Yahalom, Reasoning about belief
  in cryptographic protocols, 1990 IEEE Symposium
  on Security and Privacy
• Approach
• Modal logic of belief plus specialized predicates
  and inference rules
• Example B believes A said (K is fresh)
• Example if A shares K with B and B sees XK
  then A said X
• Protocol messages are idealized into logical
  statements
• Objective is to prove that both parties share
  common beliefs
• Logic of authentication
• Elegant, popular

17
The Problem with BAN

• Nessett noted problem Nes90
• A ? B T, KKA-1
• Shared key K given away by encryption with
  private key of pair
• A can still believe A shares K with B
• Secrecy failures may be subtle
• Secrecy analysis must be prior to authentication
  proof
• Prove that good keys or shared secrets are not
  compromised during the protocol (due to an
  attack)
• Logics like this address authentication, must use
  other techniques to verify confidentiality where
  assumed/needed

18
Early Specialized Model Checkers

• Interrogator MCF87, Mil95
• Prolog program
• Backward state search for attack from goal state
  pattern
• No guarantee of completeness or termination
• NRL Protocol Analyzer Mea91, Mea96a
• Prolog program
• Backward state search, plus
• Generation of "unreachable" languages
• No guarantee of completeness or termination
• Can sometimes prove a protocol correct

19
General-Purpose Model CheckerApplications

• Application of software tools designed for
  hardware CAD
• Verification by state space exploration -
  exhaustive on model
• Like earlier Prolog tool approach, but
• Special algorithms (BDD, SAT, etc.)
• Require finite model
• bounds on number of sessions, message structure,
  etc.
• Fully automatic once protocol is encoded
• Researchers
• Roscoe Ros95, using FDR (the first)
• Mitchell, et al, using Murphi MMS97
• Marrero, et al, using SMV MCJ97
• Denker, et al, using Maude DMT98
• and more

20
Model-Checking Observations

• Very effective at finding flaws, but
• No guarantee of correctness, due to artificial
  finite bounds
• Bound on message structure depth later found
  unnecessary
• Setup and analysis is quick when done by experts
• Automatic translation from simple message-list
  format to model-checker input is possible Lowe's
  Casper Low98a
• Successful example Lowe attack on
  Needham-Schroeder public-key protocol, using FDR
  Low96

21
Lowe Small-System Result

• Theorem if Assumptions 1-6 (below) are
  satisfied, then any secrecy breach can be
  demonstrated in a small system with only one
  instance of each role. Low98b
• Functions that return keys are one-to-one (no key
  coincidence)
• All short-term secrets are fresh
• No long-term keys are (normally) sent (as data)
  in messages
• Encrypted message components mention all roles
• Encrypted message components are textually
  distinct
• No temporary secrets (secrets must not be
  revealed after use)
• Example (Davis-Swick)
• A ? B B,Tsk(A,B)
• B ? A T,Ask(B,A)
• This satisfies the assumptions if
• sk(A,B) ? sk(B,A) (for 1)
• T is a recognizably different type from principal
  (for 5)

22
Recent Specialized Methods

• Athena
• Song/Berezin/Perrig SBP01
• ML program
• Uses strand-space model (free algebra, atomic
  keys)
• Special-purpose model checker
• Very fast
• Usually terminates, no fixed bound
• Bounded-Process Decidable
• Bounded set of legitimate processes
• Decidable despite no bound on message term
  complexity
• Shown NP-complete by Rusinowitch/Turuani RT01
• Constraint solver is in this category

23
Inductive Proofs

• Approach like proofs of program correctness
• Induction to prove loop invariant
• State-transition model, objective is security
  invariant
• General-purpose specification/verification system
  support
• Kemmerer, using Ina Jo and ITP Kem89 (the
  first)
• Paulson, using Isabelle Paul98 (the new wave)
• Dutertre and Schneider, using PVS DS97
• Bolignano, using Coq Bol97
• Can also be done manually
• Schneider, using CSP Sch98
• Thayer et al, using Strand Spaces THG98
• Spi calculus proofs (Abadi, Gordon, ...)
• Full guarantee of correctness (with respect to
  model)
• No bounds imposed
• Proofs include secrecy
• But they are usually hard work

24
Strand Spaces
Thayer, Herzog, Guttman THG98 Message ground
term in free algebra over symbolic constants,
with pairs and encryption Message does not
include "A ? B" header Strand sequence of nodes
Node is labeled with /- message Bundle causal
partial ordering of nodes in strands
Penetrator strands, for primitive
operations Examples
A strand
Example NSPK
B strand
n,akb
-n,akb
x
xk
-n,rka
n,rka
y
k-1
rkb
x,y
x
Penetrator strands are universal
25
Bundles

• A bundle combines strands into a partial ordering
• Nodes are ordered by internal strand sequence
• Nodes are also ordered by message delivery
• Bundles are backward complete
• Non-initial nodes have predecessor in strand
• Every received message must have been sent

n,akx
kx-1
Example NSPK attack
n,rka
n,a
rkx
kb
n,akb
n,rka
26
Parametric Strand Specification
Suggested by Son99 and CDLMS00
A-role strand "A"(A,B,Na,Nb)
Na is a nonce generated by "A" roles A, B, Na,
Nb (initial capitals) are variables Addresses
lost
Protocol
A,Napk(B)
A ? B A,Napk(B) B ? A Nb,Napk(A) A ? B
Nbpk(B)
-Nb,Napk(A)
Nbpk(B)
There's also a B-role strand
Semibundle incomplete bundle, partially
instantiated strands
27
Example Spec

• Yahalom protocol
• "A"(A,B,S,Na,Nb,K)
• A,Na
• B,K,Na,Nbsk(A),NbK
• "B"(A,B,S,Na,Nb,K,T)
• A,Na
• B,A,Na,Nbsk(B)
• T,A,Ksk(B)
• T,NbK
• "S"(A,B,S,Na,Nb,K)
• B,A,Na,Nbsk(B)
• B,K,Na,Nbsk(A),A,Ksk(B)

A ? B A, Na B ? S B,A,Na,Nbsk(B) S ? B
B,K,Na,Nbsk(A), A,Ksk(B) B ? A
B,K,Na,Nbsk(A), NbK
Term T encrypted for A is just passed on
28
Characteristics of Spec Style

• Keys may be constructed
• Symmetric key may be any term, not just constants
• Public keys constructed with pk(A)
• Secret keys sk(A) assumed to be shared with
  server
• Free term algebra (no term reductions or
  relations)
• Advantage WYSIWYG simplicity
• Can't specify decryption explicitly in protocol
  spec
• Some loss of generality (EV-freedom discussion)
• Untyped
• Advantage or disadvantage?
• Typing can be simulated with type-coercion
  functions
• Dont yet handle commutative operations (xor,
  exponentiation)

29
Free Term Algebra Question

• Suppose that a protocol is expressible (in
  parametric strand style) using a free term
  algebra to represent encryption.
• (Write e(X,K) for XK so we can introduce d(X,K)
  below)
• Example strand S(A,B,X,K) -e(X,A,K)
  e(X,B,K)
• Assume that the attacker can perform decryption
  transformations as usual, such as e(X,K), K ?
  X
• Can new attacks be discovered by adding an
  explicit decryption operator with cancellation
  relations?
• d(e(X,K),K) ? X e(d(X,K),K) ? X

30
Counterexample
A strand
B strand
-e(e(X,c),k)
e(s,k)
X
Assumptions s is a secret constant k is a
secret key c is a compromised key X is a variable
Observation if e(s,k) is acceptable as
e(e(X,c),k) then s e(X,c) and X d(s,c) so the
attacker can get s.
A free term algebra can't see this.
31
Remarks

• What's missing ability to decrypt something that
  was not encrypted
• Generality is restored if e(X,K) is disallowed
  for any variable X
• Spec is "EV-free" if this restriction is
  satisfied
• (OK to have X in context, e.g., e(X,a,K))
• "On the freedom of decryption," Millen, IPL
  86(2003)
• All this applies to public key encryption too
  (Lynch)
• Why use free term algebra model?
• Analysis advantages efficient constraint
  solving, proof of completeness and termination
• EV-freedom is realistic
• But free algebras still can't handle group
  management protocols...

32
Multicast Group Management

• Multicast group members share a group key
• A suite of protocols is used to perform different
  tasks
• Addition of a new member to the group (rekey)
• Deletion of a member from the group (rekey)
• Merge two groups or split one into two
• Distribute new group key
• Application-dependent tasks
• Different methods for key distribution
• Group Diffie-Hellman, key hierarchy,
• Secrecy objectives
• Backward access control new members can't read
  old messages
• Forward access control deleted members can't
  read new messages

33
Group Diffie-Hellman
Steiner-Tsudik-Waidner 1996 Finite-field
arithmetic uses exponentiation mod p Constant
base g for exponentiations r1, r2, etc. are
private random contributions Last party (M3 in
this example) multicasts Group key gr1r2r3
computed by each party
"upflow"
gr2,gr1,gr1r2
g,gr1
M1
M2
M3
gr2r3,gr1r3
"downflow"
34
Need for Authentication

• Attacker can misdeliver upflow message as
  downflow
• Party computes wrong group key, something public
• This is a problem for two-party Diffie Hellman
  also
• First attempt at solution AGDH (Authenticated)
• Assume pairwise shared keys
• Include key with downflow terms
• gr2r3k13,gr1r3k23
• Insufficient Pereira-Quisquater attack PQ01

M1
g,gr1
Attacker
g,gr1
M1 computes group key as gr1
35
Pereira-Quisquater Attack
M2
M4
g,gr1
gr2,gr1,gr1r2
_,gr2,gr2,_
_,gr2r4k24,gr2r4k34
M3 gets gr2r4
Second round, M3 (malicious) has been deleted
M2
g,gr2r4
gs2,gr2r4,gr2r4s2
s2 is new private contribution from M2
_,gr2r4k24
M2 computes new group key as gr2r4s2
(compromised)
The analysis technique has not yet been put into
tools.
36
Bounded-Process Decidable Case
Crypto Protocol Analysis
Formal Models
Computational Models
Dolev-Yao (ideal encryption)
Probabilistic poly-time Random oracle (bit
leakage)
Belief Logics
Model Checking
Inductive Proofs
Bounded-process decidable
Finite-state
Antti Huima, 1999 Symbolic states (extended
abstract)
Inspired subsequent work Amadio-Lugiez Boreale Fi
ore-Abadi Rusinowitch-Turuani (NP-complete) Millen
-Shmatikov Basin
37
Constraint Solving

• Millen-Shmatikov MS01
• Bounded-process decidable
• Two-phase approach
• Use the protocol spec to generate algebraic
  "constraint" sets
• Use inference rules to solve constraint sets

38
Constraint Solving

• Parametric strand specification for protocol
• Choose N strand instances (small N)
• Enumerate possible node orderings (strand
  interleavings)
• Generate a constraint set for each ordering
• Solve constraint set (finds attack) or prove
  unsolvable (N-secure)
• No attack in any constraint set with N? Try N1

39
Example Spec

• NSPK protocol
• "A"(A,B,Na,Nb)
• A,Napk(B)
• Na,Nbpk(A)
• Nbpk(B)
• "B"(A,B,Na,Nb)
• A,Napk(B)
• Na,Nbpk(A)
• Nbpk(B)

A ? B A,Napk(B) B ? A Na,Nbpk(A) A ? B
Nbpk(B)
Caution variable scope is local to a strand.
The "A" strand value of A is not necessarily
equal to the "B" strand value of A (in a bundle).
40
Choose Strand Instances
A-role instances
B-role instances
Secrecy test strand
ma1
mb1
s
?
a1
b1
s is the secret If a bundle exists with this
strand, s is compromised
mb2
ma2
a2
b2
ma3
mb3
a3
b3
Zero, one, two, or more instances per role (not
necessarily the same)
41
Constraint Set Generation
1. Enumerate all linear node orderings consistent
with strands
ma1
-mb1
-m'b1
a1
b1
b'1
mb2
-ma2
m'b2
a2
b2
b'2
ma3
-mb3
-m'b3
a3
b3
b'3
a1 b1 b'1 b'2 b2 a2 a3 b3 b'3
with message ordering
ma1 -mb1 -m'b1 m'b2 mb2 -ma2 ma3 -mb3 -m'b3
42
Phase I Constraint Set Generation
2. One constraint for each received message
ma1 -mb1 -m'b1 m'b2 mb2 -ma2 ma3 -mb3 -m'b3
mb1 ma1 m'b1 ma1 ma2 ma1,m'b2,mb2 mb3
ma1,m'b2,mb2,ma3 m'b3 ma1,m'b2,mb2,ma3
Constraint m1 m2, m3, means that m1 is
derivable using available operations (by the
attacker) from the messages m2, m3, and from
constants known to the attacker. These are term
closure constraints.
43
Derivation Constraint Example

• A ? B A original protocol
• "A"(A) A "B"(A) -A strand spec
• a, -A semibundle
• a -A interleaving
• A a the constraint

44
How Many Interleavings?

• For two strands of sizes m and n nodes, there are
  choose(mn,n) different orderings (binomial
  coefficient)
• Send optimization
• m1, -m2, has at least as many solutions as -m2,
  m1,
• Therefore always choose send nodes first (order
  doesn't matter)
• Common path optimization (Corin, Etalle)
• Constraint differentiation (Basin, et al. ACM CCS
  '03)

45
Common Path Optimization

• Node orderings have common initial subsequences
• Unsolvability of initial subsequence implies
  unsolvability of extensions
• Test solvability at every step to avoid fruitless
  extensions
• Implementation by Corin and Etalle, U. Twente,
  Holland
• Significant speed improvement

A a1 -a2 a3 -a4
B -b1 b2 -b3
a1 -b1 b2 -a2 a3 -b3 -a4
Failure at a2 eliminates second sequence
a1 -b1 b2 -a2 a3 -a4 -b3
46
Phase II Constraint Set Solution
Initial constraint set
apply every possible transformation rule to first
mT where m is not a variable


No rule is applicable
var1 T1 varN TN
Simple set always satisfiable!
or
47
Some Transformation Rules
Synthesis Analysis
Other
x, y T (pair) x T y T
x y, z,T (split) x y, z, T

• x z, T
• (unify)
• ? unifies x, z
• partial solution

xy T (senc) x T y T
x yz, T (sdec) z yz, T x y,
z, T
x v, T (elim) x T if v is a variable
T is any set of terms yz is a marked
encryption to prevent rule looping (elim) rule
based on origination, monotonicity properties
48
Example CS Run in Prolog
semibundle(Sa,Sb,St) - strand(roleA,A,B,na
,Nb,Sa), strand(roleB,A,B,Na,nb,Sb), strand(te
st,nb,St). ?- semibundle(B),search(B,).
Trace recv(a,e) send(a,na
pk(e)) recv(a,na pk(b)) send(na,nb
pk(a)) recv(na,nb pk(a)) send(nb
pk(e)) recv(nb pk(b)) recv(nb)
49
AVISPA Tools and Interface
AVISPA members ETH Zurich On-the-fly model
checker (OFMC) constraint solver INRIA/CASSIS CAS
RUL (CL) U. Genova (SAT) model checker Also
Siemens AG
Spec in High Level Protocol Spec Language three
analyzers
50
Some New Directions

• Extension of decidable protocol analysis to
  (group) Diffie-Hellman and other
  associative-commutative operations
• At SRI and independently at INRIA
• Application of type theory to authentication
  protocol proofs
• Type-safe implies attacker-unsafe dependent
  types
• Abadi-Blanchet, Debbabi-Mejri, Jeffrey
• Derivation/composition of secure protocols
• Datta-Derek-Mitchell-Pavlovic
• Composition/transformation/refinement of
  functional components
• Proof rules based on cord calculus (something
  like strand space)
• Use of computationally ideal crypto primitives
• Backes-Pfitzmann-Waidner (IBM Zurich)
• Special crypto interface with implementation
  proved "ideal"
• Can we use these operations for Dolev-Yao
  analysis?
