High-Resolution TEM
Fumiyasu Oba
1/23/2003 TUG meeting
2
Outline

• Basics (phase contrast)
• Image simulation
• Microscope conditions alignments
• Important parameters
• Image recording on CCD

3
Imaging in TEM

• Contrast (intensity difference) on image plane
• Mass-thickness contrast (BF imaging)
• Diffraction contrast (BF, DF imaging)
• Phase contrast (HR imaging)

4
Phase Contrast (1)

• Phase (and amplitude) change by an object
  (potential).

Objective lens
Diffraction pattern
Plane wave
Spherical wave
Back focal plane (reciprocal space)
Specimen (real space)
Image plane (real space)
5
Phase Contrast (2)
Si lt110gt
q(x,y) A(x,y) exp(isjt(x,y))

• Specimen

jt(x,y)
s interaction constant
jt(x,y) projected potential
Image plane
y(x,y) F F q(x,y)T(u)
T(u) contrast transfer function
Intensity (image) I(x,y) y (x,y)2
In practice, phases and amplitudes are modulated
when passing through objective lens. This effect
is given by T(u) .
6
Contrast Transfer Function

• (Phase) contrast transfer function

T(u) exp (i c(u))
Or, its imaginary part T(u) sin(c(u))
c (u) p ( Df l u2 0.5 CS l3 u4 )
u spatial frequency
Df defocus value (lt0 underfocus)
l wave-length of electron beam
CS spherical aberration coefficient
7
Effective CTF

• Effective contrast transfer function
• Teff(u) T(u) Ec (u) Ea (u)
• Envelope damping functions
• Ec (u) Chromatic aberration envelope
• Electron beam energy spread
• Objective lens current spread
• Ea (u) Spatial coherence envelope
• Convergent angle

T(u)
8
Defocus Dependence of CTF

• Teff(u)E(u) sin(c(u)), c (u) p ( Df l u2
  0.5 CS l3 u4 )

Df Dfsch
Df 1.6 Dfsch
Df 0.33 Dfsch
Df 0
CTF significantly depends on defocus value.
9
Point Resolution
CTF at Scherzer defocus

• lt point resolution
• Phase contrast images are directly
  interpretable.
• gt point resolution
• Difficult to interpret because of the
  oscillation of CTF.

10
CTF of Tecnai F30 S-TWIN
CTF at Scherzer defocus (EMS software package)
1 / u
Information limit
- Teff(u)
Point resolution
u

• Point resolution 0.2 nm
• Information limit 0.14 nm

Cs1.2mm, Cc1.4mm Energy spread 0.7eV
11
Outline

• Basics (phase contrast)
• Image simulation
• Microscope conditions alignments
• Important parameters
• Image recording on CCD

12
Image Simulation (1)

• Why image simulations necessary?
• Specimens are not ideally thin.
• Multiple scattering complicates resultant
  images.
• Images significantly change with defocus values.
• If it is not close to Scherzer defocus, images
  are not directly related to atomic positions.

13
Image Simulation (2)

• Simulated images for Si lt110gt (Multi-slice, EMS)

Microscope parameters Tecnai F30 S-TWIN
Df (nm)
0
-120
-20
-40
-60
-80
-100
15
12
9
t (nm)
6
3
1.7Dfsch
Dfsch
0.33Dfsch
- Teff(u)
14
Outline

• Basics (phase contrast)
• Image simulation
• Microscope conditions alignments
• Important points
• Image recording on CCD

15
HRTEM Recommended Conditions (1)

• Mode TEM BF (microprobe)
• C1 aperture 2 mm (largest)
• C2 aperture 100/50 um (second/third largest)
• Objective aperture 100 um (largest)
• or, second largest ? (slightly larger than the
  point resolution)
• Extractor 3.5 - 4 kV
• Emission lt100 mA
• Gun Lens 1 - 3
• Spot size 1
• Magnification 500 kx to 750 kx
• gt 750kx for quantitative analysis of
  CCD-recorded images.
• Exposure time 3 - 5 seconds with emulsion
  setting 5.6
• lt 1.5 seconds to minimize the effect of
  specimen drift.

16
HRTEM Recommended Conditions (2)

• The spatial coherence is maximized while
  minimizing the energy spread in the beam.
• A beam is bright enough to allow a reasonable
  exposure time at high magnification.
• C2 aperture
• Smaller aperture ----- smaller beam size, higher
  coherency
• Effective when the specimen charges.
• (The total beam current on the specimen is
  reduced.)
• Larger aperture ----- larger beam size, lower
  coherency
• Effective when the specimen contaminates.
• (The edge of the beam can be far from the
  area of interest.)

17
Alignment Procedures
18
Astigmatism Correction (1)

• FFT pattern of amorphous area
• (Real-time processing on DigitalMicrograph)

Well aligned
Misaligned
19
Astigmatism Correction (2)
Defocus dependence of images from amorphous area
?f
Well aligned
LaB6
Misaligned
For FEG, astigmatism correction is difficult
without real-time FFT.
20
Beam Tilt Alignments

• Methods to locate the beam on (near) the
  optical axis.
• Current rotation center ----- by wobbling the
  objective lens current and minimizing image
  displacements.
• High voltage rotation center ----- by wobbling
  the high tension and minimizing image
  displacements.
• (N/A on Tecnai)
• Coma-free alignment (accurate) ----- by wobbling
  the beam tilt angle and minimizing focus
  difference.
• (Defocus values should be the same when beam is
  tilted with respect to the optical axis by the
  same angle with opposite sign.)

21
Current Center

• 1. Go to an area which has some feature.
• 2. Click Rotation center.
• Objective lens current is wobbled, and the image
  go through focus.
• 3. Make the sideways movement of the image as
  small as possible.
• The focus wobble can be made smaller or larger
  with the Focus Step Size knob.

22
Coma-Free Alignment (1)

• 1. Go to an amorphous area.
• 2. Click Coma-free alignment x or y.
• The beam is wobbled in the x or y direction by
  tiling beam.
• 3. Adjust the beam tilt until the images for both
  tilts have the same apparent defocus.
• Preparations
• Coma-free pivot points to minimize the movement
  of the beam under coma-free alignment conditions.
• Coma-free amplitude to adjust the tilt angle used
  for coma-free alignment.
• Astigmatism correction.

23
Coma-Free Alignment (2)

• Carbon foil images obtained at two different
  angles of the incident beam, before and after
  coma-free alignment.

Before
After
a
a
-a
-a
24
Effect of Beam Tilt on Diffractograms

• Diffractograms
• (FFT patterns of amorphous regions)
• Similar to the effect of astigmatism
• Astigmatism correction may be required after the
  alignment of beam tilt.

25
Suggested Alignment Procedures

• 1. Align beam tilt based on rotation center.
• 2. Correct astigmatism of objective lens.
• 3. Align beam tilt based on coma-free alignment.
• 4. Correct astigmatism (if necessary).

Readjustment of zone axis may be required after
the beam tilt alignment.
26
Outline

• Basics (phase contrast)
• Image simulation
• Microscope conditions alignments
• Important parameters
• Image recording on CCD

27
Important Parameters

• Microscope alignment
• objective lens astigmatism, beam tilt
• Thin Foil Specimen
• Thin area with minimal ion-thinning damage
• Zone axis
• Alignment for the area of interest

28
Thin Foil Specimen

• Make thin area with minimal ion-thinning damage.

hole
Damaged

• Finishing with low gun energy may be effective
• PIPS lt 2.5keV
• DuoMill lt 3keV ( liquid Nitrogen cooling stage)

29
Zone Axis

• Precise alignment for the area of interest is
  important when we are interested in atomic
  structure.

On zone axis
ZnO 0001
Off zone axis
5nm
30
Outline

• Basics (phase contrast)
• Image simulation
• Microscope conditions alignments
• Important parameters
• Image recording on CCD

31
Image Recording on CCD (1)

• CCD (charge-coupled device)

1 x 1 1024 x 1024 pixels (pixel size 25 x 25
mm)
32
Image Recording on CCD (2)
As recorded at 900kx
Resolution halved ? 450kx
InP lt110gt
Cu2O lt100gt
Image automatically smoothed on PowerPoint. See
raw image on another software.
1nm
For quantitative analysis, relatively high
magnification (900kx or 1.35Mx) is required.
