EEGNCSCI 660 Introduction to VLSI Design Lecture 4

1
EEGN-CSCI 660 Introduction to VLSI
DesignLecture 4

• Khurram Kazi

2
Review of ROM/RAM assignment
3
Signal Generator using Finite State Machine Method
4
Signal Generator using Finite State Machine Method
BEGIN wave lt temp PROCESS (clk,
reset) Begin IF (reset '0') then Wstate lt
zero ELSIF (clk'EVENT and clk '1') THEN CASE
Wstate IS WHEN zero gt temp lt '0'
Wstate lt one WHEN one gt temp lt '1'
Wstate lt two WHEN two gt temp lt '0'
Wstate lt three WHEN three gt temp lt '1'
Wstate lt four WHEN four gt temp lt '1'
Wstate lt five WHEN five gt temp lt '1'
Wstate lt six WHEN six gt temp lt '0'
Wstate lt seven WHEN seven gt temp lt '0'
Wstate lt zero END CASE END PROCESS END
finite_state_machine
library ieee use ieee.std_logic_1164.all ENTITY
signal_gen1 IS PORT ( clk IN STD_LOGIC
reset IN STD_LOGIC wave OUT
STD_LOGIC) END signal_gen1 Architecture
finite_state_machine OF signal_gen1 IS TYPE
states IS (zero, one, two, three, four, five,
six, seven) signal Wstate, states signal temp
STD_LOGIC
5
Clock divider
Bits change on every rising clock edge!
Do the clocks have to be 50 duty cycle? How
would you design a divide by 3 clock??
6
Serial to parallel conversion

• library ieee
• use ieee.std_logic_1164.all
• ENTITY ser_to_par is
• generic(N integer 8)
• port( clk in STD_LOGIC
• sin in STD_LOGIC
• resetb in STD_LOGIC
• par_dout out std_logic_vector
  ((n-1) downto 0))
• end ser_to_par
• architecture behavior of ser_to_par is
• signal par_reg std_logic_vector((n-1)
  downto 0)
• signal bit_counter integer
• signal shiftreg std_logic_vector
  ((n-1) downto 0)
• begin
• shiftin process (clk, resetb)
• begin

• Parallel_load_data process (clk, resetb)
• begin
• if (resetb '0') then
• par_reg lt (others gt '0')
• elsif rising_edge (clk) then
• if(bit_counter (n-1)) then
• par_reg lt shiftreg
• end if
• end if
• end process
• process (clk, resetb)
• begin
• if (resetb '0') then
• bit_counter lt 0
• elsif rising_edge (clk) then
• if (bit_counter n - 1) then
• bit_counter lt 0
• else

7
SONET Frame
8
SONET Framer

• Framing States within the SONET Framer
• Out of Frame (OOF)
• In this state when out of reset state and if
  contiguous 24 errored frames (i.e. 24 invalid
  framing patterns)
• Errored Frame (EF)
• In this state if 2 contiguous errored frames
  received (i.e. 2 invalid framing patterns)
• Severely Errored Frame (SEF)
• In this state if 4 contiguous errored frames
  received (i.e. 4 invalid framing patterns)
• In Frame
• When 2 contiguous valid frames received

9
Scrambling in SONET (STS-1)1 x6 x7 Why
scramble data?

• 1234567 datain dataout unscrambled data
• 1 1111111 1 0 1
• 2 0111111 1 0 1
• 3 0011111 0 1 0
• 4 0001111 0 1 0
• 5 0000111 0 1 0
• 6 0000011 1 0 1
• 7 0000001 1 0 1
• 8 1000000 1 1 1
• 9 0100000 1 1 1
• 10 0010000 0 0 0
• 11 0001000 0 0 0

On the receive side use the same circuit. The
receive data goes in the datain pin and the
original unscrambled data is extracted on
dataout. A1A2 Bytes are NOT scrambled
10
PRBS (Pseudo Random Binary Sequence)

• PRBS is a very powerful pattern generator and
  that can be self- checking on the receiving end.
• Use one of the PRBS pattern generator as the data
  source for the payload area within the SONET
  frame

11
Sample code of LFSR (3bit LFSR)

• LIBRARY ieee
• USE ieee.std_logic_1164.all
• USE ieee.std_logic_arith.all
• ENTITY lfsr IS
• PORT ( clk IN std_logic
• resetb IN std_logic
• lfsr_out OUT std_logic
• )
• END lfsr
• ARCHITECTURE behavior of lfsr IS
• signal lfsr_reg std_logic_vector (2 downto 0)
• signal tap1 std_logic
• BEGIN

Process (clk, resetb) BEGIN if (resetb '0')
then lfsr_reg lt (others gt '1')
--presetting the LFSR elsif (clk'event and clk
'1') then lfsr_reg lt lfsr_reg(1 downto 0)
tap1 end if end process tap1 lt
lfsr_reg(0) xor lfsr_reg(2) lfsr_out lt
lfsr_reg(2) END behavior
12
Data Com bytes (D1-D3)

• D1-D3 bytes are the 1st three bytes in the 3rd
  row of the STS-1 frame. These bytes are used as a
  192 kbps data channel for operations functions,
  such as Operations, Administration, Management
  and Provisioning (OAMP). These bytes are used
  between 2 section type equipment (like
  regenerator)

13
Data Com bytes D4-D12

• These bytes (1st three bytes of rows 6,7 and 8)
  represent a 576 kbps message-based channel used
  for OAMP messages between SONET line-level
  network equipment.

14
Clock generator block

• Input serial clock
• Internal byte_clock also output clock (spe_clk)
• D1_3_clock
• D4_12_clk
• All the clocks going to different blocks need to
  be generated from this block

15
Some recommendation for test benches (package)

• Package package_name IS
• (package delcrations)
• End package_name
• e.g.
• PACKAGE SONET_Pkg IS
• Signal tb_d1Byte std_logic_vector (7 downto 0)
• Signal tb_d2Byte std_logic_vector (7 downto 0)
• Signal tb_d3Byte std_logic_vector (7 downto 0)
• Signal tb_d4Byte std_logic_vector (7 downto 0)
• Signal tb_d5Byte std_logic_vector (7 downto 0)
• Signal tb_d6Byte std_logic_vector (7 downto 0)
• Signal tb_d7Byte std_logic_vector (7 downto 0)
• Signal tb_d8Byte std_logic_vector (7 downto 0)
• Signal tb_d9Byte std_logic_vector (7 downto 0)
• Signal tb_d10Byte std_logic_vector (7 downto
  0)
• Signal tb_d11Byte std_logic_vector (7 downto
  0)
• Signal tb_d12Byte std_logic_vector (7 downto
  0)
• END SONET_Pkg

1) write this package in a vhdl file, e.g.
SONET_Pkg.vhd. 2) Compile the package vhdl
file 3) Include under the library
declarations USE work.SONET_Pkg.all
16
Suggested pinout of the Framer
17
Block diagram of the Framer Receiver direction
18
Block diagram of top.vhd
Declare signals in framer_pkg.vhd Drive the
signals in generator Monitor the signals in
analyzer to see whatever OHs received matched the
values in the generator
19
Some recommendation for test benches

• Use global signals to pass information between
  the generator to the data analyzer. These global
  signals can be used to control the pattern
  generators as the simulation progress.
• Use some sort of timestamp to keep track of
  events. For example use frame counter (in the
  test bench) to keep track of data sent a
  particular frame and use that information during
  the self checking of the output data!

20
Assignment

• InFrame in frame
• EF Errored Frame 2 contiguous invalid framing
  pattern
• SEF Severely Errored Frame 4 contiguous
  invalid framing pattern
• OOF out of Frame 24 contiguous invalid
  framing pattern
• Extend SONET Framer to incorporate four states of
  the framer
• 1) In-Frame state, 2) EF, 3)SEF, 4) OOF
• USE concept developed in slide 13 (lecture 4) to
  define these states
• Extend the SONET Framers testbench to
  incorporate
• Generate SONET valid SONET frames (i.e. proper A1
  A2 Byte contents of F6 28) for at least 3 frames
• Generate 4 contiguous invalid framing pattern (by
  changing different bits inside the A1 or A2 byte)
• This will result in SONET Framer detecting EF and
  SEF States
• Continue generating invalid framing pattern for a
  total of 24 frames
• This will result in SONET Framer going into OOF
  state
• Add to the framers port list
• InFrame, EF, SEF and OOF. Each will be a
  std_logic.
• Assert these ports high whenever the framer is in
  the respective state.

21
Assignment

• After acquiring frame
• Convert serial data into parallel data
• Store the Over Head portion of data into a RAM
• 8 bit data should be written to the RAM at a
  time.

22
Assignment

• Use the SONET scramble to scramble the data
  (except A1 and A1 bytes)
• Use PRBS pattern generator to insert in the 3
  Data Com bytes D1-D3 byte positions
• Take first 9 characters of your name and convert
  them into ASCII (bit value). Insert those values
  in the D4-D12 byte positions.
• The D1-D3 and D4-D12 data should come out on
  separate serial ports along with 192 kbps and 576
  kbps clock. The firs byte should be indicated by
  a start of frame signal. (3 ports per Data com
  bytes should be output ports from your block,
  therefore total of 6 output ports)

23
How do I get started (1)?

• 1) Look for the framing pattern
• Design a bit counter that rolls over every 8th
  cycle (i.e. it goes from 0 7 and then back to 0
• Design a byte counter that counts from 0 809
  and rolls over back to 0
• The starting values of both the bit and byte
  counters should coincide with every occurrence of
  the framing pattern to ensure that the framing
  pattern comes in at the desired expected bit
  count value/byte count value

24
How do I get started (2)?

• Develop a state machine that has the states
• In-frame state (go in this state if two
  consecutive valid frames are received)
• Errored Frame (EF) state go in this state if 2
  contiguous errored frames received (i.e. 2
  invalid framing patterns)
• Severely Errored Frame (SEF) state go in this
  state if 4 contiguous errored frames received
  (i.e. 4 invalid framing patterns) are received
• Out of Frame (OOF) state go in this state when
  out of reset state and if contiguous 24 errored
  frames (i.e. 24 invalid framing patterns)

25
How do I get started (3)?

• Normal operation of data occurs when the device
  goes from OOF to Inframe-state
• Store the Overhead bytes (OH) in the RAM after
  they have been received serially and subsequently
  converted into parallel (8 bits).
• At a later time of receiving the OH bytes read
  the data from the proper RAM location (read in 8
  bits at a time).
• Convert 8 bits into serial form
• Transport the serialized bit out of the
  appropriate ports (e.g. d1_d3_dataout, and
  d4_d12_dataout)
• Transport spe_dataout(70) as soon as the data is
  converted from serial to parallel

26
What are the basic components I need to get
started?

• Bit counter
• Byte counter
• Serial to parallel converter
• Parallel to serial converter
• Framing state machine that has the states defined
  in 2 of How do I get started?
• Clock generation blocks
• Refer to 17 for more blocks needed in the design.
