1What Do We Know About Cervical Cancer, HPV and
HPV Vaccines ?
- Ricky Lu
- Amy Kleine
- MAQ Mini-University
- 5 October 2007
2Global Incidence of Cervical Cancer
Incidence /100,000 women
- 470,000 New Cases
- 235,000 Deaths
- 80 in Developing Countries
Globocan 2002
3What and Where is the Cervix ?
Squamous epithelium lining
Transformation Zone
Cervical Opening
Columnar epithelium lining
Squamocolumnar Junction-SCJ
4What is Cervical Cancer?
- Starts in lining of cervix
- Gradual development from precancer
- Good prognosis with early diagnosis and
treatment - Stage 1 - 80-90
- Stage 2 50-65
- Treatment
- Surgery
- Radiotherapy
- Chemotherapy
- Squamous Cell Carcinoma (SCC)
- 80-90 of Cervical Cancer
- Squamous cells covering the cervix
- Starts at the Squamocolumnar junction
- Adenocarcinoma
- 10-20 of Cervical cancer
- Mucus producing cervical cells
5Human Papillomavirus (HPV)
- DNA VIRUS
- Preferentially infect squamous epithelial cells
- 100 genotypes
- 40 genital HPV types
6Genital HPV Types and Outcomes
Uncertain cancer potential HPV 26, 34, 53, 57,
66, 83
7Epidemiology of HPV
- The most common STI worldwide
- 80 sexually active adults in the US infected
with at least one HPV type by age 501 - Peak prevalence during adolescence and young
adulthood - Prevalence decreases with age
- HPV 16 is the most common HR type (HPV 16/18
account for 70 of cervical Cancer) - Centers for Disease Control and Prevention.
Rockville, Md CDC National Prevention
Information Network 2004
8 HPV Test
John Sellors, PATH, 2007
9Natural History of CIN and Cervical Cancer
10Link between HPV and HIV Infections
- Different natural history for HPV infection in
HIV sero women- it is more - Prevalent across age groups
- Persistent
- Likely to develop dysplasia
- High grade dysplasia/cancer stage
- Likely not to survive their cancer
- Persistence of HPV Infection in HIV Sero women
- HIV infection affects cell-mediated immunity
- 6-18 x likely to persist
- Lower CD4 cell counts is a risk factor for
persistence (HPV DNA clearance unlikely in CD4
cell count - Inherent interaction between HPV and HIV
infection?
Shaun Biggers, 2000Moscicki et al., 2000
11Cervical Cancer is Preventable
15
30
45
12Cervical Cancer Prevention Options
- Primary Prevention
- Behavioral Interventions
- Prophylactic Vaccines
- Quadrivalent or GARDASIL(HPV 6/11/16/18)
- Bivalent or CERVARIX (HPV 16/18)
- Vaccinated women will still be at risk for
contracting other high-risk HPV types - Secondary Prevention
- Screening
- Cytology based
- Unaided Visual Inspection
- Magnified Visual Inspection
- HPV Test
13HPV VACCINES CHARACTERISTICS
14HPV vaccines Key findings
- Vaccines efficacy extremely high against HPV
vaccine-type disease in HPV naive women - Vaccines are much less effective in non-naïve or
women already exposed to HPV types 16/18, - For the both vaccines, partial protection against
new infections by two other types has been
reported - Types 31 and 45
- Good antibody persistence for 5 or more years
- Acceptable safety profile
15Considerations for Introducing HPV Vaccine
- Affordability
- Healthcare infrastructure
- Capacity to initiate and sustain vaccination
- Cost effectiveness
- Cultural Acceptability
- Political Will
- Public Support
- Capacity for secondary prevention-screening and
treatment - Agnosti and Goldie, 2007
16Key Research Questions
- How to motivate parents and teens for
vaccination? - Community-based or school-based delivery?
- What is the best age for community-based
delivery? - What is the best school-based delivery strategy?
- Alternate dose schedules?
- Two doses only?
- What lessons can be learned for eventual HIV
vaccine introduction?
Scott Wittet, PATH 2006-2011 Cervical cancer
Vaccine project
17Is Secondary Prevention Still Needed As Vaccines
Become Available
- Vaccine may not be available in communities and
countries most affected by cervical cancer (for a
long while). Many competing health priorities - Reaching pre-adolescents is problematic. School
health programs are non existent and do not reach
more the 60 of girls out of school anyway. - Early age of sexual debut and some uncertainty on
how long vaccine effectiveness will last. - Vaccine is only highly effective if all doses
completed. Long term follow up is currently a
significant challenge for all public heath
programs that require return visits.
18What women in the US and other developed
countries have had for 30 years since, women in
Africa, Latin America and Asia can have now
The right to protect themselves from cervical
cancer !
19The Single Visit Approach (SVA) to Cervical
Cancer Prevention using Visual Inspection with
Acetic Acid (VIA) and cryotherapy
20(No Transcript)
21Limitations of Pap Smear
- Complex laboratory test
- (sampling instruments, slides, fixatives,
reagents, cover slips, processing equipment,
microscopes,) - Requires trained cytotechnician for reading and
pathologist for review - Continuous monitoring needed to maintain
high-quality results - Reports often take 1 week to 3 months to obtain
- Follow-up of women is difficult
- Usually available only in large cities in many
countries
22What Is VIA?
- Looking at the cervix to detect abnormalities
after applying dilute (3-5) acetic acid
(vinegar). - Acetic acid enhances and marks a precancerous
lesion or cancer by turning it a whitish hue
(acetowhite change).
White Lesion
Normal (No White lesion)
23Why VIA is a Practical Alternative to Pap Smears
- Safe, easy to perform and inexpensive
- Can be learned by all types of healthcare
professionals - All equipment and supplies are available locally
- Results are available immediately
- Potential for immediate link to outpatient
treatment - Suitable for lowest-resource settings
24VIA Test Qualities
Test qualities are similar to Pap Smear
25SAFE Demonstration Projects Conclusions
- The Single-Visit Approach using VIA and
Cryotherapy is - Safe for testing and treating women at district
hospitals and in primary health care facilities, - Acceptable to both patients and providers,
- Feasibleas well as cost effectivefor use in
low-resource settings. - Based on results of SAFE Demonstration Projects
conducted between 2000 and 2002. - Thailand 6000 women tested, 13 VIA-positive
- Ghana Urban 4089 women tested, 12 VIA-positive
- Ghana Rural 1437 women tested, 8 VIA-positive
26Long-Term Impact of VIA screening
- Effect of visual screening on cervical cancer
incidence and mortality in Tamil Nadu, India a
cluster-randomised trial (Lancet 2007
370398-406) - Published by group from International Agency for
Research on Cancer (IARC) - KEY FINDINGS
- Cervical cancer burden was reduced by a single
round of VIA screening. 25 reduction in
incidence and 35 reduction in mortality. - All-cause mortality was significantly reduced in
the intervention group compared to the controls. - VIA screening, in the presence of good training
and sustained quality assurance, is an effective
method to prevent cervical cancer in developing
countries.
27Elements of Successful Screening Program
Source Max Parkin, IARC
28Outpatient Treatment Options
Low
1500 1 Loop electrosurgical excision procedure.
29Single Visit Approach Steps
- 1 Counseling
- 2 Speculum Exam to see Cervix
- 3 Apply 3-5 Acetic Acid to Cervix
- 4 Inspect Cervix for lesions
- 5 Discuss results with the woman. Offer
treatment option if positive
30Single Visit Approach Steps
- 6 Speculum exam to re-view cervix
- 7 Apply Cryoprobe and freeze for 3 minutes
- 8 Defrost for 5 minutes
- 9 Re-freeze for 3 minutes
- 10 Post treatment and followup instructions
Cryotherapy Before and After
31CECAP Country Programs
- Thailand
- Ghana
- Malawi
- Philippines
- Indonesia
- South Africa
32Malawi Experience
33Thailand Experience
34Take Home Messages
- Cervical cancer is a burden for women in
developing countries - Cervical cancer deaths are highly preventable
- Persistent, chronic HPV infection leads to
cervical cancer - HIV infection increases the risk of Cervical
Cancer - HPV vaccine is highly effective in naïve females
for High Risk HPV types 16/18 - Screening services will continue to be needed
even for vaccinated women - Every woman needs to be screened at least 1x in
her lifetime
