CAR NAVIGATION

1
CAR NAVIGATION MULTIMEDIA SYSTEMStage 2
product
Wireless Integrated
2

• Car Navigation Multimedia System
• Features
• TFT Touch screen Multimedia Menus
• GPS maps Guidance
• Voice Navigation
• Complete Car PC Car office
• Multimedia DVD Movies Video
• MP3 Player
• Mobile Internet e-mail
• Real Time News Information
• City Guide
• DTH/Dish TV
• Vehicle Rear View Camera Parking assistance
• Voice recorder Hidden Camera
• DVR Server
• Language options
• Laptop data connectivity Sync.
• Wireless LAN, Ethernet, USB Bluetooth
  connectivity options

3
Block Description
USB/ PCMCIA/ RJ45/ VGA
USB/ RS232/ PS2
GSM/GPRS
Wi-Fi/Bluetooth
GPS
Ethernet
Camera
Extra USB Ports
CPM
Mic
Vehicle CPU
Speakers
Memory
VGA
Power Supply
TFT LCD with Optional Touch Screen
DVD Drive
Dish TV Antenna
Touch Screen
Navigation Kit
4
Casing Design options
63.5mm(H) x 273mm(D) x 295mm(W)
65mm(H) x 210mm(W) x 274mm(D)
5
TFT LCD options
6
System Components
WiFi/Bluetooth receiver
GSM Modem
Camera
Hands Free kit
GPS Receiver
7
Software systems

• Menu Browsing system and Car PC Manager
• GPS Navigation software
• Voice Navigation manager
• Multimedia manager for DVD, MP3
• Device Manager (manage all devices connected,
  their settings, configuration, automation
• Camera parking assistance Manager
• DVR, Spy Cam Mic Manager software
• Video Conference Manager
• Windows OS is used

8
Car Anti-theft RF Security system design and
development is identified by us as a independent
task. We will define this system in other
presentation. Stage 1 Product presentation is
still under development but as per our analysis,
we can develop Stage 2 project faster, hence we
have made its presentation first.
9
Project views

• We have studied your requirements and identified
  a development strategy
• Work involve Design, Sourcing, Assembling,
  Software development, Testing
• Power supply management, Vibration proof design,
  Compact design, Complete Multimedia experience,
  GPS Navigation are considered important critical
  systems
• We can develop this system in 2-3 stages with
  Important hardware and software first. First
  Production ready prototypes stage delivery can
  come within 2-3 months which shall include GPS
  Navigation and basic system architecture.
• Most part in this system will be sourced from
  OEM manufacturers , these parts will be tested
  production parts and once developed , the product
  can be immediately manufactured in large volumes.
• Most software will be developed by us, though we
  will also suggest many ready software for GPS
  Navigation and other systems. Few software needs
  to be custom developed

10
Further Steps

• We would like you to review our presentation and
  views
• Basic product options have been already
  presented
• We would like you to prioritize important
  options for your customers
• After this we will analyze and provide you price
  quotation for various modules
• We will also provide you approx. price points
  that can be achieved for production of these
  units
• All designs, BOMs, software will be owned by you
• In case you have some Budget allocations and
  time schedule for these development, we would
  like to know.
• Can we know how much time it will take you to
  finalize for the project after getting such
  quotations
