Design of Digital Operating Procedure for FuQing NPP

1
Design of Digital Operating Procedure for
FuQing NPP
Zhang Li General Design Department
2008-11-05
IAEA
Technical Meeting on Impact of Digital IC
Technologies on the Operation and Licensing of
NPPs
2
contents
Design of Digital Operating Procedure for FuQing
NPP

• 1 Background
• 2 Development of the NPP procedure
• 3 Development of Emergency operating procedure
• 4 Implementation of the digital operating
  procedure
• 5 Conclusions

3
1 Background
Design of Digital Operating Procedure for FuQing
NPP

• 1 Background
• Fuqing NPP Phase I is a Standardized 3-loop
  1000MWe Pressurized Water Reactor, which designed
  and constructed by China Nuclear Power
  Engineering CO. Ltd. (CNPE).
• It is the first EPC project of CNPE.
• The First Concrete Date (FCD) of Unit 1 is on 18
  October, 2008.

4
1 Background
Design of Digital Operating Procedure for FuQing
NPP

• 1 Background
• It will use the digital technology for IC system
  and advantage main control room (MCR) design.
• The main operating procedures are based on
  computerized operating procedure (digital
  operating procedure).

5
2 Development of the NPP procedure
Design of Digital Operating Procedure for FuQing
NPP

• 2.1 The classification of Fuqing NPP Operating
  procedure
• Operating procedures shall be developed
  which apply comprehensively for normal, abnormal
  and emergency conditions, in accordance with the
  policy of the operating organization and the
  requirements of the regulatory body.
• ---- Based on the requirement of HAF
  103Safety code for nuclear power plant
  operation, Nuclear Safety Regulations of PRC

6
2 Development of the NPP procedure
Design of Digital Operating Procedure for FuQing
NPP

• 2.1 The classification of Fuqing NPP Operating
  procedure

7
2 Development of the NPP procedure
Design of Digital Operating Procedure for FuQing
NPP

• 2.2 Development of the NPP procedure in using
  digital technology Development of the NPP
  procedure
• There are three possible options regarding
  the computerization of operating procedure usage
  in the main control room
• Full paper procedures, no computerization
• Stand-alone computerized procedures
• On-line computerized procedures.

8
2 Development of the NPP procedure
Design of Digital Operating Procedure for FuQing
NPP

• 2.2 Development of the NPP procedure in using
  digital technology Development of the NPP
  procedure
• A stand-alone computerized version does not bring
  much advantage compared to the paper version. The
  operator is still in charge of reading and
  understanding the procedures on the computer and
  of collecting the necessary plant information.
• On-line computerized procedure can markedly
  improve the use of the operating procedures. The
  detailed procedure displays could indicated the
  currently status of the procedure step and the
  related necessary information of plant states, it
  can reduce the work load of operator and the
  operating risk in NPP.

9
2 Development of the NPP procedure
Design of Digital Operating Procedure for FuQing
NPP

• 2.2 Development of the NPP procedure in using
  digital technology Development of the NPP
  procedure
• Up to now, as the digital technology
  implement is not so normal and maturity in NPP of
  the world, the main operating procedures is Full
  paper procedures or Stand-alone computerized
  procedures, just N4 NPPs apply computerized
  procedures in France.
• Especially in China, it is a new projects
  that how to development the NPP procedure in
  using digital technology.

10
2 Development of the NPP procedure
Design of Digital Operating Procedure for FuQing
NPP

• 2.2 Development of the NPP procedure in using
  digital technology
• Digital NPP has the characteristic of more
  safety, reliability and maintenance, and as the
  using of digital technology, it is possible to
  design in the advantage digital main control
  room.
• It can provide more safety, facility,
  redundancy operating mode and information for
  NPP.

11
2 Development of the NPP procedure
Design of Digital Operating Procedure for FuQing
NPP

• 2.2 Development of the NPP procedure in using
  digital technology Development of the NPP
  procedure
• It is important to consider the following
  items which operating procedure adaptation with
  the digital technology and advantage main control
  room
• The digital operating procedure should adapt with
  the classification of operating procedure in NPP,
  should include normal operating procedures,
  abnormal operating procedures, accident
  procedures, etc.

12
2 Development of the NPP procedure
Design of Digital Operating Procedure for FuQing
NPP

• 2.2 Development of the NPP procedure in using
  digital technology Development of the NPP
  procedure
• (2) The digital operating procedure should
  adapt with the system of management in NPP
• There is strict management in NPP, such
  as
• Distribution and the responsibilities management
  of roles in control room
• the revision validity management of the procedure
• the modification management of the procedures

13
2 Development of the NPP procedure
Design of Digital Operating Procedure for FuQing
NPP

• 2.2 Development of the NPP procedure in using
  digital technology Development of the NPP
  procedure
• The digital operating procedure should adapt with
  the Human system interface
• Human system interface is importance in
  the design and operation of nuclear facilities.
• During normal operating, abnormal
  operating and accident states, the HSI ensure the
  safety of NPP operation and protecting the
  environment from potential hazards.

14
2 Development of the NPP procedure
Design of Digital Operating Procedure for FuQing
NPP

• The digital operating procedure should adapt with
  the Human system interface
• It is provided for operators that control
  consoles, control panels, switches, pushbuttons,
  indicators, registers and alarm windows in main
  control room in the traditional NPP.
• The operator can operate the actuator and
  detect the information at the fixed place
  directly, but as the limit of space in MCR, most
  of the information and alarms are grouped, it is
  not use for the operator to confirm the
  integrated information of plant states at once.
• On the other hand, as the operator should
  go around in front of the consoles and panels
  during operation, it is also not so convenience
  for the operation.

15
2 Development of the NPP procedure
Design of Digital Operating Procedure for FuQing
NPP

• The digital operating procedure should adapt with
  the Human system interface
• Within Fuqing NPP, the majority of plant
  systems will be controlled and monitored on
  computerized work station (visual display units
  VDUs).
• The operator could implement most of the
  operation in one work station , and also the
  operator could use a number of these human system
  interface (HSI) systems, including Back up panel
  (BUP), Emergency control panel (ECP), Large
  display panel (LDP), etc.

16
2 Development of the NPP procedure
Design of Digital Operating Procedure for FuQing
NPP

• The digital operating procedure should adapt with
  the Human system interface
• So the operator can get more information
  and more convenience for operation.

17
2 Development of Emergency operating procedure
Design of Digital Operating Procedure for FuQing
NPP

• 3 Development of Emergency operating procedure
• Historically, the first sets of emergency
  procedures used at nuclear power plants before
  the Three Mile Island (TMI) accident and
  Chernobyl accident, consisted entirely of event
  based procedures.

18
2 Development of Emergency operating procedure
Design of Digital Operating Procedure for FuQing
NPP

• 3 Development of Emergency operating procedure
• In modern EOP packages -Symptom/state
  based procedures, due to the evolving industry
  insights, industry operating experience (e.g.,
  TMI, Chernobyl, etc.) and human factors studies,
  symptom/state-based procedures were developed.

19
2 Development of Emergency operating procedure
Design of Digital Operating Procedure for FuQing
NPP

• 3 Development of Emergency operating procedure
• Symptom/state based procedures is
  continuous or repetitive diagnosis, which helps
  to correct any initial misdiagnosis and to ensure
  that the operators respond to changing plant
  conditions that could be more threatening to the
  core integrity than the initial event.
• Experience indicates that events can also
  evolve differently than predicted by pure
  analysis because they can evolve into a
  combination of events and operator errors over
  time.

20
2 Development of Emergency operating procedure
Design of Digital Operating Procedure for FuQing
NPP

• 3 Development of Emergency operating procedure

21
2 Development of Emergency operating procedure
Design of Digital Operating Procedure for FuQing
NPP

• 3 Development of Emergency operating procedure
• The reference design of Fuqing NPP is
  LingAo NPP.
• The EOP of LingAo NPP combined
  event-oriented and state-oriented approaches.

22
2 Development of Emergency operating procedure
Design of Digital Operating Procedure for FuQing
NPP

• 3 Development of Emergency operating procedure
• Event-Oriented Approach for DBA, starting
  from one initial diagnosis, in applying a
  predetermined operating strategy. These
  procedures are not designed to cover simultaneous
  equipment or human faults, includes
• I (Incident) procedures
• A (design based accidents) procedures
• H (beyond design based accidents) procedures

23
2 Development of Emergency operating procedure
Design of Digital Operating Procedure for FuQing
NPP

• 3 Development of Emergency operating procedure
• State-oriented approaches used in
  ultimate procedures and accident permanent
  monitoring procedures, includes
• U (Ultimate conditions)-initiated by safety
  engineer
• such as U1 Ultimate core safeguard
  procedure
• SPI/SPU ( safety function control, is redundancy
  to above)- initiated and executed by safety
  engineer

24
2 Development of Emergency operating procedure
Design of Digital Operating Procedure for FuQing
NPP

• 3 Development of Emergency operating procedure
• And now, the EOP of Fuqing NPP prefer to
  use Generalized State Approach procedures as the
  implement of digital technology.

25
4 implementation of the digital operating
procedure
Design of Digital Operating Procedure for FuQing
NPP

• 4 Implementation of the digital operating
  procedure
• The key point of the implementation
• Development of operating strategies and validity
  of the strategies
• Adaptation of digital technology
• Verification and Validation of procedures and
  rules

26
4 implementation of the digital operating
procedure
Design of Digital Operating Procedure for FuQing
NPP

• 4 implementation of the digital operating
  procedure
• The solution of implementation
• Through safety analysis, probabilistic safety
  assessment (PSA), plant operating experience and
  engineering insights to confirm the correctness
  of strategies
• Taking advantage of the digital technology and
  system, according to the requirements of
  procedure, set up correctness of digital
  guideline, include the computerized method of
  procedure, defined the operating display, etc.

27
4 implementation of the digital operating
procedure
Design of Digital Operating Procedure for FuQing
NPP

• 4 implementation of the digital operating
  procedure
• The solution of implementation
• As the digital operating procedures use a new
  human system interface with computer work
  station, it is different to the papered
  procedures. The written correctness, technical
  accuracy and usability of the procedures should
  be VV. The simulator and review of operation
  experts, designer and analysis would be a better
  way.

28
5 Conclusions
Design of Digital Operating Procedure for FuQing
NPP

• 5 Conclusions
• As the development of operating procedure and the
  utilization of digital technology, it is more
  safety, reliability and convenient of the digital
  operating procedures than the papered operating
  procedure.
• (2) The development of digital operating
  procedure depends on the international criteria
  regarding operating procedure development, the
  study of operating strategies, design
  modifications, the digital technology, the
  upgrade human system interface, review of the
  plant operating experience from internal and
  external, and the procedure Verification
  Validation.

29
5 Conclusions
Design of Digital Operating Procedure for FuQing
NPP

• 5 Conclusions
• The implementation of digital operating procedure
  can upgrade the NPPs safety and reliability, and
  reduce the operator load, it will take enhance
  sociality and economical benefit for Fuqing NPP.
• Development of the digital operating
  procedure will be the object of the digital NPP
  in the future.

30
Design of Digital Operating Procedure for FuQing
NPP
Thanks for your attention!
