VentilationPerfusion Relationships in the Lung

1
Ventilation/Perfusion Relationships in the Lung
Experimental Biology Refresher Course

• Robb Glenny, M.D.
• University of Washington

2
Overview of Approach

• Review nomenclature and abbreviations
• Begin with lung as single unit
• Relationships between PO2, PCO2, alveolar
  ventilation, and blood flow
• Alveolar gas equation
• No Alveolar-arterial differences in PO2
• Introduce additional lung units with mismatch
  between V and Q
• Alveolar-arterial differences in PO2

3
Overview of Approach

• Discuss passive and active mechanisms matching
  regional V and Q
• Provide clinical examples

4
Schematic lung unit

VA
(ml/min)
Mixed venous
PA
Pa Ca

Q
(ml/min)
5
Nomenclature
gas
PAO2
Partial Pressure
Alveolar
CvO2
venous
Content
PaCO2
arterial
FIO2
Fraction
inhaled
6
PAO2

Q

Q
where PB is barometric pressure
7


Q
PACO2
8
(No Transcript)
9
Alveolar PO2 and PCO2

• Determined by the ratio between ventilation and
  blood flow V/Q.
• PO2 and PCO2 are inversely related through
  alveolar ventilation.
• Increasing V/Q produces higher PAO2 and lower
  PACO2.
• Hyperventilation defined as PACO2 lt 40
• Decreasing V/Q produces lower PAO2 and higher
  PACO2.
• Hypoventilation defined as PACO2 gt 40

10
Alveolar Gas Equation

VO2
PAO2 PIO2 -
PB

VA

PaCO2
where R is respiratory quotient
11
Hypoxemia

• Less than normal partial pressure of Oxygen in
  arterial blood
• Normal PaO2 90 mmHg
• Age dependent
• 70 mmHg at 70 years of age
• Five causes of hypoxemia
• 2 are due to decreased alveolar PO2

12
Low PIO2 -gt hypoxemia

• Altitude
• FIO2 0.21 everywhere
• Barometric pressure (PB)
• Seattle 760 mmHg
• Denver 630 mmHg
• Mt. Rainier 430 mmHg
• Mt. Everest 225 mmHg
• PAO2 30 mmHg on Rainier without compensatory
  mechanisms

13
Compensation for Altitude
PaO2

PaCO2
14
Hypoventilation ?hypoxemia
PAO2
PaO2

Q
15
Alveolar-arterial O2 difference

• One measure of efficiency of gas exchange across
  alveolar-capillary membrane.
• Helpful in determining cause of hypoxemia and
  making clinical decisions.
• In conditions where hypoxemia is due to low
  alveolar PO2, the A-a O2 difference is normal.

16
where CC is content in end capillary blood
PvO2
PAO2
PAO2
17
Ventilation-Perfusion Mismatch

• Differences in airway geometry and lung expansion
  produce uneven regional ventilation.
• Differences in vascular geometry and hydrostatic
  pressures produce uneven regional blood flow.
• V/Q ratios vary across regions within normal
  healthy lung.
• Pathologies that lead to regional changes in
  ventilation (e.g. asthma) or changes in perfusion
  (e.g. pulmonary embolism) will increase V/Q
  mismatch.

18
(No Transcript)
19
Dead space
Shunt
20
(No Transcript)
21
Review/Introduce

• Partial pressures of O2
• Content of O2
• Hgb-oxygen dissociation curve
• Determinants of Alveolar PO2 and PCO2.

22
(No Transcript)
23
Hemoglobin-Oxygen Dissociation Curve
Plasma without Hgb
24
PO2 100
PO2 40


Vol. 1 liter Hgb 15 gm/dL sat 70 CO2
14.8 ml/dL O2 148 ml
Vol. 1 liter Hgb 15 gm/dL sat 98 CO2
20.7 ml/dL O2 207 ml
Vol. 2 liters Hgb 15 gm/dL O2 355 ml CO2
17.7 ml/dL sat ? PO2 ?
25
(No Transcript)
26
PO2 100
PO2 40


Vol. 1 liter Hgb 15 gm/dL sat 70 CO2
14.8 ml/dL O2 148 ml
Vol. 1 liter Hgb 15 gm/dL sat 98 CO2
20.7 ml/dL O2 207 ml
Vol. 2 liters Hgb 15 gm/dL O2 355 ml CO2
17.7 ml/dL PO2 52 sat 82
27
PvO2
CvO2
PcO2PvO2
CcO2 CvO2
PcO2
CcO2
PaO2
CaO2
28
Shunt
CaO2 is a weighted average of the venous and
capillary O2 contents
CaO2 Qs/Qt CvO2 (1-Qs/Qt) CcO2
Shunt
Non-shunt
Where QS is blood flow through shunt regions of
lung and QT is total blood flow through lungs
29
Formal Shunt Equation
Measure CvO2 and CaO2 Estimate CcO2 from alveolar
gas equation
30
Normal Shunt Fraction

• Normal shunt 5.
• venous return from bronchial circulation
• Thebesian veins in haert
• Normal A-aO2 difference 10 mmHg (age dependent).

31
Increased FIO2 in Shunt

• Arterial PO2 increases little with increased FIO2.

32
PIO2 150 mmHg
PvO2 40 mmHg
CvO2 15ml/dl
PAO2 100
PvO2 40 mmHg
CvO2 15ml/dl
PcO2 100
CcO2 20 ml/dl
PaO2 54 mmHg
CaO2 17.5 ml/dl
33
PIO2 713 mmHg
PvO2 40 mmHg
CvO2 15ml/dl
PAO2 673
PvO2 40 mmHg
CvO2 15ml/dl
PcO2 673
CcO2 22 ml/dl
PaO2 70 mmHg
CaO2 18.5 ml/dl
34
Confirming Quantifying Shunts

• Bubble study
• immediate intracardiac
• 4 beats intrapulmonary
• Perfusion scan
• more sensitive
• quantitative
• Clinical significance
• CNS emboli

35
Shunt recap

• Blood that does not exchange gas.
• Normal shunt fraction 5
• Shunt contributes to hypoxemia.
• Pathologic conditions include pneumonia,
  atelectasis, and intracardiac shunts
• Little change in PaO2 with increasing FIO2.

36
(No Transcript)
37
Increased FIO2 in V/Q mismatch

• V/Q mismatch can be differentiated from shunt by
  the response to increasing FIO2.

38
PIO2 713 mmHg
PvO2 40 mmHg
CvO2 15ml/dl
PAO2 500 mmHg
PAO2 673
CvO2 21ml/dl
PcO2 673
CcO2 22 ml/dl
PaO2 600 mmHg
CaO2 21.5 ml/dl
39
Ventilation-Perfusion Mismatch

• Regional V/Q ratios vary throughout lung
• Pathologic conditions include asthma, emphysema,
  and atelectasis
• Low V/Q regions contribute to hypoxemia.
• Hypoxemia responsive to increasing FIO2.
• Regions with V/Q gt 1.0 do not contribute to
  hypoxemia.

40
Effect of Dead space on PaO2
PIO2 150 mmHg
PvO2 40 mmHg
PAO2 150
PAO2 100
PcO2 100
PaO2 100 mmHg
CcO2 20 ml/dl
CaO2 20 ml/dl
41
Mechanisms matching regional V and Q

• Passive
• shared effect of gravity
• both V and Q increase down the lung
• shared geometry of airways and vasculature
• airways and pulmonary arteries branch together
• Active
• hypoxic pulmonary vasoconstriction
• crucial role in diseased lungs
• ? role in healthy lung

42
Hypoxic Pulmonary Vasoconstriction
43
Five Causes of Hypoxemia
44
Hypoxemia
? (A-a)O2 difference
Normal
Increased
FIO2 1.0
Hypoventilation or Altitude
responsive
?response
Shunt
Low V/Q
45
Clinical correlates

• 24 year old man found down in street minimally
  responsive, transported to ER.
• RR 12 b/min, HR 96 b/min, BP 90/60 mmHg, Hgb-O2
  sat 86
• Arterial blood gas PaO2 55 mmHg, PaCO2 70
  mmHg.

46
Hypoxemia (PO2 lt 90 mmHg)
(A-a)O2 difference
Normal
Increased
FIO2 1.0
Hypoventilation or Altitude
responsive
? response
Shunt
Low V/Q
47
Clinical correlates

• 24 year old woman very short of breath.
• RR 32 b/min, HR 126 b/min, BP 156/90 mmHg,
  Hgb-O2 sat 86
• Arterial blood gas PaO2 55 mmHg, PaCO2 32
  mmHg.
• Put on FIO2 of 1.0, PaO2? 600 mmHg.

48
Hypoxemia (PO2 lt 90 mmHg)
(A-a)O2 difference
Normal
Increased
FIO2 1.0
Hypoventilation or Altitude
responsive
? response
Shunt
Low V/Q
49
Summary of Approach

• Begin with lung as single unit where
• PAO2 and PACO2 are determined by the ratio
  between ventilation and blood flow.
• PAO2 and PACO2 are inversely related through
  alveolar ventilation.
• V/Q is uniform throughout and there is no
  difference in PO2 between alveolus and blood
  leaving alveolus
• V/Q mismatch leads to A-a O2 difference
• Five causes of hypoxemia
• A-a O2 difference and response to increased FiO2
  helps assess causes.
