Key Components of a Green Transportation Measure

1
Key Components of a Green Transportation Measure
Reid EwingDept. of City and Metropolitan
PlanningUniversity of Utah
2
(No Transcript)
3
www.support.smartgrowthamerica.org/growing_cooler
4
Climate Change Is the Ultimate Green Issue
5
Chapter 3
6
(No Transcript)
7
Climate Change Impacts at 2 to 3C

• More than 1/3 of species at risk of extinction
  (corals, polar bears)
• Amazon rainforest Great Lakes ecosystem at risk
  of collapse
• Hundreds of millions displaced from coastal
  areas, at risk of hunger
• Partial deglaciation of Greenland Ice Sheet
  expected to begin sea level to increase 4-6
  meters over centuries to millennia

8
Global Warming Fingerprints
Hurricanes Ophelia, Nate, and Maria were among 15
hurricanes that raged across the Atlantic, Gulf
of Mexico, and Caribbean in 2005.
9
Global Warming Fingerprints
10
Global Warming Fingerprints
J. Madsen and E. Figdor, When It Rains, It Pours
Global Warming and the Rising Frequency of
Extreme Precipitation in the United States,
Environment America Research Policy Center,
December 2007. http//www.environmentamerica.org/u
ploads/oy/ws/oywshWAwZy-EXPsabQKd4A/When-It-Rains-
It-Pours----US---WEB.pdf
11
Energy Bill CAFE -10 Fuel GHG by 2025
12
VMT Growth to Wipe Out Energy Bill Savings
13
Chapter 4
14
Main Questions Addressed

• What reduction in vehicle miles traveled (VMT) is
  possible in the United States with compact
  development rather than continuing urban sprawl?
• What reduction in CO2 emissions will accompany
  such a reduction in VMT?
• What policy changes will be required to shift the
  dominant land development pattern from sprawl to
  compact development?

15
Portland vs. Raleigh
16
35 Less VMT with Compact Development
17
Southern Village (40 lower)
18
Answer to 1st Question

• 20-40 VMT Reduction for Each Increment of
  Compact Development

19
Doing the Math through 2050

• 60-90 Compact
• x
• 67 New Development
• x
• 30 VMT Reduction
• 12-18 Reduction in Metropolitan VMT

20
Add Smart Growth -15 VMT ? 2030 CO2 is 14 below
1990
21
Chapter 8
22
What Would It Take?

• What would it take to reach the 2030 CO2
  reduction target of 33 percent below 1990 levels?

• Will compact development with supportive
  transportation policies be enough?
• If not, how much VMT reduction must be achieved
  through pricing, and what price changes would be
  required?

23
Urban VMT Reduction
24
Compact Development Transit Road
Pricing-Highway Expansion38 VMT reduction
by 2030
25
No Ballot Measure Can Be Considered Green If It
Includes a Lot of New Money for Highways
26
1995 Report on Induced Travel (with Minority View)
27
Short-Term Supply and Demand
28
Short-Term Increases in Traffic

• New Trips
• More Distant Destinations
• Mode Shifts
• Route Shifts
• Most important effect according to Dowling et
  al., 1994

29
Long-Term Supply and Demand
30
Long-Term Increases in Traffic

• Higher Car Ownership
• Reduced Transit Service
• Activity Location Shifts
• Most important effect according to Cervero,
  2002

31
Growth of Traffic Over Time
32
Cerveros Bottom Lines

• the preponderance of research suggests that
  induced-demand effects are significant, with an
  appreciable share of added capacity being
  absorbed by increases in traffic.
• All that can be said with certainty is that
  induced-demand effects exist and they
  accumulate over time.

33
Average Elasticities
34
No Transit Measure Can Be Considered Green Unless
It Is Coupled with Transit-Oriented Development
35
What is TOD?

• TOD is widely defined as compact, mixed-use
  development near transit facilities with
  high-quality walking environments, not
  necessarily at the expense of automobile access.

36
More Than 100 TODs in USA
37
High Mode Shares for TOD Residents
38
Introducing the 3Ds
39
Density
40
33 Units per Acre (gross)
41
15 Units per Acre
42
Diversity
43
Seamless Pattern
44
Design
45
Simple Correlations with Design Variables
46
Pedestrian-Friendly Design
47
Pedestrian-Friendly Design
48
Effect of Density Bay Area Rail
49
Effect of Diversity
50
Effect of Design
