Substrate

1
Stream Ecosystems
Watersheds to Reaches
2
Sample Reach
3
Hydrologic Cycle
4
Contributing Area Watershed
A watershed is defined as an area of land that
drains water, sediment, and dissolved materials
to a common outlet at some point along a stream
channel (Dunne and Leopold 1978).
5
Watersheds
Occur at multiple scales Watersheds range from
the largest river basins, with watersheds
thousands of acres in size to small streams,
with watersheds measuring only a few acres in size
6
Delineating Your Watershed
7
Large Scale Factors to Consider
LATITUDE
ALBEDO
CLIMATE
8
Watershed Characteristics
Slope Aspect Shape
9
Watershed Characteristics
Land Cover Surface Roughness
10
Watershed Characteristics
Soil Characteristics
texture structure moisture
Permeable High infiltration
Impermeable clay High surface runoff
Large Macropores High Infiltration
11
Cumulative Effects
Land Management Throughout Your Watershed Can
Have Impacts Downstream
12
Measuring Physical Characteristics

• What is the function of a stream?
• What data reflect a streams ability to
  function?
• How can the physical data and stream function
  be summarized in a useful way?

13
Stream Function

• To move water

Each stream balances erosion, transport, and
deposition in the context of its climate and
landscape.

• To move sediment

A Stream is a Transport Machine
14
Streams as Transport Machines
Some independent variables, functions of the
watershed influence the streams ability to
function as a transport machine Elevations,
Elevation Change Sediment load Discharge
(flow) Bankfull flow (channel forming) Flood
flow (floodplain)
15
Balancing Water and Sediment
Qs . D50 in balance with Qw . S Qs
sediment load Qw stream discharge D50
sediment size S stream slope
16
Stream Reach Characteristics
Stream Channel - a channel with flowing water at
least part of the year. Bankfull stage of
water which maintains channels (1.5-2 year
recurrence interval) Floodplain - a highly
variable area on one or both sides of the stream
channel that is inundated by floodwaters at some
interval, from frequent to rare. Terraces
remnants of historic floodplains
17
Indicators of Floodplain/Terraces
18
Collecting Data on Stream Function
When gathering data, choose parameters that
reflect the streams ability to function as a
transport machine Bankfull Characteristics Flo
odplain Characteristics Sediment
Characteristics Stream Bank Characteristics
19
Physical Characteristics
Channel Dimension map cross-sections Bankfull
width Mean bankfull depth Bankfull
cross-sectional area Width depth
ratio Maximum depth Channel Pattern use aerial
photos Sinuosity Channel Profile map
longitudinal profiles Bankfull, water surface
and channel slopes
20
Physical Characteristics
Floodplain Characteristics Floodprone
width Entrenchment ratio (bankfull width
floodprone width) Sediment Load
Characteristics D-50 D-84 Bar samples Stream
Bank Characteristics Field observation
21
Bankfull Stage
The bankfull stage corresponds to the discharge
at which channel maintenance is the most
effective, that is, the discharge at which moving
sediment, forming or removing bars, forming or
changing bends and meanders, and generally doing
work that results in the average morphological
characteristics of the channel.
Water in Environmental Planning, T. Dunne and
L.B. Leopold, W.H. Freeman and Co., San
Francisco, CA, 1978
22
Bankfull Flow
1.5-2 year recurrence interval
Bankfull Flow
Baseflow
Big Goose Creek near Sheridan, Wyoming
23
Indicators of Bankfull Stage

• The height of depositional features (especially
  the top of the pointbar, which defines the
  lowest possible level for bankfull stage)
• A change in vegetation
• Slope or topographic breaks along the bank

• A change in the particle size of bank material,
  such as the boundary between coarse cobble or
  gravel with fine-grained sand or silt
• Undercuts the bank, which usually reach an
  interior elevation slightly below bankfull stage
• Stain lines or the lower extent of lichens on
  boulders

24
Cross Section Measurements
25
Physical Characteristics
Channel Dimension map cross-sections Bankfull
width Mean bankfull depth Bankfull
cross-sectional area Width depth
ratio Maximum depth Channel Pattern use aerial
photos Sinuosity Channel Profile map
longitudinal profiles Bankfull, water surface
and channel slopes
26
WidthDepth Ratio
27
Physical Characteristics
Channel Dimension map cross-sections Bankfull
width Mean bankfull depth Bankfull
cross-sectional area Width depth
ratio Maximum depth Channel Pattern use aerial
photos Sinuosity Channel Profile map
longitudinal profiles Bankfull, water surface
and channel slopes
28
Sinuosity
River Distance Straight Line Distance
29
Sinuosity
30
Physical Characteristics
Channel Dimension map cross-sections Bankfull
width Mean bankfull depth Bankfull
cross-sectional area Width depth
ratio Maximum depth Channel Pattern use aerial
photos Sinuosity Channel Profile map
longitudinal profiles Bankfull, water surface
and channel slopes
31
Water Surface Slope
Rise/Run
32
Physical Parameters
Floodplain Characteristics Floodprone
width Entrenchment ratio (bankfull width
floodprone width) Sediment Load
Characteristics D-50 D-84 Bar samples Stream
Bank Characteristics Field observation
33
Floodprone Width
Width Where Stage is 2X Bankfull Max Depth
34
Physical Parameters
Floodplain Characteristics Floodprone
width Entrenchment ratio (bankfull width
floodprone width) Sediment Load
Characteristics D-50 D-84 Bar samples Stream
Bank Characteristics Field observation
35
Entrenchment Ratio
Flood Prone Width/Bankfull Width
36
Entrenchment Ratio
37
Physical Parameters
Floodplain Characteristics Floodprone
width Entrenchment ratio (bankfull width
floodprone width) Sediment Load
Characteristics D-50 D-84 Bar samples Stream
Bank Characteristics Field observation
38
Sediment Characteristics
Boulder gt 256 mm Cobble 64-256
mm Pebble 16-64 mm Gravel 2-16
mm Sand 0.0625-2 mm Silt 0.0039-0.0625
mm Clay lt0.0039 mm
39
Quantitative Description of Stream Function
These parameters are the basic delineative
criteria needed to quantitatively describe a
streams function and begin assessment if can
organize data in useful system Rosgen Channel
Classification
40
Stream Classification
41
Rosgen Stream Classification
Rosgen classification scheme initially sorts
streams into the major, broad stream types (A-G)
at a landscape level A-headwater B-intermediate C
and E-meandering D-braided F-entrenched G-gully
Stream types are divided into subtypes based on
slope ranges, and dominant channel material
particle sizes. 1-bedrock 2-boulder 3-cobble 4-gr
avel 5-sand 6-silt/clay
42
Rosgen Stream Classification
Applied River Morphology, Dave Rosgen, Wildland
Hydrology, Fort Collins, Colorado, 1996.
43
Rosgen Stream Classification
44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
Why Establish Reference Sites?
Establishes a baseline for a broad range of
physical, chemical and biological monitoring.
Monitor trends in fluvial and geomorphic
conditions over time Quantify environmental
impacts Assess stream and watershed response to
management Provide channel and flow facts for
water allocation Support resource inventories
(habitat, water quality, vegetation) Track
cumulative effects for entire drainage
areas Contributing to regional, state, national
and international databases
53
Site Selection
Ask the following questions What do we want to
know about this stream or drainage? What
variations (geology, elevation, land use) exist
in the area? How can we set up the most useful
comparisons with the fewest sites? How can this
site contribute to the existing or planned
efforts? How much can be accomplished with
present resources?
54
Site Selection

• Choose sites with evident natural
  features-floodplains, terraces, bars and natural
  vegetation
• Reach should include an entire meander length
  (two bends) if possible. The length should be at
  least 20 times bankfull width of the channel.
• Unless your purpose includes studies of beaver
  dams, debris jams, boulder fields, bedrock
  controls, and recently adjusted channels (flood,
  disturbance), select your site to avoid such
  features

55
Natural stream channel stability is. Stable
dimension, pattern, and profile such that, over
time, the channel features are maintained and the
stream system neither aggrades nor degrades for
a given climate.
Applied River Morphology, Dave Rosgen, Wildland
Hydrology, Pagosa Springs, Colorado, 1996.
56
Major Sub-Basins of Wyoming
