Cluster Analysis

1
Cluster Analysis

• Hal Whitehead
• BIOL4062/5062

2

• What is cluster analysis?
• Non-hierarchical cluster analysis
• K-means
• Hierarchical divisive cluster analysis
• Hierarchical agglomerative cluster analysis
• Linkage single, complete, average,
• Cophenetic correlation coefficient
• Additive trees
• Problems with cluster analyses

3
Cluster Analysis

• Classification
• Maximize within cluster homogeneity
• (similar individuals within cluster)
• The Search for Discontinuities
• Discontinuities places to put divisions between
  clusters

4
Discontinuities

• Discontinuities generally present
• taxonomy
• social organization
• community ecology??

5
Types of cluster analysis

• Uses data, dissimilarity, similarity matrix
• Non-hierarchical
• K-means
• Hierarchical
• Hierarchical divisive (repeated K-means)
• Hierarchical agglomerative
• single linkage, average linkage, ...
• Additive trees

6
Non-hierarchical Clustering TechniquesK-Means

• Uses data matrix with Euclidean distances
• Maximizes between-cluster variance for given
  number of clusters
• i.e. Choose clusters to maximize F-ratio in 1-way
  MANOVA

7
K-Means

• Works iteratively
• 1. Choose number of clusters
• 2. Assigns points to clusters
• Randomly or some other clustering technique
• 3. Moves each point to other clusters in
  turn--increase in between cluster variance?
• 4. Repeat step 3. until no improvement possible

8
K-means with three clusters
9
K-means with three clusters

• Variable Between SS df Within SS df
  F-ratio
• X 0.536 2 0.007 7
  256.163
• Y 0.541 2 0.050 7
  37.566
• TOTAL 1.078 4 0.058 14

10
K-means with three clusters

• Cluster 1 of 3 contains 4 cases
• Members
  Statistics
• Case Distance Variable Minimum
  Mean Maximum St.Dev.
• Case 1 0.02 X 0.41
  0.45 0.49 0.04
• Case 2 0.11 Y 0.03
  0.19 0.27 0.11
• Case 3 0.06
• Case 4 0.05
• Cluster 2 of 3 contains 4 cases
• Members
  Statistics
• Case Distance Variable Minimum
  Mean Maximum St.Dev.
• Case 7 0.06 X 0.11
  0.15 0.19 0.03
• Case 8 0.03 Y 0.61
  0.70 0.77 0.07
• Case 9 0.02
• Case 10 0.06
• Cluster 3 of 3 contains 2 cases
• Members
  Statistics
• Case Distance Variable Minimum
  Mean Maximum St.Dev.
• Case 5 0.01 X 0.77
  0.77 0.78 0.01
• Case 6 0.01 Y 0.33
  0.35 0.36 0.02

11
Disadvantages of K-means

• Reaches optimum, but not necessarily global
• Must choose number of clusters before analysis
• How many clusters?

12
Example Sperm whale codas

• Patterned series of clicks
• ic1 ic2 ic3 ic4
• For 5-click codas 681 x 4 data set

13
5-click codas
ic1 ic2 ic3 ic4
93 of variance in 2 PCs
14
5-click codasK-means with 10 clusters
15
Hierarchical Cluster Analysis

• Usually represented by
• Dendrogram or tree-diagram

16
Hierarchical Cluster Analysis

• Hierarchical Divisive Cluster Analysis
• Hierarchical Agglomerative Cluster Analysis

17
Hierarchical Divisive Cluster Analysis

• Starts with all units in one
  cluster, successively splits them
• Successive use of K-Means, or some other divisive
  technique, with n2
• Either Each time use the cluster with the
  greatest sum of squared distances
• Or Split each cluster each time.
• Hierarchical divisive are good techniques, but
  rarely used

18
Hierarchical Agglomerative Cluster Analysis

• Start with each individual units occupying its
  own cluster
• The clusters are then gradually merged until just
  one is left
• The most common cluster analyses

19
Hierarchical Agglomerative Cluster Analysis

• Works on dissimilarity matrix
• or negative similarity matrix
• may be Euclidean, Penrose, distances
• At each step
• 1. There is a symmetric matrix of
  dissimilarities between clusters
• 2. The two clusters with least dissimilarity are
  merged
• 3. The dissimilarity between the new (merged)
  cluster and all others is calculated
• Different techniques do step 3. in different
  ways

20
Hierarchical Agglomerative Cluster Analysis

• A B C D E
• A 0 . . . .
• B 0.35 0 . . .
• C 0.45 0.67 0 . .
• D 0.11 0.45 0.57 0 .
• E 0.22 0.56 0.78 0.19 0

• AD B C E
• AD 0 . . .
• B ? 0 . .
• C ? 0.67 0 .
• E ? 0.56 0.78 0

How to calculate new disimmilarities?
21
Hierarchical Agglomerative Cluster
AnalysisSingle Linkage

• A B C D E
• A 0 . . . .
• B 0.35 0 . . .
• C 0.45 0.67 0 . .
• D 0.11 0.45 0.57 0 .
• E 0.22 0.56 0.78 0.19 0

• AD B C E
• AD 0 . . .
• B 0.35 0 . .
• C ? 0.67 0 .
• E ? 0.56 0.78 0

d(AD,B)Mind(A,B), d(D,B)
22
Hierarchical Agglomerative Cluster
AnalysisComplete Linkage

• A B C D E
• A 0 . . . .
• B 0.35 0 . . .
• C 0.45 0.67 0 . .
• D 0.11 0.45 0.57 0 .
• E 0.22 0.56 0.78 0.19 0

• AD B C E
• AD 0 . . .
• B 0.45 0 . .
• C ? 0.67 0 .
• E ? 0.56 0.78 0

d(AD,B)Maxd(A,B), d(D,B)
23
Hierarchical Agglomerative Cluster
AnalysisAverage Linkage

• A B C D E
• A 0 . . . .
• B 0.35 0 . . .
• C 0.45 0.67 0 . .
• D 0.11 0.45 0.57 0 .
• E 0.22 0.56 0.78 0.19 0

• AD B C E
• AD 0 . . .
• B 0.40 0 . .
• C ? 0.67 0 .
• E ? 0.56 0.78 0

d(AD,B)Meand(A,B), d(D,B)
24
Hierarchical Agglomerative Cluster
AnalysisCentroid Clustering (uses data matrix,
or true distance matrix)

• V1 V2 V3
• A 0.11 0.75 0.33
• B 0.35 0.99 0.41
• C 0.45 0.67 0.22
• D 0.11 0.71 0.37
• E 0.22 0.56 0.78
• F 0.13 0.14 0.55
• G 0.55 0.90 0.21

• V1 V2 V3
• AD 0.11 0.73 0.35
• B 0.35 0.99 0.41
• C 0.45 0.67 0.22
• E 0.22 0.56 0.78
• F 0.13 0.14 0.55
• G 0.55 0.90 0.21

V1(AD)MeanV1(A),V1(D)
25
Hierarchical Agglomerative Cluster
AnalysisWards Method

• Minimizes within-cluster sum-of squares
• Similar to centroid clustering

26

• 1 1.00
• 2 0.00 1.00
• 4 0.53 0.00 1.00
• 5 0.18 0.05 0.00 1.00
• 9 0.22 0.09 0.13 0.25 1.00
• 11 0.36 0.00 0.17 0.40 0.33 1.00
• 12 0.00 0.37 0.18 0.00 0.13 0.00 1.00
• 14 0.74 0.00 0.30 0.20 0.23 0.17 0.00 1.00
• 15 0.53 0.00 0.30 0.00 0.36 0.00 0.26 0.56 1.00
• 19 0.00 0.00 0.17 0.21 0.43 0.32 0.29 0.09 0.09
  1.00
• 20 0.04 0.00 0.17 0.00 0.14 0.10 0.35 0.00 0.18
  0.25 1.00
• 1 2 4 5 9 11
  12 14 15 19 20

27
(No Transcript)
28
Hierarchical Agglomerative Clustering Techniques

• Single Linkage
• Produces straggly clusters
• Not recommended if much experimental error
• Used in taxonomy
• Invariant to transformations
• Complete Linkage
• Produces tight clusters
• Not recommended if much experimental error
• Invariant to transformations
• Average Linkage, Centroid, Wards
• Most likely to mimic input clusters
• Not invariant to transformations in dissimilarity
  measure

29
Cophenetic Correlation CoefficientCCC

• Correlation between original disimilarity matrix
  and dissimilarity inferred from cluster analysis
• CCC gt 0.8 indicate a good match
• CCC lt 0.8, dendrogram not a good representation
• probably should not be displayed
• Use CCC to choose best linkage method (highest
  coefficient)

30
CCC0.83
CCC0.77
CCC0.75
CCC0.80
31
Additive trees

• Dendrogram in which path lengths represent
  dissimilarities
• Computation quite complex (cross between
  agglomerative techniques and multidimensional
  scaling)
• Good when data are measured as similarities and
  dissimilarities
• Often used in taxonomy and genetics

A B C D E A . . . . . B 14 . . . . C 6 12 . . . D
81 7 13 . . E 17 1 6 16 .
32
Problems with Cluster Analysis

• Are there really biologically-meaningful clusters
  in the data?
• Does the dendrogram represent biological reality
  (web-of-life versus tree-of-life)?
• How many clusters to use?
• stopping rules are arbitrary
• Which method to use?
• best technique is data-dependent
• Dendrograms become messy with many units

33
Social Structure of 160 northern bottlenose whales
34
Clustering Techniques

• Type Technique Use
• Non-hierarchical K-Means Dividing data sets
• Hierarchical divisive Repeated K-means Good
  technique on small data sets
• Hierarchical agglomerative
• Single linkage Taxonomy
• Complete linkage Tighter Clusters
• Average linkage,
• Centroid, Wards Usually Preferred
• Hierarchical Additive trees Excellent for
  displaying similarity/dissimilarity
  taxonomy, genetics
