Introduction to the Advanced Mobile Phone System AMPS

1
Introduction to the Advanced Mobile Phone System
(AMPS)

• EE421
• Fall 2001
• Dr. Julie Dickerson

2
Information Sources

• Theodore Rappaport, Wireless Communications
  Principles Practice, Prentice-Hall, 1996
• Gallagher Snyder, Mobile Telecommunications
  Networking with IS-41, McGraw-Hill
• Tutorial on Mobile Communications from the
  International Engineering Consortium - on course
  web site

3
History

• 1946 First mobile phones deployed, FM 120KHz,
  half-duplex
• 1950 FM 60KHz, better RF filters available
• Mid 1960s 30KHz, full-duplex, IMTS (Improved
  Mobile Telephone Service), limited capacity 12
  channels, 543 paying customers in New York City
  (1976)

4
Early Mobile Systems
5
Cellular Communications

• 1968 Cell concept proposed by ATT
• 1983 FCC allocates 40 MHz of spectrum in 800
  MHz band, 30 kHz for each one-way channel (for
  full-duplex) analog
• Channels split between two carriers
• More frequencies allocated, 1.8-1.9 GHz, etc.
  over time
• Bandwidth limited

6
Cellular Concept
7
Digital Communications

• Early 1990s digital systems begin with the goal
  of increasing the number of users, D-AMPS
• TDMA
• FDMA
• CDMA

8
FDMA-Frequency Division Multiple Access
-Requires no synchronization or central timing,
channels independent.
9
TDMA-Time Division Multiple Access Fixed Slots
10
CDMA-Code Division Multiple Access Frequency
Hopping
Frequency
Time
11
(No Transcript)
12
Terminology

• Base Station
• Fixed station used for radio communication with
  mobiles. Located at the center or edge of
  coverage region. Consists of radio channels,
  transmit/receive antennas.
• Control Channels
• Radio channels used for transmission of call
  setup, request, initiation and other control
  purposes
• Full Duplex
• Communication system that allows simultaneous
  two-way communication, transmission reception
  usually on two different frequencies (FDD)

13

• Forward Channel
• Radio channel for transmission from base station
  to mobile
• Reverse channel
• Radio channel for transmission from mobile to
  base station
• Handoff
• Process of transferring a mobile from one channel
  or base station to another
• Mobile Switching Center
• Switching center that coordinates call routing in
  a large service area. MSC connects cellular base
  stations and the mobiles to the PSTN (also called
  Mobile Telephone switching office (MTSO)

14
Wireless System Basics
Reverse Link
Forward Link
Control or Setup Channels
Mobile Unit
Base Station
15
Cellular System
16
Making calls from a cellphone

• Mobile sends call initiation request, its ID
  number to base station on reverse control channel
• Base station receives and relays to the MSC
• MSC validates user, instructs base station to
  move mobile to voice channels
• Base station pages mobile with instructions
• Mobile moves to voice channel
• MSC connects mobile to PSTN
• Voice transmission/reception between mobile and
  base station begins

17
Making calls to a cellphone

• MSC receives call from PSTN , sends page to base
  stations
• Base stations send page on forward control
  channel to mobiles
• Mobile receives page and acknowledges on reverse
  control channel sends validation information
• MSC validates mobile, asks base station to put
  user on voice channel pair
• Base station sends voice channel information on
  FCC, mobile moves to voice channel
• Voice transmission/reception initiated MSC
  connects with PSTN.

18
Forward/Reverse Channels
849-851 Air Mobile, air cellular 851-869 Private
land mobile, public safety frequencies, trunk
lines
19
Cell Frequency Reuse
20
Locating Cells
N19 (i 3, j2)
21
Channel Assignment

• Need to assign frequencies to users/cell
• Fixed
• Each cell has predetermined number of channels
• If all channels used, cell is blocked, no
  service
• Cells can borrow channels from neighboring cells
• Dynamic
• No permanent allocation
• Frequency band requested from MSC, assigned using
  reuse distance, blocking probabilities, use of
  channel, signal strength

22
Handoff Scenarios
23
Umbrella Cells
24
Interference and Capacity

• Interference causes
• cross-talk, poor quality,(voice channel)
• blocking and missed calls (control channel)
• Co-channel interference
• Frequency reuse in nearby cells
• Adjacent channel interference
• Signal in adjacent frequency band
• Signals from other cell companies

25
Co-Channel Interference
26
Adjacent Channel Interference

• Comes from imperfect filters that allow frequency
  leakage into the band
• Serious problem if interferer is nearby, near-far
  effect
• Nearby mobile transmits on a frequency near to
  that of a weak mobile
• Base station receivers need high-Q filters to
  reject adjacent channel interference.

27
Power Control

• Each mobile should use the minimum amount of
  power to have good quality.
• Base station controls power
• CDMA power toggles up and down continuously, like
  delta modulation
• TDMA, AMPS adjusted by base station

28
Increasing Capacity

• Cell Sectoring
• Divide cell up into angular sections, typically 3
  or 6
• Increases reuse
• Cell Splitting
• Subdivide cell into smaller cells, increases the
  number of channels, keep same structure
• Needs power control

29
Cell Sectoring
30
Cell Splitting
31
AMPS Specs
32
AMPS Voice Processing
Compander compresses signal in amplitude,
roughly 21 ratio Deviation Limiter assures that
the max. deviation is the /- 12
kHz Postdeviation limiter filter LPF,
attenuated signal to keep in band and avoid
interfering with SAT tones
33
Other Cell Specs

• IS-54 Digital cellular in US, DQPSK
• IS136 PCS
• IS 95 A CDMA spread spectrum
• Global system for mobiles (GSM)
• TDMA with channelization
