Title: Security in Wireless Sensor Networks


1
SecurityinWireless Sensor Networks
  • by
  • Toni Farley

2
Security Concerns
  • Security Concerns Defined
  • Integrity - Ensure that information is accurate,
    complete, and has not been altered in any way.
  • Availability - Ensure that a system can
    accurately perform its intended purpose and is
    accessible to those who are authorized to use it.
  • Confidentiality - Ensure that information is only
    disclosed to those who are authorized to see it.

Integrity
Availability
Confidentiality
3
Security Concerns
  • Authentication Ensure correctness of claimed
    identity.
  • Authorization Ensure permissions granted for
    actions performed by entity.

Authentication
Authorization
ICA3
4
Points of Security Concern
  • System
  • System Integrity
  • Availability
  • Source
  • Authentication
  • Authorization
  • Data
  • Data Integrity
  • Confidentiality

WSN
Data
Source
5
Threats
  • Authentication
  • Man in the middle
  • Data Integrity
  • Modification
  • Forgery
  • Deletion
  • Replay
  • Confidentiality
  • Eavesdropping

6
Wireless Security
  • Magnified Threats
  • Detectability Ability to discover a wireless
    system
  • Theft of Service Unauthorized use of wireless
    signal
  • Interception Easy to capture signals
    transmitted through air
  • Limited Resources
  • Low b/w
  • Low memory capacity
  • Slow CPU
  • Battery Power Limits

7
Current Solution Encryption
  • Symmetric (private key) encryption
  • Fixed keys cannot be changed when compromised
  • Dynamic keys require high cost key exchange
    protocol
  • Faster algorithms computational overhead
  • Asymmetric (public/private) key encryption
  • Data sent to many devices must be encrypted
    separately with each devices public key
  • Longer keys provide better security
  • Longer keys require more resources, which becomes
    problematic if many keys are needed

8
Current Solution Encryption
  • Pretty Good Privacy (PGP)
  • Uses session key to encrypt data, thus only need
    to encrypt data one time for multiple recipients
  • Uses public keys to encrypt session key, requires
    multiple smaller encryptions
  • Overhead is reduced, but still exists

9
Research SPINS
  • Security Protocols for Sensor Networks 1
  • Securing Node/Base Station communications
  • Secure Network Encryption Protocol (SNEP)
  • Secure channels for confidentiality
  • Data integrity through authentication
  • Data freshness through partial message ordering
    (weak) and total order with delay estimation
    (strong)
  • micro Timed, Efficient, Streaming, Loss-tolerant
    Authentication Protocol (µTESLA)
  • Authentication through asymmetric authenticated
    broadcast

10
Research Security for Sensor Networks
  • Security for Sensor Networks 2
  • Securing Node/Base Station communications
  • Broadcasts of end-to-end encrypted packets
  • Authentication
  • Integrity
  • Confidentiality
  • Replay
  • Base station looks for corrupted packets or long
    period of inactivity
  • Mechanism for detecting bad behavior

11
Research Secure Routing in WSN
  • Security Routing in Wireless Sensor Networks
    Attacks and Countermeasures 3
  • Describes routing attacks
  • Known attacks
  • Invented attacks
  • Protocol specific attacks
  • Describes countermeasures for each attack
  • Encryption with globally shared key
  • Unique key between each node base station
  • Neighbor authentication between nodes
  • Authenticated broadcast techniques

12
Security Sources
  • SANS Glossary of Terms Used in Security and
    Intrusion Detection, http//www.sans.org/resources
    /glossary.phpC, May 2003.
  • MobileBook
  • Andrew S. Tanenbaum, Computer Networks, Prentice
    Hall, 2003.
  • Encyclopedia of Cryptography and Security,
    Kluwer, to be published in 2004.

13
Research References
  • 1 SPINS Security Protocols for Sensor
    Networks. A. Perrig, R. Szewczyk, V. Wen, D.
    Culler, and J. Tygar. In Seventh Annual ACM
    International Conference on Mobile Computing and
    Networks (Mobicom), 2001.
  • 2 Jeffery Undercoffer, Sasikanth Avancha,
    Anupam Joshi, and John Pinkston, Security for
    Sensor Networks 2002 CADIP Research Symposium
  • 3 Secure Routing in Sensor Networks Attacks
    and Countermeasures, Chris Karlof and David
    Wagner, To appear in Elsevier's AdHoc Networks
    Journal, Special Issue on Sensor Network
    Applications and Protocols.
