The Societal Value of Soil Carbon Sequestration

1
The Societal Value of Soil Carbon Sequestration

• Rattan Lal
• Director, Carbon Management and Sequestration
  Center
• The Ohio State University, Columbus, Ohio

2
Global Climate Change

• ?T over the 20th century. 0.60.2C
• Rate of ?T increase since 1950 0.17C/decade
• Sea level rise over 20th century.. 0.1-0.2 m
• Change in precipitation.. 0.5-1/decade
• Extreme events. 2-4
• ..IPCC (2001)

3
Atmospheric Concentration of Trace Gases Between
1750 and 1999
IPCC (2001)
4
Global Carbon Budget
IPCC (2001)
5
(No Transcript)
6
How Much C is in Soil?

• (i) Soil organic C 1550 Pg
• Soil inorganic C 750 Pg
• Total 2300 Pg
• (ii) Atmosphere 720 Pg
• (iii) Biota 560 Pg
• (iv) Ocean 38,000 Pg
• SOC pool 40 - 100 Mg/ha

7
Soil vs. Atmospheric C

• 1 Pg (billion tonnes) of soil C 0.47 ppm of CO2

8
Mean Residence Time of C in Different Pools

• The average atom of C spends about
• 5 yrs in the atmosphere,
• 10 yrs in vegetation (including trees),
• 35 yrs in soil, and
• 100 yrs in the sea.
• Residence time pool / flux
• The residence time is longer in soils of high
  latitude.

9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
ra
15
Effects of Soil Erosion and Redistribution on
Trace Gases Emissions.
CO2
CO2
CH4 N2O
Depressed oxidation of CH4
CH4 N2O
C burial
Erosion Redistribution Depression
C burial
DOC
16
Soil erosion and C emission
17
1.14 x 1015 g/yr decomposition and emission to
the atmosphere
1500 x 1015 C in world soil
C sequestration
3.99 x 1015 g/yr stored within the terrestrial
ecosystem
5.7 x 1015 g/yr C displaced due to erosion
0.57 x 1015 g/yr transported to the ocean
Global soil erosion and dynamics of soil organic
carbon (Lal, 1995).
18
Historic Soil C Loss

• World soils.. 66-90 Pg
• U.S. soils.. 5 Pg
• Recoverable C. 50-75
• Time horizon25-50 yrs

19
The magnitude of soil C loss

• 30-40 Mg/ha
• Agricultural soils now contain lower SOC pool
  than their potential, and thus have a C sink
  capacity.

20
Anthropogenic emissions (1850-2000)

• 1. Fossil fuel 270 30 Pg
• 2. Land use change 136 55 Pg
• Soil 78 12

21
Soils and Global Warming

• Can we use soils and vegetation for scrubbing a
  dirty atmosphere?

22
Carbon Sequestration

• It is the net removal of CO2 from the atmosphere
  into the long-lived pools of C such as vegetation
  and soil by biotic and abiotic processes.

23
A New Definition of Agriculture

• It is an anthropogenic manipulation of carbon
  through uptake, fixation, emission and transfer.
• CU CF CE CT

24
How to Increase Soil C

• A. Increase
• (i) density of C in the soil
• (ii) depth of C in the profile
• B. Decrease
• (i) decomposition of C
• (ii) losses due to erosion

25
Increasing Density of C in Soil

• Plow No till
• Residue removed Residue return
• Bare fallow Cover crops
• Low input Judicious input (precision
  farming, IPM)
• No water control Water conservation and
• supplemental irrigation
• Fence to fence cropping Forestation/vegetation
  on
• marginal lands/CRP

26
(No Transcript)
27
Disposition of Organic Residues
CO2
60-80
Organic residues 100 grams
3-8
10-30
3-8
Nonhumic compounds (polyuronides, acids, etc.)
Biomass (soil organisms)
Complex humic compounds
Humus 10-35
28
Mulch Rate and SOC Content in Ohio

• No till
• SOC (Mg ha-1) 15.2 0.321 M R 0.68
• Plow till
• SOC (Mg ha-1) 11.9 0.266 M R 0.72

29
Cover Crop and SOC Pool in a Miamian Soil in Ohio
Lal (1998)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
SOC pool in 0-30 cm depth over a 60-year period
at Coshocton, OH (Hao, Lal, Owen, 2002)
35
Biofuel vs. Fossil Fuel

• 1 gallon of biofuel 0.5 gallon of oil/diesel
  saving

36
Global Cooling Potential

• GCP (GWP)-1
• Conservation tillage
• Cover crops
• Nutrient management
• Soil restoration
• CRP/WRP
• Land use and afforestation

100-1000 Kg C/ha/y
37
Land Use and Soil C Sequestration in the U.S.
38
U.S. Emissions and Soil C Sequestration

• Total U.S. gas emissions.1500 MMTC/yr
• Emission from agricultural activities133 MMTC/yr
• Net soil C sequestration potential..332 MMTC/yr

39
Agricultural Soils and Mitigation of GHE

• 1 bbl of diesel 220 L
• 1 L of diesel 0.73 Kg C
• ? 1 ton of C 1370 L of diesel 6.2 bbl of
  diesel
• C sequestration potential of ag soils 2 billion
  barrels/yr

40
Potential of Global Soil C Sequestration

• 1-2 Pg C/yr or
• 24 of the total emissions by fossil fuel
  combustion.

41
Is Soil C Sequestration A Free Lunch?

• Not really!
• Additional N, P, S etc. are needed for
  humification of residue C.
• There are hidden C costs of RMPs.

42
Building Blocks of Humus

• C is only one of several constituents of humus.
• Other constituents are H, O, N, P, S and
  micronutrients.

43
Nutrients Needed for Humification

• How much N, P and S are needed to convert residue
  into humus?
• How to adjust fertilizer use for desired
  productivity and converting residue into humus?

44
Elemental Composition of Humus and Crop Residues
45
Additional Nutrients Required to Convert 10,000kg
of Carbon into Humus
46
(No Transcript)
47
Energy-based Input and C Sequestration

• 1. What is the carbon budget in relation to
• (i) Fertilizer use
• (ii) Manure application
• (iii) Tillage practices
• (iv) Irrigation
• (v) Liming of acid soils
• 2. C sequestration occurs only if output gt input.

48
Hidden C costs of tillage methods
49
Hidden C cost of fertilizers
50
Hidden C cost of pesticides
51
Hidden C cost of irrigation
52
Farming Carbon

• Commodification of C (price)
• Incentives

53
Societal Value of Carbon

• Nutrients and H2O contained in 1 kg of humus
  0.2
• ?Rational price 200/ton

54
Undervaluing a Commodity

• Undervaluing carbon has and will perpetuate its
  misuse.

55
40
30
20
Cumulative C sequestration (M/ha)
10
0
0
10
20
30
40
50
Time after conversion (yrs)
56
(No Transcript)
57
Economics of C Sequestration

• Assessing economics of C by itself is not
  adequate.
• Evaluate the entire package of benefits

(i) To the farmer (ii) To the society
58
Can soil C sequestration mitigate the greenhouse
effect?
59
Dependency on Carbon

• Modern civilization is hooked on carbon. It needs
  rehabilitation, in a big way.

60
Role of soil and biomass C in global C
management. Source The Global Energy Technology
Strategy, Battelle, Washington, D.C., 1998
61
Soil C Sequestration

• It is aDevelopment challenge in the tropics and
  sub-tropics.
• Policy reform and implementation challenge in
  developed countries.

62
A Bridge to the Future

• C sequestration in soil and vegetation is a
  bridge to the future.
• It buys us time while alternatives to fossil fuel
  take effect.
• It is a good thing to do, regardless of what
  happens to the climate.

It is truly a win-win strategy.
