Chapter 2 Introduction to Systems Architecture

1
Chapter 2Introduction to Systems Architecture
2
Chapter Goals
Chapter 2
Systems Architecture

• Discuss the development of automated computing
• Describe the general capabilities of a computer
• Describe computer system components and their
  functions
• List computer system classes and their
  distinguishing characteristics

3
Chapter Goals
Chapter 2
Systems Architecture

• Define the role and function of application and
  system software
• Describe the economic role of system and
  application development software
• Describe the components and function of computer
  networks

4
Introduction to Systems Architecture
Chapter 2
Systems Architecture

• The term systems architecture describes a
  computer systems components and the interaction
  between them.

5
Automated Computation
Chapter 2
Systems Architecture

• A definition of a computer is any device that
  can
• Accept numeric inputs
• Perform computational functions, such as addition
  and subtraction
• Communicate results

6
Automated Computation
Chapter 2
Systems Architecture

• Modern computer systems may implement the
  basic functions using many methods and/or
  devices
• Implement computation electronically
• Implement storage optically
• Implement communication using a combination of
  electronics and mechanics

7
Mechanical Implementation
Chapter 2
Systems Architecture

• The difference engine is an early mechanical
  computation device that was designed to perform
  repetitive mathematical computations.
• The mechanical implementation of computers used
  gears and wheels and other mechanical movements.

8
Mechanical Implementation
Chapter 2
Systems Architecture
9
Mechanical Implementation
Chapter 2
Systems Architecture

• There are inherent limitations and
  shortcomings of mechanical computation including
• Complex design and construction
• Wear, breakdown, and maintenance and mechanical
  parts
• Limits on operating speed

10
Electrical Implementation
Chapter 2
Systems Architecture

• The design of the mechanical computer devices
  gave way to the construction of electrical
  devices during World War II.
• Electrical devices were used to replace
  mechanical devices within the computer system,
  and input/output devices.

11
Electrical Implementation
Chapter 2
Systems Architecture

• Electrical computers addressed most of the
  shortcomings of mechanical computation.
• The use of the electrical components made it
  possible to increase the speed of the computer
  system, which made it possible to solve larger
  more complex problems.

12
Optical Implementation
Chapter 2
Systems Architecture

• Data can be represented as pulses of light and
  stored either directly or indirectly by materials
  that reflect or dont reflect light.
• Optical devices are currently used for storing
  and retrieving large amounts of data.

13
Quantum Computing
Chapter 2
Systems Architecture

• Some scientists and engineers have been
  experimenting with quantum computing devices
  during the last decade.
• These experiments are still in their infancy and
  a commercially viable quantum computer is
  estimated to be more than a decade away.

14
Quantum Computing
Chapter 2
Systems Architecture
15
Computer Capabilities
Chapter 2
Systems Architecture

• Primary characteristics of a computer
• General-purpose processor capable of performing
  computation, data movement, comparison, and
  branching functions
• Storage capacity sufficient to hold large numbers
  of program instructions and data
• Flexible communication capability through the use
  of multiple media and devices

16
Computer Capabilities
Chapter 2
Systems Architecture

• A processor is a device that performs data
  manipulation and/or transformation functions
  including
• Computation
• Comparison
• Data movement

17
Computer Capabilities
Chapter 2
Systems Architecture

• A processor executes a sequence of instructions
  stored in a program.
• An instruction is a signal or command to a
  processor to perform one of its functions.

18
Computer Capabilities
Chapter 2
Systems Architecture

• A processor executes a function is response to an
  instruction.
• A long sequence of instructions is called a
  program.

19
Computer Capabilities
Chapter 2
Systems Architecture

• A processor can be classified as
• General-purpose
• Special-purpose

20
Computer Capabilities
Chapter 2
Systems Architecture

• A general-purpose processor is capable of
  executing many different instructions in many
  different sequences or combinations.
• Their function can be changed by altering the
  program that directs its actions.

21
Computer Capabilities
Chapter 2
Systems Architecture

• A special-purpose processor is designed to
  perform only one specific task.
• Used by devices such as microwave ovens, compact
  disc players and computer printers.

22
Computer Capabilities
Chapter 2
Systems Architecture

• Formulas and Algorithms
• If processing tasks require more than a
  processors computation instructions, a formula
  and/or algorithm is needed.

23
Computer Capabilities
Chapter 2
Systems Architecture

• Formulas
• A processor executes a sequence of computation
  and data movement instructions to solve a formula.

24
Computer Capabilities
Chapter 2
Systems Architecture

• Formulas
• Gross_Profit Quantity_Sold x Selling_Price
  Selling_Expenses

25
Computer Capabilities
Chapter 2
Systems Architecture

• Algorithms
• Computer processors also can perform a more
  complex class of processing tasks called
  algorithms.

26
Computer Capabilities
Chapter 2
Systems Architecture
27
Computer Capabilities
Chapter 2
Systems Architecture

• The procedure for computing United States income
  tax is an example of an algorithm.
• The program examines the income value and decides
  which set of instructions to execute to compute
  the tax.

28
Computer Capabilities
Chapter 2
Systems Architecture
29
Computer Capabilities
Chapter 2
Systems Architecture

• If decisions need to be made within the
  processing tasks, then comparisons and branching
  is needed.
• Comparisons are called conditions and the result
  of evaluating the condition is true or false.

30
Computer Capabilities
Chapter 2
Systems Architecture

• When a comparison condition is true, the
  program jumps or branches to the first
  instruction that implements the corresponding
  formula.

31
Computer Capabilities
Chapter 2
Systems Architecture
32
Computer Capabilities
Chapter 2
Systems Architecture

• Storage Capacity
• A computer stores immediate processing
  results, data and programs.

33
Computer Capabilities
Chapter 2
Systems Architecture

• Input/Output Capability
• A computers input/output devices must be
  flexible and encompass a variety of communication
  modes.

34
Computer Capabilities
Chapter 2
Systems Architecture

• Input/Output Capability
• The communication modes are
• Sound
• Text
• Graphics

35
Computer Capabilities
Chapter 2
Systems Architecture

• Input/Output Devices
• Video display
• Keyboard
• Mouse
• Printer
• Modem
• Network Interface

36
Computer Hardware
Chapter 2
Systems Architecture

• Computer Hardware Functions
• Processing
• Storage
• External communication
• Internal communication

37
Computer Hardware
Chapter 2
Systems Architecture
38
Computer Hardware
Chapter 2
Systems Architecture

• Computer System Components
• Central Processing Unit (CPU)
• Primary Storage
• Secondary Storage
• Input/Output Units
• System Bus

39
Computer Hardware
Chapter 2
Systems Architecture
40
Computer Hardware
Chapter 2
Systems Architecture

• Central Processing Unit (CPU)
• Arithmetic and Logic Unit
• Registers
• Control Unit

41
Computer Hardware
Chapter 2
Systems Architecture
42
Computer Hardware
Chapter 2
Systems Architecture

• The Arithmetic and Logic Unit contains
  electrical circuits that implement each
  instruction.
• The Registers are small internal storage
  locations that hold a single instruction or data
  item.

43
Computer Hardware
Chapter 2
Systems Architecture

• The Control Unit has two primary functions
• Control movement of data to and from CPU
  registers and other hardware components
• Access program instructions and issue appropriate
  commands to the ALU

44
Computer Hardware
Chapter 2
Systems Architecture

• The system bus is the primary pathway for data
  transmission among hardware components.

45
Computer Hardware
Chapter 2
Systems Architecture

• Storage Devices
• Primary Storage
• Secondary Storage

46
Computer Hardware
Chapter 2
Systems Architecture

• Primary Storage
• Primary storage is referred to as memory or
  main memory.
• Primary storage holds program instructions
  that are currently being executed and data being
  processed by those instructions.

47
Computer Hardware
Chapter 2
Systems Architecture

• Primary Storage
• Primary storage is referred to as Random
  Access Memory (RAM).
• The data stored in RAM is volatile. Volatile
  data is lost when the computer system is turned
  off.

48
Computer Hardware
Chapter 2
Systems Architecture

• Secondary Storage
• Secondary storage refers to nonvolatile
  storage devices.

49
Computer Hardware
Chapter 2
Systems Architecture

• Secondary storage devices hold
• Program not currently being executed
• Data not needed by currently executing programs
• Data needed by currently executing programs that
  does not fit within available primary storage

50
Computer Hardware
Chapter 2
Systems Architecture
51
Computer Hardware
Chapter 2
Systems Architecture

• Input/Output Devices
• Each input/output device is a separate hardware
  component attached to the system bus.

52
Computer Hardware
Chapter 2
Systems Architecture

• Input devices accept input from a human and
  convert that input into something the computer
  can understand.
• Output devices display information to the user
  and implement communication among computer
  systems.

53
Computer Hardware
Chapter 2
Systems Architecture

• Input devices include
• Keyboards
• Pointing devices
• Voice recognition

54
Computer Hardware
Chapter 2
Systems Architecture

• Output devices include
• Video displays
• Printers
• Plotters
• Devices for speech and sound output
• Modem
• Network Interface Units

55
Computer System Classes
Chapter 2
Systems Architecture

• Computer systems can be loosely classified
  into the following categories
• Microcomputer/Network Computer
• Minicomputer
• Mainframe
• Supercomputer

56
Computer System Classes
Chapter 2
Systems Architecture

• Microcomputer
• A microcomputer (personal computer or
  workstation) is a computer system designed to
  meet the information-processing needs of a single
  user.

57
Computer System Classes
Chapter 2
Systems Architecture

• Network Computer
• A network computer is a microcomputer with
  minimal secondary storage capacity and little or
  no installed software.

58
Computer System Classes
Chapter 2
Systems Architecture

• Minicomputer
• A minicomputer is designed to provide
  information processing for multiple users and to
  execute many application programs simultaneously.

59
Computer System Classes
Chapter 2
Systems Architecture

• Mainframe
• A mainframe computer system is designed to
  handle the information processing needs of a
  large number of users and applications.

60
Computer System Classes
Chapter 2
Systems Architecture

• Supercomputer
• A supercomputer is designed for one purpose,
  to quickly perform many mathematical
  computations.

61
Computer System Classes
Chapter 2
Systems Architecture
62
The Role of Software
Chapter 2
Systems Architecture

• Definition of Software
• Software Types
• System Software Layers
• Operating Systems
• Application Development Software

63
The Role of Software
Chapter 2
Systems Architecture

• Definition of Software
• Software translates user needs and requests
  into computer instructions that, when executed,
  will produce a result that satisfies the need or
  request.

64
The Role of Software
Chapter 2
Systems Architecture
65
The Role of Software
Chapter 2
Systems Architecture

• Software Types
• Application software
• System software

66
The Role of Software
Chapter 2
Systems Architecture

• Application software is a stored set of
  instructions for responding to a very specific
  request.

67
The Role of Software
Chapter 2
Systems Architecture

• System software is a collection of programs
  that are used to
• Implement utility functions needed by many
  application programs
• Allocate computer resources to application
  programs
• Manage computer resources

68
The Role of Software
Chapter 2
Systems Architecture
69
The Role of Software
Chapter 2
Systems Architecture

• System Software Layer Functions
• System management
• System services
• Resource allocation
• Hardware interface

70
The Role of Software
Chapter 2
Systems Architecture
71
The Role of Software
Chapter 2
Systems Architecture

• Operating Systems
• An operating system is a collection of
  programs that
• Provides utility functions needed by users and
  application programs.
• Allocates computer resources among multiple users
  and application programs
• Controls access to computer hardware

72
The Role of Software
Chapter 2
Systems Architecture

• Operating system functions
• Program storage, loading and execution
• File manipulation and access
• Secondary storage management
• Network and interactive user interfaces

73
The Role of Software
Chapter 2
Systems Architecture

• Application Development Software
• Application development software describes
  programs used to develop other programs.

74
The Role of Software
Chapter 2
Systems Architecture

• Application Development Software
• Program translator
• Program editors
• Debugging tools
• System development tools

75
Economics of System and Applications Development
Software
Chapter 2
Systems Architecture

• Three economic facts of computer hardware
  and software
• System software requires hardware resources.
• The cost per unit of computing power has
  decreased at nearly an exponential rate.
• Software is more cost effective when it is reused
  many times.

76
Economics of System and Applications Development
Software
Chapter 2
Systems Architecture
77
Technology Focus Intel CPUs and Microsoft
Operating Systems
Chapter 2
Systems Architecture
78
Computer Networks
Chapter 2
Systems Architecture

• A computer network is a set of hardware and
  software components that allows information,
  software and hardware resources to be shared
  among multiple users and computer systems.

79
Computer Networks
Chapter 2
Systems Architecture
80
Computer Networks
Chapter 2
Systems Architecture

• Computer network functions
• External Resources
• Network Software
• Network Communication and the Physical Network

81
Computer Networks
Chapter 2
Systems Architecture

• External Resources
• Much of the complexity of modern networks
  arise from the huge quantity of distributed
  resources and the difficulties inherent in
  finding, accessing and managing those resources.

82
Computer Networks
Chapter 2
Systems Architecture

• Network Software
• System Software must
• Find the requested resources on the network
• Negotiate resource access with distant resources
  allocation software
• Receive and deliver the resources to the
  requesting user or program

83
Computer Networks
Chapter 2
Systems Architecture

• Network Software
• System software must (cont.)
• Listen for resource requests
• Validate resource requests
• Deliver resources via the network

84
Computer Networks
Chapter 2
Systems Architecture

• Network Communication and the Physical
  Network
• A computer system requires at least one hardware
  device to implement its connection to a network.

85
Computer Networks
Chapter 2
Systems Architecture

• Network Communication and the Physical
  Network
• The physical network is a complex combination of
  communication protocols, methods of data
  transmission and network hardware devices.

86
Summary
Chapter 2
Systems Architecture

• A computer is an automated device for performing
  computational tasks.
• Computer capabilities include processing,
  storage, and communication.
• A computer system consists of a central
  processing unit, primary storage, secondary
  storage and input/output devices.

87
Summary
Chapter 2
Systems Architecture

• A computer system can be classified as a
  microcomputer, minicomputer, mainframe and
  supercomputer.
• The role of software is to translate user
  processing requests into machine instructions.
• An operating system is the most important type of
  system software on most computer systems.

88
Summary
Chapter 2
Systems Architecture

• A computer network is a set of hardware and
  software components that permits information,
  software, and hardware resources to be shared
  among multiple users and computer systems.

89
Summary
Chapter 2
Systems Architecture
