DM216 The Three Ps of Replication in a High Availability Environment

1
DM216The Three Ps of Replication in a High
Availability Environment
Tony T. Sheng Technical Team Lead PLW Data
Architecture Bell Atlantic tony.t.sheng_at_bellatlant
ic.com
2
The Three Ps of Replication in a High
Availability Environment

• Who am I?
• Overview of Configuration
• Best Practices
• Pitfalls
• The Principles
• Q A

3
The Three Ps of Replication in a High
Availability Environment

• Who am I?
• Tech Lead for a DBA team
• ASE/Rep Server administration for DEV/TEST
• Development of processes for schema changes and
  custom data conversion to support application
• Infrastructure and configuration design
• Production Support for poor performance
• Around 5 years of experience with Sybase products

4
Configuration Overview

• Overview of PLW/CW configuration
• Homogenous dataservers
• Bi directional replication
• No stored procedures, no function strings yet
• No routes, one RS serves PDB-gtRDB
• No Sybase Warm Standby

5
Configuration Overview

• R4 HA

6
Configuration Overview

• R4 to R2 W1CP

7
Configuration Overview

• R4 to R2 W1CP (in more detail)

8
Configuration Overview

• CW

9
Configuration Overview

• Overview of Configuration
• Why is this so confusing?
• TUXEDO, XA Server for 2-phase commit
• Application architecture start up is too long
• Can use the Rep Server to queue for maintenance
  and availability
• Alternative to System 12
• Wanted DBAs to be disconnected from the failover

10
Best Practices

• Design
• Rep Server
• On another host to get data out of the Rep Agent
  fast
• Its own host to reduce network/CPU bottleneck
• Lots of disk so you dont run out of SD
• Hold lots of transactions in the SD if you need
  to
• Data Model
• Login and timestamp field on every table
• Could be used in the future for conflict
  resolution

11
Best Practices

• Design
• Data Server
• Hardware layout and software configuration all to
  accommodate more users in case of failover
• Each database resides on its own set of disks, no
  controller/disk contention
• Use 11.5 Rep Agent and Rep Server
• Hold lots of days in transaction logs if you need
  to

12
Best Practices

• Standards
• Data Definition Language
• Each table has unique index and primary key that
  are relevant (used for auto generation of
  repdefs)
• Object name allows generation of a repdef that is
  less than 30 characters
• UNIX host and Dataserver naming standards
• Each host has a isXXXXXX name
• Each ASE servers is a SQLNAAXXXXXX

13
Best Practices

• Standards
• UNIX host and Data Server naming standards
• Each host has a isXXXXXX name
• is001277
• Each ASE servers is a SQLNAAXXXXXX
• SQL1LW001277, SQL1CW002147
• Can have a backupserver, XA Server and Rep Server
• REP1LW001277, REP2LW001277, REP1CW002147
• SYB_BACKUP1LW001277

14
Best Practices

• Standards
• Replication Objects
• Repdefs - rmachinedatabaseobject
• r1001931w1mdtlb
• Subscriptions - smachinedatabaseobject
• s1001929w1mdtlb
• Function strings names would also be standard

15
Best Practices

• Standards
• Every Sybase server is configured identically.
• Filesystems, partitions, disk names, database
  names
• Configuration changes between the type of
  application, ie. sqljumbo, replarge, etc.
• Flat File Site Specific Information (SSI)
• Flat files to map database names and replication
  flow
• rep_env.hostname
• PRSPDSPDBRRSRDSRDB

16
Best Practices

• Standards
• Allows getting a quick diagnosis
• Assists in getting a quick handle on replication
  flow
• Assists to drill down to specific objects that
  have issues
• The key is to recover quickly from problems

17
Best Practices

• Operational Procedures
• Who updates where ?
• Replication is on the whole time and is
  bidirectional
• Transactions executed by the maintenance user are
  not replicated
• (see send_maint_xacts_to_replicate under
  sp_config_rep_agent)

18
Best Practices

• Operational Procedures
• Who updates where ?
• Application user groups are GRANTed/REVOKEd
  permission based upon operating state (normal
  versus failover)
• One dataserver is always considered the REAL ONE,
  data on this server can be assumed to be correct

19
Best Practices

• Operational Procedures
• Constraints
• Used in the data model to keep integrity of the
  data
• Can bring the Rep Server thread down because of
  the sequence of the SQL
• We have been having OPS drop them on the
  replicate side when necessary
• Probably should include a DROP/ADD constraint
  process during the failover

20
Best Practices

• Operational Procedures
• Autocorrection
• Can help get rid of duplicate key errors that are
  stuck in the queue when synching the data.
• Cant be used with Replicate Minimal Columns
  (which we dont do but probably should)

21
Best Practices

• Monitor
• You must monitor!!
• Rep Agent and Transaction Logs
• Ran into some bugs with Rep Agent hanging
• Check that the transaction log dumps are not
  growing in size
• This would infer that the Rep Agent is not moving
  through the transaction log and moving the
  secondary truncation pointer

22
Best Practices

• Monitor
• Replication Server DSI Threads
• Had a few days where the thread(s) were down (OPS
  error)
• Takes time to recover from this to drain the
  queue
• Vulnerable if failover is needed. You would have
  the potential for in flight transactions. (BIG
  headache)

23
Best Practices

• Monitor
• Some kind of replication heartbeat
• rep_verify process
• Heartbeat table every 10 minutes

24
Best Practices

• Monitor
• Extra Monitoring
• Rep Server queue throughput
• Difference between first and last block every
  hour
• Capture trends for load, additional data, peak
  volumes, future capacity

25
Best Practices

• Monitor
• Rep Server queue throughput

26
Best Practices

• Monitor
• Other various monitoring
• Latency
• Have not noticed too much latency but could
  assimilate data with queue throughput
• rs_lastcommit timestamp on replicate database -
  the last time an update flowed through
• select getdate(), db_name, origin,
  datediff(ss,origin_time,dest_commit_time)from
  rs_lastcommit where origingt0 and origin_time gt
  "Jan 1 1900"

27
Best Practices

• Monitor
• Other various monitoring
• Aggregate information for our rollup replication

89354 ---- md 1449 ---- wv 328029 ----
pa 63383 ---- dc 25255 ---- de 126779 ----
va 98929 ---- nj 733178
SQL1R2051972 -----------
733178 SQL1R2051973 ----------- 733178
28
Best Practices

• Tools and Utilities
• droprep.sh DBNAME ALL
• Utility to drop all replication components for a
  database or all databases on the dataserver
• Large schema changes when it is easier to rebuild
  all replication
• Drops subs/repdefs
• Shutdown Rep Agents and disable
• Remove secondary truncation point (most important)

29
Best Practices

• Tools and Utilities
• Standard process to build replication
• Establish connection for PDB/RDB
• Turn on Rep Agent for PDB
• Build repdefs/subs
• Set replicate bit
• Grant permissions to maintenance user

30
Best Practices

• Tools and Utilities
• REPON/REPOFF.sh
• Utility to temporarily turn off and on
  replication
• Shutdown Rep Agents and disable secondary
  truncation point
• Resets truncation point, turns on Rep Agent

31
Best Practices

• Tools and Utilities
• dump/rcp/load
• Set of scripts to synch up databases from primary
  to replicate
• Make sure no users on the replicate so the
  database can be loaded
• Must reset generation id, reset truncation point,
  reconfigure Rep Agent to the correct Rep Server
  (two way)

32
Best Practices

• Tools and Utilities
• REPdelta
• Process which adds/drops/synchs replication
  objects to database schema changes
• Reads from flat files that have been generated by
  data model process

33
Pitfalls

• Recovering Data from Operational Errors
• Queue was down and a failover was executed
• Have to figure out what updates were held at the
  PDB and what updates were executed at the RDB.
  Timestamp field can help here.

34
Pitfalls

• Application Doing Very Bad Things
• A HUGE Transaction
• One large update took more than 75000 locks on
  the replicate database.
• Rep Server would open the transaction, flow, get
  an error for insufficient locks, rollback the
  transaction and then try again (for 36 hours)
• Had to shutdown the RDS and reconfigure the
  number of locks and let the Rep Server replicate
  the transaction
• Got lucky because the RDS was not in use

35
Pitfalls

• Application Doing Very Bad Things
• Moving the Primary Key of a Unique Index Column
  to another value
• This is a documented restriction.
• Causes the DSI thread to go down because the
  order of the transaction causes a duplicate key
  violation
• Must skip the transaction
• see Chapter 8 of the Rep Server Admin Guide

36
Pitfalls

• Application Doing Very Bad Things
• Moving the Primary Key of a Unique Index Column
  to another value

Table cu_ln clustered unique index is on cu_f,
cu_ln_f update cu_ln set a.cu_ln_f (select
a.cu_ln_f max(b.cu_ln_f) from cu_ln b
where b.cu_f 23732123) from cu_ln a where
a.cu_f 982323433 go
37
Pitfalls

• Application Doing Very Bad Things
• Moving the Primary Key of a Unique Index Column
  to another value
• the workaround involves making all the updates to
  a temp table and then inserting them and deleting
  the old rows

1. select into getoldculn from cu_ln where
cu_f OLD 2. update getoldculn set cu_ln_f
(select cu_ln_f max(cu_ln_f) from getoldculn
where cu_f OLD 3. insert into cu_ln select
from getoldculn where cu_f OLD
38
Pitfalls

• DBA functions
• Tried to move the logsegment off a device onto
  another device using sp_dropsegment and
  sp_extendsegment
• alter database xlvww1ma log on SYBLDEV26 500
• go
• use xlvww1ma
• go
• sp_dropsegment "logsegment", "xlvww1ma","SYBLDEV04
  "
• go
• sp_extendsegment "default", "xlvww1ma","SYBLDEV04"

• go

39
Pitfalls

• DBA functions
• Tried to move the logsegment off a device onto
  another device using sp_dropsegment and
  sp_extendsegment
• Ended up getting 605 and 692 errors on the log
  segment of the database.
• Should have turned off the Rep Agent before any
  of this work.
• Recovered by reloading the databases. (painful)

40
Pitfalls

• DBA functions
• Bad constraint added manually
• Had a DSI thread that was up but no data would
  flow.
• Maintenance user spid IOs never increased.
• Queue would drain when autocorrection was turned
  on
• Found a bad constraint on the replicate database
  (most likely put in by manual process
• C_AD_gssl_adr_rng_1
• adr FOREIGN KEY (adr_f) SELF REFERENCES
  adr(adr_f)

41
Pitfalls

• Synching databases
• You will probably have to synch your data
  periodically
• Skipped transactions
• Incorrect failover
• Make this a documented standard procedure so it
  is readily available.
• Use autocorrection to avoid the first few
  duplicate key errors from data that is in the log

42
The Principles

• A Replication Lab
• Have a restricted development lab that mimics
  production
• Owned by DBAs, no other teams have access
• Same DS/RS configuration
• Number of databases, Rep Servers, rs_config,
  sp_configure
• Used to isolate replication problems
• Mock deploy replication fixes
• Test out new replication topologies
• Recreate production problems

43
The Principles

• Send all SQL through the SW lifecycle
• When we get burned, 90 is from SQL that didnt
  go through the software lifecycle.
• Be stringent about application transaction size
• every SQL is reviewed by DBA team for
• Performance standards (valid SARGs, good
  showplan, etc.)
• Replication Server standards
• (no update table set col1T where col1R) -gt
  sends into a big update transaction on the
  replicate

44
The Principles

• More Principles We Have Learned
• Have good standards
• Assist you in debugging quickly
• Start simple with Rep Server
• Monitor, Monitor, Monitor
• Know your Operating Procedures
• Step by Step of failover/failback process

45
What Is Next?

• Replicating data through different schemas
• combination of function strings/operational steps
  depending on the type of change
• Configuration that is similar to System 12
• move to hot/cold configuration where the disks
  are shared and switched
• no Rep Server for local failover but still for
  DR mode data replication

46
Q A
