Essential Disaster Recovery

1
Essential Disaster Recovery Business
Continuity Technologies for Healthcare

• Custom Storage
• Pete Schmitt
• Kelly Mooney

2
How we make a difference

• Personal, hands-on approach
• Strong data storage technologies services.

3
Single Point of Contact

• Disaster Recovery
• Business Continuity
• Reduced Power Consumption
• Server Consolidation
• Simplified Provisioning
• Centralization
• Replication
• Fast Recovery
• Specific App. Support

4
Agenda

• Business Drivers / Challenges for DR
• Todays Disaster Recovery Technology
• Choosing technology to match business needs
• Questions / Discussion / Wrap up

5
IT Managers Agree

• Key storage management challenges for 2008?

Enhanced backup disaster recovery
59
File Archiving
57
Email Archiving
55
42
Database Archiving
Continuous Data Protection
26
Encryption of archived data
22
Storage Management / ILM
13
Based on Bridge-Head Softwares survey of 472 IT
executives across North America. 9/2007
6
Disaster Recovery Plan Development
Disaster Recovery Plan
7
Symantec Annual IT Survey
September 2008 Symantec Annual IT Survey

• 1000 businesses worldwide
• 500 employees

33 of the organizations surveyed had to
execute their disaster recovery plans in the
past year.
Published in IT News 9/9/2008
8
Disaster Recovery Drivers
Symantec Annual IT Survey Results
Published in IT News 9/9/2008 Symantec Annual
IT Survey
9
Business Impact Analysis

• A BIA is designed to identify
• The business functions performed by an
  organization
• The resources required to support each business
  function performed
• Interdependencies between business functions
  (the information flow)
• The impact/criticality of not performing a
  specific business function
• A Recovery Time Objective (RTO) for each
  business function
• A Recovery Point Objective (RPO) for the data
  that supports each
• business function

10
Business Impact Analysis
11
Which Technology?
RemoteReplication
Synchronous
Network-based Replication
Snapshots
Multihop
Point-in-timeCopy
Asynchronous
Cascading
Host-basedReplication
Clustering
Disk Protection
12
Determine Recovery Objectives
Cost
Cost Vs Availability
Cost
Source Deloitte Touche
13
Software Architecture
ContinuousOperations
Availability
LAN/WANClustering
SynchronousReplication
Synchronous Clusters MetroCluster
Asynchronous Replication
Synchronous Mirroring and Clustering
Block LevelIncremental Backups
Synchronous Mirroring Asynchronous Mirroring
Cost
Vaulting
ApplicationRecovery
Off Site Backup
Daily Backup
Snapshots
Low Level SLA
Medium Level SLA
High Level SLA
Cost
14
Disaster Recovery Architecture
Major Data Center
Disaster Recovery Site
D2D Storage
Clustered/Non clusteredServers
BackupServer
Mirroring
Vault
TapeLibrary
D2D Storage
Mirroring
15
MetroCluster
MetroCluster is a unique, cost-effective
synchronous replication solution for combined HA
and DR, protecting against site disasters within
a campus or metropolitan area
Configurations
Major Data Center
Nearby Office

• Stretch MetroCluster provides Campus DR
  protection
• Distances up to 500m
• Fabric MetroCluster provides Metropolitan DR
  protection
• Distances to 100 km

LAN/SAN
FAS or Vseries
Disks
Effective distances depend on speed, cable type,
and connections
16
MetroCluster Features Benefits

• Highest Level of Availability
• Provides superior availability to RAID 1 0
• Protects against data center failures and site
  disasters for a negligible cost premium
• Simple Fast Recovery
• Automatic Recovery for any single component
  failure
• Single command recovery even for major
  catastrophic site failures
• Cost-effective
• Combines High Availability clustering with
  Disaster Recovery mirroring
• Zero Data Loss
• Synchronous data replication
• Enhanced Read Performance
• Up to 80 improved read performance for random
  reads, due to simultaneous read operations
  occurring on both plexes

17
Which Technology?

• Choosing technology to match business needs

18
Real World Application
Key Objectives

• Economical support for new technologies EMR and
  surgical video streaming/editing
• Minimize unplanned downtime
• Support long-term goal of business continuity /
  Risk mitigation
• Flexible, thoughtfully mapped technology to
  planned growth
• One-time, strategic technology upgrade vs.
  incremental upgrades

19
(No Transcript)
20

• Operational Impact
• Simplified Administration with consolidated
  infrastructure
• Improved Network Security
• Disaster Recovery capable at a lower cost
• Reduced Help Desk Requirements
• Flexible and Scalability built in for future
  growth

When we needed to upgrade our environment we
partnered with Custom Storage who helped us to
develop a solution that supported technology
upgrades such as EMR and surgical video
streaming, provided flexibility to consolidate
critical environments such as Exchange, SQL and
file shares and incorporated redundancy
supporting our long team DR strategy. Steve
Slack, Director of Information Technology,
Barrow Neurosurgical Associates
21
Replication to Central Repository
22
Symantec Annual IT Survey
September 2008 Symantec Annual IT Survey

• 1000 businesses worldwide
• 500 employees

How is my DR Strategy going to measure up?
Published in IT News 9/9/2008
23
Discussion

• Questions / Wrap up
