Cosequential Processing

1
Cosequential Processing

• Chapter 8

2
Cosequential Processing

• Coordinated processing of two or more sequential
  lists
• Goals
• To merge lists into a single sorted list (union)
• Make a single sorted list from many
• To match records with the same keys
  (intersection)
• Apply transactions to a master file
• Find entries which exist in multiple lists

3
Cosequential Processing

• Keys
• Matching/merging may be by a single key or
  several.
• Number of keys only affects compare operator, not
  sort strategy

4
Master Transaction File Processing

• Common processing strategy on sequential files.
• Common since historically sequential processing
  was the rule (tapes, cards)
• Companies stored data in sequential files
• Lists of transactions posted against these
  record periodically.

5
Master Transaction File Processing

• Consider a grocery store
• Record of inventory for each type of item stored
  in a large sequential file (master file)
• As items sold, a the item number and quantity
  sold posted (written) as records to a transaction
  file
• As trucks deliver new items, item numbers and
  quantities are entered into the transaction file.
• As new types of items are added to inventory, or
  old items are discontinued, entries about this
  are placed in the transaction file.

6
Master Transaction File Processing

• grocery store example

Master File
Transaction File
Item Item Name Type Quan 20231 Shoe Shine (br)
6 4 20231 Shoe Shine (bl) 6 1 20177 Cottage
Cheese 5 392 20179 Chicken Soup 6 32 20231
T-bone 2 43 ....
Item Trans Quan Item Name 20231 U
-2 20231 U 50 20379 U -5 20443 U
-4 20445 A 40 Corn Chips 20532 A 300
Butter 20534 D 20558 U 200 ....
U - Update A - Add D - Delete
7
Master Transaction File Processing

• Periodically update master from transaction

New Master File
Transaction File
Update Operation
Old Master File
Update Messages
8
Master Transaction File Processing

• Transactions are applied against master.
• New master is created
• Invalid Transactions result in Message
• Important changes in Messages - audit trail
• Transaction and master must be in sorted order.

9
Master Transaction File Processing

• Processing Scheme
• Read record Mast from old Master and Trans from
  Transaction
• While more records in both files
• if Add and Trans.ID lt Mast.ID, write Mast to new
  master
• else If Trans.ID Mast.ID then
• If UPDATE then update record and write to new
  master
• If Delete then continue (no write)
• else trasaction error
• else write Mast to new master
• Read next from transaction, next from old master
• If more records in old master, write to new
  master
• If more records in transaction, give errors

10
Merging

• Merge two (or more) sorted lists into a single
  sorted list
• May remove duplicates (union) or keep

Bill Gray Hillery Jenny Linda Mary Randy
Bill Cathy Fran Gray Hillery Jenny Kenny Linda Mar
y Pete Randy Sally Zeke
merge
Cathy Fran Kenny Pete Sally Zeke
11
Merging

• Merge(List1,Max1,List2, Max2,Result)
• int next1 0 next2 0 out 0
• while Max1 gt next1 and Max2 gt next2
• if (List1next1 gt List2next2)
• Resultout List2next2
• else
• Resultout List1next1
• if (List1 lt Max1)for ( next1 lt Max1
  Resultout List1next1)
• if (List2 lt Max2)for ( next1 lt Max2
  Resultout List2next1)

12
Sorting

• Small files
• sort completely in memory
• Called internal sorting.

13
Sorting

• Larger files
• may be too large to fit in memory simultaneously
• require "external sorting"
• Sorting using secondary devices

14
External Sorting

• Criteria for evaluating external sorting
  algorithms
• Different from internal sorts
• Internal sort comparison criteria
• Number of comparisons required
• Number of swaps made
• Memory needs
• External sort comparison criteria
• Dominated by I/O time
• Minimize transfers between secondary storage and
  main memory

15
External Sorting

• Two major external sorting methods
• in situ - sort the file in place
• use additional storage space

16
External Sorting

• Characteristics of in situ sorting
• uses less file space, thus larger files may be
  sorted.
• if crash occurs during sort, file may be left in
  corrupt state
• in site sorts may be done on direct-access files
  using standard internal type sorts.
• direct-access required (may not be available)
• performance of such algorithm's tends to be data
  sensitive

17
External Sorting

• Consider a file with 1000 records, 120 bytes each
• We have 25,000 bytes available for a buffer.
• Solution?
• read in 200 records at a time, sort internally
• This results in 5 sorted files
• merge the resulting sorted files into 1sorted file

18
Sort/Merge

• A common non-in situ method is an algorithm
  called "sort-merge"
• "safe" sorting technique
• performance is guaranteed
• requires only serial file access

19
Sort/Merge
Sort
Sort
Merge
Partition
Sort
Sort
20
Sort/Merge

• Sort/Merge techniques have two stages
• sort stage - sorted partitions are generated
• Size depends on available memory
• merge stage - sorted partitions are merged
  (repetitively if necessary)
• Why might more then one merge phase be needed?

21
Basic Sort/Merge

• initial partition size is 1
• Merge begins immediately (no sort)
• Smallest main memory use
• requires only 2 buffers in memory.
• File starts with N "sorted" files of size 1
• Similar to internal merge/sort

22
Improving Sort/Merge

• Increase buffer size
• Partitions sorted (in memory) with little I/O
• Larger partitions mean fewer (I/O intensive)
  merges needed
• Take advantage of already sorted runs of data
• Consider the "unsortedness" of the data

23
Sort/Merge

• Producing sorted partitions
• internal sorting
• natural selection - (use already sorted runs)
• replacement selection

24
Internal sorting

• read M records (M determined by available memory)
• sort them using internal sorting techniques
• write back out, creating a partition of size M

25
Sort/Merge

• Replacement selection (snowshovel)
• files usually not totally out of order
• take advantage of partial ordering in file
• partition size varies with already existing
  ordering

26
Replacement selection (snowshovel)

• Start with primary buffer of size N (snowshovel)
• 1. Read in N records into buffer
• 2. Output record with smallest key
• 3. Replace with next record in file
• 4. if this new record is smaller then the last
  record written, "freeze" (must wait for next
  partition)
• 5. if unfrozen records remain, go to 2
• 6. If all records frozen, unfreeze them all,
  start new partition, go to 2

27
Replacement selection (snowshovel)

• if file is sorted or almost sorted, one pass may
  suffice for complete sort!
• average partition length is 2N
• Consider file with, N 4
• 29 42 3 7 9 101 99 87 89 100 16 8 12 2 15 EOF

28
Natural Selection

• Frozen records in the replacement scheme take up
  space and search time.
• Natural, rather than freezing, writes these
  unused records to a fixed length secondary file
  (called reservoir)
• partition creation terminates when reservoir
  full.
• Next, buffer is refilled first with records from
  buffer, than records from file (if more needed)
• expected partition length is 2.718N if reservoir
  and buffer same size - (about 30)

29
Natural Selection

• Redo example with reservoir size 4
• 29 42 3 7 9 101 99 87 89 100 16 8 12 2 15 EOF

30
Distribution and Merging

• Merging
• required to bring the sorted partitions together
  into a sorted whole
• may require a series of merge phases, where
  shorter partitions are merged into larger
  partitions
• More then one partitions per file
• Not all partitions can be openned at once

31
MergingSingle phase
32
MergingMultiple phase
33
MergingMultiple Partitions / File
P5-8
P1-8
P9-12
P1-12
34
Merging

• Major issues - minimizing overall I/O
• Different length partitions
• Spend time simply reading and writing from one
  file
• Left over partitions
• Spend time simply copying partitions

35
Distribution and Merging

• Distribution
• In order to merge, partitions must be
  distributed to files in a manner facilitaing
  the merge process.
• If 1 partition per file, distribution is trivial
• If gt1 partition per file, distribution should
  minimize I/O
• Several partitions may be placed in each file

36
Balanced N-way merge

• use as many files (or tapes) as the system can
  open at once
• Distribute the partitions evenly amoung F/2 files
• repetitively merge back and forth between one set
  of F/2 files and the other
• Distribute the generated partitions evenly amoung
  the F/2 output files

37
Balanced 2-way merge
File 1
File 2
File 3
File 4
P5-8
File 1
File 2
P1-8
P9-12
File 3
File 4
P1-12
File 1
38
Balanced 2-way merge

• Example 4 files, 700 records, 100 primary
  records can be sorted in memory

1-100 201-300 401-500 601-700
1-200 401-600
1-400
1-700
1-700
101-200 301-400 501-600
201-400 601-700
401-700
39
Balanced N-way merge

• advantage
• simple
• disadvantage
• wastes time if partition size different
• spend time reading and write records without
  actually merging

40
Polyphase merging

• Strategically distribute the partitions onto F
  files based on the Fibonacci Sequence
• Algorithm
• During each phase merge the F smallest files
  until the end of one file is reached.
• After each phase at least one partition will now
  be empty - this file becomes available new place
  to merge into
• Continue to merge until only one file exists

41
Polyphase merging

• Consider Initially generate three files
• 24 partitions, 20 partitions , and 13 partitions

42
Polyphase merging

• advantages
• No overhead from merging partitions of different
  sizes
• disadvantages
• complex management of files
• must know partition sizes
• still not completely optional - partition sizes
  not always maximal.
