Chap' 6 Classification and Prediction

1
Chap. 6 Classification and Prediction

• Data Mining

2
Classification vs. Prediction

• Classification
• Predicts categorical class labels of a data
• Constructs a model based on the training set,
  tests the model by using the test set, and uses
  it in classifying new data
• Prediction
• Models continuous-valued functions
• Typical Applications
• Credit approval
• Target marketing
• Medical diagnosis

3
Classification

• Model construction
• The set of tuples used for model construction
  training set
• ? Each tuple/sample belongs to a predefined
  class, as determined by the class label
• The model is represented as classification rules,
  decision trees, or mathematical formulae
• Model usage
• Classify future or unknown data
• Estimate accuracy of the model - a test set with
  known class label is classified, and the result
  is compared
• Accuracy rate the percentage of test set samples
  that are correctly classified by the model

4
Model Construction
Classification Algorithms
IF rank professor OR years gt 6 THEN
tenured yes
5
Use the Model in Prediction
Unseen Data
Class
(Jeff, Professor, 4)
Yes
Tenured?
6
Supervised vs. Unsupervised

• Supervised learning (classification)
• Supervision The training data (observations,
  measurements, etc.) are accompanied by labels
  indicating the class
• New data is classified based on the training set
• Unsupervised learning (clustering)
• The class labels of training data is not given
• Given a set of measurements, observations, etc.
• ? establishing the existence of classes or
  clusters in the data

7
Preparing the Data

• Data cleaning
• Preprocess data in order to reduce noise and
  handle missing values
• Relevance analysis (feature selection)
• Remove the irrelevant or redundant attributes
• Data transformation
• Generalize and/or normalize data
• Exgt income ? Low, Medium, High
• Exgt income, age integer ? 0.0, 1.0

8
Comparing Classification Methods

• Predictive accuracy
• Speed
• Time to construct the model / use the model
• Robustness
• Handling noise and missing values
• Scalability
• Efficiency in disk-resident large databases
• Interpretability
• Understanding and insight provided by the model

9
Decision Tree Induction

• Decision tree
• Internal node - a test on an attribute
• Branch - an outcome of the test
• Leaf nodes - class labels
• Decision tree generation - two phases
• Tree construction
• At start, all the training examples are at the
  root
• Partition examples recursively based on selected
  attributes
• Tree pruning
• Identify and remove branches that reflect noise
  or outliers
• Classifying an unknown sample
• Test the attribute values of the sample against
  the decision tree

10
Training Dataset
11
Output A Decision Tree for buys_computer
X (agelt30, incomemedium,
studentyes, creditfair)
Yes
12
Algorithm for DT Induction

• Basic algorithm
• Top-down recursive divide-and-conquer manner
• At start, all the training examples are at the
  root
• Test attributes are selected on the basis of a
  heuristic or statistical measure (e.g.,
  information gain)
• Examples are partitioned recursively based on
  selected attributes
• Conditions for stopping partitioning
• All samples belong to the same class
• No samples left ? majority class
• No attributes left ? majority sample

13
Algorithm for DT Induction - Example
age?
lt30
gt40
30..40
9,11(Yes) 1,2,8(No)
3,7,12,13(Yes)
4,5,10(Yes) 6,14(No)
age?
lt30
gt40
30..40
student?
credit rating?
Yes
n
y
fair
excellent
1,2,8(No)
9,11(Yes)
4,5,10(Yes)
6,14(No)
14
Information Gain (ID3/C4.5)

• S contains s data samples in C1, C2, , Cn
  classes
• Number of samples in class Ci si
• Prob. That a sample belongs to Ci pi si / s
• Information required to classify a sample in Ci
• Expected information to classify a sample in S
  (Entropy of S)

15
Information Gain (ID3/C4.5)

• Expected entropy after check attribute A value
• Average entropy of S1, S2, Sn after partition
  S using attribute A with values a1,a2,,av
• Information gained by branching on attribute A
• Select attribute with largest gain

16
Attribute Selection by Information Gain - Example

• C1 buys_computer yes, C2 buys_computer
  no
• I(S) I(9,5)
• E(age)
• Gain(age)
• Gain(income) 0.03, Gain(student) 0.15

17
Information Gain for Continuous-Value Attributes

• Let attribute A be a continuous-valued attribute
• Must determine the best split point for A
• Sort the value A in increasing order
• Typically, the midpoint between each pair of
  adjacent values is considered as a possible split
  point
• (aiai1)/2 is the midpoint between the values of
  ai and ai1
• The point with the minimum expected information
  requirement for A is selected as the split-point
  for A
• Split
• D1 is the set of tuples in D satisfying A
  split-point, and D2 is the set of tuples in D
  satisfying A gt split-point

18
Gain Ratio for Attribute Selection

• Information gain measure is biased towards
  attributes with a large number of values
• C4.5 uses gain ratio to overcome the problem
  (normalization to information gain)
• GainRatio(A) Gain(A)/SplitInfo(A)
• Ex.
• gain_ratio(income) 0.029/0.926 0.031
• The attribute with the maximum gain ratio is
  selected as the splitting attribute

19
Extracting Classification Rules

• Represent the knowledge in the form of IF-THEN
  rules
• One rule is created for each path from the root
  to a leaf
• Each attribute-value pair along a path forms a
  conjunction
• The leaf node holds the class prediction
• Rules are easier for humans to understand
• Example
• IF age lt30 AND student no THEN
  buys_computer no
• IF age lt30 AND student yes THEN
  buys_computer yes
• IF age 3140 THEN buys_computer
  yes
• IF age gt40 AND credit excellent THEN
  buys_computer yes
• IF age gt40 AND credit fair THEN
  buys_computer no

20
Avoid Overfitting

• The generated tree may overfit the training data
• Too many branches, some may reflect anomalies due
  to noise or outliers
• Result is in poor accuracy for unseen samples
• Prepruning
• Halt tree construction earlydo not split a node
  if this would result in the goodness measure
  falling below a threshold
• Postpruning
• Remove branches from a fully grown tree
• If pruning a node lead to a smaller error rate
  (with test set), prune it

21
Discussion on DT

• Advantages
• Convertible to understandable classification
  rules
• Relatively faster learning/classification speed
• Disadvantages
• Sensitive (not robust) to noises
• Continuous-valued attributes - dynamically
  partition the continuous attribute value into a
  discrete set of intervals

22
Bayes Theorem

• Given a data X, we want to know P(hX)
• h a hypothesis that X belongs to a class C
• Posteriori probability of a hypothesis h, P(hX)
• MAP (maximum posteriori) hypothesis
• Assign X to h with maximum P(h X) Bayesian
  Classifier

23
Naïve Bayesian Classifier

• Assumption attributes are conditionally
  independent
• Steps
• Compute P(Ck), P(xiCk) for all xi and Ck from
  training samples
• To classify an unknown sample X (x1, x2, , xn
  ), compute
• Assign X to Ck with maximum probability

24
Naïve Bayesian Classifier - Example
25
Naïve Bayesian Classifier - Example

• Compute P(Ck), P(xiCk)
• P(Yes) 9/14 0.643
• P(No) 5/14 0.357
• P(age lt30 Yes) 2/9 0.222
• P(age lt30 No) 3/5 0.600
• P(income medium Yes) 4/9 0.444
• P(income medium No) 2/5 0.400
• P(student yes Yes) 6/9 0.667
• P(student yes No) 1/5 0.200
• P(credit fair Yes) 6/9 0.667
• P(credit fair Yes) 2/5 0.400

26
Naïve Bayesian Classifier - Example

• Classify unknown sample
• X (agelt30, incomemedium,
• studentyes, creditfair)
• P(Yes X) ? P(Yes) P(XYes)
• 0.643 x 0.222 x 0.444 x 0.667 x 0.667
  0.028 ?
• P(No X) ? P(No) P(XNo)
• 0.357 x 0.600 x 0.400 x 0.200 x 0.400
  0.007 ?
• Classify X as Yes

27
Discussion on Naïve Bayesian

• Advantages
• Optimal classifier if all the joint probabilities
  P(X h) are known (without the independence
  assumption)
• Easy to apply
• Disadvantages
• Need large number of training examples
• Low accuracy when there are strong dependencies
  between attributes
• Laplace correction
• Eliminate possibility of too strong probability
  estimation (0, 1)

28
Bayesian Belief Networks

• The independence hypothesis
• Makes computation possible and yields optimal
  classifiers when satisfied
• But it is seldom satisfied in practice, as
  attributes are often correlated
• Bayesian networks
• A graphical model of causal relationships
• Combine Bayesian reasoning with causal
  relationships between attributes joint
  conditional probability distribution
• It allows a subset of the variables conditionally
  independent

29
Bayesian Belief Networks
30
Bayesian Belief Networks

• Computing probability
• Compute any P(Ck x1 .. xn)
• with the probability distribution

31
Bayesian Belief Networks

• Example compute P(LungCancer F, S, PX, D)
• Use Naive Bayesian
• Need P(LC), P(F LC), P(S LC), P(PX LC), P(D
  LC)
• ? 2 4 4 4 4 18 prob.
• Use Bayesian network model
• Need P(F), P(S), P(LC F, S), P(PX LC), P(D
  LC)
• ? 2 2 8 4 4 20 prob.
• Use full joint probability table
• Need P(LC, F, S, PX, D) ? 25 prob.

32
Linear Classification

• Classification Mathematical mapping
• x ? X ?n, y ? Y 1, 1
• We want a function f X ? Y
• Binary Classification problem
• The data above the red line
• belongs to class x
• The data below red line
• belongs to class o
• Examples SVM, Perceptron,
• Probabilistic Classifiers

33
Perceptron

• Vector X, W
• Input (X1, y1),
• Output classification function f(X)
• f(Xi) gt 0 for yi 1
• f(Xi) lt 0 for yi -1
• f(x) ? WX b 0
• or w1x1w2x2b 0

• Perceptron update W additively

34
Neural Networks

• A neuron

?j
w0
x0
w1
x1
å
. . .
output o
wn
xn
Input vector X
weighted sum
Activation function
weight vector W
35
Learning of a Neuron

• Given (X, t), minimize error E

36
Multi-Layer Perceptron
Output vector O
Output nodes
wjk
Hidden nodes
wij
x1
x2
Input vector X
37
Network Training

• The objective of training
• Obtain a set of weights that makes almost all the
  samples in the training data classified correctly

• Steps
• Initialize weights wij with random values
• Feed the traning samples X into the network one
  by one
• For each unit
• Compute the output value O using the activation
  function
• Compute the error E
• Update the weights wij and the biases

38
Backpropagation Learning
Output vector O
Output nodes
wjk
Hidden nodes
wij
x1
x2
Given (X, T)
Input vector X
39
Neural Network Classifier - Example
40
Neural Network Classifier - Example

• Training with 14 examples 1000 times
• Classify unknown sample
• X (agelt30, incomemedium,
• studentyes, creditfair)
• ? (0, 0.5, 1, 0)
• O 0.85
• Classify X as Yes

41
Discussion on NN

• Advantages
• Robust - works when training examples contain
  errors
• Output may be discrete, real-valued, or a vector
  of several discrete or real-valued attributes
• Fast evaluation of the learned target function
• Criticism
• Long training time
• Difficult to understand the learned function
  (weights)
• Not easy to incorporate domain knowledge

42
Classification Based on Association

• Use association rule mining
• Associative classification
• Mines high support and high confidence rules
• cond_set gt y (y a class
  label)
• If several rules have same cond_set, select
  highest confidence rule ? Possible Rule Set
• Rules are organized in decreasing confidence
  order
• Classification of new data
• - First rule that satisfying the data is applied

43
Associative Classification - Example

• Possible rule set
• (age 30-40) ? Yes (c 100, s 21)
• (age lt30)?(student No) ? No (c 100, s
  14)
• (student yes) ? Yes (c 86, s 43)
• (income low) ? Yes (c 75, s 21)
• Classify unknown sample
• X (incomemedium, studentyes)
• Classify X as Yes

44
k-Nearest Neighbor Algorithm

• Store all training examples (instances)
• All instances correspond to points in the n-D
  space.
• Classify new instance by finding the nearest
  example
• The nearest neighbor are defined in terms of
  Euclidean distance.
• The target function could be discrete or real
  valued.

_
_
_

_


X
_

_

45
k-Nearest Neighbor Algorithm

• For discrete-valued target
• The k-NN returns the most common value among the
  k training examples nearest to X
• Exgt Classify Yes or No, 10-NN, 7 Yes, 3 No ? Yes
• For continuous-valued target
• Calculate the mean values of the k nearest
  neighbors
• Distance-weighted method
• Weight k neighbors according to their distance to
  X
• Larger weight to closer neighbor

46
k-NN - Example

• Given 14 examples ? map to 4-D space
• Classify unknown sample
• X (agelt30, incomemedium,
• studentyes, creditfair) ? (0,
  0.5, 1, 0)
• 3-NN (0, 0, 1, 0) 1(yes), d 0.5, w 1/0.5
• (0, 0.5, 0, 0) 0(no), d 1.0, w
  1/1.0
• (0, 0.5, 1, 1) 1(yes), d 1.0, w
  1/1.0
• W 4
• y 2/4 x 1(yes) 1/4 x 0(no) 1/4 x 1(yes)
  0.75
• Classify X as Yes

47
Discussion on k-NN

• Advantage
• Robust to noisy data (averaging k-nearest
  neighbors)
• No training time
• Disadvantage
• Classification time can be long when there are
  too many instances (O(n2) distance computations)
• Curse of dimensionality - distance between
  neighbors could be dominated by irrelevant
  attributes

48
Case-Based Reasoning

• Similar to k-NN
• Instances(cases) are symbolic descriptions (not
  points in a Euclidean space)
• Customer service help desk, law cases, technical
  designs
• Methodology
• Instances are represented by symbolic
  descriptions
• Find cases with similar descriptions
• Solutions of multiple retrieved cases are
  combined
• Research issues
• Finding similarity measure
• Combining cases

49
Lazy vs. Eager Learning

• Eager learning
• Construct generalization model before receiving
  new samples to classify
• Decision tree, Bayesian classifier, neural
  network
• Lazy learning
• Do not build a model until a new sample to
  classify is given
• k-nearlest neighbor classifier, case-based
  reasoning
• Difference
• Training - Lazy learning is faster
• Classifying Eager learning is faster

50
Fuzzy Set Approaches

• Fuzzy logic
• Uses truth values in 0.0, 1.0 (not F, T)
• ? Represented as a membership function
• IF (income gt 50K) THEN yes ? false for income 49K
• IF (income high) THEN yes ? 0.9 yes for income
  49K

51
Fuzzy Set Approaches

• Using fuzzy logic in rule-based system
• Rules are represented with fuzzy categories
• IF (income high) THEN yes
• IF (income medium) THEN no
• For a given new sample, attribute values are
  converted to fuzzy values
• income 49K ? 0.1 medium, 0.9 high
• Each applicable rule contributes a vote for
  membership in the categories
• 0.9 yes, 0.1 no,
• The truth values for each predicted category are
  summed

52
Prediction

• Prediction is similar to classification
• Construct a model ? use model to predict unknown
  value
• Linear regression Y ? ? X
• ? and ? are estimated using the least squares
  criterion to the known data (X1, Y1 ), (X2, Y2 ),
  , (Xn, Yn)
• Mininize ?(Yi - ? - ? Xi )2 ? find ? and ?
• Multiple regression Y ? ?1X1 ?2X2
• Y is modeled as a linear function of multiple
  attributes
• Non-linear regression Y ? ?1X ?2X2
• Y is modeled as a non-linear function of single
  attribute

53
Classification Accuracy

• Holdout
• Partition dataset into training set and test set
• Training set derive the classifier
• Test set estimate the accuracy
• K-fold cross-validation
• Divide the data set into k subsets
• Use k-1 subsets as training data and 1 subset as
  test data
• Repeat k times, and average the accuracy

S1, S2, S3, S4, S5
? S1, S2, S3, S4, S5
? S1, S2, S3, S4, S5
54
Classification Accuracy

• Bootstrap
• Works well with small data sets
• Samples the given training tuples uniformly with
  replacement
• i.e., each time a tuple is selected, it is
  equally likely to be selected again and re-added
  to the training set
• .632 boostrap
• Given a data set of d tuples, the data set is
  sampled d times, with replacement, resulting in a
  training set of d samples.
• The data tuples that did not make it into the
  training set end up forming the test set.
• 36.8 will form the test set. (1 1/d)d e-1
  0.368

55
Ensemble Methods

• Ensemble
• Use a combination of models to increase accuracy
• Combine a series of k learned models, M1, M2, ,
  Mk, with the aim of creating an improved model M
• Popular ensemble methods
• Bagging averaging the prediction over a
  collection of classifiers
• Boosting weighted vote with a collection of
  classifiers

56
Bagging

• Analogy
• Diagnosis based on multiple doctors majority
  vote
• Training
• Given a set D of d tuples, at each iteration i, a
  training set Di of d tuples is sampled with
  replacement from D (i.e., boostrap)
• A classifier model Mi is learned for each
  training set Di
• Classification
• Each classifier Mi returns its class prediction
• The bagged classifier M counts the votes and
  assigns the class with the most votes to an
  unknown sample X
• Accuracy
• Often significant better than a single classifier
  derived from D
• For noise data not considerably worse, more
  robust
• Proved improved accuracy in prediction

57
Boosting

• Analogy
• Consult several doctors, based on a combination
  of diagnoses
• Weight assigned based on the previous diagnosis
  accuracy
• Training
• Weights are assigned to each training tuple
• A series of k classifiers is iteratively learned
• After a classifier Mi is learned, the weights are
  updated to allow the subsequent classifier, Mi1,
  to pay more attention to the training tuples that
  were misclassified by Mi
• Classification
• The final M combines the votes of each
  individual classifier, where the weight of each
  classifier's vote is a function of its accuracy
• Accuracy
• Comparing with bagging boosting tends to achieve
  greater accuracy, but it also risks overfitting
  the model to misclassified data

58
References

• C. Apte and S. Weiss. Data mining with decision
  trees and decision rules. Future Generation
  Computer Systems, 13, 1997.
• C. M. Bishop, Neural Networks for Pattern
  Recognition. Oxford University Press, 1995.
• L. Breiman, J. Friedman, R. Olshen, and C. Stone.
  Classification and Regression Trees. Wadsworth
  International Group, 1984.
• C. J. C. Burges. A Tutorial on Support Vector
  Machines for Pattern Recognition. Data Mining and
  Knowledge Discovery, 2(2) 121-168, 1998.
• P. K. Chan and S. J. Stolfo. Learning arbiter and
  combiner trees from partitioned data for scaling
  machine learning. KDD'95.
• W. Cohen. Fast effective rule induction.
  ICML'95.
• G. Cong, K.-L. Tan, A. K. H. Tung, and X. Xu.
  Mining top-k covering rule groups for gene
  expression data. SIGMOD'05.
• A. J. Dobson. An Introduction to Generalized
  Linear Models. Chapman and Hall, 1990.
• G. Dong and J. Li. Efficient mining of emerging
  patterns Discovering trends and differences.
  KDD'99.
• R. O. Duda, P. E. Hart, and D. G. Stork. Pattern
  Classification, 2ed. John Wiley and Sons, 2001
• U. M. Fayyad. Branching on attribute values in
  decision tree generation. AAAI94.
• Y. Freund and R. E. Schapire. A
  decision-theoretic generalization of on-line
  learning and an application to boosting. J.
  Computer and System Sciences, 1997.
• J. Gehrke, R. Ramakrishnan, and V. Ganti.
  Rainforest A framework for fast decision tree
  construction of large datasets. VLDB98.

59
References

• J. Gehrke, V. Gant, R. Ramakrishnan, and W.-Y.
  Loh, BOAT -- Optimistic Decision Tree
  Construction. SIGMOD'99.
• T. Hastie, R. Tibshirani, and J. Friedman. The
  Elements of Statistical Learning Data Mining,
  Inference, and Prediction. Springer-Verlag,
  2001.
• D. Heckerman, D. Geiger, and D. M. Chickering.
  Learning Bayesian networks The combination of
  knowledge and statistical data. Machine Learning,
  1995.
• M. Kamber, L. Winstone, W. Gong, S. Cheng, and
  J. Han. Generalization and decision tree
  induction Efficient classification in data
  mining. RIDE'97.
• B. Liu, W. Hsu, and Y. Ma. Integrating
  Classification and Association Rule. KDD'98.
• W. Li, J. Han, and J. Pei, CMAR Accurate and
  Efficient Classification Based on Multiple
  Class-Association Rules, ICDM'01.
• T.-S. Lim, W.-Y. Loh, and Y.-S. Shih. A
  comparison of prediction accuracy, complexity,
  and training time of thirty-three old and new
  classification algorithms. Machine Learning,
  2000.
• J. Magidson. The Chaid approach to segmentation
  modeling Chi-squared automatic interaction
  detection. In R. P. Bagozzi, editor, Advanced
  Methods of Marketing Research, Blackwell
  Business, 1994.
• M. Mehta, R. Agrawal, and J. Rissanen. SLIQ A
  fast scalable classifier for data mining.
  EDBT'96.
• T. M. Mitchell. Machine Learning. McGraw Hill,
  1997.
• S. K. Murthy, Automatic Construction of Decision
  Trees from Data A Multi-Disciplinary Survey,
  Data Mining and Knowledge Discovery 2(4)
  345-389, 1998

60
References

• J. R. Quinlan. Induction of decision trees.
  Machine Learning, 181-106, 1986.
• J. R. Quinlan and R. M. Cameron-Jones. FOIL A
  midterm report. ECML93.
• J. R. Quinlan. C4.5 Programs for Machine
  Learning. Morgan Kaufmann, 1993.
• J. R. Quinlan. Bagging, boosting, and c4.5.
  AAAI'96.
• R. Rastogi and K. Shim. Public A decision tree
  classifier that integrates building and pruning.
  VLDB98.
• J. Shafer, R. Agrawal, and M. Mehta. SPRINT A
  scalable parallel classifier for data mining.
  VLDB96.
• J. W. Shavlik and T. G. Dietterich. Readings in
  Machine Learning. Morgan Kaufmann, 1990.
• P. Tan, M. Steinbach, and V. Kumar. Introduction
  to Data Mining. Addison Wesley, 2005.
• S. M. Weiss and C. A. Kulikowski. Computer
  Systems that Learn Classification and
  Prediction Methods from Statistics, Neural Nets,
  Machine Learning, and Expert Systems. Morgan
  Kaufman, 1991.
• S. M. Weiss and N. Indurkhya. Predictive Data
  Mining. Morgan Kaufmann, 1997.
• I. H. Witten and E. Frank. Data Mining Practical
  Machine Learning Tools and Techniques, 2ed.
  Morgan Kaufmann, 2005.
• X. Yin and J. Han. CPAR Classification based on
  predictive association rules. SDM'03
• H. Yu, J. Yang, and J. Han. Classifying large
  data sets using SVM with hierarchical clusters.
  KDD'03.
