eMOR NEW RELEASE

1
eMOR NEW RELEASE
Presented By Amber Vaughn KY Division of Water
Drinking Water Branch
2
MOR and Kentucky requirements for public water
systems are according to 401 KAR Chapter 8
These are always available for your review.
www.water.ky.gov/dw/rules
We encourage you to consult the KY Drinking Water
Branch for questions and clarification. We are
here for YOU.
3
You may also refer to the EPA regulations. www.ep
a.gov/safewater/regs.htmlproposed
4

• EVERY SYSTEM
• MONTH/YEAR
• PWSID (KY012356)
• PWS NAME
• AI
• SOURCE NAME
• OPERATORS
• COUNTY
• DATE MAILED

UNIVERSAL eMOR FORM
Same for EVERY public water system in KY
There are no new regulations only a new form
5
ON the eMOR, (Excel file) these will be populated
throughout when you enter them on this cover page.
EVERY SYSTEM regardless of what type must have
these sections completed.
EVERY PUBLIC WATER SYSTEM
6
All eMOR forms and instructions are available for
you to download as Excel files (eMORs) and WORD
documents (instructions) at WWW.WATER.KY.GOV/DW
We encourage you to consult the KY Drinking Water
Branch if you need help. We are here for YOU.
7

• Month and Year you are reporting for

• Your PWSID (Be CAREFULLY correct)

• PWS Name
• Source Name County

• Plant ID TREATMENT PLANTS ONLY

8
Plant ID FOR TREATMENT PLANTS ONLY

• This is to indicate or identify which treatment
  plant the report is for.

• Some systems have two TPs. (treatment plants)
• Some have one TP that has been shut down and now
  have another TP. (the old one-TPA and the new-
  TPB)
• If left blank we assume that the report is for
  TPA.

9

• Date Mailed

• Superintendent/Operators

They do not need to sign their names on the MOR
- the person filling out the report may list the
names.
10
Next sectionTreatment Plants CompleteIf
you treat water, you are considered a treatment
plant.(excluding Cl boosters)
11
Those systems that treat water must complete this
section.
Percent Backwash Water Used - This section will
be automatically calculated from page 6 on the
Excel file when completing the eMOR on the
computer.
You cannot type the percentage in this field.
12
And FINALLY
Sign it and Date it
THIS should be the last step in the Monthly
Operating Reportafter all pages have been
completed and checked.
13
Page 1 of 11

• This column should coincide with the dates the TP
  was operating.

eMOR will total, average, and calculate for you
based on this column.

• For dates the plant was not operating, leave that
  space blank.

• Total gallons of raw water that were treated for
  the entire month.

• Also include the hours of operation in the next
  column.

Complete/answer ANY yellow field on the eMOR
file..
14
Page 1 of 11
eMOR will calculate for you the PPM based on
gallons of raw water treated and lbs. of chemical
added

• Proceed through page 1 and page 2 to include any
  chemicals added to the water by lbs. of actual
  chemical - not the lbs of product.

gallons of product x 8.34 lbs. lbs. of
product Lbs. of product x chemical lbs. of
chemical

• Include pounds of disinfectant added. - If only
  one dose of disinfectant, use column for pre or
  post treatment.

Complete/answer ANY yellow field on the eMOR
file..
15
Page 3 of 11

• Page 3 and Page 5 - Water Quality

• Page 3 - These are not required, but if you have
  taken these you may provide the results on this
  page.

• Chlorine residual here is different from the
  distribution system residual on page 7.
• This is for plant tap - not the entry point.

This column will NOT transfer to the Plant
Summary as the Entry Point Residual.

• This turbidity reading should be taken before
  water has been treated and/or gone through the
  filter(s). These can be the average of multiple
  readings or the lowest of the day.

• Settled Water is the same as Top of Filter.

16
Page 5 of 11
Lowest Daily Cl Residual Plant Tap. isthe
disinfectant residual at the entry point to the
distribution system

• Every system that serves gt3,300 people (surface
  water or groundwater under direct influence) are
  required to have an on-line Chlorine analyzer.

• This analyzer monitors continuously the residual
  just before the water goes to the dist. system.

• The number that belongs in this column for each
  day is the lowest recorded residual for that day.

Do not forget to answer any field in yellow or
Y/N questions
This column is to be summarized on the Plant
Summary Sheet. The eMOR will populate it for you.
17
Page 6 of 11

• According to regulation, true groundwater systems
  are not required to filter. Therefore, if you are
  GW and you filter, we do not require you to
  include this. If you have the information, it
  would be helpful to include however.

• The filter run hours have changed. It should be
  the number of hours of plant operation each day
  minus the number of hours the filter was off line
  for backwash.
• 24 hours - 2 hr. (filter off-line) 22 Dont
  total that with any hours from the next or
  previous day.

The eMOR will take this information, calculate
backwash percentage and populate the line on the
cover page. Else, you must calculate and include
on the cover page yourself.
18
Page 7 of 11
Distribution System Test Results Chlorine
Residual
Check chlorine residuals DAILY at representative
points throughout the system. (401 KAR 8150
(1)(a)4)

• The points used to sample within the
  distribution system should represent the system.

• At least one location must be sampled every day,
  but the point(s) and the frequency you sample at
  each should be decided upon based on the
  distribution system.

• Chlorine boosters are not required Unless you
  have them. If more than two, use the Additional
  Data page 11 for the boosters.

Dont forget the yellow!
eMOR program will calculate totals at the bottom
and populate the section on Summary Sheet. If by
hand - no requirement to complete the totals at
bottom, but you will need to complete the Summary
Page section.
19
Page 8 of 11
The eMOR will already have the Hours of Operation
and the number of samples required - calculated
just as the formula in the past. Enter the
turbidity results and the eMOR will list the
Maximum each day, count samples, and populate the
Plant Summary Form section.
20
Plant Summary Sheet and Summary Sheet Must be
completed and included by ALL WATER SYSTEMS
21
If you individually monitor filters, complete
these Y/N questions every month. (Only include
Page 9 if there was an exceedance.)
Summary of column on page 5 - the lowest Cl at
entry point
Summary of page 8
22
Only for plants using Chlorine Dioxide as a
disinfectant.
Summary of page 10
Summary of page 10
23
(No Transcript)
24
If you SELL water to another system complete
this section.
Rules to Remember

• The PWSID of the system to which you have sold
  water (including state ID)

• The total amount sold to each system

• Your own PWSID does not belong in this section

25
Summary of page 7 - chlorine residual in the
distribution system - N, S, E, W
26
ANNUAL WATER SYSTEM DATA APPLICABLE TO ALL WATER
SYSTEMS TO BE SUBMITTED WITH DECEMBER MOR
27
Be sure to review, sign, and date the MOR.
Regulation states the MOR must be to the state by
the 10th of the following month - mail or
electronic submittal
Mail MOR to
Drinking Water Branch 14 Reilly Rd. Frankfort, KY
40601
It is very important to send it toDrinking
Water Branch
You no longer need to submit a copy to your
regional office.
28
Resources and Weblinks
MOR/eMOR Instructions http//www.water.ky.gov/dw
EPA Quick Reference Guides http//www.epa.gov/saf
ewater/publicoutreach/ quickreferenceguides.html
State Drinking Water Regulationswww.water.ky.gov
/dw/rules
EPA Drinking Water Treatment Rules www.epa.gov/sa
fewater/regs.htmlproposed
29
ELECTRONIC SUBMITTAL
By the end of the 2nd quarter, we hope to have
all of our pilot systems working.
By the end of the 3rd quarter, we hope to have
all of the systems who have already signed up
working.
30
Electronic Submittal

• By the end of the 4th quarter, we hope to have
  everyone who wishes to submit electronically
  signed up and working.
• The Drinking Water Branch will contact every
  system as we are ready to move forward with these
  steps.

31
Questions?
