Using Genomics in Clinical Trial Design

1
Using Genomics in Clinical Trial Design

• Richard Simon, D.Sc.
• Chief, Biometric Research Branch
• National Cancer Institute
• http//linus.nci.nih.gov

2
BRB Websitehttp//linus.nci.nih.gov/brb

• Powerpoint presentations and audio files
• Reprints Technical Reports
• BRB-ArrayTools software
• BRB-ArrayTools Data Archive
• Sample Size Planning for Targeted Clinical Trials

3

• Many cancer treatments benefit only a small
  proportion of the patients to which they are
  administered
• Targeting treatment to the right patients can
  greatly improve the therapeutic ratio of benefit
  to adverse effects
• Treated patients benefit
• Treatment more cost-effective for society

4
(No Transcript)
5
Genomic Targeting

• Enables patients to be treated with drugs that
  actually work for them
• Avoids false negative trials for heterogeneous
  populations
• Avoids erroneous generalizations of conclusions
  from positive trials

6
Biomarkers

• Surrogate endpoints
• A measurement made before and after treatment to
  determine whether the treatment is working
• Predictive classifiers
• A measurement made before treatment to select
  good patient candidates for the treatment

7
ValidationFit for Purpose

• FDA terminology of valid biomarker and
  probable valid biomarker are not applicable to
  predictive classifiers
• Validation has meaning only as fitness for
  purpose and the purpose of predictive classifiers
  are completely different than for surrogate
  endpoints

8

• The purpose of a multi-gene predictive classifier
  is to predict
• It is often much easier to develop an accurate
  predictive classifier than to elucidate the role
  of the component genes in disease biology

9
New Drug Developmental Strategy (I)

• Develop a diagnostic classifier that identifies
  the patients likely to benefit from the new drug
• Develop a reproducible assay for the classifier
• Use the diagnostic to restrict eligibility to a
  prospectively planned evaluation of the new drug
• Demonstrate that the new drug is effective in the
  prospectively defined set of patients determined
  by the diagnostic

10
Develop Predictor of Response to New Drug
Using phase II data, develop predictor of
response to new drug
Patient Predicted Responsive
Patient Predicted Non-Responsive
Off Study
New Drug
Control
11
Applicability of Design I

• Primarily for settings where the classifier is
  based on a single gene whose protein product is a
  target of the drug
• Herceptin
• With substantial biological basis for the
  classifier, it will often be unacceptable
  ethically to expose classifier negative patients
  to the new drug

12
We dont think that this drug will help you
because your tumor is test negative. But we need
to show the FDA that a drug we dont think will
help test negative patients actually doesnt
13
Evaluating the Efficiency of Strategy (I)

• Simon R and Maitnourim A. Evaluating the
  efficiency of targeted designs for randomized
  clinical trials. Clinical Cancer Research
  106759-63, 2004.
• Maitnourim A and Simon R. On the efficiency of
  targeted clinical trials. Statistics in Medicine
  24329-339, 2005.
• reprints and interactive sample size calculations
  at http//linus.nci.nih.gov/brb

14
(No Transcript)
15
(No Transcript)
16
Two Clinical Trial Designs

• Un-targeted design
• Randomized comparison of T to C without screening
  for expression of molecular target
• Targeted design
• Assay patients for expression of target
• Randomize only patients expressing target

17

• Efficiency relative to trial of unselected
  patients depends on proportion of patients test
  positive, and effectiveness of drug (compared to
  control) for test negative patients
• When less than half of patients are test positive
  and the drug has little or no benefit for test
  negative patients, the targeted design requires
  dramatically fewer randomized patients

18
No treatment Benefit for Assay - Patientsnstd /
ntargeted
Proportion Assay Positive Randomized Screened
0.75 1.78 1.33
0.5 4 2
0.25 16 4
19
Treatment Benefit for Assay Pts Half that of
Assay Pts nstd / ntargeted
Proportion Assay Positive Randomized Screened
0.75 1.31 0.98
0.5 1.78 0.89
0.25 2.56 0.64
20
Trastuzumab

• Metastatic breast cancer
• 234 randomized patients per arm
• 90 power for 13.5 improvement in 1-year
  survival over 67 baseline at 2-sided .05 level
• If benefit were limited to the 25 assay
  patients, overall improvement in survival would
  have been 3.375
• 4025 patients/arm would have been required
• If assay patients benefited half as much, 627
  patients per arm would have been required

21
Comparison of Targeted to Untargeted DesignSimon
R, Development and Validation of Biomarker
Classifiers for Treatment Selection, JSPI
Treatment Hazard Ratio for Marker Positive Patients Number of Events for Targeted Design Number of Events for Traditional Design Number of Events for Traditional Design Number of Events for Traditional Design
Percent of Patients Marker Positive Percent of Patients Marker Positive Percent of Patients Marker Positive
20 33 50
0.5 74 2040 720 316

22
Randomized Ratiosensitivityspecificity0.9
Express target ?00 ?0 ?1/2
0.75 1.29 1.26
0.5 1.8 1.6
0.25 3.0 1.96
0.1 25.0 1.86
23
Screened Ratiosensitivityspecificity0.9
Express target ?00 ?0 ?1/2
0.75 0.9 0.88
0.5 0.9 0.80
0.25 0.9 0.59
0.1 4.5 0.33
24
Web Based Software for Comparing Sample Size
Requirements

• http//linus.nci.nih.gov/brb/

25
Developmental Strategy (II)
26
Developmental Strategy (II)

• Do not use the diagnostic to restrict
  eligibility, but to structure a prospective
  analysis plan
• Having a prospective analysis plan is essential
  stratifying (balancing) the randomization is
  not except that stratification ensures that all
  randomized patients will have tissue available
• The purpose of the study is to evaluate the new
  treatment overall and for the pre-defined
  subsets not to modify or refine the classifier
• The purpose is not to demonstrate that repeating
  the classifier development process on independent
  data results in the same classifier

27
Analysis Plan A

• Compare the new drug to the control for
  classifier positive patients
• If pgt0.05 make no claim of effectiveness
• If p? 0.05 claim effectiveness for the
  classifier positive patients and
• Compare new drug to control for classifier
  negative patients using 0.05 threshold of
  significance

28
Sample size for Analysis Plan A

• 88 events in classifier patients needed to
  detect 50 reduction in hazard at 5 two-sided
  significance level with 90 power
• If test is predictive but not prognostic, and if
  25 of patients are positive, then when there are
  88 events in positive patients there will be
  about 264 events in negative patients
• 264 events provides 90 power for detecting 33
  reduction in hazard at 5 two-sided significance
  level
• Sequential futility monitoring may have enabled
  early cessation of accrual of classifier negative
  patients
• Not much earlier with time-to-event endpoint

29

• Study-wise false positivity rate is limited to 5
  with analysis plan A
• It is not necessary or appropriate to require
  that the treatment vs control difference be
  significant overall before doing the analysis
  within subsets

30
Analysis Plan B

• Compare the new drug to the control overall for
  all patients ignoring the classifier.
• If poverall? 0.03 claim effectiveness for the
  eligible population as a whole
• Otherwise perform a single subset analysis
  evaluating the new drug in the classifier
  patients
• If psubset? 0.02 claim effectiveness for the
  classifier patients.

31

• This analysis strategy is designed to not
  penalize sponsors for having developed a
  classifier
• It provides sponsors with an incentive to develop
  genomic classifiers

32
Sample size for Analysis Plan B

• To have 90 power for detecting uniform 33
  reduction in overally hazard at 3 two-sided
  level requires 297 events (instead of 263 for
  similar power at 5 level)
• If test is predictive but not prognostic, and if
  25 of patients are positive, then when there are
  297 total events there will be approximately 75
  events in positive patients
• 75 events provides 75 power for detecting 50
  reduction in hazard at 2 two-sided significance
  level
• By delaying evaluation in test positive patients,
  80 power is achieved with 84 events and 90
  power with 109 events

33
Song Chi Refinement of Testing Procedure for
Plan B

• Specify ?1 lt ? lt ?1
• e.g. ?.025, ?1.02, ?1.10
• calculate ? .013
• Reject overall null hypothesis if
• Poverall ?1 or
• P ? and Poverall ?
• Reject null hypothesis in test positive subset if

• P ? and Poverall ?1
• e.g. ?.025, ?1.02, ?1.10, ? .013

34
Adaptively Modifying the Types of Patients
AccruedWang, ONeill, Hung

• Plan RCT to accrue N total patients
• Interim futility analysis of test negative
  patients
• If accrual of test negative patients is
  terminated, replace them with test positive
  patients to achieve the planned total N
• May prolong duration of trial substantially
• Futility for test negative patients declared only
  if efficacy for control group is superior to
  treatment group by specified amount
• Limited opportunity to reduce number of test
  negative patients

35
Analysis Plan C

• Test for interaction between treatment effect in
  test positive patients and treatment effect in
  test negative patients
• If interaction is significant at level ?int then
  compare treatments separately for test positive
  patients and test negative patients
• Otherwise, compare treatments overall

36
Sample Size Planning for Analysis Plan C

• 88 events in classifier patients needed to
  detect 50 reduction in hazard at 5 two-sided
  significance level with 90 power
• If test is predictive but not prognostic, and if
  25 of patients are positive, then when there are
  88 events in positive patients there will be
  about 264 events in negative patients
• 264 events provides 90 power for detecting 33
  reduction in hazard at 5 two-sided significance
  level

37
Simulation Results for Analysis Plan C

• Using ?int0.10, the interaction test has power
  93.7 when there is a 50 reduction in hazard in
  test positive patients and no treatment effect in
  test negative patients
• A significant interaction and significant
  treatment effect in test positive patients is
  obtained in 88 of cases under the above
  conditions
• If the treatment reduces hazard by 33 uniformly,
  the interaction test is negative and the overall
  test is significant in 87 of cases

38
The Roadmap

1. Develop a completely specified genomic classifier
   of the patients likely to benefit from a new drug
2. Establish reproducibility of measurement of the
   classifier
3. Use the completely specified classifier to design
   and analyze a new clinical trial to evaluate
   effectiveness of the new treatment with a
   pre-defined analysis plan.

39
Guiding Principle

• The data used to develop the classifier must be
  distinct from the data used to test hypotheses
  about treatment effect in subsets determined by
  the classifier
• Developmental studies are exploratory
• And not closely regulated by FDA
• Studies on which treatment effectiveness claims
  are to be based should be definitive studies that
  test a treatment hypothesis in a patient
  population completely pre-specified by the
  classifier

40
Use of Archived Samples

• From a non-targeted negative clinical trial to
  develop a binary classifier of a subset thought
  to benefit from treatment
• Test that subset hypothesis in a separate
  clinical trial
• Prospective targeted type I trial
• Using archived specimens from a second previously
  conducted clinical trial

41
Development of Genomic Classifiers

• Single gene or protein based on knowledge of
  therapeutic target
• Empirically determined based on evaluation of a
  set of candidate classifiers
• e.g. EGFR assays
• Empirically determined based on genome-wide
  correlating gene expression or genotype to
  patient outcome after treatment

42
Development of Genomic Classifiers

• During phase II development or
• After failed phase III trial using archived
  specimens.
• Adaptively during early portion of phase III
  trial.

43
Biomarker Adaptive Threshold Design

• Wenyu Jiang, Boris Freidlin Richard Simon
• JNCI 991036-43, 2007

44
Biomarker Adaptive Threshold Design

• Randomized phase III trial comparing new
  treatment E to control C
• Survival or DFS endpoint

45
Biomarker Adaptive Threshold Design

• Have identified a predictive index B thought to
  be predictive of patients likely to benefit from
  E relative to C
• Eligibility not restricted by biomarker
• No threshold for biomarker determined

46
Analysis Plan

• S(b)log likelihood ratio statistic for treatment
  versus control comparison in subset of patients
  with B?b
• Compute S(b) for all possible threshold values
• Determine TmaxS(b)
• Compute null distribution of T by permuting
  treatment labels
• Permute the labels of which patients are in which
  treatment group
• Re-analyze to determine T for permuted data
• Repeat for 10,000 permutations

47

• If the data value of T is significant at 0.05
  level using the permutation null distribution of
  T, then reject null hypothesis that E is
  ineffective
• Compute point and bootstrap confidence interval
  estimates of the threshold b

48
(No Transcript)
49
Model Hazard reduction for those who benefit Overall Power Adaptive Test
Everyone benefits 33 .775 .751
50 benefit 60 .888 .932
25 benefit 60 .429 .604
50
Adaptive Biomarker Threshold Design

• Sample size planning methods described by Jiang,
  Freidlin and Simon, JNCI 991036-43, 2007

51
Adaptive Signature Design An adaptive design for
generating and prospectively testing a gene
expression signature for sensitive patients

• Boris Freidlin and Richard Simon
• Clinical Cancer Research 117872-8, 2005

52
Adaptive Signature DesignEnd of Trial Analysis

• Compare E to C for all patients at significance
  level 0.03
• If overall H0 is rejected, then claim
  effectiveness of E for eligible patients
• Otherwise

53

• Otherwise
• Using only the first half of patients accrued
  during the trial, develop a binary classifier
  that predicts the subset of patients most likely
  to benefit from the new treatment E compared to
  control C
• Compare E to C for patients accrued in second
  stage who are predicted responsive to E based on
  classifier
• Perform test at significance level 0.02
• If H0 is rejected, claim effectiveness of E for
  subset defined by classifier

54
Treatment effect restricted to subset.10 of
patients sensitive, 10 sensitivity genes, 10,000
genes, 400 patients.
Test Power
Overall .05 level test 46.7
Overall .04 level test 43.1
Sensitive subset .01 level test (performed only when overall .04 level test is negative) 42.2
Overall adaptive signature design 85.3
55
Overall treatment effect, no subset effect.10
of patients sensitive, 10 sensitivity genes,
10,000 genes, 400 patients.
Test Power
Overall .05 level test 74.2
Overall .04 level test 70.9
Sensitive subset .01 level test 1.0
Overall adaptive signature design 70.9
56
Conclusions

• New technology makes it increasingly feasible to
  identify which patients are likely or unlikely to
  benefit from a specified treatment
• Targeting treatment can greatly improve the
  therapeutic ratio of benefit to adverse effects

57
Conclusions

• Some of the conventional wisdom about how to
  develop predictive classifiers and how to use
  them in clinical trial design and analysis is
  flawed
• Prospectively specified analysis plans for phase
  III studies are essential to achieve reliable
  results
• Biomarker analysis does not mean exploratory
  analysis except in developmental studies
• Prospective analysis of previously conducted
  trials can provide reliable conclusions

58
Conclusions

• Achieving the potential of new technology
  requires paradigm changes in correlative
  science and in some aspects of design and
  analysis of clinical trials

59
Collaborators

• Boris Freidlin
• Aboubakar Maitournam
• Kevin Dobbin
• Wenu Jiang
• Yingdong Zhao

60
Using Genomic Classifiers In Clinical Trials

• Dupuy A and Simon R. Critical review of published
  microarray studies for clinical outcome and
  guidelines for statistical analysis and
  reporting, Journal of the National Cancer
  Institute 99147-57, 2007
• .
• Dobbin K and Simon R. Sample size planning for
  developing classifiers using high dimensional DNA
  microarray data. Biostatistics 8101-117, 2007.
• Dobbin K, Zhao Y and Simon R. How large a
  training set is needed to develop a classifier
  for microarray data? Clinical Cancer Research (In
  Press).
• Simon R. Development and validation of
  therapeutically relevant predictive classifiers
  using gene expression profiling, Journal of the
  National Cancer Institute 981169-71, 2006.
• Simon R. Validation of pharmacogenomic biomarker
  classifiers for treatment selection. Cancer
  Biomarkers 289-96, 2006.
• Simon R. Guidelines for the design of clinical
  studies for development and validation of
  therapeutically relevant biomarkers and biomarker
  classification systems. In Biomarkers in Breast
  Cancer, Hayes DF and Gasparini G, pp 3-15, Humana
  Press, 2006.
• Simon R. A checklist for evaluating reports of
  expression profiling for treatment selection.
  Clinical Advances in Hematology and Oncology
  4219-224, 2006.
• Simon R. Identification of pharmacogenomic
  biomarker classifiers in drug development. In
  Pharmacogenomics, Anti-cancer Drug Discovery and
  Response, F Innocenti (ed), Humana Press (In
  Press).
• Simon R. New challenges for 21st century clinical
  trials, Controlled Clinical Trials 4167-169,
  2007.

61
Using Genomic Classifiers In Clinical Trials

• .
• Simon R and Maitnourim A. Evaluating the
  efficiency of targeted designs for randomized
  clinical trials. Clinical Cancer Research
  106759-63, 2004.
• Maitnourim A and Simon R. On the efficiency of
  targeted clinical trials. Statistics in Medicine
  24329-339, 2005.
• Simon R. When is a genomic classifier ready for
  prime time? Nature Clinical Practice Oncology
  14-5, 2004.
• Simon R. An agenda for Clinical Trials clinical
  trials in the genomic era. Clinical Trials
  1468-470, 2004.
• Simon R. Development and validation of
  therapeutically relevant multi-gene biomarker
  classifiers. Journal of the National Cancer
  Institute 97866-867, 2005..
• Simon R. A roadmap for developing and validating
  therapeutically relevant genomic classifiers.
  Journal of Clinical Oncology 237332-41,2005.
• Freidlin B and Simon R. Adaptive signature
  design. Clinical Cancer Research 117872-78,
  2005.
• Simon R. and Wang SJ. Use of genomic signatures
  in therapeutics development in oncology and other
  diseases, The Pharmacogenomics Journal 6166-73,
  2006.
• Trepicchio WL, Essayan D, Hall ST, Schechter G,
  Tezak Z, Wang SJ, Weinreich D, Simon R. Designing
  prospective clinical pharmacogenomic trials-
  Effective use of genomic biomarkers for use in
  clinical decision-making. The Pharmacogenomics
  Journal 689-94,2006.

62
Using Genomic Classifiers In Clinical Trials

• .
• Simon R Challenges of microarray data and the
  evaluation of gene expression profile signatures.
  Cancer Investigation (In Press)
• Simon R. Lost in translation Problems and
  pitfalls in translating laboratory observations
  to clinical utility. European Journal of Cancer
  (In Press)
