Overview of the Language Technologies Institute and AVENUE Project

1
Overview of the Language Technologies Institute
and AVENUE Project

• Jaime Carbonell, Director
• March 2, 2002

2
Language Technologies Institute

• Director Jaime Carbonell
• Founded in 1986 as the Center for Machine
  Translation.

3
School of Computer Science Carnegie Mellon
University

• Center for Automated Learning and Discovery
• Computer Science Department
• Entertainment Technology Center
• Human-Computer Interaction Institute
• Institute for Software Research, International
• Language Technologies Institute
• Robotics Institute

4
LTI Research Areas

• Machine Translation
• Information Retrieval, Summarization, Extraction,
  Topic Detection and Tracking
• Speech Recognition and Synthesis
• Computer Assisted Language Instruction
• Multi-modal Interaction

5
Members of LTI

• 18 core faculty
• over 40 students (working on masters and Ph.D.)
• approximately 10 courtesy and adjunct faculty
  (e.g., in machine learning)
• probably around 20 funded projects

6
Funding of LTI Projects

• Companies e.g., Caterpillar
• National Science Foundation
• DARPA Defense Advance Research Projects Agency
• Other ATR research institute, Japan

7
LTI Degree Programs

• Masters in Language Technologies (MLT) two
  years.
• Ph.D. in Language and Information Technologies
  usually three years after masters degree.
• Graduate Program Director Robert Frederking
  (ref_at_cs.cmu.edu)

8
Potential Uses of Language Technologies in
Bilingual Education

• For language instruction
• For teaching subjects other than language

9
LT for Language Instruction

• Speech Recognition
• Pronunciation tutor (Eskenazi)
• Reading tutor (Mostow)
• Grammar checking
• Dialogue immersion
• Adventure game
• Blocks world
• Using authentic materials

10
LT for bilingual education in indigenous
languages

• Partially automated translation of teaching
  materials (science, history, etc.) into
  indigenous languages.

11
The AVENUE Project
12
Machine Translation of Indigenous Languages

• Policy makers have access to information about
  indigenous people.
• Epidemics, crop failures, etc.
• Indigenous people can participate in
• Health care
• Education
• Government
• Internet
• without giving up their languages.

13
History of AVENUE

• Arose from a series of joint workshops of NSF and
  OAS.
• Workshop recommendations
• Create multinational projects using information
  technology to
• provide immediate benefits to governments and
  citizens
• develop critical infrastructure for communication
  and collaborative research
• training researchers and engineers
• advancing science and technology

14
Resources for MT

• People who speak the language.
• Linguists who speak the language.
• Computational linguists who speak the language.
• Text on paper.
• Text on line.
• Comparable text on paper or on line.
• Parallel text on paper or on line.
• Annotated text (part of speech, morphology, etc.)
• Dictionaries (mono-lingual or bilingual) on paper
  or on line.
• Recordings of spoken language.
• Recordings of spoken language that are
  transcribed.
• Etc.

15
MT for Indigenous Languages

• Minimal amount of parallel text
• Possibly competing standards for
  orthography/spelling
• Maybe not so many trained linguists
• Access to native informants possible
• Need to minimize development time and cost

16
Two Technical Approaches

• Generalized EBMT
• Parallel text 50K-2MB (uncontrolled corpus)
• Rapid implementation
• Proven for major Ls with reduced data

• Transfer-rule learning
• Elicitation (controlled) corpus to extract
  grammatical properties
• Seeded version-space learning

17
Architecture Diagram
SL Input
Run-Time Module
Learning Module
SL Parser
EBMT Engine
Elicitation Process
SVS Learning Process
Transfer Rules
Transfer Engine
TL Generator
User
Unifier Module
TL Output
18
EBMT Example
English I would like to meet
her. Mapudungun Ayükefun trawüael fey
engu.
English The tallest man is my
father. Mapudungun Chi doy fütra chi wentru
fey ta inche ñi chaw.
English I would like to meet the
tallest man Mapudungun (new)
Ayükefun trawüael Chi doy fütra chi
wentru Mapudungun (correct) Ayüken ñi
trawüael chi doy fütra wentruengu.
19
Version Space Learning

• Symbolic learning from and examples
• Invented by Mitchell, refined by Hirsch
• Builds generalization lattice implicitly
• Bounded by G and S sets
• Worse-case exponential complexity (in size of G
  and S)
• Slow convergence rate

20
Example of Transfer Rule Lattice
21
Seeded Version Spaces

• Generate concept seed from first example
• Generalization-level hypothesis (POS feature
  agreement for T-rules in NICE)
• Generalization/specialization level bounds
• Up to k-levels generalization, and up to j-levels
  specialization.
• Implicit lattice explored seed-outwards

22
Complexity of SVS

• O(gk) upward search, where g of
  generalization operators
• O(sj) downward search, where s of
  specialization operators
• Since m and k are constants, the SVS runs in
  polynomial time of order max(j,k)
• Convergence rates bounded by F(j,k)

23
Next Steps in SVS

• Implementation of transfer-rule intepreter
  (partially complete)
• Implementation of SVS to learn transfer rules
  (underway)
• Elicitation corpus extension for evaluation
  (under way)
• Evaluation first on Mapudungun MT (next)

24
NICE Partners
25
Agreement Between LTI and Institute of Indigenous
Studies (IEI), Universidad De La Frontera, Chile

• Contributions of IEI
• Native language knowledge and linguistic
  expertise in Mapudungun
• Experience in bicultural, bilingual education
• Data collection recording, transcribing,
  translating
• Orthographic normalization of Mapudungun

26
Agreement between LTI and Institute of Indigenous
Studies (IEI), Universidad de la Frontera, Chile

• Contributions of LTI
• Develop MT technology for indigenous languages
• Training for data collection and transcription
• Partial support for data collection effort
  pending funding from Chilean Ministry of
  Education
• International coordination, technical and project
  management

27
LTI/IEI Agreement

• Continue collaboration on data collection and
  machine translation technology.
• Pursue focused areas of mutual interest, such as
  bilingual education.
• Seek additional funding sources in Chile and the
  US.

28
The IEI Team

• Coordinator (leader of a bilingual and
  multicultural education project)
• Eliseo Canulef
• Distinguished native speaker
• Rosendo Huisca
• Linguists (one native speaker, one near-native)
• Juan Hector Painequeo
• Hugo Carrasco
• Typists/Transcribers
• Recording assistants
• Translators
• Native speaker linguistic informants

29
MINEDUC/IEIAgreement Highlights

• Based on the LTI/IEI agreement, the Chilean
  Ministry of Education agreed to fund the data
  collection and processing team for the year 2001.
  This agreement will be renewed each year, as
  needed.

30
MINEDUC/IEI AgreementObjectives

• To evaluate the NICE/Mapudungun proposal for
  orthography and spelling
• To collect an oral corpus that represent the four
  Mapudungun dialects spoken in Chile. The main
  domain is primary health, traditional and western.

31
MINEDUC/IEI AgreementDeliverables

• An oral corpus of 800 hours recorded,
  proportional to the demography of each current
  spoken dialect
• 120 hours transcribed and translated from
  Mapudungun to Spanish
• A refined proposal for writing Mapudungun

32
Nice/MapudungunDatabase

• Writing conventions (Grafemario)
• Glossary Mapudungun/Spanish
• Bilingual newspaper, 4 issues
• Ultimas Familias memoirs
• Memorias de Pascual Coña
• Publishable product with new Spanish translation
• 35 hours transcribed speech
• 80 hours recorded speech

33
NICE/MapudungunOther Products

• Standardization of orthography Linguists at UFRO
  have evaluated the competing orthographies for
  Mapudungun and written a report detailing their
  recommendations for a standardized orthography
  for NICE.
• Training for spoken language collection In
  January 2001 native speakers of Mapudungun were
  trained in the recording and transcription of
  spoken data.

34
Underfunded Activities

• Data collection
• Colombia (unfunded)
• Chile (partially funded)
• Travel
• More contact between CMU and Chile (UFRO) and
  Colombia.
• Training
• Train Mapuche linguists in language technologies
  at CMU.
• Extend training to Colombia
• Refine MT system for Mapudungun and Siona
• Current funding covers research on the MT engine
  and data collection, but not detailed linguistic
  analysis

35
Outline

• History of MT--See Wired magazine May 2000 issue.
  Available on the web.
• How well does it work?
• Procedure for designing an LT project.
• Choose an application What do you want to do?
• Identify the properties of your application.
• Methods knowledge-based, statistical/corpus
  based, or hybrid.
• Methods interlingua, transfer, direct
• Typical components of an MT system.
• Typical resources required for and MT system.

36
How well does it work?Example SpanAm

• Possibly the best Spanish-English MT system.
• Around 20 years of development.

37
How well does it work?Example Systran

• Try it on the Altavista web page.
• Many language pairs are available.
• Some language pairs might have taken up to a
  person-century of development.
• Can translate text on any topic.
• Results may be amusing.

38
How well does it work?Example KANT

• Translates equipment manuals for Caterpillar.
• Input is controlled English many ambiguities are
  eliminated. The input is checked carefully for
  compliance with the rules.
• Around 5 output languages.
• The output might be post-edited.
• The result has to be perfect to prevent accidents
  with the equipment.

39
How well does it work?Example JANUS

• Translates spoken conversations about booking
  hotel rooms or flights.
• Six languages English, French, German, Italian,
  Japanese, Korean (with partners in the C-STAR
  consortium).
• Input is spontaneous speech spoken into a
  microphone.
• Output is around 60 correct.
• Task Completion is higher than translation
  accuracy users can always get their flights or
  rooms if they are willing to repeat 40 of their
  sentences.

40
How well does it work?Speech Recognition

• Jupiter weather information 1-888-573-8255. You
  can say things like what cities do you know
  about in Chile? and What will be the weather
  tomorrow in Santiago?.
• Communicator flight reservations 1-877-CMU-PLAN.
  You can say things like Im travelling to
  Pittsburgh.
• Speechworks demo 1-888-SAY-DEMO. You can say
  things like Sell my shares of Microsoft.
• These are all in English, and are toll-free only
  in the US, but they are speaker-indepent and
  should work with reasonable foreign accents.

41
Different kinds of MT

• Different applications for example, translation
  of spoken language or text.
• Different methods for example, translation rules
  that are hand crafted by a linguist or rules that
  are learned automatically by a machine.
• The work of building an MT program will be very
  different depending on the application and the
  methods.

42
Procedure for planning an MT project

• Choose an application.
• Identify the properties of your application.
• List your resources.
• Choose one or more methods.
• Make adjustments if your resources are not
  adequate for the properties of your application.

43
Choose an application What do you want to do?

• Exchange email or chat in Quechua and Spanish.
• Translate Spanish web pages about science into
  Quechua so that kids can read about science in
  their language.
• Scan the web Is there any information about
  such-and-such new fertilizer and water
  pollution? Then if you find something that looks
  interesting, take it to a human translator.
• Answer government surveys about health and
  agriculture (spoken or written).
• Ask directions (where is the library?)
  (spoken).
• Read government publications in Quechua.

44
Identify the properties of your application.

• Do you need reliable, high quality translation?
• How many languages are involved? Two or more?
• Type of input.
• One topic (for example, weather reports) or any
  topic (for example, calling your friend on the
  phone to chat).
• Controlled or free input.
• How much time and money do you have?
• Do you anticipate having to add new topics or new
  languages?

45
Do you need high quality?

• Assimilation Translate something into your
  language so that you can
• understand it--may not require high quality.
• evaluate whether it is important or interesting
  and then send it off for a better
  translation--does not require high quality.
• use it for educational purposes--probably
  requires high quality.

46
Do you need high quality?

• Dissemination Translate something into someone
  elses language e.g., for publication.
• Usually should be high quality.

47
Do you need high quality?

• Two-Way e.g., chat room or spoken conversation
• May not require high reliability on correctness
  if you have a native language paraphrase.
• Original input I would like to reserve a double
  room.
• Paraphrase Could you make a reservation for a
  double room.

48
Type of Input

• Formal text newspaper, government reports,
  on-line encyclopedia.
• Difficulty long sentences
• Formal speech spoken news broadcast.
• Difficulty speech recognition wont be perfect.
• Conversational speech
• Difficulty speech recognition wont be perfect
• Difficulty disfluencies
• Difficulty non-grammatical speech
• Informal text email, chat
• Difficulty non-grammatical speech

49
Methods Knowledge-Based

• Knowledge-based MT a linguist writes rules for
  translation
• noun adjective -- adjective noun
• Requires a computational linguist who knows the
  source and target languages.
• Usually takes many years to get good coverage.
• Usually high quality.

50
Methods statistical/corpus-based

• Statistical and corpus-based methods involve
  computer programs that automatically learn to
  translate.
• The program must be trained by showing it a lot
  of data.
• Requires huge amounts of data.
• The data may need to be annotated by hand.
• Does not require a human computational linguist
  who knows the source and target languages.
• Could be applied to a new language in a few days.
• At the current state-of-the-art, the quality is
  not very good.

51
Methods Interlingua

• An interlingua is a machine-readable
  representation of the meaning of a sentence.
• Id like a double room/Quisiera una habitacion
  doble.
• request-actionreservationhotel(room-typedouble)

• Good for multi-lingual situations. Very easy to
  add a new language.
• Probably better for limited domains -- meaning is
  very hard to define.

52
Multilingual Interlingual Machine Translation

• Instructions
• Delete sample document icon and replace with
  working document icons as follows
• Create document in Word.
• Return to PowerPoint.
• From Insert Menu, select Object
• Click Create from File
• Locate File name in File box
• Make sure Display as Icon is checked.
• Click OK
• Select icon
• From Slide Show Menu, Select Action Settings.
• Click Object Action and select Edit
• Click OK

53
Methods Transfer

• A transfer rule tells you how a structure in one
  language corresponds to a different structure in
  another language
• an adjective followed by a noun in English
  corresponds to a noun followed by an adjective in
  Spanish.
• Not good when there are more than two languages
  -- you have to write different transfer rules for
  each pair.
• Better than interlingua for unlimited domain.

54
Methods Direct

• Direct translation does not involve analyzing the
  structure or meaning of a language.
• For example, look up each word in a bilingual
  dictionary.
• Results can be hilarious the spirit is willing
  but the flesh is weak can become the wine is
  good, but the meat is lousy.
• Can be developed very quickly.
• Can be a good back-up when more complicated
  methods fail to produce output.

55
Components of a Knowledge-Based Interlingua MT
System

• Morphological analyzer identify prefixes,
  suffixes, and stem.
• Parser (sentence-to-syntactic structure for
  source language, hand-written or automatically
  learned)
• Meaning interpreter (syntax-to-semantics, source
  language).
• Meaning interpreter (semantics-to-syntax, target
  language).
• Generator (syntactic structure-to-sentence) for
  target language.

56
Resources for a knowledge-based interlingua MT
system

• Computational linguists who know the source and
  target languages.
• As large a corpus as possible so that the
  linguists can confirm that they are covering the
  necessary constructions, but the size of the
  corpus is not crucial to system development.
• Lexicons for source and target languages, syntax,
  semantics, and morphology.
• A list of all the concepts that can be expressed
  in the systems domain.

57
Components of Example Based MT a direct
statistical method

• A morphological analyzer and part of speech
  tagger would be nice, but not crucial.
• An alignment algorithm that runs over a parallel
  corpus and finds corresponding source and target
  sentences.
• An algorithm that compares an input sentence to
  sentences that have been previously translated,
  or whose translation is known.
• An algorithm that pulls out the corresponding
  translation, possibly slightly modifying a
  previous translation.

58
Resources for Example Based MT

• Lexicons would improve quality of translation,
  but are not crucial.
• A large parallel corpus (hundreds of thousands of
  words).

59
Omnivorous Multi-Engine MT eats any available
resources
60
Approaches we had in mind

• Direct bilingual-dictionary lookup because it is
  easy and is a back-up when other methods fail.
• Generalized Example-Based MT because it is easy
  and fast and can be also be a back-up.
• Instructable Transfer-based MT a new, untested
  idea involving machine learning of rules from a
  human native speaker. Useful when computational
  linguists dont know the language, and people who
  know the language are not computational
  linguists.
• Conventional, hand-written transfer rules in
  case the new method doesnt work.
