Computer Graphics For Games Part 2

1
Computer Graphics For Games Part 2
2
The Pink Bunny

• Triangle Rasterization
• Hidden Surface Elimination
• Lighting
• Other stuff

3
Triangles

• Why do we use triangles in graphics?
• Normals are unique Important for lighting
• Space filling triangles tile so they can be used
  to represent surfaces.
• Atomic All polygons decompose into triangles

4
Scan Conversion

• Ray tracing determines a pixels color by tracing
  the path of light through the scene to arbitrary
  precision.
• The result is an extremely realistic image.
• In scanline rendering surfaces are projected on
  the screen and space filling rasterizing
  algorithms are used to fill in the color.
• Color values from light are approximated.

5
Quick Math!!
6
Barycentric Coordinates

• The axis of a coordinate system dont have to be
  perpendicular.
• If you use two sides of a triangle as axis, you
  can create a coordinate system called barycentric
  coordinates.
• Basically, in the barycentric coordinate system
  you have three coordinates ?,?,? which represents
  the signed distance from each of the triangle
  edges.

7
Why are Barycentric coordinates useful?

• For any point x, if the barycentric
  representation of that point x?,x?, x?
• Also ?,?,? can be used as a mass function across
  the surface of a triangle to be used for
  interpolation.
• This is used to interpolate normals across the
  surface of a triangle to make polygon surfaces
  look rounder.

8
Definitions

• In this example the origin is at point a.
• The ? and ? axis are the normalized vectors

A barycentric coordinate can Be represented by
the equation
Where
And
9
Calculating ?,? and ? for anarbitrary point,
(x,y)

• These are derived from the implicit line equation.

10
Math Done!!
11
Rasterize This!(Rasterization intuition)

• When we render a triangle we want to determine if
  a pixel is within a triangle. (barycentric
  coords)
• Calculate the color of the pixel.
• Draw the pixel.
• Repeat until the triangle is appropriately filled.

12
Rasterization Pseudo Code
13
A simple optimization
14
(No Transcript)
15
Hidden Surface Removal

• Currently our projection and rasterization
  process doesnt preserve any 3d depth
  information.
• This will cause some problems when triangles
  overlap eachother.

16
BSP Trees

• A BSP tree is an example of a painters
  algorithm.
• The polygons are painted in back to front order
  from the perspective of the viewer, this handles
  the hidden surface problem.
• BSP trees are typically pre-computed in games for
  performance.

17
The Z-Buffer
Note You must use the z value of the 3d
coordinate after perspective projection but
BEFORE the homogenizing step!!
Typically this algorithm is implemented in
hardware
18
Surface Shading

• For now we will assume that when light interacts
  with objects of various compositions it is either
  diffuse or reflected.
• Diffuse light represent light that is partially
  absorbed by the surface. Diffuse lighting is also
  called matte shading.
• Reflected light, is light that bounces directly
  off of the object (like a mirror) and primarily
  maintains the original color of the light source.

19
Lamberts Law

• We assume Lamberts Law to approximate light.
• Basically we assume that the effect of a light
  source on the color of a surface is proportional
  to the cosine of the angle between the surface
  normal and the direction to the light.
• We know when the surface points away from the
  light if the cosine is negative.

20
What is a Normal!?

• A normal is a vector that is perpendicular to two
  other vectors.
• It is calculated as the cross product of the two
  vectors.
• Triangles are nice b.c. theres a unique normal
  (2 actually) for every triangle.
• Remember the right-hand/left-hand rule applies
  here!

21
How do we compute the Cosine betweenTwo vectors
quickly?!

• The dot product of two vectors is equal to the
  cosine of the angle between the two vectors!
• Note The vectors have to be unit vectors for
  this to be true, otherwise youve got to
  normalize them.

22
Diffuse Shading
To Deal with negative light
Add in the ambient light
23
Reflective Shading(phong shading)

• Phong shading is a simplified reflection model.
• Basically it puts a bright spot which is colored
  with the light color on surfaces that are nearest
  to the light origin.
• Generally we want the bright spot to be brightest
  when the reflected component r is going right
  into the viewers eye and fall off from there.

24
Phong Math
p is the phong exponent, which determines the
falloff rate
We can approximate r with h to eliminate negative
values
This gives us our final phong equation
25
What happens when you vary p ?
p 1
p 2
p 8
p 4
26
Final Lighting
27
Our Pipeline is Complete!
The Bunny Model
Triangle and line drawing
Z buffering
Projection matrices
Diffuse/phong shading
28
Other topics

• Alpha blending
• Texture mapping
• Bump mapping
• Shadows
• Surface effects
• Tessellation (curved surfaces)
• Level Of detail

29
Alpha Blending
30
Texture Mapping
31
Bump Mapping
32
Normal Interpolation
33
Hair
34
Surface Shaders
35
Tessellation
36
Shadows
37
Level of Detail
