High Resolution, Low Cost Ultrasound Camera for In-service Composite NDI

1
High Resolution, Low Cost Ultrasound
Camera for In-service Composite NDI Robert
Lasser, Marvin Lasser, Ron Westernik, John Kula,
David Rich Imperium, Inc.
2
Imperium

• Formed in 1996
• Focused solely on ultrasound camera technology
• In development for 10 years, now selling
  commercially
• Implement for different embodiments of ultrasound
  camera

3
Easy-to-Interpret Image Examples
Imperium
Conventional
Bone
Medical Image of Finger
Industrial Detection of Fault
Defect
4
Industry Sectors

• Industrial
• Underwater
• Biometrics
• Medical

5
Sampling of Customers
6
Imperium Architecture
Apply optical imaging techniques to ultrasound
Optical Sensor
Lens
7
Imperium Architecture
Ultrasound Sensor
Acoustic Flashlight
Acoustic Lens Set
8
Through Transmission

Source Transducer
Target
Acoustic Lens
Imaging Array
9
Imaging Array
Multiplexing
Piezoelectric Layer
Signal Conditioning
Pre-amp/ detection
I500 to I600
10
Through Transmission of Composite Laminate
Three inches
11
DAV TM Technology - Pulse Echo
Sound Transmitter
Water
Pulse echo image of quarter
Subsurface fault
Array
Video
Water
Electronics
Lens
Target
12
Pulse Echo 50/50 Beamsplitter
Sound Transmitter
Pulse echo image of quarter
Array
Subsurface fault
Video
Water
Lens
Acoustic beamsplitter
Target
13
Pulse Echo of Composite Laminate
One inch
14
Pulse Echo of Quarter
One inch
15
Camera Head Cutaway
Source transducer
Imaging Array
Target
LCD
Acoustic Lens
Beamsplitter
16
B-scan versus C-scan
17
Impact Damage in Composite Structure
One inch
Leading Edge Inspection
18
Pulse Echo of Honeycomb Composite
One inch
19
Range Gating
Gate 1
Gate 2
Gate 3
20
Range Gating for Depth Pick the C-scan plane of
interest
21
Integrated A-scan for Flaw Detector Functionality
22
Presentation of Imagery and A-scan/ Match Gates
Set A-scan gates, automatically changes C-scan
gates
23
Production Scanning Results ATK Thiokol
Hex nut and paper clip placed on surface
Graphite/epoxy laminate defect standard with
embedded Teflon wafers
24
UT camera scan with stitching algorithm applied
- 0.3 scan increment
Conventional immersion scan - 2.25 MHz, 0.25
diameter transducer - 0.075 scan increment
25
Gridlines/Sizing
26
Future Developments Pulse Echo
Handheld portion goes from 4 lbs. to 2 lbs.
27
Current Development Camcorder Handheld
Focus with finger
Strap
Grip
Handheld portion goes from 4 lbs. to under 2 lbs.
28
New Control Unit
29
Current Development Camcorder Handheld

30
Time of flight color code different depths
Blue Level 1 Red Level 2 Yellow Level 3
2
3
3
1
2
Increments to be selected by user (e.g. 1 mm)
31
Future Developments Through Transmission
32
Boeing Remote NDI Program

• Lack of trained NDI personnel
• Use by non-certified personnel
• SIMPLE, SIMPLE, SIMPLE
• Remotely monitored in real time
• Wireless
• Program began in early 2007

33
Remote Wireless NDI Program
34
Boeing Remote NDI Program

• Successful demonstration Fall 2008
• Equipment at Boeings Everett, WA production
  facility
• Remotely monitored at Boeing GoldCare center in
  Seattle, WA
• Pilot program with airlines during 2009

35
