Volcanoes and Volcanic Rocks II

1
Volcanoes and Volcanic Rocks II
Volcanoes and Volcanic Rocks II
Photo credit G. Mattioli
2
Lava Floods

• Submarine Eruptions
• Pillow Basalts

3
Flood Basalts, Columbia River
4
Columnar Jointing, Devils Postpile, CA
5
Columnar Jointing
6
Empty Lava Tube
7
Pillow Basalts, Iceland
8
Composite Volcano
9
Popocatépetl, Mexico, 1960
10
Recent Global Volcanic Activity
11
Introduction to Pyroclastic Volcanism

• Volcanic rocks and tectonics
• Island arcs as sites for pyroclastic rocks
• Pyroclastic rock generation modes
• Effusive vs. explosive volcanism
• Some characteristics of pyroclastic rocks
• Soufriere Hills Volcano, Montserrat

12
Volatile Control on Eruption Style
From Sparks, 1978
13
Pressure Effects on Volatile-rich Systems
From Best, 2003
14
Volatiles and Eruptions
From Best, 2003
15
Dome Formation
16
1993 Dome MSH
17
circum-Caribbean seismicity
Caribbean
epicenters lt 30 km depth from USGS
Modified from Jansma et al., 2000
18
Caribbean bathymetry
BR Beata Ridge HE Hess Escarpment NPDB North
Panama Deformed Belt SCDB South Caribbean
deformed belt
19
Montserrat Location Map
From Mattioli et al., 1998
20
1995 Tar River Valley
Tar River Valley - Looking ENE October 1995
English Crater 4 Ka Sector Collapse
Photo credit G. Wadge
21
1995 earthquakes
Harmonic Tremor
VT Eqs -gt
22
Destroyed Hermitage CGPS Site, 1996
Photo credit G. Mattioli
23
Kinematic Flow Models

• Theoretical background
• Data required
• Parameterization of the models
• Results from Montserrat
• Implications

24
Required data

• Accurate DEMs - required adding a synthetic
  dome to generate current topopgraphy not on
  available maps
• Previous direct measurements at other similar
  volcanoes Mt. St. Helens and Mt. Unzen

25
Kinematic Flow Models
From Hooper Mattioli, 2001
26
Tar River Valley, Spring 1996
Burnt Zone - Initial channelization of small PFs
Photo credit G. Mattioli
27
Simulated Flow Velocities
From Hooper Mattioli, 2001
28
SHV Pyroclastic Deposits to 1998
29
New Tar River Delta
July 12th 2003 eruption
From http//www.bgs.ac.uk/news/montserrat.html
Photo credit Steve OMeara Volcano Watch
International
30
Plymouth, Montserrat - Oct. 1997
Photo credit G. Mattioli
31
Sub-surface magmatic processes

• Campaign and continuous GPS geodesy done from
  1995-2003
• Several CGPS sites destroyed over the years
  current network was 6 sites WTYD site destroyed
  on July 12th, but will be replaced.
• Data processed in absolute point positioning mode
  with final JPL orbits, clocks, and earth
  orientation parameters
• CALIPSO Project recently added 4 additional sites

32
Hermitage CGPS site, Jul. 1996
Photo credit G. Mattioli
33
General CGPS Schematic
34
Vulcanian Explosions, Oct. 1997
No Surface Flux
Renewed Dome Growth
Explosions -gt
lt-Dome Growth
13 km
Subsidence Again! -gt
lt- Subsidence
Inflation -gt
Photo credits G. Mattioli
Data from Mattioli et al., 2001 Sparks et al.,
1998
35
GPS Data and Elastic Model
From Mattioli et al., 2002
36
GPS Vertical Velocity Field
From Mattioli et al., 1998 Mattioli et al., 2002
37
CALIPSO Borehole Observatory

• Sacks-Evertson single component dilatometer (10-9
  strain)
• Nearly broadband 3 component seismometer (2 Hz
  to 1 kHz)
• Pinnacle Systems short-baseline electronic
  tiltmeter
• Ashtech µ-Z code-phase CGPS w/ choke ring antenna

38
Unloading DOSECC Drill Rig
Photo credits G. Mattioli
39
SHV Dome - Dec. 2002
Photo of dome in Dec. 02 on a rare clear day. By
July 2003 the dome had grown to gt230 M m3 and
had not collapsed significantly for 2 years!!
Photo credit G. Mattioli
40
Drilling Operations Core Logging
Photo credits G. Mattioli
41
Grouting Strainmeter at Air Studios
Photo credit G. Mattioli
42
Trants Construction
Photo credit G. Mattioli
43
Trants Instrument Crypt GPS Monument
Photo credit G. Mattioli
44
Reftek Downloads
Photo credit G. Mattioli
45
July 12th PFs
July 12th, 2003 - Dome collapse begins at 9 AM
AST By sunset, pyroclastic flows are getting
more energetic and now routinely reach the sea
at the Tar River delta. NB white is steam while
gray is co-ignimbrite ash cloud.
Photo credit G. Mattioli
46
July 12 Data
Trants Borehole Seismic and Strain Records for
July 12th Sub-plinian to Plinian event at 11 PM
AST
Seismometer 200 Hz (803 PM to 1213AM AST)
Strainmeter 50 Hz (842 PM to 1242AM AST)
Although Trants site was impacted by ash during
the culminating event of the July12th dome
collapse, the CALIPSO BH instruments
functioned throughout the eruption.
Photo credit G. Mattioli
47
Air Studios on July 14th
First visit to Air Studios on July 14th - 12.5 cm
of ash and 6 cm mud in crypt NB infrasound
microphone under ash, but CALIPSO was still up!
Photo credits G. Mattioli
48
Ash in Olveston - July 13th
The morning after at Sea Dreams in Olveston 12
cm of ash and 6.5 cm pumice fragments!
Photo credits G. Mattioli
