Built-in Built-in-Testing for Base band and RF Integrated Circuits

1
Built-in Built-in-Testing for Base band and RF
Integrated Circuits
Analog and Mixed-Signal Center
Edgar Sánchez-Sinencio
Texas AM University http//amsc.tamu.edu/
2
Outline

• Analog/RF Testing Research Overview
• Switched Capacitor Spectrum Analyzer
• Fully Integrated Transfer-Function
  Characterization System
• CMOS RMS Detector for HF/RF Testing
• Summary of Publications

3
Analog/RF Testing Research Overview

• Switched Capacitor Spectrum Analyzer ( low
  frequency)
• Robust SC techniques applied for magnitude
  response and harmonic distortion
  characterization.
• Applicable for high frequency testing through
  up/down conversion.
• Fully Integrated Transfer-Function
  Characterization System ( 100s MHz)
• Magnitude and phase response characterization at
  various nodes.
• Fully digital system control and output.
• Suitable for testing in the range of hundreds of
  MHz.
• CMOS RF RMS Detector (GHz)
• Characterization of RF transceiver building
  blocks at 2.4GHz.
• Testing of a 350 MHz Low Pass Boost Filter for
  read channels.

4
Testing Strategy Conceptual Description
C H I P
External Digital Test System
Digital Interface
Analog Device Under Test
Information Processing
(DUT)
Test activation and control
-Frequency response (Magnitude and
Phase) -Harmonic Distortion
Test Circuitry
Characterization data
Test circuitry area ltlt DUT area
Pass/Fail
5
Outline

• Analog/RF Testing Research Overview
• Switched Capacitor Spectrum Analyzer
• Fully Integrated Transfer-Function
  Characterization System
• CMOS RMS Detector for HF/RF Testing
• Summary of Publications

6
Switched Capacitor Spectrum Analyzer
Clocks
Clocks

• A simple sinewave generator synchronized with
  a high-Q
• SC bandpass filter enables a precise magnitude
  response and harmonic distortion characterization
  of the DUT.

7
On-Chip Spectrum Analyzer Operation
f0 is synchronized with fBP
fBP is digitally controlled
8
Switched Capacitor Sinewave Generator
The Sinewave Generator is an integrator that
generates 16 steps per period of a Sinusoidal
wave.
9
Chip MicrographAMI 0.5um CMOS technology
Sinewave Generator 280µm330µm Bandpass
Filter 400µm?330µm VGA 200µm?210µm ADC
420µm?330µm Total Area for BIT Circuitry
0.5mm2
10
Chip Layout and Microphotograph

• AMI 0.5 µm process
• Total area 750µm ?550 µm

11
Experimental Results Sinewave Generator
Time Domain
Spectrum

• Output frequency 10KHz
• Harmonic distortion for a 1Vpp output -38dBm
• Noise density lt -85 dBc
• Power consumption 50uW

12
Experimental Results BP Filter and VGA
BP Filter Transfer Function
VGA output for different gains

• Q programmability (BP Filter) 30, 60 and 120
• Gain programmability (VGA) 0, 8, 12, 16 and 20dB

• Error in center frequency lt 0.4

13
Testing a 2nd Order LP Filter Commercial
Spectrum Analyzer Vs. Proposed System
Test Setup
Test Setup
14
Experimental Results Frequency Response
15
Experimental Results Harmonic Distortion
3rd harmonic distortion at the input of the BP
filter -30dB Measured distortion with the
proposed system -29.3dB
16
SC Spectrum Analyzer Summary

• The use of robust SC techniques yields accurate
  magnitude response and harmonic distortion
  on-chip measurements.
• Despite the frequency limitations of SC circuits,
  combining proposed techniques with of building
  blocks available in HF systems enables the
  application for testing of HF DUTs.
• Area overhead is 4, 10, and 3 for Audio
  processor, Line Driver for ADSL and Cellular
  transceiver, respectively.
• Experimental Results from a prototype in CMOS
  0.5um
• M. Mendez-Rivera, A. Valdes-Garcia, J.
  Silva-Martinez and E. Sánchez-Sinencio, An
  On-Chip Spectrum Analyzer for Analog Built-In
  Testing, in Journal of Electronic Testing
  Theory and Applications, vol. 21, pp. 205-219,
  June 2005.

17
Fully Integrated Transfer-Function
Characterization System

• Magnitude and frequency response characterization
  at different nodes of the CUT.
• System includes frequency synthesizer, magnitude
  and phase detector and ADC.
• The control interface and the output are fully
  digital.
• The testing technique is robust to process
  variations.
• The system can be employed as a tester chip or
  for built-in characterization.
• Suitable for testing analog blocks and subsystems
  in the range of hundreds of MHz.
• Silicon area is 0.3mm2 in 0.35um CMOS technology.

18
Outline

• Analog/RF Testing Research Overview
• Switched Capacitor Spectrum Analyzer
• Fully Integrated Transfer-Function
  Characterization System
• CMOS RMS Detector for RF Testing
• Summary of Publications

19
Transfer Function Characterization
The transfer function of a circuit under test
(CUT) is obtained by comparing the amplitude and
phase of the signals at the input and output.
20
Magnitude and Phase Detector
An analog multiplier sequentially performs 3
multiplication operations between the input and
output of the CUT. 3 DC voltages are generated
(X, Y, Z).
21
How to determine the magnitude (B/A) and phase
(q) responses?

• Simple operations performed by the external
  digital tester

From









W
e

c
an obtain

• The measurements do not depend neither on
• The amplitude of the signal generator (A)
• Nor on the gain of the multiplier (K).

22
Block Diagram of Chip Prototype with Integrated
CUT

• Full On-Chip Characterization System
• Transfer function can be characterized at
  multiple nodes
• A digital word selects the test frequency and the
  node

23
Phase Amplitude DetectorAnalog multiplier
with LPF

• Transistors operating in the linear region (M1)
• Source follower (M2)

24
Experimental Results Amplitude Phase Detector

• Dynamic range for amplitude detection is gt 30dB
• Phase detection error is lt 1 over 95 of the
  overall 360 range

25
Simple and Robust VCO of the PLL

• Multivibrator Lowpass Filter
• VC controls both the frequency and LPF
• A relatively constant amplitude and distortion
  over 2-150MHz

26
Signal Generator Experimental Results
Tuning Range
Output Spectrum Locked PLL
27
7-bits Successive Approximation ADC

• Output is taken serially through Dout (MSB down
  to LSB).
• Can be employed to digitize (monitor) any DC
  voltage in the chip using less than 0.1mm2 of
  area.
• Experimental Results
• Power consumption less than 200 mwatt
• Conversion time 1.2ms

28
ADC Experimental Results
End of Conversion Clock Data
29
Chip MicrographTSCMC 0.35um CMOS technology
Amplitude Phase Detector (APD)
310µm180µm Frequency Synthesizer 380µm?390µm A
DC 300µm?300µm Total Area for BIT Circuitry
0.3mm2 Area for each CUT 0.5mm2
30
Application as a Tester Chip Testing a 70MHz
PGA for ADSL
Experimental Results Gain Programmability
Test Setup
31
Application Testing a 70MHz PGA for ADSL
Magnitude Response
Phase Response
32
Complete System Testing On-Chip BPF
33
Built-in Testing of Continuous Time Boost Filter

• RMS Detector at the filter Output
• Gives maximum Fault Coverage
• Functional testing of w3dB, Boost, DC Gain
• RMS Detector at the input Calibration path
• RMS Detector at An Intermediate Node
• Should maximize the incremental fault coverage.
• Should be able to allow additional loading due to
  power detector.

34
Outline

• Analog/RF Testing Research Overview
• Switched Capacitor Spectrum Analyzer
• Fully Integrated Transfer-Function
  Characterization System
• CMOS RMS Detector for RF Testing
• Summary of Publications

35
On-Chip RF RMS Detection Motivation

• Increasing need for SOC test cost reduction.
• Fast fault diagnosis is required to accelerate
  the product development phase and time-to-market.
• Observation of RF signal paths through DC
  voltages is an effective and low cost test method
  for RF systems.
• Some implementations exist in SiGe but full CMOS
  solutions are desirable.

36

• RMS detection at different nodes of a wireless
  transceiver improves the fault diagnosis
  capabilities

Detection points
37
LNA Test Example

• Setup LNA with RMS Det. at input and output
• LNA1 On Spec.
• LNA2 Faulty

Robust Method Gain and 1dB comp. can be measured
regardless of the rms dectors gain or linearity.
38
RF RMS Detector Concept

• Desired Features
• High input impedance and low substrate noise
  injection.
• Low area overhead (lt10 of the entire transceiver
  area).
• Dynamic range suitable for the characterization
  of the CUT.

39
Proposed RF RMS Detector
40
Pre-rectification Current Amplification

• M1 - Common Source RF Input transistor - converts
  the ac input voltage to ac current.
• Two current mirrors (M2-M3 and M6-M9) magnify the
  AC current.
• R1 and R3 increase the bandwidth of the AC
  current mirrors.

41
Current Rectification Positive Cycle

• The working principle is to turn M10 and M11 on
  and off using AC current.
• M10 and M11 are DC-biased in the weak inversion
  region.
• M10-M11 operate as a current mirror and the AC
  current is mirrored to the Low Pass Filter.

42
Current Rectification Negative Cycle

• The AC current from C1, is extracted out of Cpar
  and IB_small.
• M10 and M11 go into cutoff (off-state) and no ac
  current is fed to the low pass filter.
• AC current is fed to the filter only during the
  positive cycle and hence the half-wave-rectificati
  on is performed.

43
AC-DC Conversion Filtering

• Post-rectification consists of a Second-order
  Low-Pass Filter with I-V Conversion
• First pole is implemented in the PMOS Current
  Mirror Load formed by M12 and C2.
• R6 and C3 perform the Second Low-Pass Pole.

44
Post Layout Simulation Results
Transfer Characteristic at 2.4 GHz
45
RMS Detector Performance Summary
Area Overhead Analysis
46
Integrated Prototype

• Implementation in TSMC 0.35mm process including
• Stand alone RMS Detector
• 2.4GHz LNA and Buffer with RMS detectors.

47
Experimental Results
Wideband operation (1.5GHz), Dynamic Rangegt30dB
48
Additional Application Built-in Testing of HF
Continuous Time Systems
Fault Diagnosis
CORE
HF RMS Detect
Boost Filter
On-Chip Signal Gen
Functional Testing
49
RMS Detector at An Intermediate Node

• Capturing Q obviates the need of a dedicated
  phase detection
• Band-Pass node is more sensitive to captures Q
  errors than a Low-Pass Node.
• Biquad1 has an available BP node Biquad2 has a
  BP node cascaded with a second order LP

50
Built-in Testing of Continuous Time Boost Filter
LP-1
LP-2
BQ1
BQ2
LPF3
BP-1
BP-2
RMS Detect 4
RMS Detect 2
RMS Detect 1
RMS Detect 2
Functional tests Fault Diagnosis for overall
Filter w3dB and DC gain, Boost Observable
BP Nodes Q Observable
Calibration Path
51
Filter Characterization for Fault Diagnosis

• DC Gain and w3dB Observable at the output
• Boost Gain for different settings Observable at
  the output
• Q for the Filter Observable at the BP node of
  Biquad 1 and Biquad 2
• Boost Slope and the Stop-Band Slope Observable
  at the output

52
Summary

• A practical CMOS RF RMS detector is developed for
  on-chip characterization of RF circuits and
  systems.
• A methodology for the use of this device in the
  gain and 1dB comp. measurement of an RF circuit
  is developed.
• An implementation in a standard 0.35mm CMOS
  process uses lt0.15mm2 of area and presents an
  input capacitance lt25fF. Experimental results
  show broadband operation from 900MHz to 2.4GHz.
• The direct on-chip measurement of signal
  amplitudes at RF frequencies is feasible in CMOS
  with a very low area and parasitic loading.

53
Modified Architecture for Testing a HF DUT
Frequency response and linearity
characterizations can be performed
54
Integral On-Chip Test of a Transceiver
Work in progress Combining RF RMS detection,
Transfer Function Characterization and a
Loop-back architecture.
55
Outline

• Analog/RF Testing Research Overview
• Switched Capacitor Spectrum Analyzer
• Fully Integrated Transfer-Function
  Characterization System
• CMOS RMS Detector for RF Testing
• Summary of publications

56
Recent Publications on Analog Testing

• A. Valdes-Garcia J. Silva-Martinez and E.
  Sanchez-Sinencio, An On-Chip Transfer Function
  Characterization System for Analog Built-In
  Testing, IEEE VLSI Test Symposium, pp. 261-266,
  April 2004.
• A. Valero-Lopez, A. Valdes-Garcia and E.
  Sanchez-Sinencio, Frequency Synthesizer for
  On-Chip Testing and Automated Tuning, IEEE
  International Symposium on Circuits and Systems,
  pp. 561-568, May 2004.
• M. Mendez-Rivera, A. Valdes-Garcia, J.
  Silva-Martinez and E. Sanchez-Sinencio, An
  On-Chip Spectrum Analyzer for Analog Built-In
  Testing, Journal of Electronic Testing Theory
  and Applications, vol. 21, pp.205-219, June 2005.
  Most downloaded paper from the website of this
  journal (06/05- present).
• A. Valdes-Garcia, R. Venkatasubramanian, R.
  Srinivasan, J. Silva-Martinez and E.
  Sanchez-Sinencio, A CMOS RF RMS Detector for
  Built-in Testing of Wireless Receivers, IEEE
  VLSI Test Symposium, pp. 249-254, May 2005.
• A. Valdes-Garcia J. Silva-Martinez and E.
  Sanchez-Sinencio, On-Chip Testing Techniques for
  RF Wireless Transceivers, Invited to IEEE Design
  Test Journal.
• A. Valdes-Garcia J. Silva-Martinez and E.
  Sanchez-Sinencio, On-Chip Testing Techniques for
  Analog and RF Integrated Circuits, To be
  presented at Semiconductor Research Corporation
  (SRC) TECHCON Conference, October 2005.

Alberto Valdes-Garcia 1st place winner IEEE Test
Technology Technical Council (TTTC) Doctoral
Thesis Award
