Avoider Enforcer games

Same Boards, Different goal.

Hyper Graph G (V, E)

Simple illustration

Biased Game (p, q, H)

- Avoider on each move, selects p vertices
- Enforcer on each move, selects q vertices

- P
- q

Are Avoider Enforcer andMaker Breaker

games equivalent ?

- Makers goal is to fully occupy a hyperedge
- Avoiders goal is NOT fully occupying an hyperedge

- Breakers goal is failing Maker
- Enforcers goal is failing Avoider

A remainder a game of (p,q,H)

- Maker Breaker a sufficient condition for

Breaker to win - Was derived (by Beck) by constructing a

potential function, taking after ErdosSelfridge.

More about Maker Breaker

- Tight bound
- Monotone
- if Maker wins a game of (p, q, H), then he surely

wins a game of (p1, q, H) and of (p, q-1, H). - If Breaker wins a game of (p, q, H), then he

surely wins a game of (p, q1, H) and of (p-1, q,

H).

Avoider Enforcer - There are some similarities

- A sufficient condition for Avoider to win a game
- of (1, 1, H) is
- Which is the same as the last condition for

Breaker to win for all - (p, q, H).
- However, in general there is much difference.

Avoider Enforcer A sufficient condition for

Avoider

- In a game of (p, q, H) -
- if
- then Avoider has a winning strategy.
- If Enforcer has the last move, this condition can

be relaxed to

Based upon Beck ErdosSelfridge

Avoider Enforcer A sufficient condition for

Avoider

- Notice the condition is independent of q

(Enforcers bias) not a tight bound. - Although, for any constant q, it is not far.
- (One of the important open questions)
- Not monotone in general !
- as demonstrated next in two games victory is

accomplished through parity!

1. A game of (1, q, H)

EVEN

- H
- For t large enough
- Enforcer wins
- q is even

1. A game of (1, q, H)

ODD

- H
- For t large enough
- Enforcer wins
- q is even

2. A game of (p, 1, H)

- Vertices of H vertices of
- Hyperedge of H set of a vertex of each level
- For t large enough
- Avoider wins
- p is even
- Exactly the same method as the last game

Avoider Enforcer games

- Are considerably different from Maker Breaker
- Not monotone
- Different sufficient condition (for Avoider)
- The sufficient condition is not tight
- Next, we study more closely 2 quite natural

Avoider Enforcer (1, q, H) games - Perfect Matching
- Connectivity
- Searching for a sufficient condition for Enforcer

to win (1,q,H) - Maker Breaker threshold of order n/log(n).

Perfect Matching over the edges of (1, q, K2n

)

U V

- H is a complete graph on 2n vertices.
- Let be a copy of

in . - Enforcer enforces Avoider to select edges so that

at the end of the game Avoider has a complete

Matching. - Take t edges of E and let E1E \ those t edges
- t is the minimal integer such that (q1)

n(n-1)t - Let E2 denote all the remaining edges except E1

Perfect Matching over the edges of (1, q, H)

- Each time Avoider picks an edge from E2, Enforcer

picks q edges from E2. this is always possible as

E2 is divisible by q1 (choosing t

appropriately) - We will focus on the edges of E1
- Each time Avoider picks an edge from E1, Enforcer

picks q edges from E1 (this is always possible,

except maybe once).

U V

Perfect Matching over the edges of (1, q, H)

U V

- In order to show a complete Matching of (U, V,

E1), we will see that at the end of this game,

the set of edges picked by Avoider satisfies

Halls condition - Let (X,Y,E) be a bipartite graph
- for every X U,
- N(X) X
- X has a perfect Matching.

X

N(X)

The trick A transposition

U V

- Define a hypergraph
- as following
- 1. the hyper vertices of
- are the edges of E1.
- 2. The hyperedges of
- are all the sets of edges between vertices of X

U and Y V so that - XY n1.

X

Y

The trick A transposition

U V

- In the new graph, Enforcer
- plays as Halls-Avoider,
- and Avoider plays as Halls-Enforcer.
- The new game (q, 1, )
- Now - Halls-Avoider
- applies the sufficient condition for winning the

new game thus, not fully occupying any

hyperedge of . - Later, we examine the size of the appropriate q

X

Y

The trick A transposition

U V

- Now well see that if Halls-Avoider

doesnt fully occupy any hyperedge, Halls

condition is satisfied by Halls-Enforcer. - At the end of the new game, take any subset X of

U. - Look at N(X) which were picked by

Halls-Enforcer. - This implies all the other edges (the new hyper

vertices) were picked by Halls-Avoider.

N(X)

X

V-N(X)

The trick A transposition

U V

- As Halls-Avoider wins, it is impossible

that - Xn-N(X) n1
- (otherwise Halls-Avoider would have lost), and

so - Xn-N(X) n
- N(X) X
- and so Hall condition is satisfied by

Halls-Enforcer. - Now, retranspose
- Halls-Enforcer is our Avoider

N(X)

X

V-N(X)

About that q

- Showing that Halls-Avoiders bias in the (q,1,

) game satisfies Avoiders sufficient condition

at the start of the new game

About that q

About that q

Remember The condition

Perfect Matching over the edges of (1, q, H)

U V

- We saw for
- Enforcer has a winning strategy!
- We dont know whether this is a tight bound!
- We dont know whether it is monotone!
- Next, we play connectivity

Connectivity on (1, q, H)

- Where H contains q1 pairwise edge disjoint

spanning trees(or more). - Avoider and Enforcer pick edges.
- We will see that Enforcer can enforce Avoider to

pick a spanning tree.

Connectivity on (1, q, H)

- Let T1, T2, , Tq1 be pairwise disjoint spanning

trees of G(V,E). - Let W be the union (of the edges) of the q1

spanning trees. - Let L E\W.

Enforcers strategy

- Maintains in memory q1 acyclic graphs G1, G2,

, Gq1. - In the beginning, Gi Ti (i1.q1) which are

the original spanning trees.

Enforcers strategy

- Whenever Avoider picks an edge e of some Gj,

Enforcer picks one edge fi of each Gi (i J),

hence a total of q edges. - For all i j If Gi U e contains a (unique)

cycle then fi is chosen as some unclaimed edge on

this cycle. If Gi U e doesnt contains a cycle

then fi is chosen arbitrarily. - In any case, Enforcer replaces Gi with Gi U e \

fi.

Enforcers strategy

- If Avoider picks an edge of L then Enforcer picks

q edges of L. if there are not enough edges in L,

Enforcer picks the rest of his acyclic graphs

one edge of a different Gi. - If Enforcer starts the game, he would also start

on the edges of L. - In any case, Enforcer removes his picks from the

Gi.

An example

A winning strategy

- Every unclaimed edge of W is in exactly one Gi,

and every edge of W claimed by Avoider is in

every Gi. - (an edge is added to Gi it was chosen

by Avoider). - Every edge claimed by Enforcer is in no Gi.
- (an edge is removed from Gi it was

chosen by Enforcer).

A winning strategy

- After each round, each Gi is either a spanning

tree, or a panning tree minus one edge. - It is obviously true at the beginning.
- Suppose it is true after the Kth round.
- If Avoider, on his K1 move, picks an edge e of

some Gj, then Enforcer, on his K1 move, picks an

edge fi of the other Gi. - If Gi U e is acyclic, then Gi U e \ fi is a

spanning tree minus one edge. - If Gi U e contains a cycle then removing an

edge fi from this cycle makes Gi U e \ fi a

spanning tree over the same vertices as it was on

the Kth round, thus it is a spanning tree or a

spanning tree minus one edge.

A winning strategy

- In the end, each Gi has no unclaimed edges.
- thus, all the edges of Gi are those which were

picked by Avoider (as Enforcers picks are

removed of each Gi and Avoiders picks are in

each Gi). - So every Gi where is the set of

edges picked by Avoider. - Gi in the end is a spanning tree or a spanning

tree minus one edge. - We know that V - 1

because there are - (q1)(n-1) edges in W, so each player plays at

least (n-1) rounds. - Thats why Gi must be a spanning tree, and

Enforcer has won!

Connectivity on (1, q, H)

- We saw that if H contains q1 edge disjoint

spreading trees, Enforcer has a winning strategy. - If H does not contain q1 edge disjoint spanning

trees, and there is some limit on the number of

total edges and the identity of the first player

then, Avoider has a winning strategy.

Connectivity on (1, q, H)

- For maker Breaker generally, the existence of

q1 edge disjoint spanning trees does not ensures

Makers win. - There exists a polynomial time algorithm for

finding q1 edge disjoint spanning trees, so

Enforcers strategy is realistic. - Next we apply this outcome on special cases.

Connectivity on complete graphs

- On complete graphs, the game of (1, q, Kn ) has a

threshold of - Kn contains edge disjoint spanning trees.
- By what we have seen, Enforcer would win.
- If q almost always Enforcer wins

Kn

Connectivity on complete graphs

- If q then each round total of

are colored. - For Avoider to lose, the game must last at least

n-1 rounds. - So total of edges.
- If n is even then this is more than we have.
- So Avoider wins.

Kn

Connectivity on complete graphs

- If n is odd and the graph has

total edges. - In case Enforcer is the first player, we need
- total edges.
- which is still too much, so Avoider wins.

Kn

Connectivity on complete graphs

- If Avoider is the first player, we need
- Which is exactly what we have.
- Avoider wins only if he completes some cycle.
- In an analogues game of Maker Breaker, it could

be shown that Breaker wins. - So Avoider loses in this case.

Kn

Connectivity on complete graphs

- We saw the threshold is
- except for special cases where n is odd and

Avoider starts, and then the threshold is - Another way of putting it is that this game is

monotone.

Kn

Connectivity on complete graphs

- Another special game is the game of (1,1 Kn).
- Enforcer can enforce Avoider to build

spanning trees. - The strategy playing
- separate games, each on a graph with 2 edge

disjoint spanning trees.

Kn

Summery

- Avoider Enforcer games are not generally

monotone. - A sufficient condition for Avoider to win in

(p,q,H), which was not tight. - We studied 2 special games
- Perfect Matching in (1,q,Kn,n), where Enforcer

has a winning strategy for q of order n/log2n. We

dont know whether there exists a threshold, and

if so, of what ordeer.

Summery

- Connectivity we saw a general sufficient

condition for Enforcer to enforce a spanning tree

in (1,q,H), where H contains q1 edge disjoint

spanning trees. - Connectivity in (1,q,Kn), which is a special case

of a monotone game with a threshold of - Connectivity in (1,1,Kn), in which Enforcer can

enforce Avoider to build edge disjoint

spanning trees.

About PowerShow.com

PowerShow.com is a leading presentation/slideshow sharing website. Whether your application is business, how-to, education, medicine, school, church, sales, marketing, online training or just for fun, PowerShow.com is a great resource. And, best of all, most of its cool features are free and easy to use.

You can use PowerShow.com to find and download example online PowerPoint ppt presentations on just about any topic you can imagine so you can learn how to improve your own slides and presentations for free. Or use it to find and download high-quality how-to PowerPoint ppt presentations with illustrated or animated slides that will teach you how to do something new, also for free. Or use it to upload your own PowerPoint slides so you can share them with your teachers, class, students, bosses, employees, customers, potential investors or the world. Or use it to create really cool photo slideshows - with 2D and 3D transitions, animation, and your choice of music - that you can share with your Facebook friends or Google+ circles. That's all free as well!

For a small fee you can get the industry's best online privacy or publicly promote your presentations and slide shows with top rankings. But aside from that it's free. We'll even convert your presentations and slide shows into the universal Flash format with all their original multimedia glory, including animation, 2D and 3D transition effects, embedded music or other audio, or even video embedded in slides. All for free. Most of the presentations and slideshows on PowerShow.com are free to view, many are even free to download. (You can choose whether to allow people to download your original PowerPoint presentations and photo slideshows for a fee or free or not at all.) Check out PowerShow.com today - for FREE. There is truly something for everyone!

You can use PowerShow.com to find and download example online PowerPoint ppt presentations on just about any topic you can imagine so you can learn how to improve your own slides and presentations for free. Or use it to find and download high-quality how-to PowerPoint ppt presentations with illustrated or animated slides that will teach you how to do something new, also for free. Or use it to upload your own PowerPoint slides so you can share them with your teachers, class, students, bosses, employees, customers, potential investors or the world. Or use it to create really cool photo slideshows - with 2D and 3D transitions, animation, and your choice of music - that you can share with your Facebook friends or Google+ circles. That's all free as well!

For a small fee you can get the industry's best online privacy or publicly promote your presentations and slide shows with top rankings. But aside from that it's free. We'll even convert your presentations and slide shows into the universal Flash format with all their original multimedia glory, including animation, 2D and 3D transition effects, embedded music or other audio, or even video embedded in slides. All for free. Most of the presentations and slideshows on PowerShow.com are free to view, many are even free to download. (You can choose whether to allow people to download your original PowerPoint presentations and photo slideshows for a fee or free or not at all.) Check out PowerShow.com today - for FREE. There is truly something for everyone!

presentations for free. Or use it to find and download high-quality how-to PowerPoint ppt presentations with illustrated or animated slides that will teach you how to do something new, also for free. Or use it to upload your own PowerPoint slides so you can share them with your teachers, class, students, bosses, employees, customers, potential investors or the world. Or use it to create really cool photo slideshows - with 2D and 3D transitions, animation, and your choice of music - that you can share with your Facebook friends or Google+ circles. That's all free as well!

For a small fee you can get the industry's best online privacy or publicly promote your presentations and slide shows with top rankings. But aside from that it's free. We'll even convert your presentations and slide shows into the universal Flash format with all their original multimedia glory, including animation, 2D and 3D transition effects, embedded music or other audio, or even video embedded in slides. All for free. Most of the presentations and slideshows on PowerShow.com are free to view, many are even free to download. (You can choose whether to allow people to download your original PowerPoint presentations and photo slideshows for a fee or free or not at all.) Check out PowerShow.com today - for FREE. There is truly something for everyone!

For a small fee you can get the industry's best online privacy or publicly promote your presentations and slide shows with top rankings. But aside from that it's free. We'll even convert your presentations and slide shows into the universal Flash format with all their original multimedia glory, including animation, 2D and 3D transition effects, embedded music or other audio, or even video embedded in slides. All for free. Most of the presentations and slideshows on PowerShow.com are free to view, many are even free to download. (You can choose whether to allow people to download your original PowerPoint presentations and photo slideshows for a fee or free or not at all.) Check out PowerShow.com today - for FREE. There is truly something for everyone!

Recommended

«

/ »

Page of

«

/ »

Promoted Presentations

Related Presentations

Page of

Page of

CrystalGraphics Sales Tel: (800) 394-0700 x 1 or Send an email

Home About Us Terms and Conditions Privacy Policy Contact Us Send Us Feedback

Copyright 2017 CrystalGraphics, Inc. — All rights Reserved. PowerShow.com is a trademark of CrystalGraphics, Inc.

Copyright 2017 CrystalGraphics, Inc. — All rights Reserved. PowerShow.com is a trademark of CrystalGraphics, Inc.

The PowerPoint PPT presentation: "Avoider" is the property of its rightful owner.

Do you have PowerPoint slides to share? If so, share your PPT presentation slides online with PowerShow.com. It's FREE!
