Freshwater Resources

1
Freshwater Resources

• Chapter 15

2
Freshwater

• Water that is relatively pure with very few
  dissolved salts
• Freshwater occurs in
• Lakes rivers streams groundwater glaciers
  rainwater soil water vapor in the atmosphere
• (In contrast ocean water is salty because salts
  from land run into it and stay there as surface
  water evaporates.)

3
Freshwater

• Only 2.5 of the planets water is freshwater.
• And only 1 of that exists on Earths surface.
• Only 1 part in 10000 of water is easily
  accessible for drinking and irrigation.

4
Where is the Freshwater

• Rivers and streams
• Wetlands
• Lakes and Ponds
• Groundwater

5
Groundwater

• Water beneath Earths surface that did not
  evaporate flow into rivers or get taken up by
  organisms
• Groundwater is contained in aquifers porous
  spongelike layers of rock sand or gravel.
• Water table boundary between the upper zone of
  aeration and the lower zone of saturation

6
Aquifers

• Confined or artesian aquifer water under
  pressure trapped within impermeable layers
  (often clay)
• Unconfined aquifer water under less pressure
  no overlying impermeable layer
• Aquifer recharge zone geographic area where
  water infiltrates soil and recharges aquifer

7
Groundwater and aquifers
8
Freshwater distribution

• Global freshwater distribution is very uneven.
• Rainfall varies from nearly zero up to 1200
  centimeters (470 inches)/year.
• Canada has 20 times as much water per citizen as
  does China.

9
Available freshwater resources

• Nations vary by more than a factor of 100 inches
  of water per capita.

10
Available freshwater resources

• Asia has lots of water but very little water per
  capita.
• Australia has lots of water per capita but little
  water overall.

11
Water Use

• Consumptive use water is removed from an
  aquifer or surface body and not returned (e.g.
  most agricultural industrial and residential
  use)
• Nonconsumptive use removal of water is only
  temporary (e.g. passing water through a
  hydroelectric dam)

12
Biggest Issue is Depletion and Pollution of
Freshwater
13
Solutions for depletion Desalination

• Desalination or desalinization removal of salt
  from seawater to create freshwater
• Perfecting this technology would mean the oceans
  could provide us with unlimited freshwater.
• But so far it is expensive!
• Most of the worlds 7500 desalination plants are
  in wealthy oil states of the Middle East where
  water is scarce enough to make desalination
  economically feasible.

14
Solutions for depletion Reducing demand

• In AGRICULTURE
• Use high-efficiency irrigation techniques
• Line irrigation canals to prevent leaks
• Level fields to reduce runoff
• Choose crops appropriate to climate
• Eliminate government subsidies of inappropriate
  crops and methods
• New GM crops

15
Solutions for depletion Reducing demand

• In the INDUSTRIAL and MUNICIPAL sectors
• Shift to processes that save water (and thus
  money)
• Invest in repairing pipe leaks
• Recycle gray wastewater

16
Solutions for depletion Reducing demand

• In the RESIDENTIAL sector (what YOU can do)
• Install low-flow faucets and appliances
• Use automatic dishwashers
• Replace lawns with native vegetation
• If you keep lawns water them at night
• Recycle gray wastewater

17
Solutions for depletion Economic approaches

• Market-based strategies
• End government subsidies of inefficient practices
• Make water a commodity whose price reflects its
  costs
• Privatize water supplies
• Decentralize control over water
• Many of these strategies risk increasing the gap
  between rich and poor

18
Freshwater pollution

• Over half of the worlds major rivers are
  seriously depleted and polluted degrading and
  poisoning the surrounding ecosystems threatening
  the health and livelihood of people who depend on
  them.
• World Commission on Water 1999
• Groundwater pollution is extensive but invisible
  a covert crisis.

19
Water pollution point and non-point sources
20
Urban Runoff organic waste is largest single
pollutant
21
Types of pollution Eutrophication

• Excess runoff of nutrients like nitrogen and
  phosphorus leads to blooms of algae or
  phytoplankton
• and then microbial decay that sucks oxygen from
  the water
• (e.g. the hypoxic zone in the Gulf of Mexico)

22
Eutrophication
Oligotrophic water body Low-nutrient high-
oxygen conditions
Eutrophic water body High-nutrient low-oxygen
conditions
23
Types of pollution Pathogens

• Waterborne disease from viruses bacteria etc.
  contributes to 5 million deaths per year.
• In 2002 1.1 billion people were still without
  safe water supplies.
• 2.4 billion people had no sewer or sanitation
  facilities.
• 4/5 of people without sanitation lived in rural
  areas.

24
Types of pollution Toxic chemicals

• Many thousands of chemicals we manufacture find
  their way into our water where some have toxic
  effects.
• Pesticides
• Petroleum products
• Arsenic lead mercury other metals
• Acids from mining runoff and acid precipitation

25
Types of pollution Sediment

• Erosion of soil from mining clear-cutting real
  estate development and farming puts sediment
  into waterways.
• There it alters conditions and can kill organisms.

26
Types of pollution Heat and cold

• Yes even heat and cold can pollute!
• Organisms not adapted to the new temperature
  conditions can suffer or die.
• Warm water from power plants decreases
  dissolved oxygen.
• Clearing streamside vegetation also warms
  water.
• Cold water is released below dams harming
  native fish.

27
Indicators of water quality

• Scientists use biological properties to measure
  water quality
• Presence of pathogens disease-causing
  organisms may be present making water risky for
  drinking

28
Indicators of water quality

• Scientists use chemical properties to measure
  water quality
• Nutrient concentrations
• pH waters acidity or alkalinity
• Taste and odor can show presence of certain
  chemical contaminants
• Hardness hard water has high concentrations of
  salts
• Dissolved oxygen content indicates suitability
  for life high D.O. generally good for organisms

29
Indicators of water quality

• Scientists use physical properties to measure
  water quality
• Turbidity density of suspended particles
  water with sediments from erosion is turbid
• Color indicates tannins and other chemicals
• Temperature aquatic organisms sensitive to
  temperature warm water holds less dissolved
  oxygen

30
Groundwater pollution

• Worse than surface water pollution because it is
  longer lasting
• (e.g. persistent toxicants get washed out of
  rivers but remain in groundwater until they
  break down.)

31
Groundwater pollution

• Sources are both natural and anthropogenic.

• NATURAL SOURCES
• Arsenic
• Aluminum
• Fluoride
• Nitrates
• Sulfates

• HUMAN SOURCES
• Leaky underground storage tanks (oil gas
  industrial chemicals septic waste)
• Nitrates from fertilizers
• Pesticides
• Pathogens from wells and feedlots
• Contamination from underground hazardous waste
  disposal
• Industrial chemical waste
• Compounds from military sites

32
Sources of groundwater contamination
33
Pollution prevention

• Drinking water is treated before it reaches your
  tap.
• But it is easier and more cost effective to
  prevent pollution than to mitigate it once it
  occurs.

34
What is waste water treatment

• Municipal and industrial sewage
• Water has been changed because of addition of
  suspended solids salts nutrients bacteria or
  other oxygen-demanding material

35
What is BOD

• Biological Oxygen Demand the amount of oxygen
  needed by bacteria to decompose the organic
  material in the water
• Indirectly is a measure of organic matter in
  water
• The higher the BOD the more organic matter in
  the water

36
Waste Water Treatment in Rural Areas

• Septic Tanks
• Problems
• Septic tank is full of solids so bacteria cant
  work (needs to be emptied)
• Leach lines dont release water due to
• Soil compacted or impermeable or tree roots
  have clogged the lines

37
(No Transcript)
38
(No Transcript)
39
Waste Water Treatment in Cities

• Centralized Municipal Treatment Plant
• There are 3 steps in the process

40
Primary Treatment

• Removes 30 to 40 of the suspended solids and
  organic matter
• Screens remove large pieces of floating organic
  matter
• Grit chambers where sand small stones are
  removed
• Sedimentation tank where smaller particles can
  settle out forming a sludge. The sludge is
  combed out and transported elsewhere

41
Secondary Treatment

• The waster water from the primary treatment goes
  into an aeration tank. Sometimes called
  activated sludge tank. Air may be pumped in.
  Aerobic bacteria consume organic material
• The wastewater than goes into the final
  sedimentation tank
• Waste water is disinfected with chlorine gas
• Water is released into lake river ocean or
  recycled

42
Advanced Waste Water Treatment

• If the water coming out of the Secondary
  Treatment process still contains pollutants then
  another level of treatment is required
• Nitrates are removed by charcoal filters
• Heavy metals are removed by sand and grit filters
• Disinfected with chlorine or UV light

43
What to do with the treated waste water

• Discharge in river or ocean
• Use it for irrigating crops landscape golf
  courses
• Settling ponds to recharge aquifers

44
What to do with the sludge

• Further decomposition with bacteria also produces
  methane which can be use as fuel source
• Recycle sludge and use to seed in primary
  treatment
• Dry sludge and put in landfill or burn

45
What to do with storm drain water

• Mostly remains untreated and just flows into the
  ocean. Contains oil metals pesticides home
  fertilizers detergents

46
Natural sites of Water Treatment

• Wetlands marshes serve as natural areas of
  treatment

47

• Virtual Water Treatment Plant Tour
