QUORUMS

1
QUORUMS

• By gil ben-zvi

2
definition

• Assume a universe U of servers, sized n. A quorum
  system S is a set of subsets of U, every pair of
  which intersect, each Q belongs to S is called a
  quorum.

3
EXAMPLES

• Weighted majorities assume that every server s
  in the universe U is assigned a number of votes
  w(s). Then weighted majorities is a quorum set
  defined by

4
EXAMPLES

• MAJORITIES a weighted majorities quorum system
  when all weights are the same.
• Singleton a weighted majorities quorum system
  when for one server s w(s)1, and for each v of
  the other servers w(v)0. (only quorum is s)

5
EXAMPLES

• Grid suppose n is a square of some integer k.
  arrange the universe in a k x k grid. A quorum is
  the union of a full row and one element from each
  row below.
• FPP suppose a projective plane over a field
  sized q. each point is an element, and each line
  is a quorum. By projective plane attributes, each
  quorum intersect.

6
More definitions

• Coterie a coterie S is a quorum system such that
  for any Q1,Q2 quorums in S Q1 isnt included in
  Q2
• Domination coterie S1 dominates coterie S2 if
  for every quorum Q2 belongs to S2, there exist Q1
  in S1, such that S1 is contained in S2.
• Strategy a probability vector representing the
  probability to access each quorum.

7
measures

• Load the load L(S) of a quorum system is the
  minimal access probability minimized over the
  strategies.
• Resilience resilience is k, if k is the largest
  number such that for every k server crashes, one
  quorum remains unhit.

8
measures

• Failure probability if every server has certain
  probability to crash (assuming independently
  here), the probability that each quorum is hit.
  Usually assuming each server has the same crash
  probability p.

9
Measures examples

• Singleton load1, resilience0, failure
  probabilityp
• Majorities load is about ½. Resilience about
  (n-1)/2. failure probability (if p lt ½) smaller
  than exp(e,-n).
• Grid load is O(1/sqrt(n)). Resilience
  sqrt(n)-1, failure probability tends to 1 as n
  grows.

10
Access protocol

• Implements the semantics of a multi-writer
  multi-reader atomic variable.
• Assumes all clients and servers are non
  byzantine, unique timestamp for a client
• Write a client asks some quorum to obtain a set
  of value/timestamps pairs, then he writes his
  value with higher timestamp than each of the
  timestamps received to each server in the quorum.

11
Access protocol

• Read a client asks for each server in some
  quorum to obtain a set of value/timestamp. The
  client chooses the pair with the highest
  timestamp. It writes back the pair to each server
  in some quorum
• Server S updates a pair of value/timestamp, only
  if the timestamp is greater than the timestamp
  currently in S

12
Byzantine quorum systems

• We will use access protocol to demonstrate the
  subject
• Assuming communication is reliable, clients are
  correct, servers can be byzantine, assuming that
  a non-empty set of subsets of U BAD, is known,
  some B in BAD contains all the faulty servers.

13
Masking quorum systems

• A quorum system S is a masking quorum system for
  a fail-prone system BAD if the following
  properties are satisfied

14
Access protocol

• write remains the same
• Read for a client to read the variable x, it
  queries servers for some quorum Q to obtain a set
  of value/timestamp pairs

15
Access protocol

• The client chooses the pair with the highest
  timestamp in C, or null if C is empty.

16
Access protocol

• Claim a read operation that is concurrent with
  no write operations return the value written by
  the last preceding write operation in some
  serialization of all preceding write operations.
• Claim there exists a masking quorum system for
  BAD iff is a
  masking quorum system for BAD

17
Access protocol

• Criterion there exists a masking quorum system
  for BAD iff for all

18
F-masking quorum systems

• F-masking quorum system A masking quorum system
  where BAD is the set of all groups of servers
  sized f.
• By previous claims
• There exists a masking quorum system for BAD iff
  ngt4f
• Each pair of quorums must intersect by at least
  2f1 elements.

19
examples

• For f-masking quorums

20
Dissemination quorum systems

• Assumes clients can digitally sign the
  value/timestamp they propagate.
• Therefore weaker demands than masking
• A quorum system S is a dissemination quorum
  system for a fail-prone system BAD if the
  following properties are satisfied

21
Dissemination quorum systems

• The same way as masking we reach the (different)
  criterion
• There exists a dissemination quorum system for
  BAD iff

• If no more than f servers can fail, but any set
  of f servers can fail, then must hold ngt3f

22
Opaque masking quorum systems

• Motivation We want not to expose the fail-prone
  system BAD.
• done by majority decision.
• properties for quorum system to become opaque
  masking system

23
Opaque masking quorum systems

• Read the modification is that the client choose
  the pair ltv,tgt that appears most often, if there
  are multiple such sets, it chooses the newest
  one.
• Claim Suppose maximum f servers can fail, there
  exists an opaque quorum system for BAD iff ngt5f,
  sufficient because quorums sized (2n2f)/3 is
  an opaque quorum system for B.

24
Opaque masking quorum system

• Claim The load of any opaque system is at least
  ½.
• Proof if we sum up the load of a certain quorum,
  well get its bigger than its size/2. the claim
  follows.
• Example hadamard matrix, world of size exp(2,l)

25
Faulty clients

• Solves the problem that a client will try to fail
  the protocol.
• The treatment here provides a single-writer
  multi-reader semantics.
• The write operation starts when the 1st server
  receives update request, and ends when the last
  server sent acknowledgment.

26
Faulty clients

• Write for a client c to write the value v, it
  chooses legal timestamp, larger than any
  timestamp it has chosen before, chooses a quorum
  Q, And then it sends ltupdate,Q,v,tgt to each
  server in Q, if after some timeout period it has
  not received acknowledgment, than it chooses
  another quorum.

27
Faulty clients-servers protocol

• The servers protocol is as follows
• if a server receives ltupdate,Q,v,tgt from a client
  c, with legal timestamp, then it sends
  ltecho,Q,v,tgt to each member of Q.
• If a server receives identical echo messages
  ltecho,Q,v,tgt from every server in Q, then it
  sends ltready,Q,v,tgt to each member of Q.

28
Faulty clients-servers protocol

• 3. If a server receives identical ready messages
  ltready,Q,v,tgt from a set of servers that
  certainly doesnt contain faulty server, it sends
  ltready,Q,v,tgt to Q.
• 4. If a server receives identical ready messages
  ltready,Q,v,tgt from a set Q1 of servers, such that
  Q1Q\B for some B in BAD, it sends acknowledgment
  for c, and update the pair if t is greater than
  the timestamp it currently has.

29
Faulty servers-properties

• Agreement if a correct server delivers ltv,tgt and
  a correct server delivers ltr,tgt then rv
• Proof if a correct server delivers ltv,tgt, then
  echo must have been send by all correct servers
  in Q1. same about Q2, they intersect in a correct
  server, which doesnt send different value with
  the same timestamp

30
Faulty servers-properties

• Claim Read received last written value if its
  not concurrent with write operations.
• Proof same as masking quorum system.
• Propagation similar ideas to r.b, and byzantine
  agreement, if server decides to deliver, it is
  promised that all other decides that too.
• Validity at the end a correct quorum will be
  accessed, so the write can end.

31
Load, capacity, availability

• Load we will mark L(S), definition as before
• availability failure probability with the same
  p for all the servers, we will mark it as Fp(S)
• Capacity well define a(S,k) as the maximum
  number of quorum accesses that S can handle
  during a period of k time units. Capp(S) is the
  limit of a(S,k)/k as k tends to infinity.

32
Load, capacity, availability

• Example majorities
• The claim is that cap(S)1/L(S), and there is a
  trade off between good availability and good
  load.

33
definitions

• The cardinality of the smallest quorum is denoted
  by c(S)
• The degree of an element i in a quorum system S
  is the number of quorums that contain i
• Let S be a quorum system. S is a s-uniform if Q
  s for each Q in S
• S is (s,d) fair if it is s-uniform and deg(i)d
  foreach i, it is called s-fair if it is (s,d)
  fair for some d.

34
LP

• We can use a linear programming to calculate the
  load and the strategy achieving the load.

35
DUAL LP

• Some time we want to use the dual linear program,
  in which we give probabilities over the elements
  of the world. It is a known fact that DLPltLP

36
The load with failures

• A configuration is a vector
  in which it holds 1 in places representing the
  failing elements in the world
• Dead(x) is the group of elements failed, live(x)
  is the non failed ones
• S(x) is the sub collection of functioning quorums


37
Load with failiures

• The load of quorum system S over a configuration
  x, if S(x) is empty then L(S(x)) 1, if there
  are functioning quorums we define it in similar
  way as before by linear programming problem.
• Let the elements fail with probabilities
  P(p1,,pn). Then the load is a random variable
  Lp(S) defined by

38
Load with fails

• Claim E(Lp(S))gtFp(S)
• Claim If (configurations) xgtz than
  L(S(x))gtL(S(z))
• Proof S(z) contains S(x), strategy for S(x) is
  for S(z) too.
• Claim E(Lp(S)) is a non decreasing function.

39
Properties of the load

• Claim L(S)gtc(S)/n
• Claim L(S)gt1/c(S)
• Proof if we choose probability 1/c(S) for every
  element in c(S) and 0 in the rest, we achieve
  possible solution for the DLP problem.
• Conclusion L(S)gt1/sqrt(n) (achieved when c(S) is
  close to sqrt(n)

40
Load/fail probability trade off

• Claim Fp(S)gtexp(p,nL(S))
• Proof the probability that all the elements in
  the smallest quorum will fail, (and therefore the
  quorum system fails) exp(p,c(S)). Since
  c(S)ltnL(S) the claim follows.

41
examples

• Optimal load, optimal load/ failure tradeoff,
  good failure load paths system
• B-grid system
• SC-grid system
• AndOr system

42
Load analyses

• Claim Non dominated coteries have lower bounds.
• The claim follows if you choose strategy for the
  dominator by giving the probability only in
  quorums which contained by a quorum in the
  dominated quorum system
• Claim voting systems have high load (more than
  ½)

43
Last slide!!!!

• Proof if we define Vthe sum of all votes (Vi),
  then the vector YiVi/V is a solution for DLP
  larger than ½.
