EIN 6133 Enterprise Systems Engineering

1
EIN 6133Enterprise Systems Engineering

• Fall 2007
• Chin-Sheng Chen
• Florida International University

2
T6 Engineering process

• Engineering process
• Need and specification
• Modeling and analysis
• Functional design
• Implementation design

3
The ESE Framework Re-visit
4
Readings References

• Readings
• HEA Chapter 2
• Reference
• Product design and development by Karl Ulrich and
  S. Eppinger, McGraw-Hill, 2002

5
Engineering process need and specification (1)

• Need, definition
• An attribute of a potential system (product) that
  is desired by the customer.
• Other names customer attributes, customer
  requirements
• Guideline for need statements
• Express the need in terms of what the system
  (product) has to do, not how.
• Express the need as specific as possible
• Use positive, not negative phrasing
• Express the need as an attribute of the system
  (product).
• Avoid using the words must and should.
• Organize needs into a hierarchy
• Establish their relative importance

6
Engineering process need and specification (2)

• Specification, definition
• A precise description of what the system
  (product) has to do.
• A specification has a metric and a value. A value
  may take on several forms such as a number or a
  range.
• A specifications is a set of the individual
  specifications.
• Other terms used
• system (product) requirements, engineering
  characteristics, technical specifications

7
Engineering process need and specification (3)

• Specification types
• Target specifications
• Preliminary, ideal specifications
• Final specifications (in the contract book)
• Final specifications depend on
• what customers needs,
• what is technical and economic feasible and
• what our competitors offer in the market place.

8
Engineering process need and specification (4)

• Metrics
• The most useful metrics are those that reflect as
  directly as possible the degree to which the
  system (product) satisfies the customer need.
• Metrics must be precise and measurable such that
  meeting specifications lead to satisfaction of
  the related customer needs
• A need may be translated into more than one
  metrics, and one metrics may satisfy one or
  multiple needs.

9
Engineering process need and specification (5)

• Setting metrics value
• Competitive benchmarking
• Set ideal and marginally acceptable target
• Develop technical and economic models to assess
  feasibility
• Use the above data to create competitive maps and
  conduct trade-off analysis

10
Engineering process need and specification (6)

• Hierarchy of system specifications
• Each system (product) may have a hierarchy of
  subsystems (products).
• Each subsystem has its specifications
• Therefore, the overall specifications for the
  system must be decomposed (or flowed down) to a
  hierarchical set of specifications, one for each
  subsystem.

11
Engineering process modeling and analysis (1)

• Model, definition
• Analytical or physical approximation of the
  system (product), used as a tool for predicting
  the values of the metrics for a particular set of
  design decisions
• Models can be focused or comprehensive, depending
  on the degree to which they implement all of the
  attributes of the system (product).
• Various models (including prototypes) may be
  developed to support the engineering process
  including system specification, engineering
  analysis, functional design, and implementation
  design.
• Modeling
• the process for creating a model that reflects a
  desired system representation for understanding,
  assessment, and/or communication.
• Two well-known models AS-IS and TO-BE.

12
Engineering process modeling and analysis (2)

• Analysis, Def.
• An engineering activity that uses a mathematical
  means or an engineering tool (such as a system or
  its model) to
• understand and assess its behaviors and
• Determine its desired end and the most efficient
  method of obtaining this (that is, to seek an
  optimal technical solution)
• It may be exercised in all engineering phases.
• types of engineering analysis
• A technical decision for
• A specification
• A system (product) solution approach
• A functional design
• An implementation design

13
Engineering process modeling and analysis (3)

• Engineering analysis
• ESE focus
• The system level of engineering analysis
• The ESE analysis activity at system level
• Input
• System (product) specifications
• Output
• A technical solution approach
• A conceptual design, for example

14
Engineering process modeling and analysis (4)

• Example of engineering analysis I
• A die design
• Analysis issue whether to use a progressive die
  or engineering dies.
• Technical solution approach use a sequence of
  engineering dies
• Output the WIP shape and size specification for
  each engineering die and its QA guidelines.
• Example of engineering analysis II
• An enterprise system design
• Analysis issue whether to use client-server or
  web-based system
• Solution use a hybrid approach of client-server
  and web-based.
• Output Interface and response time
  specifications.

15
Engineering process functional design (1)

• Functional design, def.
• An activity that translates a conceptual design
  into an engineered system (product) design which
  meets the functional requirements as specified.
• It may include industrial design, such as
• use interface design and usability
• Security and safety design
• Functional design types
• Architectural design
• System architecture
• Subsystems architecture
• Components (detailed) design

16
Engineering process functional design (2)

• Architecture, Def
• An assembly drawing (or structure) of something
• A representation of all the processes involved in
  the life cycle of the something.
• System architecture, Def.
• A scheme by which the functional elements of the
  system are arranged into physical blocks and by
  which the blocks interact.

17
Engineering process functional design (3)

• Architectural design output (product)
• Geometric layout
• Assembly model
• Bill of Materials (BOM)
• Relationships (systems interface)
• Man-machine, system-system, or system-subsystem
• Fundamental interactions
• Incidental interactions
• Flow designs
• Coolant flows,
• Mechanical electrical flows
• Material channels (runways)

18
Engineering process functional design (4)

• Architectural design output (physical system)
• Geometric layout
• Plant layout
• List of plant components
• Relationship
• Fundamental interactions
• Incidental interactions
• Flow designs
• Aisles, staircases, driveways, conveyers

19
Engineering process functional design (5)

• Architectural design output (Computer/ Management
  Systems)
• Layout design
• Menu layout (organization chart)
• Listing of menu items (components)
• Relationship design
• E-R diagrams
• Flow design
• information and work flows
• Business processes
• Communication channels

20
Engineering process functional design (6)

• Components design
• For product
• Competency and specifications
• 2D/3D part drawings
• For physical system
• Competency and specifications
• 2D/3D component drawings
• For managerial system
• Competency and specifications
• functional procedures and diagrams, flowcharts,
  formulas, report, etc.
• For computer system
• Competency and specifications
• Detailed object models, dynamic models,
• functional procedures and diagrams, flowcharts,
  formulas, report, etc.

21
Engineering process functional design (7)

• The three system layers - revisit
• Physical system
• Management system
• Computer management system

22
Engineering process implementation design (1)

• Implementation design
• Overall implementation approach
• System-wide implementation plan
• Detailed implementation plan
• Deployment design
• Overall deployment approach
• (Process modeling and analysis)
• Installation process design
• Training design
• Data migration design
• Validation design
• Switch-over design

23
Engineering process implementation design (2)

• For product design
• Technical solution approach
• Manufacturing technology
• For example, material deformation (casting,
  molding, die-forming, crystal growing, etc.),
  removal (machining), or joining (welding)
• System-wide implementation plan
• Assembly process plans
• Component implementation plan
• Component process plans

24
Engineering process implementation design (3)

• For physical system design
• Technical solution approach
• Implementation technology
• For example, use modular or integrated approach
• System-wide implementation plan
• High-level project action plan
• Component implementation plan
• Component process plans

25
Engineering process implementation design (4)

• For managerial systems design
• Technical solution approach
• Implementation technology
• For example, use modular or integrated approach
• System-wide implementation plan
• System-level implementation plan
• Component implementation plan
• Component implementation plan

26
Engineering process implementation design (5)

• For computer system design (1)
• Technical solution approach
• Implementation environment tools
• For coding C vs. .NET vs. Java
• For structure 3-layer vs. integrated

27
Engineering process implementation design (6)

• For computer system design (3)
• System-wide implementation plan
• Project management
• Change management and version control
• Packaging and installation process
• System implementation plan
• Guidelines for code structure, user interface
  design and documentation
• Library of system standard components
• Testing
• Test policy and guidelines
• Classes of tests
• Expected software responses
• Performance bounds
• Identification of critical components
• System debugging
• Policy and strategy

28
Engineering process implementation design (7)

• For computer system design (3)
• Component implementation plan
• Flow implementation design
• Program interface, flowchart, variables,
  parameters.
• User interface implementation design
• Interface details, messages design, on-line help
  search
• Form design
• Data design (internal, global and temporary data
  structure in implementation, variable
  conventions)
• Software interface
• Machine interface and system interface
• Database implementation design
• Table list, definition, and relationship

29
Engineering process implementation design (8)

• Deployment design (1)
• Deployment approach
• Unit by unit, or function by function
• Top down or bottom up
• Installation (upgrade) process design
• Automatic or manual
• Training process design
• Development of use cases
• Training programming
• by unit or by function
• Top down or bottom up
• Online training

30
Engineering process implementation design (9)

• Deployment design (2)
• Data migration/entry process design
• Automatic or manual entry
• Validation process design
• by phase or one time
• Switch-over process design
• Gradual or one time

31
Engineering process with focus on methods and
techniques (1)

• ESE is different from other enterprise
  system-related efforts in its emphasis for
  development and application of methods and
  techniques to each engineering activity. They
  are
• Specification methods and techniques
• Modeling and analysis methods and techniques
• Design and optimization methods and techniques
• Implementation planning methods and techniques

32
Engineering process activity methods and
techniques (2)

• Enterprise strategy engineering process
• Create (specify) strategic identity
• Conduct strategic analysis
• Formulate (design) strategy
• Develop strategy implementation plan

33
Engineering process activity methods and
techniques (3)

• Enterprise strategy engineering process (1)
• Create the strategic identity
• Define a mission/value
• Develop a vision
• Declare strategic intent
• Identify core work (product/service)

34
Engineering process activity methods and
techniques (4)

• Enterprise strategy engineering process (2)
• Conduct strategic analysis
• Develop an industry foresight
• Identify current market, product/service and
  resource concepts
• (Identify required new competencies)

35
Engineering process activity methods and
techniques (5)

• Enterprise strategy engineering process (3)
• Design (formulate) strategy
• (Develop a balanced portfolio of capabilities)
• (Develop a resource and capability acquisition
  agenda)
• Strategically position the company
• Create generic product strategies
• Develop generic market strategies

36
Engineering process activity methods and
techniques (6)

• Enterprise strategy engineering process
• Design (formulate) strategy (3-1)
• Strategically position the company (as a
  prospector, analyzer, defender or reactor),
  according to
• Org. readiness for risk taking
• Readiness for developing new products
• Technological orientation
• Administrative orientation (type of company
  control)

37
Engineering process activity methods and
techniques (7)

• Enterprise strategy engineering process
• Design (formulate) strategy (3-2)
• Create generic product strategies
• Low cost or price differentiation
• Image differentiation (distinctive design)
• Support differentiation (after-sales service)
• Quality differentiation
• Design differentiation (added, improved
  production functionality)
• Penetration strategy
• Bundling strategy
• Market, product and diversification strategies

38
Engineering process activity methods and
techniques (8)

• Enterprise strategy engineering process
• Design (formulate) strategy (3-3)
• Develop generic market strategies
• Size and diversity
• Location (local, regional, national, global)
• Stage of evolution
• Emerging market
• Established market
• Eroding market
• Erupting market

39
Engineering process activity methods and
techniques (9)

• Enterprise strategy engineering process
• Develop strategy implementation plan (4-1)
• Plan to articulate and codify strategy, by
  translating it into
• Strategic vision
• Strategic objectives
• Key success factors
• (Key performance indicators)
• (Key personal performance indicators)
• Plan to evaluate strategy
• For consistency, advantages, and feasibility

40
Engineering process activity methods and
techniques (10)

• Enterprise strategy engineering process
• Develop strategy implementation plan (4-2)
• Plan to elaborate strategy
• Transform the strategy into executable and
  operational plans in strategic and annual plans
• Plan to promote strategy
• To be advertised, debated, understood, and
  accepted by all employees
• Plan to execute strategy
• For launch of projects to implement the strategy
• For carry-out of projects via execution actions,
  monitoring, and control
• For evaluation of project success and strategy
  performance

41
Engineering process activity methods and
techniques (11)

• Enterprise competency engineering process
• Specify enterprises competency gaps, based on
  vision and strategy plans for product/service
• Identify required new competencies
• Conduct analysis for a technical approach to
  bridging the time-phased competency gaps
• Identify a solution approach such as buying
  (licensing or outsourcing), cultivating, and/or
  co-developing.
• Design a competency acquisition map
• Develop a balanced portfolio of capabilities
• Create a resource and capability acquisition
  agenda
• Develop an implementation plan for securing
  required competencies
• Develop a hiring training plan for in-house
  resource acquisition
• Develop a competency qualification plan for
  external resource acquisition

42
Engineering process activity methods and
techniques (12)

• Enterprise capacity engineering process
• Specify enterprises capacity gaps, based on
  vision, strategy, and competency.
• Identify required new capacity
• Conduct analysis for a technical approach to
  bridging the time-phased capacity gaps
• Identify a solution approach such as buying
  (licensing or outsourcing), or cultivating a
  resource (a machine, a worker, or a computer
  system including an ERP system)
• Design a capacity acquisition/decommission map
• Develop a balanced portfolio of capacity
  requirement
• Create a resource acquisition/decommission agenda
• Develop an implementation plan for meeting
  time-phased capacity requirement
• Develop a hiring training plan for in-house
  human resource
• Develop an acquisition plan for qualified
  external resources
• Develop decommission plan for excessive resources

43
Engineering process activity methods and
techniques (13)

• Enterprise structure engineering process
• Define enterprise system structural
  specifications, based on vision strategy,
  competency, and capacity requirement for
  product/service
• Conduct analysis for a technical approach to
  enterprise system structuring
• Decide on a conceptual solution such as a job
  shop vs. a cellular shop
• Furthermore, possible migrating from a job-shop
  structure to a cellular layout over time
• Design an enterprise system structure
• Enterprise structural design for physical,
  managerial, and computer systems
• Enterprise component design for the three system
  elements
• Develop an implementation plan for enterprise
  system structure
• Implementation plan for physical, managerial, and
  computer systems structure
• Implementation plan for physical, managerial, and
  computer systems component.

44
T6 Home work

• Identify and classify 2 ESE tools that could be
  used to perform an engineering activity with.
• Due next week.
