Security Technologies: Penetration Testing

1
Security TechnologiesPenetration Testing

• Kenneth Balogh
• Aaron Lafferty

2
Learning ObjectivesUpon completion of this
material, you should be able to

• Understand the definition of Penetration Testing
• Introduction to Open Source Tools that assist in
  Penetration Testing
• Understand the key terms and critical concepts of
  the testing methodology
• Identify different organizations to assist in
  testing and standards

3
What is Penetration Testing?

• Definition-a method of evaluating the security of
  a computer system or network by simulating an
  attack by a malicious user
• Why-Security issues that are found will be
  presented, along with an assessment of their
  impact and often with a proposal for mitigation
  or a technical solution.

4
Methodology

• Types of testing
• White box- The tester has complete knowledge of
  the internal network.
• Not most representative of outside attacks, but
  most accurate because represents worst case
  scenario were attacker has complete knowledge of
  network
• Black box- The tester has no prior knowledge of
  the network.
• Gray box- Simulates an inside employee. Assesses
  internal threats from employees.

5
Planning

• Scope of Testing Define what is meaningful to
  the client, budget constraints
• Use of Social Engineering process of human
  based manipulation to achieve access
• Session Hijacking taking over TCP session
  between machines. Can disrupt day-to-day
  operations not always permitted
• Trojan/Backdoors client permission before use
  these tools, cause other damages
• Confidentiality of Report and Results
• How/Where to Store Results? Destroy?

6
Testing

• The penetration testing is divided into five
  stages
• Reconnaissance The initial stage of collecting
  information on the target network
• Scanning (Enumeration) The process of querying
  active systems to grab information on network
  shares, users, groups and specific applications
• Obtaining Access The actual testing
• Maintaining Access Allowing the test a backdoor
  in the exploited system for future attacks
• Erasing Evidence The process of deleting log
  file entries to appear as system was never
  exploited

7
Organizations

• Open Source Security Testing Methodology Manual
  (OSSTM)
• Open Web Security Project (OWASP)

8
Open Source Security Testing Methodology Manual
(OSSTM)

• The Open Source Security Testing Methodology
  Manual (OSSTMM) is a peer-reviewed methodology
  for performing security tests and metrics.
• The OSSTMM focuses on the technical details of
  exactly which items need to be tested, what to do
  before, during, and after a security test, and
  how to measure the results
• Areas of Security Information, Process,
  Internet Technology, Communications, Wireless,
  Physical each section further divided into
  smaller sub-modules

9
Open Web Security Project (OWASP)

• The Open Web Application Security Project (OWASP)
  is dedicated to finding and fighting the causes
  of insecure software. The OWASP Foundation, a
  not-for-profit charitable organization and
  participation is free and open to all.
• Focuses mainly of web applications and services

10
Nessus

• Nessus is a vulnerability scanner.
• Has both an open source (FREE as in LUNCH!) and
  pay for support.
• Tenablesecurity.com provides support and hosting.
• Does both local and remote vulnerabilities.

11
Nessus

• Plugin based, free section is 7 days behind paid
  subscription.
• Plugins written in Nessus Attack Scripting
  Language (NASL).
• Can write your own plugins!

12
Nessus

• Daemon and Client Configuration.
• Daemon primarily written for NIX, but windows
  ports exist.
• Client written for most common operating systems.

13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
Metasploit

• Open Source Platform (FREE as in BEER!).
• Allows for Design and Testsing of exploit code.
• Interface through HTML (localhost website) GUI or
  CLI console.

18
Metasploit

• Used as a tool for penetration testing as well as
  exploit development.
• Real strength is separation of exploit code from
  payload code.
• Contains hooks that can make it difficult to
  detect forensically

19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
Summary

• Different types of testing methods
• Proper Test Planning
• Different Organizations to provide different
  security data
• Several Tools available for testing
