Peer-to-Peer Systems

• Chapter 25

2
What is Peer-to-Peer (P2P)?

• Napster?
• Gnutella?
• Most people think of P2P as music sharing

3
What is a peer?

• Contrasted with Client-Server model
• Servers are centrally maintained and administered
• Client has fewer resources than a server

4
What is a peer?

• A peers resources are similar to the resources
  of the other participants
• P2P peers communicating directly with other
  peers and sharing resources

5
P2P Concepts

• Client-client as opposed to client-server
• File sharing I get a copy from someone, and now
  make it available for others to download---copies
  are/workload is spread out
• Advantages Scalable, stable, self-repairing
• Process A peer joins the system when a user
  starts the application, contributes some
  resources while
• making use of the resources provided by others,
  and leaves the system when the user exits the
  application.
• Session One such join-participate-leave cycle
• Churn The independent arrival and departure by
  thousandsor millions of peers creates the
  collective effect we call churn.
• The user-driven dynamics of peer participation
  must be taken into
• account in both the design and evaluation of any
  P2P application. For example, the distribution of
  session length
• can affect the overlay structure, the resiliency
  of the
• overlay, and the selection of key design
  parameters.

6
Types of clients

• Based on the client behavior, there are three
  types of clients
• True clients (not active participants take but
  dont give short duration of stay)
• Peers Clients that stay long enough and
  well-connected enough to participate actively
  (Take and give)
• Servers (Give, but dont take)
• Safe vs. probabilistic protocols
• Mostly logarithmic order of performance/cost

7
Levels of P2P-ness

• P2P as a mindset
• Slashdot
• P2P as a model
• Gnutella
• P2P as an implementation choice
• Application-layer multicast
• P2P as an inherent property
• Ad-hoc networks

8
P2P Goals/Benefits

• Cost sharing
• Resource aggregation
• Improved scalability/reliability
• Increased autonomy
• Anonymity/privacy
• Dynamism
• Ad-hoc communication

9
P2P File Sharing

• Content exchange
• Gnutella
• File systems
• Oceanstore
• Filtering/mining
• Opencola

10
P2P File Sharing Benefits

• Cost sharing
• Resource aggregation
• Improved scalability/reliability
• Anonymity/privacy
• Dynamism

11
P2P Application Taxonomy
P2P Systems
Distributed Computing SETI_at_home
File Sharing Gnutella
Collaboration Jabber
Platforms JXTA
12
Management/Placement Challenges

• Per-node state
• Bandwidth usage
• Search time
• Fault tolerance/resiliency

13
Approaches

• Centralized
• Flooding
• Document Routing

14
Centralized
Bob
Alice

• Napster model
• Benefits
• Efficient search
• Limited bandwidth usage
• No per-node state
• Drawbacks
• Central point of failure
• Limited scale

Jane
Judy
15
Flooding
Carl
Jane

• Gnutella model
• Benefits
• No central point of failure
• Limited per-node state
• Drawbacks
• Slow searches
• Bandwidth intensive

Bob
Alice
Judy
16
Connectivity
17
Napster

• Uses a centralized directory mechanism
• To control the selection of peers
• To generate other revenue-generating activities
• In addition is has several regional servers
• Users first connect to the Napsters centralized
  server to one of the regional servers
• Basically, each client system has a Napster proxy
  that keeps track of the local shared files and
  informs the regional server
• Napster uses some heuristic evaluation mechanisms
  about the reliability of a client before it
  starts using it as a shared workspace

18
Gnutella and Kazaa

• Unlike Napster, it is a pure P2P with no
  centralized component---all peers are completely
  equal
• Protocol
• Ensures that each user system is concerned with a
  few Gnutella nodes
• Search for files if the distance specified is 4,
  then all machines within 4 hops of the client
  will be probed (1st all M/C within 1 hop then 2
  hops and so on)
• The anycast mechanism becomes extremely costly as
  system scales up.
• Kaaza also does not have a centralized control
  (as Gnutella) it uses Plaxton trees.

19
CAN

• Content Addressable Network
• Each object is expected to have a unique system
  wide name or identifier
• The name is hashed into a d-tuple--- identifier
  is converted into a random-looking number using
  some cryptographic hash function
• In a 2-dimensional CAN the id is hashed to a
  2-dimensional tuple (x,y)
• Same scheme is used to convert machine IDs
• Recursively subdivide the space of possible
  d-dimensional identifiers, storing each object at
  the node owning the part of the space (zone) that
  objects ID falls in.
• When a new node is added, it shares its space
  with the new node similarly when a node leaves,
  its space is owned by a nearby node
• Once a user provides the search key, it is
  converted to (x,y) the receiving CAN node finds
  a path from itslef to the node having (x,y)
  space. If d is the dimensions, and N is the of
  nodes, then the number of hops is (d/4)N1/d
• TO take care of node failures, there will be
  backups.
• Cost is high when there are frequent joins/leaves

20
Document Routing
001
012

• FreeNet, Chord, CAN, Tapestry, Pastry model
• Benefits
• More efficient searching
• Limited per-node state
• Drawbacks
• Limited fault-tolerance vs redundancy

212 ?
212 ?
332
212
305
21
Document Routing CAN

• Associate to each node and item a unique id in an
  d-dimensional space
• Goals
• Scales to hundreds of thousands of nodes
• Handles rapid arrival and failure of nodes
• Properties
• Routing table size O(d)
• Guarantees that a file is found in at most dn1/d
  steps, where n is the total number of nodes

Slide modified from another presentation
22
CAN Example Two Dimensional Space

• Space divided between nodes
• All nodes cover the entire space
• Each node covers either a square or a rectangular
  area of ratios 12 or 21
• Example
• Node n1(1, 2) first node that joins ? cover the
  entire space

7
6
5
4
3
n1
2
1
0
2
3
4
5
6
7
0
1
Slide modified from another presentation
23
CAN Example Two Dimensional Space

• Node n2(4, 2) joins ? space is divided between
  n1 and n2

7
6
5
4
3
n1
n2
2
1
0
2
3
4
5
6
7
0
1
Slide modified from another presentation
24
CAN Example Two Dimensional Space

• Node n2(4, 2) joins ? space is divided between
  n1 and n2

7
6
n3
5
4
3
n1
n2
2
1
0
2
3
4
5
6
7
0
1
Slide modified from another presentation
25
CAN Example Two Dimensional Space

• Nodes n4(5, 5) and n5(6,6) join

7
6
n5
n4
n3
5
4
3
n1
n2
2
1
0
2
3
4
5
6
7
0
1
Slide modified from another presentation
26
CAN Example Two Dimensional Space

• Nodes n1(1, 2) n2(4,2) n3(3, 5)
  n4(5,5)n5(6,6)
• Items f1(2,3) f2(5,1) f3(2,1) f4(7,5)

7
6
n5
n4
n3
5
f4
4
f1
3
n1
n2
2
f3
1
f2
0
2
3
4
5
6
7
0
1
Slide modified from another presentation
27
CAN Example Two Dimensional Space

• Each item is stored by the node who owns its
  mapping in the space

7
6
n5
n4
n3
5
f4
4
f1
3
n1
n2
2
f3
1
f2
0
2
3
4
5
6
7
0
1
Slide modified from another presentation
28
CAN Query Example

• Each node knows its neighbors in the d-space
• Forward query to the neighbor that is closest to
  the query id
• Example assume n1 queries f4
• Can route around some failures
• some failures require local flooding

7
6
n5
n4
n3
5
f4
4
f1
3
n1
n2
2
f3
1
f2
0
2
3
4
5
6
7
0
1
Slide modified from another presentation
29
CAN Query Example

• Each node knows its neighbors in the d-space
• Forward query to the neighbor that is closest to
  the query id
• Example assume n1 queries f4
• Can route around some failures
• some failures require local flooding

7
6
n5
n4
n3
5
f4
4
f1
3
n1
n2
2
f3
1
f2
0
2
3
4
5
6
7
0
1
Slide modified from another presentation
30
CAN Query Example

• Each node knows its neighbors in the d-space
• Forward query to the neighbor that is closest to
  the query id
• Example assume n1 queries f4
• Can route around some failures
• some failures require local flooding

7
6
n5
n4
n3
5
f4
4
f1
3
n1
n2
2
f3
1
f2
0
2
3
4
5
6
7
0
1
Slide modified from another presentation
31
CAN Query Example

• Each node knows its neighbors in the d-space
• Forward query to the neighbor that is closest to
  the query id
• Example assume n1 queries f4
• Can route around some failures
• some failures require local flooding

7
6
n5
n4
n3
5
f4
4
f1
3
n1
n2
2
f3
1
f2
0
2
3
4
5
6
7
0
1
Slide modified from another presentation
32
CFS and PAST

• Files are replicated prior to storage---copies
  are stored at adjacent locations in the hashed-id
  space
• Make use of indexing systems to locate nodes on
  which they store objects or from which they
  retrieve copies
• IDs are hashed to a 1-dimensional space
• Leaves/Joins result in several file
  copies---could be a bottleneck

33
OceanStore

• Focused on long term archival storage (rather
  than file sharing)---e.g., digital libraries
• Ensure codes --- class of error-correcting codes
  that can reconstruct a valid copy of a file given
  some percentage of copies

34
Distributed Indexing in P2P

• Two requirements
• A lookup mechanism to track down a node holding
  an object
• A superimposed file system that knows how to
  store and retrieve files
• DNS---a distributed object locator M/C names to
  IP addresses
• P2P indexing tools let users store (key, value)
  pairs---a distributed hash system

35
Chord

• It is a major DHT architecture
• Forms a massive virtual ring in which every node
  in the distributed system is a member---each
  owning part of a periphery.
• If hash value of a node is h, and the lower value
  is hL, and the higher is hH, then the node with h
  owns objects in the range hL
• E.g., if a,b, c hash to 100, 120, and 175,
  respectively, then b is responsible for IDs in
  the range 101-120 c is responsible for 121-175.
• When a new node joins, it computes its hash and
  then joins at the right place in the ring then
  the corresponding range of objects are
  transferred to it.
• Potential problems---adjacent nodes could be far
  apart in distance
• Statistics Average path length in an internet is
  22 network routers leading an average length of
  10 milliseconds this further slowed by slow nodes

36
Chord---cont.

• Two mechanisms in Chord
• Applications that repeatedly access the same
  object---Chord nodes cache link information so
  that after the initial lookup each node on the
  path remembers (its IP addresses) all nodes on
  the path for future use.
• When a node joins the Chord system, at hashed
  location hash(key), it looks up the nodes
  associated with hash(key)/2, hash(key)/4,
  hash(key)/8, etc. This is in a circular range.
• It uses a binary search to locate an object
  resulting in log(N) search time but this is not
  good enough---cached pointers help the effort
• Frequent leaves creates dangling pointersa
  problem
• Churnfrequent joins/leaves---results in several
  key shuffles---a problem

37
Document Routing Chord

• MIT project
• Uni-dimensional ID space
• Keep track of log N nodes
• Search through log N nodes to find desired key

38
Pastry

• Basic idea Construction of a matrix (of size r x
  logrN) of pointers at each participating node---r
  is a radix and N is the size of the network If N
  165 and r 5, then each matrix is of size 16 x
  5.
• Maps keys to a hashed space (like others)
• By following the pointers, a request is routed
  closer and closer to the node owning the portion
  of the space that an object belongs to.
• Hexadecimal addresses with r5, the address has
  5 hexadecimals 65A1FC as in the example.
• Top row has indices from 0 to F representing the
  1st hexadecimal in the hash address. For 65A1FC,
  there is a match at 6, so it has another level of
  index 0-F representing the 2nd position in the
  address. For the current node, there is a 2nd
  level match at 5 so this node is extended to
  next level from 0-F once again there is a match
  at A which is further expanded to the 4th level
  This has 0-F in the 4th position, current one
  matching at F. This is further expanded to 5th
  level from 0-F (not shown in Figure 25.5). Thus,
  it has 16 x 5 matrix of pointers to nodes.
• To take care of joins/leaves, Pastry periodically
  probes each pointer (finger) and repairs broken
  links when it notices problems
• It uses an application-level multicast (overlay
  multicast architecture)

39
Doc Routing Tapestry/Pastry
43FE
993E
13FE

• Global mesh
• Suffix-based routing
• Uses underlying network distance in constructing
  mesh

73FE
F990
04FE
9990
ABFE
239E
1290
40
Node Failure Recovery

• Simple failures
• know your neighbors neighbors
• when a node fails, one of its neighbors takes
  over its zone
• More complex failure modes
• simultaneous failure of multiple adjacent nodes
• scoped flooding to discover neighbors
• hopefully, a rare event

Slide modified from another presentation
41
Comparing Guarantees
State
Search
Model
log N
log N
Uni-dimensional
Chord
Multi-dimensional
2d
dN1/d
CAN
b logbN
logbN
Global Mesh
Tapestry
logbN
Neighbor map
Pastry
b logbN b
42
Remaining Problems?

• Hard to handle highly dynamic environments
• Usable services
• Methods dont consider peer characteristics
