Title: Traffic Sign Recognition


1
Traffic Sign Recognition
  • Jacob Carlson Sean St. Onge
  • Advisor Dr. Thomas L. Stewart

2
Traffic Sign Recognition
  • Project Overview
  • System Description
  • Current Functionality
  • Future Work

3
Traffic Sign Recognition
  • Project Overview
  • System Description
  • Current Functionality
  • Future Work

4
Project Overview
  • Object identification has many applications in
    various fields. This project aims to identify a
    traffic sign from a digital image. This would be
    useful in an autonomous vehicle application.
    These ideas and methods could also be used in
    other areas.

5
Project Overview
  • The overall objective of this project is to write
    a program what will identify a traffic sign from
    a digital photograph.
  • Traffic signs appear in diverse background
    situations and, at times, may be partially
    obscured.

6
Traffic Sign Recognition
  • Project Overview
  • System Description
  • Current Functionality
  • Future Work

7
System Description
8
System Description
  • When the program is initialized, an image,
    previously saved on the systems hard drive, is
    loaded for analysis.
  • At this point, some preliminary analysis will be
    performed, and preprocessing will be performed
    manually.

9
System Description
  • This portion of the program will gather and
    analyze color data, and will also perform edge
    detection.

Red Green
Blue
10
System Description
  • Additional methods (dilation, opening, closing,
    erosion) may also be applied at this time.
  • The sign will be classified based on color.

11
System Description
  • After classification, the software will highlight
    the image or area of interest.
  • The software will then write pertinent data to
    either the screen or an output file.

12
Traffic Sign Recognition
  • Project Overview
  • System Description
  • Current Functionality
  • Future Work

13
Current Functionality
  • Currently our program divides the color image
    into the three color planes.
  • We first look for red signs (stop sign, do not
    enter, wrong way). Our algorithm currently
    isolates most red signs effectively.
  • It can also isolate yellow signs, but this still
    requires some optimization.

14
Current Functionality
  • Initial Image

15
Current Functionality
  • Red Plane

16
Current Functionality
  • Red Plane, after Thresholding

17
Current Functionality
  • Green Plane


18
Current Functionality
  • Blue Plane

19
Current Functionality
  • Threshold red plane after median filter.

20
Current Functionality
  • Sobel Masks Used for edge detection
    (differentiation).

21
Current Functionality
  • Horizontal Edge Detection using Sobel masks.

22
Current Functionality
  • Vertical Edge Detection using Sobel masks.

23
Current Functionality
  • Sum of horizontal and vertical edge detection.

24
Current Functionality
  • Image after erosion by a line structuring element.

25
Current Functionality
  • Image after closing with octagon structuring
    element.

26
Current Functionality
  • Stop sign identified using blob recognition
    techniques.

27
Current Functionality
  • Final image with stop sign highlighted.

28
Traffic Sign Recognition
  • Project Overview
  • System Description
  • Current Functionality
  • Future Work

29
Traffic Sign Recognition
  • Current problem is having the computer recognize
    that the shape is a stop sign.


30
Traffic Sign Recognition
  • Identifying a region of interest and cropping out
    the background prior to performing main
    processing would streamline calculations.
  • Speed could also be increased by using C or C
    to implement the processing algorithms.

31
Questions?
